Methodologies for vaccine safety surveillance Nick Andrews, Statistics Unit Public Health England October 2015

Some dramas of the past 20 years–which do you think turned out to be real adverse reactions?

MMR

Autism Aseptic Meningitis Reduced Immunity / allergy Rotavirus Vaccine Intussusception Flu vaccine H1N1 Pandemic Vaccine Hep B vaccine HPV vaccine Narcolepsy Guillane Barre Syndrome Type 1 Diabetes Chronic Fatigue Convulsions Mercury in vaccines Neurological problems Asthma Exacerbation

Talk Overview

• The components of vaccine safety surveillance
• Epidemiological methods
• Example and comparisons
• Conclusions

Vaccine Safety Assessment Components

Vaccine Trials reactogenicity Pharmacovigilance (passive/active): hypothesis generation, RAPID Signal Strengthening/ assessment Epidemiological studies (hypothesis testing)

Individual causality assessment

Licensure and use Priority? Plausibility, other data/methods, experts, other risks, interval from vaccine,….

Passive Surveillance systems

• Often part of Pharmacovigilance by regulatory authorities
• Many countries have a system in place (UK Yellow

Card)

• Reports from health professionals / public are monitored.

e.g. by comparing rates to historical rates or other vaccines (proportional reporting ratios).

• Some countries (e.g. US VAERS system) have stimulated

passive reporting –forms sent to all physicians for return

Active Surveillance example

–! Vaccine safety data link. Using data from US Health Maintenance Organisations –! Rapid Cycle analysis – e.g .comparing observed convulsions 0-1 days post trivalent influenza vaccine to expected numbers each week based

• n histyorcial data.

Study by TSE et al, Vaccine 2012. Could look at many different

• utcomes this way

Signal strengthening

• Signals may come from many sources – recent

example HPV and Guillane Barre Syndome from a French cohort study

• What can be done to rapidly assess a signal?

– Go through the usual causality assessment steps – but likely lots of missing information. WHO has guidelines. – Look at pharmacovigilance data (if that was not the source of the signal). – Ecological studies – look in hospital / GP databases at disease rates over time. – Observed v Expected studies within databases that contain vaccination data where reporting bias is less

• likely. Ideally already be looking at possible events of

interest in rapid cycle analysis.

Rapid Ecological study

• f Guillane Barre

Syndome and HPV vaccine (done in a few days) Hospitalisations for GBS by age and period and whether vaccine scheduled that year (red) No increased risk seen

Epidemiological studies for Investigating adverse events

• Design issues

– Exact question/vaccine/population, case definition, timing relative to vaccination, confounders, how rare….

• Data sources

– For cases, vaccination, confounders (?linkage)

• Methods

– Cohort, case-control, case-coverage, case-only (self controlled case series) – BEST ONE OFTEN DEPENDS ON DATA SOURCES AND DESIGN ISSUES

Comparing designs:

Example1: Rotavirus and Intussusception

• October 1998: an anti-rotavirus vaccine is launched in the

USA for use in infants (3 doses).

• May 1999: the vaccination programme is suspended

following 9 reports of intussusception temporally associated with vaccination.

• An epidemiological investigation is launched.

Main design was a case-control study

• 382 cases and 1657 controls, matched/controlled for sex,

age, hospital of birth, proxies for socio-economic position.

• But control selection difficult – could there be residual

confounding.

• So also considered just looking at all the cases (432 could

be used) for the timing of any vaccines using self controlled case series.

Self Controlled Cases-Series (SCCS) Design

Just obtain data on cases For each individual each day and event in the study period will fall inside or outside the risk period.

• Relative incidence calculated in a similar way to a cohort

study but analysis is conditional Poisson regression – i.e. data are not aggregated across individuals so each individual has a set of exposure periods and events risk period vaccination

Jan 01 Dec 01

Event

Interval between vaccination and intussusception in 74 vaccinated cases

Murphy et al (2001) NEJM

Results for the first dose

Risk period (days) Case-control SCCS 3 – 7 37.2 (12.6, 110) 58.9 (31.7, 110) 8 – 14 8.2 (2.4, 27.6) 9.4 (3.9, 22.3) 15 – 21 1.1 (0.2, 5.4) 2.3 (0.5, 10.2) Conclusion: Possibly some residual confounding in the case-control design Almost all studies of intussusception since this have used the SCCS design – you only need the cases. SCCS implicitly controls for non-time varying confounders.

Example2: MMR and Autism studies

Study Sample size RI / OR 95% CI SCCS (UK 1999) 357 cases 0.88 (0.40, 1.95) Cohort (Denmark

• 2002)

537303 children 316 cases 0.92 (0.68, 1.24) Case-control (UK 2004) 1294 cases 4469 controls 0.86 (0.68, 1.09) In this case SCCS worked well, although it is more suited to clearer acute onsets.

Example3: Asthma exacerbation and flu vaccine

Method Sample size RI 95% CI Cohort, unadjusted 70 753 3.29 (2.55, 4.15) Cohort, adjusted 70 753 1.39 (1.08, 1.77) Case series 2075 cases 0.98 (0.76, 1.27) The cohort results are subject to indication bias. The case series results are unaffected by this bias.

