Deep Learning for Visual Manipulation and Synthesis

Jun-Yan Zhu 朱俊彦

UC Berkeley 2017/01/11 @ VALSE

What is visual manipulation?

User Input

Image Editing Program

input photo result

Desired output:

• stay close to the input.
• satisfy user’s constraint.

[Schaefer et al. 2006]

What is Visual Synthesis?

Image Generation Program

user input result

Desired output:

• satisfy user’s constraint.

Sketch2Photo [Tao et al. 2009]

So far so good

Things can get really bad The lack of “safety wheels”

Adding the “safety wheels”

Image Editing Program

User Input Input Photo Output Result

Natural Image Manifold A desired output:

• stay close to the input.
• satisfy user’s constraint.
• Lie on the natural image manifold

Prior work: Heuristic-based

Color [Reinhard et al. 2004] Color and Texture [Johnson et al. 2011] Gradient [Perez et al. 2003] “Bleeding” artifacts [Tao et al. 2010]

Prior work: Discriminative Learning

Image Compositing (20 images) [Xue et al. 2012] Image Deblurring (40 images) [Liu et al. 2013] Natural Human Motion (34 subjects) [Ren et al. 2005]

Our Goal:

• Learn the manifold of natural images

without direct human annotations.

• Improve visual manipulation and synthesis by

constraining the result to lie on that learned manifold.

Why Deep Learning Methods?

• Impressive results on visual recognition.

– Classification, detection, segmentation,3D vision, videos, etc.

• No feature engineering.
• Recent development of generative models.

(e.g. Generative Adversarial Networks)

Deep Learning trends: performance

Deep Learning trends: research

AlexNet [Krizhevsky et al.] ImageNet [Jia et al.]

Realism CNN Image Editing Model

Predict Realism Improve Editing

Discriminative Model M: {𝑦|𝑄 𝑠𝑓𝑏𝑚 𝑦 = 1} [ICCV 15’] Generative Model M: {𝑦|𝑦 = 𝐻 𝑨 } [SIGGRAPH 14’] [ECCV 16’]

Project Edit Transfer

Editing UI

Realism CNN Image Editing Model

Predict Realism Improve Editing

Discriminative Model M: {𝑦|𝑄 𝑠𝑓𝑏𝑚 𝑦 = 1} [ICCV 15’]

Foreground Object 𝐺 Background 𝐶 Image Composite 𝐽

Composite images Natural Photos

CNN Training Classifying

25K natural photos

vs.

25k composite images

Learning Visual Realism

Object Mask: (1) Human Annotation (2) Object Proposal

[Lalonde and Efros 2007]

How do we get composite images?

Composite Images Object Masks with Similar Shapes Target Object Object Mask

Ranking of Training Composites

Most realistic composites Least realistic composites

Evaluation

Dataset

• [Lalonde and Efros 2007]
• Task: binary classification
• 360 realistic photos

(natural images + realistic composites)

• 360 unrealistic photos

Methods without object mask Lalonde and Efros (no mask) 0.61 AlexNet + SVM 0.73 RealismCNN 0.84 RealismCNN + SVM 𝟏. 𝟗𝟗 Human 0.91 Methods using object mask Reinhard et al. 0.66 Lalonde and Efros (with mask) 0.81

Area under ROC Curve

Red: unrealistic composite, Green: realistic composite, Blue: natural image

Snowy Mountain Ocean Highway Least Realistic Most Realistic

Visual Realism Ranking

Our Pipeline

Realism CNN Image Editing Model

Predict Realism Improve Composites

Realism CNN Editing model: Color adjustment 𝒉 Foreground object F

𝐹(𝑕, 𝐺) = 𝐹𝐷𝑂𝑂 + 𝐹𝑠𝑓𝑕

Improving Visual Realism

Original Composite (Realism score: 0.0)

Quasi-Newton (L-BFGS)

Improved Composite (Realism score: 0.8)

Selecting Suitable Objects

Best-fitting object selected by RealismCNN Object with most similar shape

Optimizing Color Compatibility

Cut-n-paste Lalonde et al. Xue et al. Ours Object mask

Sanity Check: Real Photos

Lalonde et al. Xue et al. Ours Object mask Cut-n-paste

Visualizing and Localizing Errors (

𝜖𝐹 𝜖𝐽𝑞)

Result 𝐹 = Gradient Map 50.73 9.38 5.05 3.44 3.00 Number of L-BFGS iterations

Discriminative Model {𝑦|𝑄 𝑠𝑓𝑏𝑚 𝑦 = 1}

• Pros:

– CNN is easy to train. – Graphics programs often produce better images than generative models. – General framework for many tasks (e.g. deblurring, retargeting, etc.)

