Lock-Free, Wait-Free and Multi-core Programming Roger Deran boilerbay.com Fast, Efficient Concurrent Maps AirMap Lock-Free and Wait-Free Data Structures Overview The Java Maps that use Lock-Free techniques Graphical performance
Overview The Java Maps that use Lock-Free techniques Graphical performance of Map data structures Consensus number concept The Ubiquitous ‘CAS’ primitive Implementing AtomicInteger using CAS Implementing Java ConcurrentSkipListMap Volatile variables – vital but confusing Memory Barriers
so esoteric, we buy mutually free beer
For multiple threads sharing data Fast
Extreme concurrency with many cores active Extreme performance – no expensive wait queues Extremely low latency (wait-free)
Constructed from very powerful, simple primitives Algorithms difficult, so usually use canned ones Active research on these precious techniques
Can implement fast locks with wait queues
Mutexes, RW locks, Semaphores, Condition
Variables
Can implement fast Atomics
Integers, Longs, Booleans, References
Can implement multi-core data structures
HashMaps or Sets, Tree Maps or Sets, Queues, Lists,
Stacks
Lock-Free
Not fair between threads Always has a retry loop Guarantees progress of some thread but not which one Not a spin lock! Spins can almost stall the whole system
Wait-Free – beats Lock Free
Fair between threads Every thread is guaranteed to make progress in finite time
Rely on GC for unique ids, can generate much garbage More difficult in C, C++, boost::lockfree (the ‘ABA’ problem)
The Concurrent* are Lock-Free and AirMap is Mostly Lock-Free
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
HashMap TreeMap ConcurrentHashMap ConcurrentSkipListMap AirMap
put/get/remove
l l l l l
l l l
thread safe
l l l
most memory efficient
l
fastest multicore access
l
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Size of basic Key/Value entry in bytes given log Map size
Any given concurrency primitive has one How many Threads can be synchronized?
Consensus 1: Surprisingly, memory is weak
Atomic read or write to memory. Dekker’s Algorithm
Consensus 2: Another surprise – many are weak
Queues, test-and-set, swap, getAndAdd, stacks
Consensus infinity: A few vital powerful primitives
Augmented queue – like socket poll Compare And Set “CAS” type instruction Load-Link and Store-Conditional instruction pair AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Compare and Set Atomic, Infinite consensus number boolean compareAndSet( ValueType *p, ValueType expectedValue, ValueType newValue) { … } class AtomicInteger { public final boolean compareAndSet( int expect, int update) { return unsafe.compareAndSwapInt(this, valueOffset, expect, update); } … } Java implementation invokes secret native code: Pseudo-code, normally one instruction:
Compare and Set
Definition: Atomically change a given memory
location to a given new value if it has a given expected value, and return true iff the change took place.
Consensus infinity is expensive.
Memory bus is locked for all cores: slow x86, x64 instruction (with lock prefix byte for SMP):
LOCK; CMPXCHG ptr, expected, new
Can implement primitives with lower consensus
numbers like AtomicInteger.getAndIncrement()
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
from Java library source code. lock-free (has retry loop) /** * Atomically increments by one the current value. * * @return the previous value */ public final int getAndIncrement() { for (;;) { int current = get(); int next = current + 1; if (compareAndSet(current, next)) return current; } }
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Leaf node structure from Java source code
static final class Node<K,V> { final K key; volatile Object value; volatile Node<K,V> next; }
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
from Java source code comments
* Here's the sequence of events for a deletion of node n with * predecessor b and successor f, initially: * * +------+ +------+ +------+ * ... | b |------>| n |----->| f | ... * +------+ +------+ +------+ * * 1. CAS n's value field from non-null to null. * From this point on, no public operations encountering * the node consider this mapping to exist. However, other * ongoing insertions and deletions might still modify * n's next pointer. AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
from source code comments
* 2. CAS n's next pointer to point to a new marker node. * From this point on, no other nodes can be appended to n. * which avoids deletion errors in CAS-based linked lists. * * +------+ +------+ +------+ +------+ * ... | b |------>| n |----->|marker|------>| f | ... * +------+ +------+ +------+ +------+ * AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
from Java source code comments
* 3. CAS b's next pointer over both n and its marker. * From this point on, no new traversals will encounter n, * and it can eventually be GCed. * +------+ +------+ * ... | b |----------------------------------->| f | ... * +------+ +------+ * * A failure at step 1 leads to simple retry due to a lost race * with another operation. Steps 2-3 can fail because some other * thread noticed during a traversal a node with null value and * helped out by marking and/or unlinking. This helping-out * ensures that no thread can become stuck waiting for progress of * the deleting thread. The use of marker nodes slightly * complicates helping-out code because traversals must track * consistent reads of up to four nodes (b, n, marker, f), not * just (b, n, f), although the next field of a marker is * immutable, and once a next field is CAS'ed to point to a * marker, it never again changes, so this requires less care. AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Vital, little understood. We consider Java ‘volatile’ here Necessary for inter-thread visibility (also in C#)
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
class MyClass { // only one thread necessarily sees this int i; // vi can be seen by any thread volatile int vi; // Java array elements are not volatile! volatile int[] va = new int[SIZE]; // only the reference is volatile volatile ArrayList val = new ArrayList(); // synchronized loads, stores all variables public synchronized void set(int newI) { i = newI; } … }
Vital, little understood. Some architectures re-order loads/stores to memory!
