Market Assessment

agenda: Market Assessment

• Statistical Analysis
• Case Studies
• Conclusions

• community centers
• k-12 schools
• ffice buildings – low-rise
• wet labs

building types

statistical analysis

88

high-performance buildings

200

high-performance buildings

approach

statistical analysis

normalize data

• common location
• common time

establish comparison baseline

• the project’s original budget
• the project itself, without the green elements
• similar projects

500

buildings

wet labs

statistical analysis

100 200 300 400 500 600 700 800

Control Gold Platinum NZE/LB

$ / SF BUILDINGS MEASURED

Green

200 400 600 800 1000 1200

Control Green LEED Platinum NZE/LB

K-12

statistical analysis

BUILDINGS MEASURED $ / SF

200 400 600 800 1000 1200 1400

Control LEED Gold LEED Platinum NZE/LB

community centers

statistical analysis

BUILDINGS MEASURED $ / SF

Green Platinum

100 200 300 400 500 600 700 800 900

Control Green Platinum NZE/LB

low-rise office building

statistical analysis

BUILDINGS MEASURED $ / SF

energy performance: predicted vs. actual EUI

statistical analysis

20 10

• 10
• 20
• 30
• 40
• 50

Green Platinum ZNE/LB

50 100 150 200 250 $0 $200 $400 $600 $800 $1,000 $1,200 EUI (KWH/SF/YEAR)

Community Center Wet Lab K-12 Office Residetial Low Rise

EUI to cost

COST IN $ PER SF

Residential Low-Rise

findings

comparison of component costs

• High Performance buildings are happening
• There are two distinct families
• Demonstration projects
• ‘Mainstream’ projects – (a growing cohort)
• HPB are getting there by reducing consumption
• Costs are approaching ‘conventional’ buildings

Innovation Adoption Maturity Decline

Sales Price

statistical analysis

cost of learning curve

Price

1 2 3

cost of learning curve

statistical analysis

case studies

435 indio

concepts

Sunnyvale, CA Sharp Development RMW Architecture 30,000 gsf Net Zero within standard budget

• Passive night cooling
• Upgraded exterior insulation with thermal mass walls
• Ceiling fans extend comfort temperature range
• Custom operable skylights use prevailing breezes to induce internal airflow
• High performance glazing – no need for external shades
• Daylighting to all occupied spaces
• Skylights designed to provide equal light levels in summer and winter, and 15% higher

levels at equinox

• High efficiency LED lighting (.5W/sf)
• Integral daylight, occupancy, and temperature sensors at every light fixture
• Individually controlled desk fans and task lights
• Metering by load type (lighting, plug loads, mechanical)
• Building energy use dashboard
• Occupancy sensor controlled plug strips

impact of night purge: typical day

55 °F 60 °F 65 °F 70 °F 75 °F 80 °F 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

Automated Windows

OA Temp West Zone Air Temp West Zone MRT Slab Temp 55 °F 60 °F 65 °F 70 °F 75 °F 80 °F 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

Closed Windows

OA Temp West Zone Air Temp West Zone MRT Slab Temp

• Performance based lease provides carrot (and stick) for good occupant behavior
• Added construction cost = $44/sf including 32,000 sf PV array
• Drastically reduced reserve requirements for maintenance and HVAC
• Reduced operating expenses – utilities, landscape, etc
• Demisability to reduce churn costs
• Unanticipated cost reductions (e.g. no mechanical screen)
• IF actual energy use meets predicted, than the financial model is more profitable than

standard practice (build to code)

• Future projects – higher rents and lease rates

concepts: financial

• High Performance Buildings are

coming

• Generally they are approaching

market costs.

• It is possible with the right team to

building them at market costs

• Generally the buildings are performing
• Of the high performance buildings

there is not a correlation between performance and cost.

What does this mean?
