LLC "Dialogue-M" M" ABOUT COMPANY The company - PowerPoint PPT Presentation

LLC "Dialogue-M" M" ABOUT COMPANY The company "Dialogue" was founded in 1994 and it has over 20 years successfully working n the manufacturers market of equipment of manufacturing the paper and plastic packaging.


  1. LLC "Dialogue-M" M"

  2. ABOUT COMPANY • The company "Dialogue" was founded in 1994 and it has over 20 years successfully working о n the manufacturers market of equipment of manufacturing the paper and plastic packaging. During this time the company has gained a leading position in the industry, it has earned a reputation as a reliable and competent partner. • Our experience allows us to supply the market only high-quality equipment for the production of the paper bags and sacks. During our existence we have delivered automated line for the production of paper bags to ten largest enterprises in Russia and in other countries. • We offer our customers a wide range of equipment that is considered the best in the paper bags area production. The company "Dialogue-M" is not just an equipment supplier. We offer You to become an owner of a businesses, namely: • advise and select the optimal set of equipment for the Customer • provide a model business plan of the enterprises’ organization of the package production • assist in the delivery of raw materials and necessary materials • our specialists provide installation supervision of the equipment, they teach and accompany launch of the production • provide warranty and after warranty repair. • Extensive knowledge of production processes in this field allow us to develop innovative solutions. §

  3. PRODUCTS Our wide range of equipment for the paper bags and packages production, allows us to produce these types of bags and packages: • from 2 to 6 layers with any size, and with valve open or under weight: 5 to 70 kg. • with any logo: two, four or six colors (full color printing). The application of modern technologies allows us to automate the production of paper bags, that is it reduces the production costs. Modern control systems suffers you to monitor a production process remotely. A list of our equipment for the paper bags production : - The hose line DM-25, DM - 52, DM – 100, which are classified in six versions and are equipped with a flexographic print module, we can also produce flexographic equipment with up to 1300 mm by custom- made. - Machine for laying bottom of the bag PAD-02 ; - Additional equipment for complete lines for the production of paper bags, Kraft bags: • Installation for preparation of emulsion of the adhesive material • Valve machine - production line for paper valve • Printing machine for printing on masking tape • Connecting line DMP-3 • Press facetiously - designed for packing bags on a pallet Our company develops and manufactures the equipment for the paper packaging production, we embody the old equipment, which are the machines after overhaul.

  4. Th The production of f steel bil illets pip ipes • DM - 52 - 65 capacity bags / min, printing 2 colors - $ 77000, printing 4 - $ 85000. • DM-100 capacity of 120 bags per minute • DM - 25 a capacity of 50 bags / min According to Your order lines can be made to any specifications 1. Spinning machine part of pipe. 2. Control unit for the web tension. 3. Node shape. 4. The node of the longitudinal gluing of the pipe. 5. The node application perforation. 6. Retractor press. 7. Guillotine. 8. Transporter. 9. Shield management. 10. The cross-node sizing. 11. The folder. 12. The print module. 13. Unit for preparation and supply of adhesive material. 14. Node automatic car wash. 15. The longitudinal node of a core drill download 16. Counting packages station 17. The module perforations over the entire area of the bag. 18 The crane beam. 19. Module automatic matching of the transverse sizing.

  5. The production of f steel bil illets pip ipes • Line DM-52 is designed for the production of pipe billets from 2 to 6 layers with print one to six colors by a printing method. • The Scheme of control and synchronization of actuators provide precise operation of the entire line. • You will be able to make a tube (bag) under suitable weight on the hose line DM-52 : 2.5 to 70 kg and of different types: • longitudinal gluing each layer; • with print; • with perforation; • fan-fold; • with the longitudinal cutting; • synchronized with transverse gluing each layer; • with polyethylene liner; TECHNICAL SPECIFICATIONS STANDARD: 1. The number of layers of manufactured bags from 2 to 6. 2. Bags can be manufactured from paper, from 300 to 1060 mm. 3. Used glue: starch-based, or any other, provides the necessary strength of the bag. 4. Mains voltage lines: 380 +10V. Frequency: 50Hz. 5. Maximum power consumed: not more than 12.5 kW. 6. Equipment performance: from 50 to 100 meters per minute. 7. Dimensions line printed module: Fig.1. 14500х2400х2200 mm; 8. Staff: 2 people.