‘As if’ no change to the code but slower. Ensure loads and stores reach memory for inter-
thread visibility (except for C,C++ it’s only for I/O)
Locks and synchronized blocks do too, but they are
slower and not lock-free.
Not Atomic!
myVolatile++ by two threads may lose a count. Use AtomicInteger instead.
Generally much faster than CAS, atomics, locks.
Very fast, or free. (on x86, load is free on hardware)
Consensus number 1
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Some architectures re-order loads/stores to memory!
No reordering of volatile loads/stores to memory : program order is followed
By ahead-of-time compiler (javac)
By just-in-time compiler (the JVM)
By core (all necessary implied or explicit ‘memory barriers’)
Mixed with Non-volatiles:
Non-volatile loads and stores can mix together in any way.
Non-volatile ops can ‘float’ below a volatile load (‘acquire’)
Non-volatile ops can ‘float’ above a volatile store (‘release’)
http://www.cl.cam.ac.uk/~pes20/ppc-supplemental/test7.pdf http://g.oswego.edu/dl/jmm/cookbook.html (Doug Lea - Java) https://gcc.gnu.org/onlinedocs/gcc-4.4.0/gcc/Atomic-Builtins.html
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Vital, little understood.
Broken before Java 1.5 fixed the memory model Array elements are always non-volatile Primitives or references can be volatile Defined by ‘happens-before’ binary relation.
Seems almost nobody understands it this way. AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Vital, little understood.
volatile variables likeJava System.Threading.Volatile.Read(var) System.Threading.Volatile.Write(var) Volatile variable load/store just implies volatile
read/write as above
Can be applied to array elements, unlike Java
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Vital, little understood.
C, C++ already has a volatile keyword like const (dangerous)
Forces access to occur, in program order
Intended only for memory mapped I/O!
Not for threading but may work, e.g. in MicroSoft, probably gcc
No re-ordering control of non-volatiles at all!
Illegal in Linux kernel ! Use kernel native barriers and locks.
gcc:
Full sw-only barrier: asm volatile(“” ::: “memory”);
Full sw/hw barrier: gcc 4.4.0 and above: __sync_synchronize()
Volatile load/store: asm volatile(hw_specific_instruction)
c++11:
Nice sw-only barrier: atomic_signal_fence(std:memory_order)
Nice hw/sw barrier: atomic_thread_fence(std:memory_order)
Atomic variables: std:atomic<..>
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
prevent core from swapping its loads/stores to memory
Four conceptual primitive kinds of barriers, can be combined:
load-store: default in Sparc TSO, X86, ARM, POWER load-load: default in Sparc TSO, X86, ARM, POWER store-store: default in Sparc TSO, x86 store-load: default in none. Slow
memory barriers affect all other loads or stores by the
generating core, and not just a memory location of the load
E.g. a load-store barrier prevents any earlier load from being
swapped with any later store by that core.
A volatile load causes a succeeding load-store and load-load,
i.e. ‘acquire’ barrier. Other stores can ‘float’ down.
A volatile store causes a preceding load-store and store-store,
i.e. ‘release’ barrier. (plus a ‘store-load’ in x86 OpenJDK).
AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
Increasing Processor Relaxed Memory Ordering Levels
Total Store reordering. Can switch Store-Load
Sparc: TSO ‘total store ordering’ mode
AMD: x86, x64 instruction set architecture
Intel X86, x64:
Partial ordering. Can switch Store-Store and Store-Load
Sparc PSO (obsolete)
Full reordering: Can switch everything including atomic load/store
Sparc: RMO (obsolete)
ARM v7 or later: depends on implementation architecture?
POWER
IA-64 (Intel Itanium)
MIPS: hw implementation environment dependent
Full reordering plus dependent loads reordered
DEC Alpha: AirMap is a 90% faster 50% more capacity 7x faster Iteration Multi-core ConcurrentNavigableMap from boilerbay.com
from OpenJDK orderAccess.hpp
// sparc RMO ia64 x86 // --------------------------------------------------------------------- // fence membar #LoadStore | mf lock addl 0,(sp) // #StoreStore | // #LoadLoad | // #StoreLoad // // release membar #LoadStore | st.rel [sp]=r0 movl $0,<dummy> // #StoreStore // st %g0,[] // // acquire ld [%sp],%g0 ld.acq <r>=[sp] movl (sp),<r> // membar #LoadLoad | // #LoadStore // // release_store membar #LoadStore | st.rel <store> // #StoreStore // st // // store_fence st st lock xchg // fence mf // // load_acquire ld ld.acq <load> // membar #LoadLoad | // #LoadStore
