LunarLander-v2 using Deep Reinforcement Learning A project - - PowerPoint PPT Presentation

LunarLander-v2 using Deep Reinforcement Learning

A project developed for Autonomous Agents Course PLH513 Portokalakis Petros February 2020

Simple Game

• 8-Dimensional state space
• 4 actions per state
• +100 points for landing
• 100 points when crashed
• Infinite fuel, but -0.3 points per

frame when firing main engine

• +10 for each leg ground contact (to

encourage smooth landing)

Deep Reinforcement Learning

Objective: approximate the optimal Q-Function (which satisfies the Bellman Equation) Neural network:

• 8 node input layer - dimensionality of state space
• 150 node fully connected 1st hidden layer
• 128 node fully connected 2nd hidden layer
• 4 node output layer - q-values for actions

4 layer approach works well with a variety of hidden layer node number 5 layers prove insufficient to even train the agent

Deep Reinforcement Learning: Advancing performance

Experience replay:

• Every tuple(s,a,r,s’,done) is stored in a replay buffer (maxlength=1M)
• Randomly sample a batch of previous experiences (64). Break correlation

between consecutive samples

• Predict best action for all items in the batch via the NN
• Update neural network weights
• Generate episodes via exploration or exploitation

Deep Reinforcement Learning: Advancing performance

• Calculating loss between output Q-value and target Q-value requires a seconds

pass to the network for the next state

• s and s’ share the same network and have one step difference
• Optimization becomes unstable

Target network: Use an identical network to the policy network, but update target network weight’s every C iterations (C is a hyperparameter) First pass occures with the policy network Second pass occures with the target network

Deep Reinforcement Learning: Advancing performance

Abstract version of the agent algorithm implemented

Deep Reinforcement Learning: Performance of Lunar Lander

Deep Reinforcement Learning: Performance of Lunar Lander

Adding a third hidden layer

Deep Reinforcement Learning: Hyperparameter Tuning

Hyperparameter Value Starting epsilon 1 Minimum epsilon 0.01 Decay factor of epsilon 0.99 Discount factor gamma 0.99 Learning rate 0.001 Batch size 64 Replay buffer 1000000

Thank you Questions?

Contact: pportokalakis@gmail.com
