What did exist before? How does it work? What are the findings? What is the Conclusion? Measuring Performance on OpenBSD Alexander Bluhm bluhm@openbsd.org BSDCan, May 2019 What did exist before? How does it work? What are the findings?

slide-1
SLIDE 1

What did exist before? How does it work? What are the findings? What is the Conclusion?

Measuring Performance on OpenBSD

Alexander Bluhm

bluhm@openbsd.org

BSDCan, May 2019

slide-2
SLIDE 2

What did exist before? How does it work? What are the findings? What is the Conclusion?

Detect Changes in Performance

  • ver Commits and Releases

1

What did exist before?

2

How does it work?

3

What are the findings?

4

What is the Conclusion?

slide-3
SLIDE 3

What did exist before? How does it work? What are the findings? What is the Conclusion?

Agenda

1

What did exist before?

2

How does it work?

3

What are the findings?

4

What is the Conclusion?

slide-4
SLIDE 4

What did exist before? How does it work? What are the findings? What is the Conclusion?

genua Firewall Testbed HPF

Numbers for Customers Marketing Developers Hardware . . .

slide-5
SLIDE 5

What did exist before? How does it work? What are the findings? What is the Conclusion?

HPF Result

slide-6
SLIDE 6

What did exist before? How does it work? What are the findings? What is the Conclusion?

Multi User, Multi Purpose Hardware Setup

Source 1 Source 2 . . . Source n Switch Drain 1 Drain 2 . . . Drain n 1 Gbit 1 Gbit Target 1 Target 2 . . . Target n 10 Gbit 10 Gbit

slide-7
SLIDE 7

What did exist before? How does it work? What are the findings? What is the Conclusion?

Unsuitable HPF

too many requirements too much complexity not enough flexibility

slide-8
SLIDE 8

What did exist before? How does it work? What are the findings? What is the Conclusion?

Performance Hardware Design

Target Target 10 Gbit

slide-9
SLIDE 9

What did exist before? How does it work? What are the findings? What is the Conclusion?

Existing Regression Tests

daily test runs using /usr/src/regress multi architecture history of pass and fail useful information web access http://bluhm.genua.de/

slide-10
SLIDE 10

What did exist before? How does it work? What are the findings? What is the Conclusion?

All Regression Tests

slide-11
SLIDE 11

What did exist before? How does it work? What are the findings? What is the Conclusion?

Regression Tests with Links

run history cvs web colored status test output setup logs

  • bj download

tested version

slide-12
SLIDE 12

What did exist before? How does it work? What are the findings? What is the Conclusion?

Regression History for i386

history severity

slide-13
SLIDE 13

What did exist before? How does it work? What are the findings? What is the Conclusion?

Regression Test Hardware

local remote router server

slide-14
SLIDE 14

What did exist before? How does it work? What are the findings? What is the Conclusion?

Regression Master

web master local remote router server console publish control configure install

slide-15
SLIDE 15

What did exist before? How does it work? What are the findings? What is the Conclusion?

Agenda

1

What did exist before?

2

How does it work?

3

What are the findings?

4

What is the Conclusion?

slide-16
SLIDE 16

What did exist before? How does it work? What are the findings? What is the Conclusion?

Performance Goals

history reproducable details available drill down automatic

slide-17
SLIDE 17

What did exist before? How does it work? What are the findings? What is the Conclusion?

Performance History

install release checkout at date compile kernel run tests advance by step collect results

slide-18
SLIDE 18

What did exist before? How does it work? What are the findings? What is the Conclusion?

Performance Tests Overview

run history run detail test command run date install version cvs checkout steps

slide-19
SLIDE 19

What did exist before? How does it work? What are the findings? What is the Conclusion?

Performance Run at Date

run and install log average numbers unstable results checkout date kernel commits build quirks

slide-20
SLIDE 20

What did exist before? How does it work? What are the findings? What is the Conclusion?

Performance Repeat at CVS Checkout

reboot log single result repeat count

  • utlier

standard deviation

slide-21
SLIDE 21

What did exist before? How does it work? What are the findings? What is the Conclusion?

