slide-1
SLIDE 1

MCS TaaSTing

This work was performed under the following financial assistance award 70NANB20H005 from U.S. Department of Commerce, National Institute of Standards and Technology, PSCR 1

slide-2
SLIDE 2

Mission Critical Services (MCS) Certification

  • MCS certification Chicken or the Egg issue
  • No MCS Testing equipment ó no certification programs ó jeopardized customers

confidence ó demand for testing equipment in a “niche market”

  • Meanwhile…
  • “MCPTT aligned”
  • 3GPP ready….
  • “Certified in the Plugtest”
  • Avalailable in –your MCS network- app store
  • 1st in the certification
  • Public Safety Grade
  • How am I supposed to write my RFI/RFQ?
  • How am I supposed to write my tender response?

2/20

slide-3
SLIDE 3

X

OS OS

MCS Certification: Why it’s More Important Than Ever

  • First flagship projects deploying MCS solutions
  • Std. compliance & interop ó innovation and competition
  • Avoid vendor lock-in from the very beginning
  • More certification needs
  • Much quicker release cycles than in PMR world
  • More stakeholders and relationships

All-in-one COTS LTE device to be certified MCS UE vendor A + MCS Client from vendor B/C/D

RF LTE IP

SERVICE

RF LTE IP

MCS MCS MCS CLIENT CERTIFICATION SCOPE CERTIFICATION SCOPE?

vs.

3/20

slide-4
SLIDE 4

Background: different kind of Testing and Certification

  • Interoperability
  • Conformance
  • Performance
  • Field test

4/20

slide-5
SLIDE 5

Interop and Conformance

VENDOR A VENDOR B MESSAGE X: Header1 Header2 x …. Header n Body MESSAGE Y: OK MESSAGE X: Header1 Wrong Header2 Missing Header x …. Header n Body

PASS FAILED

Conformance & Interop Vs Interop & conformance MESSAGE X: Header1 Header2 x …. Header n Body

5/20

slide-6
SLIDE 6

How does conformance certification usually work ?

3GPP Core Test Specs

TC prose specification

RAN5_SIG MCC TF160

TC TTCN3 implementation

3GPP RAN5 Test Cases Certification Program

Certified Lab Test Equipment Test Equipment

6/20

slide-7
SLIDE 7

MCS Conformance testing: status (2019)

  • No certified MCS test equipment
  • RAN5 TS (MCPTT/MCData/MCVideo Rel 14) ongoing
  • Full TTCN3 completion & verification pending
  • Users’ demand pushing….
  • ….but economy of scale and 5G activity delaying the availability
  • Early initiatives in certification programs
  • GCF-TTCA-JTF => MCS WI

7/20

slide-8
SLIDE 8

3GPP Core MCS TS

TC prose specification

RAN5_SIG MCC TF160

TC TTCN3 implementation

3GPP RAN5 Testing

Certification Program

Certified Lab Test Equipment Test Equipment

MCS Conformance testing: status (2019)

NIST funding opportunity came to help!

3GPP Core MCS TS

TC prose specification

RAN5_SIG MCC TF160

TC TTCN3 implementation

3GPP RAN5 Testing

Certification Program

Certified Lab Test Equipment Test Equipment

8/20

slide-9
SLIDE 9

Project description

FUNDING OPPORTUNITY (NOFO) - NIST Public Safety Innovation Accelerator Program - Mission Critical Voice Test Equipment

Ref: https://www.nist.gov/news-events/news/2020/01/pscr-awards-over-6m-rd-supporting-mission-critical-voice-test-equipment

9/20

slide-10
SLIDE 10

Project Description

KEY FACTS

Project lifetime: Dec 2019-Dec 2021 7 Partners led by UPV/EHU 3.6 MUSD Targeting two commercial solutions

Ref: https://www.nist.gov/news-events/news/2020/01/pscr-awards-over-6m-rd-supporting-mission-critical-voice-test-equipment

10/20

slide-11
SLIDE 11

Objectives

O5

Deployment and evaluation of a sample testing lab

RF test equipment Development of an e2e RF MCS testing equipment => eMBMS/MC

O4

TaaS Platform

O3

Definition and development

  • f MCS TaaS platform

MCS experts Client Server TTCN3 UE

RAN5 TS analysis New rules /Upgrades TTCN3 troubleshooting

Stable TTCN3 rules TTCN3 tester

O1

Building a comprehensive MCS TTCN3 suite

O2

Definition of flexible MCS (re)certification programs

11/20

slide-12
SLIDE 12

Expected outcomes at the end of the Project

  • Enhanced / troubleshooted RAN5 TC
  • Complete TTCN3 code
  • TTCN3 tester capable of validating the test cases
  • TaaS commercial service providing remote access to the tester
  • RF capable commercial product
  • Global Certification programs
  • Testing Lab procedures and experience