• Cons:

– Task-specific: cannot apply pre-trained model to other tasks. – Graphics programs are often non-parametric and non-differentiable. – Graphics programs often require user in the loop: thus automatically generating results for CNN training is challenging.

• Code: github.com/junyanz/RealismCNN
• Data: people.eecs.berkeley.edu/~junyanz/projects/realism/

Realism CNN Image Editing Model

Predict Realism Improve Editing

Discriminative Model M: {𝑦|𝑄 𝑠𝑓𝑏𝑚 𝑦 = 1} [ICCV 15’] Generative Model M: {𝑦|𝑦 = 𝐻 𝑨 } [SIGGRAPH 14’] [ECCV 16’]

Project Edit Transfer

Editing UI

Learning Natural Image Manifold

• Deep generative models:

– Generative Adversarial Network (GAN) [Goodfellow et al. 2014] [Radford et al. 2015] [Denton et al 2015] – Variational Auto-Encoder (VAE) [Kingma and Welling 2013] – DRAW (Recurrent Neural Network) [Gregor et al 2015] – Pixel RNN and Pixel CNN ([Oord et al 2016]) – …

“Cat”

Input image 𝐽

Image Classification via Neural Network

Slides credit: Andrew Owens

Gaussian noise Image

Can We Generate Images with Neural Networks?

• r Random Distribution

Generative Model

[Goodfellow et al. 2014]

Generative Adversarial Networks (GAN)

Synthesized image

Generative Model

[Goodfellow et al. 2014]

Generative Adversarial Networks (GAN)

Discriminative Model

“real”

Generative Model

[Goodfellow et al. 2014]

Generative Adversarial Networks (GAN)

Discriminative Model

“fake”

Cat Generation (w.r.t. training iterations

GAN as Manifold Approximation

Sample training images from “Amazon Shirts” Random image samples from Generator G(z)

[Radford et al. 2015]

Traverse on the GAN Manifold

[Radford et al. 2015]

𝐻(𝑨0) 𝐻(𝑨1)

Linear Interpolation in z space: 𝐻(𝑨0 + 𝑢 ⋅ (𝑨1 − 𝑨0)) Limitations:

• not photo-realistic enough, low resolution
• produce images randomly, no user control

Overview

• riginal photo

projection on manifold Project Edit Transfer transition between the original and edited projection different degree of image manipulation

Editing UI

Overview

• riginal photo

projection on manifold Project Edit Transfer transition between the original and edited projection different degree of image manipulation

Editing UI

0.196 0.238 0.332

Optimization

Projecting an Image onto the Manifold

Input: real image 𝑦𝑆 Output: latent vector z

Generative model 𝐻(𝑨) Reconstruction loss 𝑀

0.196 0.238 0.332

Optimization

Projecting an Image onto the Manifold

Inverting Network z = 𝑄 𝑦

0.218 0.242 0.336

Auto-encoder with a fixed decoder G Input: real image 𝑦𝑆 Output: latent vector z

0.196 0.238 0.332

Optimization

Projecting an Image onto the Manifold

Inverting Network z = 𝑄 𝑦

0.218 0.242 0.336 0.153 0.167

Hybrid Method Use the network as initialization for the optimization problem

0.268

Input: real image 𝑦𝑆 Output: latent vector z

Overview

• riginal photo

projection on manifold Project Edit Transfer transition between the original and edited projection different degree of image manipulation

Editing UI

Manipulating the Latent Vector

Objective:

