Libabigail & ABI compatibility

Taming the runtime linking problem

Ben Woodard Consulting Engineer Dodji Seketeli Tools Engineer Aug 2016

INSERT DESIGNATOR, IF NEEDED

Problems due to ABI Compatibility

2

There are several problems cause by ABI compatibility problems either real or feared.

• Linking objects compiled by different compilers not recommended

○ Unforeseen problem at runtime ○ Need to compile libs for all compilers

• Library Version problems

○ Match library version with application ○ Match compiler

INSERT DESIGNATOR, IF NEEDED

Lots of compilers

3

We use a lot of compilers...

• GCC
• Intel
• PGI
• XL
• LLVM

INSERT DESIGNATOR, IF NEEDED

Lots of compilers

4

We use a lot of compilers...and a lot of different version of the compilers.

• GCC

○ 4.4.7, 4.7.2, 4.8.2, 4.9.2, 5.3, 6.1.0

• Intel

○ 9.1, 1[0-4].[01], 1[56]

• PGI

○ 7.[01], [89].0, 10.[2,9], 11.{1,10}, 12.[18], 13.{1,2,6,10}, 14.{3,7,10}, 15.

{1,5,7,10}, 16.[13]

• XL

○ ???

• LLVM

○ 3.[4-8]

INSERT DESIGNATOR, IF NEEDED

Runtime Linking Problems

5

Linking objects compiled by different compilers can sometimes cause unexplained problems. Why?

• ABI is supposed to make this work properly.

○ This does work to some extent with system libraries ○ Other libraries may hit corner cases especially C++

• We are talking about ABI not API

○ API directly affects this.

INSERT DESIGNATOR, IF NEEDED

Red Hat’s Problem

6

We make API and ABI guarantees to customers

• API and ABI should not change within a major release of RHEL
• There are some specific exceptions
• Manual verification very time consuming
• Occasionally mistakes have been made.
• Fedora doesn’t want to rebuild everything all the time
• Future projects in the devops world

INSERT DESIGNATOR, IF NEEDED

What is ABI?

7

• ABI is all the things that can affect inter-object linking
• It is not just what is written in the standard for Architecture and

language

• A first approximation is ELF and DWARF
• ??

INSERT DESIGNATOR, IF NEEDED

Libabigail

8

Libabigail reads ELF, DWARF, & XML to build an IR of the ABI

• ELF, DWARF -> IR of ABI -> can be saved as XML

○ Other formats theoretically possible e.g. Mach-O or Windows ○ Not just DWARF to DWARF comparison ■ Allows comparison between compilers ■

Saved ABI XML represents all ABI artifacts

○ Compare saved ABI to ELF, DWARF for new object ■ Used to maintain ABI stability ■ No need to keep old objects around.

INSERT DESIGNATOR, IF NEEDED

Higher level Libabigail utilities

9

Libabigail is a C++ library and is easily to write utilities using it

• abidw - dump the ABI to stdout

○ Used to save copies ABI ○ “abidw --abidiff elfobject.so” compares an object to itself. Used to test

libabigail

• abidiff - compare the ABI of one ELF or ABI XML file to another.

○ Compare two objects or saved ABI XML files. ○ “abidiff elffile1.so elffile2.so ○ “abidiff saved.abixml elffile.so

INSERT DESIGNATOR, IF NEEDED

Higher level Libabigail tools (cont)

10

Libabigail is a C++ library and is easily to write utilities using it

• abicompat - does a changed ABI matter to the program

○ If the only changed functions and variables are not used the program,

then it isn’t a problem.

○ Does not detect functional changes

• abipkgdiff - compares analogous objects from related packages or

directories

INSERT DESIGNATOR, IF NEEDED

Goals:

11

• Eliminate the need for versions of library for each and every

compiler version.

• e.g. GCC 4.4.7 4.7 4.9 5.2 …
• spack can assume rather rebuilding or discard duplicates
• Reduce the need for versions of library compiled with each

compiler

• e.g. GCC vs. Intel vs. Clang…
• This is still a ways off
• Detect library API and ABI changes
• Educate developers on library versioning
• Let runtime linker do most of the work

INSERT DESIGNATOR, IF NEEDED

Ultimate Goals:

12

• Improve the quality of ELF, DWARF generated by all compilers
• Identify and resolve areas where platform ABI is not specified or

incompletely specified.

• Fulfill the promise of ABI by providing safe inter-compiler cross

linking

• Even for C++
• Maybe even for Fortran

INSERT DESIGNATOR, IF NEEDED

Current Status

13

This past year was foundational

• Stabilized libabigail fixing many crashes and performance

pathologies.

• Now properly capturing and recording ABI artifacts.
• In the process of learning how to deal with compiler idioms
• type synonyms
• void *
• Working through issues with SPACK the build system
• Finding, reporting and/or resolving compiler bugs
• ELF bugs - improperly exported functions (PGI)
• Compiler specific internal functions in ELF (Intel)
• Type qualifiers omitted e.g. restrict (Intel)
• Double … aka DW_TAG_unspecified_parameters (GCC)
• _Bool vs. unsigned char (Intel)

INSERT DESIGNATOR, IF NEEDED

Upcoming work

14

Much is left to do

• Continue to work with SPACK developers to broaden range of

applications tested

• Currently mostly C
• C++ is the next big challenge
• Templates
• Very precise ABI requirements
• Fortran
• Not sure we’ve captured all ABI artifacts yet
• Performance trumps all ABI

THANK YOU
