Let’s Unify Theories of Programming

He Jifeng Software Engineering Institute East China Normal University Shanghai China

+ +

2 +

✬ ✫ ✩ ✪

Syllabus

• A simple theory
• Relational programming
• Link with wp-calculus
• Design calculus
• Implementation
• Design capturing
• Linking theories and Galois connection
• Algebra of programs
• An operational model
• Probabilistic programming
• Link semantic models

+ +

3 +

✬ ✫ ✩ ✪

Theories of Programming A theory of programming relates each program to the specification of what it is intended to achieve. A unifying theory is applicable to a general paradigm of computing, supporting the classification of many programming languages as correct instances of the paradigm.

+ +

4 +

✬ ✫ ✩ ✪

A Diversity of Presentation

• 1. A denotational method denotes each notation as some

value in a mathematical domain. It is a link between specifications and programs.

• 2. An algebraic method says if two different written

programs happen to mean the same thing. It is widely used for program optimisation and verification.

• 3. An operational presentation describes how a program

can be executed by an abstract machine. It supports compiler design, complexity analysis and program testing.

+ +

5 +

✬ ✫ ✩ ✪

Unit 1: A Simple Theory

+ +

6 +

✬ ✫ ✩ ✪

Ingredients (1) Alphabet: concepts related to the real world. (2) Signature : primitives and combinators (3) Laws : a set of equations that are provable.

+ +

7 +

✬ ✫ ✩ ✪

Alphabet Free variables are used to stand for possible measurement taken from the experiment.

• 1. initial state {x, y, . . . , z}.
• 2. final state {x′, y′, . . . , z′}.
• 3. status of programs {ok, st}.
• 5. interaction {tr}.
• 6. synchronisation {ref}.
• 7. control {l, start, finish}

+ +

8 +

✬ ✫ ✩ ✪

Observation and Specification An observation consists of a set of equations ascribing particular constant values to each variable x = 4 ∧ . . . ∧ z = false A specification gives a set of allowable observations x′ = x + 1 ∧ y′ = y ∧ z′ = z can be used to describe the effect of execution of assignment x := x + 1, where x, y and z are program variables used as global ones in the program.

+ +

9 +

✬ ✫ ✩ ✪

Conjunction In general, a specification is written as a conjunction of a set of predicates S1 ∧ S2 ∧ . . . For example, the operation swap(x, y) can be specified by the predicate (x′ = y) ∧ (y′ = x) The sorting program can be described by bag(A′) = bag(A) ∧ ¬∃i, j ∈ domain(A) • i < j ∧ A′[i] > A′[j]

+ +

10 +

✬ ✫ ✩ ✪

Laws Conjunction is idempotent, symmetric and associative. (∧ − 1) P ∧ P = P (∧ − 2) P ∧ Q = Q ∧ P (∧ − 3) P ∧ (Q ∧ R) = (P ∧ Q) ∧ R ∧ has true as its unit, false as its zero (∧ − 4) P ∧ true = P (∧ − 5) P ∧ false = false

+ +

11 +

✬ ✫ ✩ ✪

Water Tank t: the time since the the start of the apparatus vt: the volume of the liquid in the tank at time t int, outt: the total amount of liquid poured and drained up to time t at, bt: the setting of the input valve and output valve at time t Water tank is governed by the following laws: (1) int + v0 = outt + vt (2) 0 ≤ at ≤ amax, 0 ≤ bt ≤ bmax (3) ˙ in = k × a, ˙

• ut = k × b + δ × v

+ +

12 +

✬ ✫ ✩ ✪

Correctness Let P and S have the same alphabet {x, . . . , z}. P satisfies S if ∀x, . . . , z • (P(x, . . . , z) ⇒ S(x, . . . , z)) We rewrite it as [P ⇒ S] (or P ⊒ S) For example (x′ = x + 1 ∧ y′ = y + 2) ⊒ (x′ ≥ x ∧ y′ ≥ y) Theorem ⊒ is a pre-order. (1) P ⊒ P (2) If P ⊒ Q and Q ⊒ R, then P ⊒ R

+ +

13 +

✬ ✫ ✩ ✪

Refinement supports correct design

• Stepwise Refinement

((D ⊒ S) ∧ (P ⊒ D)) implies (P ⊒ S)

• Piecewise Refinement

((P ⊒ S) ∧ (Q ⊒ S)) implies ((P ∨ Q) ⊒ S)

• Devide-and-Conquer

(((S1 ∧ S2) ⊒ S) ∧ (P1 ⊒ S1) ∧ (P2 ⊒ S2)) implies (P1 ∧ P2 ⊒ S)

• Component Replacement

(P ⊒ S) implies (F(P) ⊒ F(S))

+ +

14 +

✬ ✫ ✩ ✪

Reusable Components Let S(x, y) be a specification, and Q(y) an existing

• component. We wish to deliver a product of form

P(x) ∧ Q(y), and use R/Q to denote the weakest product P(x). Theorem (P ∧ Q) ⊒ R iff P ⊒ R/Q (/ − 1) (R1 ∧ R2)/Q = (R1/Q) ∧ (R2/Q) (/ − 2) R/(Q1 ∧ Q2) = (R/Q1)/Q2 (/ − 3) true/Q = true (/ − 4) R/false = true

+ +

15 +

✬ ✫ ✩ ✪

Linking Models Let S(a) be a specification, and P(c) a product. P is an implementation of S with respect to an interpretation A(c, a) if (∃c • P(c) ∧ A(c, a)) ⊒ S(a) We denote the above fact by P ⊒A S Theorem If P ⊒A1 Q and Q ⊒A2 S then P ⊒A1◦A2 S, where A1 ◦ A2 =d

f ∃b • A1(c, b) ∧ A2(b, a)

+ +

16 +

✬ ✫ ✩ ✪

Unit 2 : A Theory of Relational Programming

+ +

17 +

✬ ✫ ✩ ✪

Relations A relation is a triple (IN, OUT, P) where

• IN and OUT are disjoint sets of names, and
• P is a predicate of free variables of the set IN ∪ OUT

We define inαP =d

f IN, outαP = OUT.