  6. Production li line and glu lue the bottom of f the PAD-2 Semi-automatic production line and the glue bottom are intended for the production of multilayer paper bags for storage and transport of bulk products. Bags are made from a paper sack. Gluing the bottom and valve paper bags are made with the using of German glue application metering system that allows you not to only apply glue on the required area of the bonding pouch, but also save the glue. SPECIFICATIONS: The LINE PAD-02: 1. The number of layers of bags manufactured: from 2 to 4; 1. The boot Assembly 2. Used glue: starch-based, provides the necessary strength to the bag; 2. The transferring conveyor 3. Mains voltage lines: 380 +10V, frequency: 50Hz; 3. The site of formation of the bottom 4. Installed power: 2.2 kW; 4. Station glue application – 3 units 5. Equipment performance: 20 bags/min; 5. The glue tank 6. Bottom width of paper bag: 9, 11, 13 cm; 6. A system of photocells 7 . The dimensions of the line: 6500х500х1400 mm; 7. Compressor station 8. Weight: 420 kg; 9. Staff: 2 people. 8. Crimping press 9. Remote control $ 23000

  7. In Installation for preparation of f emulsion of f th the adhesive material Installation of preparation adhesive material emulsion is intended for mixing cold adhesive and it obtain a uniform adhesive mass applied later on bonding paper bags, that are made of sack paper. HE LIST OF CONNECTIONS INCLUDED IN THE SPECIFICATIONS: INSTALLATION 1. Rotation speed: 1000 rpm./2 min. 1. Frame. 2. The voltage supply network line: 2. Tank material stainless steel, capacity 120 380V ± 10V, 50 Hz. sheet 3. Installed power: 6,0 kW. 3. Remote control. 4. Dimensions: 1400х700х1400 mm. 4. Stirrer. 5. Staff: 1 person. printing 4 colors 5. The motor-reducer. 6. Weight: 150 kg 6. System return circulation. 7. The processing unit components high pressure. 8. The drain valve. To prepare the adhesive material requires filtered running water. $ 3500 Machine for manufacturing valve bags The Valve machine is designed for blanks manufacturing of valve, which are used for the closed bags production. SPECIFICATIONS: THE LINE INCLUDES: 1. The voltage supply network line: 380V ± 10V 1. Station for unwinding. frequency: 50 Hz. printing 4 colors 2. The node of longitudinal gluing. 2. Power of motor: 0.37 kW. 3. The driver tube. 3. Weight: 250 kg. 4. Host of pullback. 4. Capacity: 110 PCs/min. 5. Guillotine. 5. Dimensions: 3450х750х1200 mm. 6. Brake. 6. Staff: 1 person. 7. Remote control.

  8. PRINTING MACHINE Flexographic printing machine is for printing on masking tape (logo, picture, etc.). The printing is made from the role to the role. The sack paper in roles and flexographic inks water-based are used for printing. SPECIFICATIONS: Package contents: Print format: 70 to 185 mm. 1. The roll-out of node Mains voltage lines: 380 +10V,50Hz. 2. Printing unit – 2/4 units Installed power: 2.0 kW. 3. The node of the tension of the canvas Equipment performance: 65 meters/min. 4. The winding station Weight: 220/320 kg 5. Remote control The dimensions of the line: 2200х800х750 /1200 mm; Staff: 1 person. Cuttin ing machin ine Slitting machine (slitter coiler) is the machine tool, that is designed for the dissolution of the paper reel in narrow strips. Specification The format, mm: 90 The diameter of the resulting roll, mm: 800 The maximum reel diameter, mm: 900 Speed, m/min: 40 Power, kW: 1,5 Weight, kg: 85

  9. Press facetiously Press baling PGP-10 is designed for packing paper bags in bales. THE LAYOUT DIAGRAM OF THE UNITS TECHNICAL SPECIFICATIONS PGP-10: ARE INCLUDED IN THE PRESS GWP-10 1. The pressing force is not more than: 40 kN 1. The cylinder. 2. The voltage supply network line: 380V ± 10V 2. The oil line. 3. Frequency: 50 Hz. 3. The hydro station. 3. Power of motor: 1.5 kW, voltage: 380 (220) V. 4. Remote control. 4. Bale dimensions: 1200x1000 mm 5. The stock power. 5. The dimensions of the PGP- 10: 1800х2200х3500 mm 6. Guide. 6. Weight: 220 kg 7. The movable platform. 7. The wait staff GWPs-10: 1 person 8. The fixed platform. A lin line of f sti titching of f paper bags Automatic line DMP-4 is designed for the paper bags piercing, and on this line we can firmware the polypropylene bags. The line works on energy-saving technologies, providing product quality. 1. A control Cabinet. TECHNICAL SPECIFICATIONS OF DMP-4: 2. Node of the feeder. 1. The number of layers being sewn bag: from 2 to 7. 3. Transporter. 2. The voltage supply network line: 380V ± 10V. 4. Unwind the crepe tape. 3. Frequency: 50Hz. 5. Piercing site. 6. The node cuts. 4. Power consumption: 2.2 kW. 7. The extractor. 5. Equipment performance: 37 bags per minute. 8. Desk drive 6. The dimensions of the line: 4800х2400х1000 mm; 9. Compressor.. 7. The wait staff line: 1. 10. Variable speed drive station. 11. The unwind of the piercing thread.