Weekly from 6.2 to 6.3

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2017-11-01 2017-12-01 2018-01-01 2018-02-01 2018-03-01 bits/sec Checkout (date) TCP Performance A B C D E F G H I J

slide-22
SLIDE 22

What did exist before? How does it work? What are the findings? What is the Conclusion?

Quirks from 6.2 to 6.3

A OpenBSD/amd64 6.2 release B fix cvs vendor branch checkout C clang update LLVM to 5.0.0 D pfctl pf packet rate matching E move kernel source file dwiic.c F pfctl pf divert type G sysctl struct vfsconf H clang update LLVM to 5.0.1 I pfctl pf syncookies J OpenBSD/amd64 6.3 release

slide-23
SLIDE 23

What did exist before? How does it work? What are the findings? What is the Conclusion?

Build Quirks

checkout at date compile kernel run tests advance by step checkout userland build toolchain

slide-24
SLIDE 24

What did exist before? How does it work? What are the findings? What is the Conclusion?

Performance Hardware Future

Target 1 Target 1 Target 2 Target 2 Linux

slide-25
SLIDE 25

What did exist before? How does it work? What are the findings? What is the Conclusion?

Performance Master

web master console local target remote target publish control configure and compile install release

slide-26
SLIDE 26

What did exist before? How does it work? What are the findings? What is the Conclusion?

Agenda

1

What did exist before?

2

How does it work?

3

What are the findings?

4

What is the Conclusion?

slide-27
SLIDE 27

What did exist before? How does it work? What are the findings? What is the Conclusion?

Drilldown from Week to Days

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2017-12-28 2017-12-30 2018-01-01 2018-01-03 2018-01-05 2018-01-07 2018-01-09 bits/sec Checkout (date) TCP Performance

slide-28
SLIDE 28

What did exist before? How does it work? What are the findings? What is the Conclusion?

Reproduce and Reboot

compile kernel run tests run again reboot machine relink kernel

slide-29
SLIDE 29

What did exist before? How does it work? What are the findings? What is the Conclusion?

6.4, 5 Days, 10 Tests, Keep Machine Running

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2018-10-11 2018-10-11 2018-10-12 2018-10-12 2018-10-13 2018-10-13 2018-10-14 2018-10-14 2018-10-15 bits/sec Checkout (date) TCP Performance Y

slide-30
SLIDE 30

What did exist before? How does it work? What are the findings? What is the Conclusion?

6.4, 5 Days, 10 Tests, Reboot Machine

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2018-10-11 2018-10-11 2018-10-12 2018-10-12 2018-10-13 2018-10-13 2018-10-14 2018-10-14 2018-10-15 bits/sec Checkout (date) TCP Performance Y

slide-31
SLIDE 31

What did exist before? How does it work? What are the findings? What is the Conclusion?

6.4, 5 Days, 10 Tests, Link and Reorder Kernel

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2018-10-11 2018-10-11 2018-10-12 2018-10-12 2018-10-13 2018-10-13 2018-10-14 2018-10-14 2018-10-15 bits/sec Checkout (date) TCP Performance Y

slide-32
SLIDE 32

What did exist before? How does it work? What are the findings? What is the Conclusion?

6.4, 15 Days, 5 Tests, 2 CPU Sockets, Keep running

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2018-10-12 2018-10-14 2018-10-16 2018-10-18 2018-10-20 2018-10-22 2018-10-24 bits/sec Checkout (date) TCP Performance Y Z ab c

slide-33
SLIDE 33

What did exist before? How does it work? What are the findings? What is the Conclusion?

