Massive scale-out of expensive continuous queries E. Zeitler and T.Risch Presentation by Thomas Pasquier

Stream splitting

Splitstream ● splistream(stream s, int q, function bfn, function rfn) ● user defines rfn (routing function) ● int rfn(int q, tupple t) ● user defines bfn (broadcast function) ● bool bfn(int q, tupple t)

Naive implementation

Tree shapped implemenation: maxtree Scalable Splitting of Massive Data Streams Erik Zeitler, Tore Risch

Parasplit

Parasplit*

Evaluation: network bound

Window router stream rate If w large enough bound by the network However, performance decrease when p large (author state reason unknown)

Evaluation parasplit* Less degradation when using parasplit*

Comparison different solutions

Cost model and heuristic

Cost model for Window router Cpr = cr + cs + ce ● cr : read cost ● cs : split cost ● ce : emit cost

Cost window splitter Cps = crw + cs (o+r+q.b) + ce(r+q.b) ● crw : read cost per window ● cs : split cost per tuple ● ce : emit cost per tuple ● o : omit % ● r : routing % ● b : broadcast % ● o + r + b = 100%

Cost model for query processor Cpq = cr + p(cp+cm) + O ● cr : read cost per tuple ● cp : poll cost ● cm : merge cost ● O : cost for executing the query and emitting the results

Cost model for parasplit ● Cpr = crw + cs + ce ● Cps = crw + cs (o+r+q.b) + ce(r+q.b) ● Cpq = cr + p(cp+cm) + O

Heuristic for estimating p ● We search p such that ● Assume: ○ 1% broadcast tuples ○ 0% omitted ○ crw = 0 ● Cps = crw + cs (o+r+q.b) + ce(r+q.b) ● ● We estimate cs + ce by measuring the maximum steam rate ● ● We can then estimate p, given the desired steam rate

Efficiency ● Measurement of the additional work incurred by executing parasplit in comparison to executing a window splitter in a single process ● Useful work: ○ p.Cps ● Overhead: ○ Cpr ○ q.Cpq with O=0

Evaluation efficiency

Related publications ● Event-based Systems: Opportunities and Challenges at Exascale, Brenna et al., 2009 ○ stream splitting shown to be a bottleneck ● MapReduce Online, Condie et al., 2010 ○ does not handle scalable stream splitting

Thank you Questions ?
