SLIDE 1
Lost in Abstraction
Sebastian Janzen
Lost in Abstraction Sebastian Janzen Sebastian @sebbe128 innoQ - - PowerPoint PPT Presentation
Lost in Abstraction Sebastian Janzen Sebastian @sebbe128 innoQ - - PowerPoint PPT Presentation
Lost in Abstraction Sebastian Janzen Sebastian @sebbe128 innoQ https://www.innoq.com What is a Smart Home ? Smart Home is NOT a connected device is NOT a cloud service is NOT a single product A dwelling incorporating a
SLIDE 2
SLIDE 3
innoQ
https://www.innoq.com
SLIDE 4
What is a Smart Home?
SLIDE 5
SLIDE 6
Smart Home
is NOT a connected device is NOT a cloud service is NOT a single product
SLIDE 7
“A dwelling incorporating a communications network that connects the key electrical appliances and services, and allows them to be remotely controlled, monitored or accessed.”
2003 UK Department of Trade and Industry - http:/ /goo.gl/7PW8Gv
SLIDE 8
It’s a system of things which support the
- ccupants use cases.
SLIDE 9
Smart Home participants
User Device Sofuware
Interaction I n t e r a c t i
- n
A c c e s s
SLIDE 10
The user’s expectations
Flexibility: Cover custom use cases Extensibility: Installation extension Sustainability: Long term benefjt Avoid vendor lock-in: Should be extensible
SLIDE 11
Passive User Ambitioned User Expert
U U+ U++
SLIDE 12
U U+ U++ UI Device
+ Best setup — Extensibility — Flexibility
SLIDE 13
U U+ U++
UI Device
Cloud
+ Modifjcations to fjnal product — Privacy — Ofgline
SLIDE 14
U U+ U++
UI UI UI
Eclipse SmartHome
Device Device Device Service UI
SLIDE 15
Eclipse SmartHome (ESH)
SLIDE 16
Eclipse SmartHome
> An open source Internet of Things framework > Java OSGi based Project > Eclipse Public License > Since 2014 > Base of openHAB > Requirements: Java >= 6 > Base of successful commercial Projects
SLIDE 17
What you get
> Structure to handle IoT devices > Web-Interfaces, Apps, Examples > More than 100 already supported things > Documentation > Commercial support available > Large and active community
SLIDE 18
What you do not get
> Hardware > A Java license
SLIDE 19
OS JVM
OSGi Container Eclipse SmartHome (ESH)
- penHAB
Solution X Solution Y
SLIDE 20
How to use this?
SLIDE 21
Representation Binding Thing Channel Channel Channel Bridge Thing Item
Link
UI
SLIDE 22
Representation Binding Thing Channel Channel Channel Bridge Thing Item
Link
Hue Lamp Color Temp. Brightness Color Hue Bridge ColorItem Status: ONLINE State: #FF0000
SLIDE 23
Representation Binding Thing Channel Channel Channel Bridge Thing Item
Link
UI Item GroupItem
Link
SLIDE 24
Binding Thing Channel Channel Channel Bridge Thing Thing
Id, Name, Description, Bridge, Confjguration, Channels
SLIDE 25
Binding Thing Channel Channel Channel Bridge Thing Id, Description, … Confjguration Channel
SLIDE 26
Thing Channel Channel Channel Bridge Thing Representation Item Type, Name, Label, Icon, Tags, … Item
SLIDE 27
Representation Binding Thing Channel Channel Channel Bridge Thing Item
Link
SLIDE 28
Bundle
Thing
Channel Channel Channel
Bridge Thing
SLIDE 29
Eclipse SmartHome Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
SLIDE 30
Eclipse SmartHome Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
Bundle
Thing
Channel Channel Channel
Bridge Thing
UI UI
SLIDE 31
Eclipse SmartHome Binding Binding Binding Binding UI UI Persistence Rules REST Discovery … UIs
SLIDE 32
Eclipse SmartHome Core Items Bindings Eclipse SmartHome Event Bus
PubSub PubSub
Rules
PubSub
Persistence
PubSub
Logging
PubSub
SLIDE 33
How to program this?
SLIDE 34
Bridge Thing
/ESH-INF/thing/bridge.xml
SLIDE 35
Thing
/ESH-INF/thing/LCT001.xml
SLIDE 36
Channel
/ESH-INF/thing/channels.xml
SLIDE 37
Core ItemTypes
> Color > Contact > DateTime > Dimmer > Group > Location > Number > Player > Rollershutter > String > Switch
SLIDE 38
What does Lost in Abstraction mean?
SLIDE 39
Use case: Wash again, if washing fjnished and the door has not been opened afuer 16h.
SLIDE 40
Hardware UI State Washing Program Extra Parameters Power Water Amount Temperature Spin Extra H2O Door contact Time running Washing Machine Convenient ✓
SLIDE 41
Hardware UI State Washing Program Extra Parameters P
- w
e r W a Washing Machine Power Water Amount Temperature Spin Extra H2O Door contact Time running Gateway Loss
SLIDE 42
Hardware UI State Washing Program Extra Parameters P
- w
e r W a Washing Machine API Power Water Amount Temperature Spin Extra H2O Door contact Time running Power Water Amount Temperature Spin Extra H2O Door contact Time running
SLIDE 43
Power Water Amount Temperature Spin Extra H2O Door contact Time running My Washing Machine
Own Solution
Loss
SLIDE 44
Power Water Amount Temperature Spin Extra H2O Door contact Time running Thing Model SwitchItem NumberItem NumberItem NumberItem SwitchItem ContactItem NumberItem Items
Own solution
X Y Setup Power Plug: Consumption NumberItem Use Cases
SLIDE 45
Use case: Wash again
- n wmPower changed to OFF
timer = startTimer({ wmPower.state = ON }, now + 16h) end
- n wmDoor changed to OPEN
if timer then timer.cancel() end
SLIDE 46
Eclipse SmartHome Benefjts
> Good framework to implement IoT device lifecycle > Easy to understand > Parallel development: UI + Binding > UI Testing without devices > Ofgline, “Intranet of Things”