12/20

slide-13
SLIDE 13

3GPP Test Models

  • 3GPP RAN5 defines the testing procedures and reference pints to be

tested

  • Also the so called testing models
MCPTT Server simulation MCPTT Client under test Test Point (1) UE under test System Simulator

º

13/20

slide-14
SLIDE 14

3GPP Test Models

RAN5 Uu model vs IP model

Traditional telco equipment From LTE Phy to MCS Complex/Expensive

Traditional testers manufacturers Economy of scale

Test Equipment

OS

MCS UE vendor A + MCS Client vendor X

RF LTE IP

MCS CLIENT CERTIFICATION SCOPE

RF LTE IP MCS

Uu Reference Point

NAS EMU IP PTC System Simulator IPCanEmu: EUTRA

IP_SOCK Ut IPsec_CTRL IP_CTRL HTTPCTRL HTTPDATA IP_SOCK IPsec_CTRL IP_CTRL

MCPTT IMS PTC

IMS_CTRL IMS_CTRL IMS S/C IMS S/C FloorCtrl

EUTRA TCP/UDP/ICMP IPsec

MCPTT HTTP PTC

HTTPCTRL HTTPDATA

MTC

Create, Start Done IPCAN IPCAN IMS HTTP E_SRB SYS_SRB NASCTRL NASCTRL SRB SRB SYSIND E_SYSIND SYS E_SYS Ut Create, Start Done Create, Start Done Create, Start Done MMI PTC_Ut EUTRA_CTRL IP DHCP Server- Simulation DNS Server- Simulation ICMPv6 Server- Simulation UT PTC_Ut PTC_Ut MMI

(S)RTP/RTCP

SRTP

IUT (MCPTT UE)

RF cable

System Interface

TTCN-3 domain

14/20

slide-15
SLIDE 15

3GPP Test Models

RAN5

OS MCS UE vendor A + MCS Client vendor X

RF LTE IP

MCS CLIENT CERTIFICATION SCOPE

IP MCS

IP PTC System Simulator IPCanEmu : DUMMY_EUTRA

IP_SOCK Ut IPsec_CTRL IP_CTRL HTTPCTRL HTTPDATA IP_SOCK IPsec_CTRL IP_CTRL

MCPTT IMS PTC

IMS_CTRL IMS_CTRL IMS S/C IMS S/C FloorCtrl

TCP/UDP/ICMP IPsec

MCPTT HTTP PTC

HTTPCTRL HTTPDATA

MTC

Create, Start Done Ut Create, Start Done Create, Start Done Create, Start Done MMI PTC_Ut DHCP Server- Simulation DNS Server- Simulation ICMPv6 Server- Simulation UT PTC_Ut PTC_Ut MMI

(S)RTP/RTCP

SRTP

IUT (MCPTT client application)

IP connection System Interface

TTCN-3 domain IPCAN IPCAN IMS HTTP EUTRA_CTRL IP

Test Equipment

Any IP network

Uu model vs IP model

OTT testing Can not guarantee LTE MC features eMBMS/MC QCI? KPIS/Integration with UE?

15/20

slide-16
SLIDE 16

IP Model and TaaS

INTERNET

TaaS Platform

OS

MCS UE vendor A + MCS Client vendor X

RF LTE IP

MCS CLIENT

Testing as a Service (pre)certification purposes Foster continuous SW integration/testing

Testcase Management

  • Version Management
  • Upgrades
  • Review / Feedback Loop

Test Execution Control

  • User Interface
  • Configuration
  • Parameterisation
  • Status Overview

Test Result Management

  • Store Test Results
  • Create Reports
  • Wireshark Traces, etc.

