Maureen McDaniel, MEd, RDMS, RDCS, RVT Sagittal Coronal Transverse Also called multiplaner, surface rendering, volume scanning Originated about 25 years ago More widely available 1990s Get the middle point in the

slide-1
SLIDE 1

Maureen McDaniel, MEd, RDMS, RDCS, RVT

slide-2
SLIDE 2
slide-3
SLIDE 3
slide-4
SLIDE 4
slide-5
SLIDE 5

Sagittal Coronal Transverse

slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8

Also called multiplaner, surface rendering,

volume scanning

Originated about 25 years ago More widely available 1990’s

slide-9
SLIDE 9

Get the middle point in the picture in 2D

For face this is the profile

Angle transducer all the way to side

Want to start in amniotic fluid

Move smoothly through anatomy till you reach other

side

Hopefully ending in amniotic fluid

The machine then calculates volume, based on the 2D

images obtained

slide-10
SLIDE 10

After you have the quad screen

Cut off surrounding objects Adjust transparency for desired effect

slide-11
SLIDE 11

Tissue Heating Cavitation

Gas bubbles developing within tissues due to

prolonged exposure.

Caviation effects are possible within range used

for diagnostic examination

Transient cavitation

Bursting of bubbles causing cellular damage

Rise in temperature of 2⁰C

slide-12
SLIDE 12
slide-13
SLIDE 13

AIUM clearly discourages US for fun Scanning for parents increases scan time AIUM prohibits videotaping because it

lengthens scan time

What are we gaining? Extra charge for insurance companies Must be ordered by perinatologist—not OB

slide-14
SLIDE 14

3 D Technology Approved October 1999 Currently, two-dimensional (2D) gray-scale real-time sonography is the primary method of medically indicated anatomic imaging with ultrasound. While three-dimensional (3D) sonography may be helpful in diagnosis, it should not be considered more than a developing technology. Its role is restricted to an adjunct of, but not a replacement for, 2D ultrasound. As with any developing technology, its diagnostic value may improve, and its diagnostic role will be periodically re-evaluated.

slide-15
SLIDE 15

The new position statement is as follows: The AIUM advocates the responsible use of diagnostic ultrasound for all fetal imaging. The AIUM understands the growing pressures from patients for the performance of ultrasound examinations for bonding and reassurance purposes largely driven by the improving image quality of 3D sonography and by more widely available information about these advances. Although there is only preliminary scientific evidence that 3D sonography has a positive impact on parental--fetal bonding, the AIUM recognizes that many parents may pursue scanning for this purpose.

slide-16
SLIDE 16

As Low As Reasonably

Achievable

Benefits must outweigh the risks Only when medically indicated

Determining gender is not medically indicated

unless risk of x-linked disease

slide-17
SLIDE 17

Maternal body habitus!!!!! Not enough amniotic fluid Face looking down Face looking up but into or against placenta Arms or legs in front of face If scanning extremities, almost always have

problems with surrounding structures

Only a problem for 3D, not 4D

Fetal movement Sonographer not keeping steady movement across

structure

slide-18
SLIDE 18
  • oh, aah
slide-19
SLIDE 19

Color Anyone?

slide-20
SLIDE 20

Face looking into placenta

slide-21
SLIDE 21

scary

slide-22
SLIDE 22

Even scarier

slide-23
SLIDE 23

I’m an alien

slide-24
SLIDE 24

OB

Cleft lip and palate

Usually ordered after previously seen in 2D

slide-25
SLIDE 25

Central nervous system anomaly

slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28

2D images 3D image

slide-29
SLIDE 29

2D image 3D images

slide-30
SLIDE 30

Polycystic ovaries Uterine anomalies

slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34

Severity of ventricular septal defect Mitral valve regurge Mitral valve repair Problems with movement

slide-35
SLIDE 35
slide-36
SLIDE 36

Vein of Galen aneurysms Periventricular leukomalacia Ventriculomegally Holoprosencephaly Circle of Willis

slide-37
SLIDE 37

2D images of ventriculomegaly and periventricular leukomalacia 3D imaging of same infant

slide-38
SLIDE 38

Breast tumor with power angio

slide-39
SLIDE 39

Echotexture

cystic or solid; homogeneous or heterogeneous

Shape

taller than wide

Shadowing

bilateral or unilateral

slide-40
SLIDE 40

Higher accuracy for staging esophageal,

gastric, colo-rectal cancer

Used to show effects of chemo/radiation

therapy

Follow up for early detection of recurrences

after tumor resection

slide-41
SLIDE 41

2D image of lining of GI tract

slide-42
SLIDE 42
slide-43
SLIDE 43

If non-moving object, can acquire all three

planes in time it takes to acquire one

Physician can manipulate images later if

proper recording techniques are used

Procedures

slide-44
SLIDE 44

Movement of object or sonographer Operator dependent Physician may take longer to read study

slide-45
SLIDE 45

Fine needle biopsies Ethanol ablation RF ablation Cryoablation Catheter placement for drainage

slide-46
SLIDE 46
slide-47
SLIDE 47

Adds time as a forth dimension Place probe.

Mechanics inside move angle for you. Very large probe

Less room for operator error Same constraints as 3D

Need amniotic fluid, fetal position

Great for real-time procedures

slide-48
SLIDE 48
slide-49
SLIDE 49

Most sonographers retire due to MSI

Carpel tunnel

slide-50
SLIDE 50
slide-51
SLIDE 51

4D is coined by GE Live 3D used by other manufacturers ATL (now Philips) had live 3D before GE introduced

4D

Marketed to public rather than Doctors and

Sonographers—why?

Why marketed for OB instead of other modalities? Similar to Pharmaceuticals Is this marketing to public effective?

slide-52
SLIDE 52