2 CPU Sockets, Repeat, Keep running

second cycle

slide-34
SLIDE 34

What did exist before? How does it work? What are the findings? What is the Conclusion?

from 6.3 to 6.4, 202 Days

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2018-04-01 2018-05-01 2018-06-01 2018-07-01 2018-08-01 2018-09-01 2018-10-01 bits/sec Checkout (date) TCP Performance K L M N O PQ RS TU V W X Y

slide-35
SLIDE 35

What did exist before? How does it work? What are the findings? What is the Conclusion?

from 6.4 to 6.5, 185 Days

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2018-11-01 2018-12-01 2019-01-01 2019-02-01 2019-03-01 2019-04-01 bits/sec Checkout (date) TCP Performance Y Z a bc d e f g h i j k l

slide-36
SLIDE 36

What did exist before? How does it work? What are the findings? What is the Conclusion?

from 6.5, 19 Days

5 × 108 1 × 109 1.5 × 109 2 × 109 2.5 × 109 3 × 109 3.5 × 109 4 × 109 2019-04-14 2019-04-16 2019-04-18 2019-04-20 2019-04-22 2019-04-24 2019-04-26 2019-04-28 2019-04-30 bits/sec Checkout (date) TCP Performance m

slide-37
SLIDE 37

What did exist before? How does it work? What are the findings? What is the Conclusion?

OpenBSD CVS Log

OpenBSD cvs log OpenBSD cvs log

created created 2019-04-20T18:30:24Z begin begin 2019-04-16T00:00:00Z end end 2019-04-17T00:00:00Z path path src/sys commits commits 8 date date 2019-04-16T04:04:19Z author author dlg files files src/sys/net/if.c log diff annotate src/sys/net/if_var.h log diff annotate src/sys/net/ifq.c log diff annotate src/sys/net/ifq.h log diff annotate message message have another go at tx mitigation the idea is to call the hardware transmit routine less since in a lot of cases posting a producer ring update to the chip is (very)

  • expensive. it's better to do it for several packets instead of each

packet, hence calling this tx mitigation. this diff defers the call to the transmit routine to a network taskq, or until a backlog of packets has built up. dragonflybsd uses 16 as the size of it's backlog, so i'm copying them for now. i've tried this before, but previous versions caused deadlocks. i discovered that the deadlocks in the previous version was from ifq_barrier calling taskq_barrier against the nettq. interfaces generally hold NET_LOCK while calling ifq_barrier, but the tq might already be waiting for the lock we hold. this version just doesnt have ifq_barrier call taskq_barrier. it instead relies on the IFF_RUNNING flag and normal ifq serialiser barrier to guarantee the start routine wont be called when an interface is going down. the taskq_barrier is only used during interface destruction to make sure the task struct wont get used in the future, which is already done without the NET_LOCK being held. tx mitigation provides a nice performanace bump in some setups. up to 25% in some cases. tested by tb@ and hrvoje popovski (who's running this in production).

  • k visa@

date date 2019-04-16T09:40:21Z author author dlg files files src/sys/dev/pci/if_myx.c log diff annotate message message make sff page reads work on little endian archs too. like amd64. some modules seem to need more time when waiting for bytes while here. hrvoje popovski hit the endian issue date date 2019-04-16T11:42:56Z

slide-38
SLIDE 38

What did exist before? How does it work? What are the findings? What is the Conclusion?

Agenda

1

What did exist before?

2

How does it work?

3

What are the findings?

4

What is the Conclusion?

slide-39
SLIDE 39

What did exist before? How does it work? What are the findings? What is the Conclusion?

Insights

measuring sucks multi socket CPUs suck reproducing is hard do not trust your numbers keep is simple stupid

slide-40
SLIDE 40

What did exist before? How does it work? What are the findings? What is the Conclusion?

Future Ideas

forwarding throughput Linux client and server better UDP tests testing patches historic releases file system performance sort kernel object files

slide-41
SLIDE 41

What did exist before? How does it work? What are the findings? What is the Conclusion?

Thanks

Jan Klemkow for Hardware Administration Moritz Buhl for Visualization genua for Hosting and Worktime

slide-42
SLIDE 42

What did exist before? How does it work? What are the findings? What is the Conclusion?

Links

http://bluhm.genua.de/ http://bluhm.genua.de/regress/results/regress.html http://bluhm.genua.de/perform/results/perform.html http://bluhm.genua.de/perform/results/gnuplot/test.data https://github.com/bluhm/regress-all https://github.com/younix/testmaster https://github.com/bluhm/talk-perform

slide-43
SLIDE 43

What did exist before? How does it work? What are the findings? What is the Conclusion?

Questions

?