TTCN3 tester

Client – Server Interface MCS Signalling and media certification

Test Execution

  • Execute TTCN-3

Testcases

  • Execute Tools,

Simulators

16/20

slide-17
SLIDE 17

MC LTE

MCS TaaSting 1.5 Model

RAN5 IMS IPCAN-like model

Intermediate Uu ó IP model MCS testing + RF capable MC features MC QCIs eMBMS bearer handling

OS MCS UE vendor A + MCS Client vendor X

RF LTE IP

MCS CLIENT TESTING SCOPE

IP MCS

Test Equipment

RF LTE

XCAP Server (SS implementation) DNSServer- Simulation IP ADAPTOR PTC System Adaptor IPCanCrtl- Component

IPCAN_CTRL UnsecClient UnsecServer SecClient SecServer MMI_SYS IPConf SigComp HTTPCTRL HTTPDATA DhcpServer DnsServer

DHCPServer- Simulation

Create, Start Create, Start Done Done UnsecClient UnsecServer SecClient SecServer IpConf SigComp DnsServer DhcpServer

IMS PTC

IMS_CTRL IMS_CTRL IMS_Server IMS_Client IMS_Server IMS_Client

EUTRA / UTRAN / GERAN TCP/UDP/ICMP SigComp IPsec

HTTP XCAP PTC

HTTPCTRL HTTPDATA

MTC

Create, Start Done Create, Start Done Done Create, Start MMI_SYS IPCAN IPCAN_CTRL IPCAN XCAP XCAP IMS XCAP Create, Start D
  • n
e IP PTC System Simulator eIPCanEmu : IP_SOCK Ut IPsec_CTRL IP_CTRL HTTPCTRL HTTPDATA IP_SOCK IPsec_CTRL IP_CTRL MCPTT IMS PTC IMS_CTRL IMS_CTRL IMS S/C IMS S/C FloorCtrl TCP/UDP/ICMP IPsec MCPTT HTTP PTC HTTPCTRL HTTPDATA MTC Create, Start Done Ut Create, Start Done Create, Start Done Create, Start Done MMI PTC_Ut DHCP Server
  • Simulation
DNS Server
  • Simulation
ICMPv6 Server
  • Simulation
UT PTC_Ut PTC_Ut MMI (S)RTP/RTCP SRTP System Interface TTCN -3 domain IPCAN IPCAN IMS HTTP EUTRA_CTRL IP IUT (MCPTT UE) (MCPTT client application) TaaSting connector RF cable EUTRA NOT_THAT_ DUMMY_EUTRA

TS 34229-4

17/20

slide-18
SLIDE 18

Testcase Management

  • Version Management
  • Upgrades
  • Review / Feedback

Loop

Test Execution Control

  • User Interface
  • Configuration
  • Parameterisation
  • Status Overview

Test Execution

  • Execute TTCN-3

Testcases

  • Execute Tools,

Simulators

Test Result Management

  • Store Test Results
  • Create Reports
  • Wireshark Traces, etc.

MC LTE

INTERNET

RF Capable Tester

1.5 Model TTCN3 MCS tester + MC LTE features Remote controlling / synching

OS MCS UE vendor A + MCS Client vendor X

RF LTE IP

MCS CLIENT TESTING SCOPE

IP MCS

Test Equipment

RF LTE TaaS Platform

TTCN3 tester

Testcase Management
  • Version Management
  • Upgrades
  • Review / Feedback Loop
Test Execution Control
  • User Interface
  • Configuration
  • Parameterisation
  • Status Overview

Test Execution

  • Execute TTCN-3
Testcases
  • Execute Tools, Simulators
Test Result Management
  • Store Test Results
  • Create Reports
  • Wireshark Traces, etc.

TTCN3 tester

Synching Off-loading Remote Control

18/20

slide-19
SLIDE 19

CURRENT STATUS (Q2’20)

  • RAN5 GAP analysis
  • Enchanced TTCN3 MCPTT rules
  • Intensive troubleshooting with TF160
  • Feedback to RAN5 (RAN5#87-e)
  • First TCCN3 tester developed
  • First RAN5 TCs verified
  • TaaS platform… following

19/20

slide-20
SLIDE 20

MCS TaaSTing

This work was performed under the following financial assistance award 70NANB20H005 from U.S. Department of Commerce, National Institute of Standards and Technology, PSCR 20

slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23

→

Monthly Security Updates Yearly Hardware Releases Weekly / Daily Application Updates

slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34
slide-35
SLIDE 35
slide-36
SLIDE 36

09/10 2020 03 2021 12 2020

slide-37
SLIDE 37

MCS Platform 3GPP RAN5 Test Cases Buyers Testing Houses Vendors MCS TaaSTing Project