Kramarz et al, Arch. Fam. Med. 2000, 9: 617 – 623

Cohort and case series studies in asthmatic children aged 1 – 6 years in 1995/6. Risk period: 2 weeks after flu vaccine.

Example4: GBS, flu vaccine and flu- like illness

Observation period: all time within GPRD in 1990 – 2005 Two types of exposures: flu vaccination and flu-like illness. Risk periods: 0-30, 31-60, 61-90 days after vaccine/onset Pre-exposure risk period: 2 weeks Age groups: 12 periods over 0 – 115 years Seasonal groups: calendar month Repeat episodes: included if > 6 months separation

Stowe et al, Am. J. Epidemiol. 2008, 169: 382 - 388

Results

775 distinct episodes in 690 individuals Flu vaccine: 0 – 30 days: RI = 0.58 (0.18, 1.86) 0 – 90 days: RI = 0.76 (0.41, 1.40) Influenza-like illness: 0 – 30 days: RI = 16.64 (9.37, 29.54) 0 – 90 days: RI = 7.35 (4.36, 12.38)

Interval between influenza-like illness and GBS

From: Stowe et al, Am. J. Epidemiol. 2008, 169: 382 - 388

Example 5: Pandemrix vaccine and Narcolepsy Miller et al, BMJ 2013

• Pandemrix (AS03 adjuvanted H1N1 vaccine) used widely

in Europe

• Signal of possible narcolepsy association from Sweden /

Denmark

• Epi studies to date have been cohort, case-control, case-

coverage and SCCS.

Choice of study design (UK)

• SAMPLE SIZE – calculations suggested we needed

to cover a large proportion of cases in England.

• Cohort > No national database for vaccinations.
• Case-control> Possible but control selection and cost/

ethical permissions issues with getting controls.

• SCCS> Yes – although potential problems with

defining risk interval and having enough follow up time for power.

• Case-coverage>Yes – since we have good coverage

data in GP databases such as RCGP.

Study Design

• Age: 4 to 18 year olds at diagnosis
• Period: Onset from Jan 2008 and diagnosed by the time of the

visit.

• Case finding: 23 sleep centres
• Validation: of cases using ICSD-2 criteria by 3 experts using

notes obtained at centre visits.

• Key index date: Onset of excessive daytime sleepiness (EDS) /

cataplexy as reported in case notes or by a GP

• Vaccination history: obtained from a letter to the GP. Details
• f being in a risk group targeted for vaccination were also
• btained from GPs.
• Case - coverage compares odds of vaccination in cases to the

age and risk group matched population

RCGP Coverage data for case- coverage design

Non risk group Risk group

Cases by EDS date and vaccination status

Results – vaccine association

• OR = 14.4, 95% CI(4.3-48.5) for vaccinated at any time prior to
• nset.
• Attributable risk: 1.9 per 100,000 doses.

Other designs (results here based on first symptoms for children and Pandemrix):

• France – case matched to hospital controls OR = 21.5 (2.8-167)
• Finland – retrospective cohort design RI ~ 25 (8-80)
• UK SCCS – did not work well because no clear risk window,

lack of control unexposed time and correlation of period effects and vaccine effects as all vaccine given over a few months.

Design Pros and Cons

• Case Control

– Pros – can get detailed information on cases and controls – Cons – control selection may lead to bias

• Cohort

– Pros – direct estimates of risks, high power – Cons – may be limited data on possible confounders, may be difficult to construct the cohort (linkage).

• Self Controlled Case Series

– Pros – just need cases so cheaper. Automatic adjustment for non- time varying confounders – Cons – usually need a risk window to be specified, sometimes co- linearity of vaccine and age/time effects.

• Case-Coverage

– Pros – simple to use with routine data without linkage. – Cons – usually limited matching to confounders

Conclusions

• Post licensure vaccine safety surveillance is an important

component of a vaccine programme

• It is important to be able to perform controlled epidemiological

studies rapidly and to be aware of potentially confounding / bias

• Record linkage and the SCCS method has proved an excellent tool

for such studies.

• Cohort and other designs such as case-coverage are also required

for some events where SCCS is not ideal.

• NEW QUESTIONS KEEP ARISING!

Acknowledgements

• ! PHE: Liz Miller, Julia Stowe, Pauline Kaye
• ! Royal Free: Brent Taylor
• ! Open University: Paddy Farrington, Heather Whitaker

EXTRA SLIDES: Useful resources

• WHO Global Vaccine Safety Initiative: http://www.who.int/

vaccine_safety/en/

• FDA: Guidance for Industry Good Pharmacovigilance Practices and

Pharmacoepidemiologic Assessment http://www.fda.gov/cder/guidance/ index.htm

• ADVANCE consortium looking at vaccine benefit risk http://

www.advance-vaccines.eu/

• SCCS Website: http://statistics.open.ac.uk/sccs

Created by Heather Whitaker – to be updated in the next year or so…

• Tutorial paper: Whitaker et al., Statist. Med. 2006, 25: 1768 – 1797
• Useful overview of case-only methods: Farrington, Vaccine 2005,

2064-70. Control without separate controls:…