𝐻(𝑨) Guidance 𝑤𝑕 𝑨0

user guidance image constraint violation loss 𝑀𝑕

Overview

• riginal photo

projection on manifold Project Edit Transfer transition between the original and edited projection different degree of image manipulation

Editing UI

Edit Transfer

𝐻(𝑨1) 𝐻(𝑨0) Input

Motion (u, v)+ Color (𝑩𝟒×𝟓): estimate per-pixel geometric and color variation

Linear Interpolation in 𝑨 space

Edit Transfer

𝐻(𝑨1) 𝐻(𝑨0) Input Linear Interpolation in 𝑨 space

Motion (u, v)+ Color (𝑩𝟒×𝟓): estimate per-pixel geometric and color variation Motion (u, v)+ Color (𝑩𝟒×𝟓): estimate per-pixel geometric and color variation

Edit Transfer

Result

𝐻(𝑨1) 𝐻(𝑨0) Input

Motion (u, v)+ Color (𝑩𝟒×𝟓): estimate per-pixel geometric and color variation

Linear Interpolation in 𝑨 space

Image Manipulation Demo

Image Manipulation Demo

Designing Products

Interactive Image Generation

The Simplest Generative Model: Averaging

AverageExplorer: {𝑦|𝑦 = 𝑜 𝑥𝑜 ⋅ 𝐽𝑜

𝑥𝑏𝑠𝑞}

• Generative model: weighted average of warped images.
• Limitations: cannot synthesize novel content.

[Zhu et al. 2014]

Generative Image Transformation

iGAN (aka. interactive GAN)

• Get the code: github.com/junyanz/iGAN
• Intelligent drawing tools via GAN.
• Debugging tools for understanding and

visualizing deep generative networks.

• Work in progress: supporting more models

(GAN, VAE, theano/tensorflow).

Generative Model {𝑦|𝑦 = 𝐻 𝑨 , 𝑨 ∈ 𝑎}

• Pros:

– Task-independent: offline generative model training is independent of the graphics applications. – Optimizing 𝑨 is easier than optimizing 𝑦. – Generative models are better and better.

• Cons:

– Low quality, low res => post-processing (still engineering work). – Limitations of current generative models: cannot produce good texture.

Related work on GAN

• Goodfellow’s NIPS 2016 Tutorial: [arxiv], [slides]
• Early work: [Tu 07’], [Gutmann and Hyvarinen 10’], etc.
• New models: InfoGAN, SSGAN, VAE-GAN, LAPGAN, BiGAN,

CoGAN, PPGAN, etc.

• Training techniques: DCGAN, Improved-GAN, EBGAN, Unrolling.
• Image: Inpainting, Inverting features, Style Transfer, Text-To-

Image, super-resolution, etc.

• Video: Frame Prediction, Tiny Videos, etc.

Image-to-Image Translation

arxiv 2016 code: github.com/phillipi/pix2pix

Image-to-Image Translation with Conditional Adversarial Nets Phillip Isola, Jun-Yan Zhu, Tinghui Zhou, and Alexei A. Efros. Arxiv 2016

Image-to-Image Problems

Conditional Adversarial Networks (cGAN)

• Loss: L1+GAN
• G:U-Net
• D: PatchGAN (70 × 70)

U-Net [Ronneberger et al. 15’]

Conditional GAN

Network and Loss Function

• Loss function: L1 + GAN
• Generator G: U-Net
• Discriminator D: PatchGAN 70 × 70 (FCN)

U-Net [Ronneberger et al. 15’]

Different Losses

Architectures for Generator G

Patch Size of PatchGAN

Applications

Label→Facade

Label→Street View

Map Generation

Day→ night

Edge→Handbag

HED [Xie and Tu. 15’]

Edge→ Shoe

HED [Xie and Tu. 15’]

User Sketch→ Photo

Automatic Colorization

Failure Cases

• Sparse input image.
• Unusual input image.

Summary: Image-to-Image Problems

Cat Paper Collection

• GitHub: github.com/junyanz/CatPapers
• 90% data is visual; most of visual data are about Cats.
• 60+ vision, learning and graphics papers.

Thank You!

Eli Philipp Alyosha Yong Jae Tinghui Philipp