+ +

18 +

✬ ✫ ✩ ✪

Signature of Relational Programming Primitives

• 1. assignment: x := e and empty: skip
• 2. top: ⊤ and bottom: ⊥

Combinators

• 1. conditional: P ⊳ b ⊲ Q
• 2. composition: P; Q
• 3. nondeterminism: P ⊓ Q
• 4. recursion: µX • F(X)

+ +

19 +

✬ ✫ ✩ ✪

Testable Conditions Any non-trivial program requires a facility to select between alternative actions in accordance with the truth

• r falsity of some testable condition b.

The restriction that b contains no dashed variables ensures that it can be tested before starting either of the action.

+ +

20 +

✬ ✫ ✩ ✪

Conditional If P and Q are predicates describing two programs with the same alphabet, then the conditional P ⊳ b ⊲ Q describes a program which behaves like P if b is true initially, or like Q otherwise. α(P ⊳ b ⊲ Q) =d

f

αP P ⊳ b ⊲ Q =d

f

(b ∧ P) ∨ (¬b ∧ Q)

+ +

21 +

✬ ✫ ✩ ✪

Laws of Conditional Conditional choice is idempotent, skew-symmetric and associative. (cond − 1) P ⊳ b ⊲ P = P (cond − 2) P ⊳ b ⊲ Q = Q ⊳ ¬b ⊲ P (cond − 3) (P ⊳ b ⊲ Q) ⊳ c ⊲ R = P ⊳ b ∧ c ⊲ (Q ⊳ c ⊲ R) Conditional choice distributes over conditional, and has ⊳true⊲ as its unit. (cond − 4) P ⊳ b ⊲ (Q ⊳ c ⊲ R) = (P ⊳ b ⊲ Q) ⊳ c ⊲ (P ⊳ b ⊲ R) (cond − 5) P ⊳ true ⊲ Q = P

+ +

22 +

✬ ✫ ✩ ✪

Additional Law (cond − 6) P ⊳ b ⊲ (Q ⊳ b ⊲ R) = P ⊳ b ⊲ R Proof LHS {(cond − 2)} = (Q ⊳ b ⊲ R) ⊳ ¬b ⊲ P {(cond − 3)} = Q ⊳ false ⊲ (R ⊳ ¬b ⊲ P) {(cond − 2, 5)} = RHS

+ +

23 +

✬ ✫ ✩ ✪

Additional Law (cond − 7) P ⊳ b ⊲ (P ⊳ c ⊲ Q) = P ⊳ b ∨ c ⊲ Q Proof LHS {(cond − 2)} = (Q ⊳ ¬c ⊲ P) ⊳ ¬b ⊲ P {(cond − 3, 1)} = Q ⊳ ¬c ∧ ¬b ⊲ P {(cond − 2)} = RHS

+ +

24 +

✬ ✫ ✩ ✪

Composition The most characteristic combinator of a sequential language is sequential composition, often denoted by

• demicolon. If P and Q are predicates describing two

programns, their composition P; Q describes a program which may be executed by first executing P, and when P terminates then Q is started. The final state of P is passed on as the initial state of Q but this is only an intermediate state of (P; Q), and cannot be directly observed.

+ +

25 +

✬ ✫ ✩ ✪

Composition Let outαP = inαQ (say {v}). Define P(v′); Q(v) =d

f

∃m • (P(m) ∧ Q(m)) inα(P; Q) =d

f

inαP

• utα(P; Q) =d

f

• utαQ

The bound variables m record the intermediate values of the program variables v, and so represent the intermediate state as control passes from P to Q.

+ +

26 +

✬ ✫ ✩ ✪

Laws of Composition Composition is associative. (; −1) P; (Q; R) = (P; Q); R Composition distributes leftward over conditional. (; −2) (P ⊳ b ⊲ Q); R = (P; R) ⊳ b ⊲ (Q; R)

+ +

27 +

✬ ✫ ✩ ✪

Assignment The assignment is the basic action in all procedural programming languages. Every assignment should technically be marked by its alphabet A, which is needed to define an important part of its meaning – that all the variables not mentioned on the left hand side remain unchanged. Let A = {x, . . . , z}, and FreeV ar(e) ⊆ A. x :=A e =d

f

(x′ = e ∧ . . . ∧ z′ = z) α(x :=A e) =d

f

A + {v′ | v ∈ A} Define skipA =d

f (x′ = x ∧ . . . ∧ z′ = z)

+ +

28 +

✬ ✫ ✩ ✪

Laws of Assignment (asgn − 1) x := e = x, y := e, y The order of the listing is immaterial. (asgn − 2) (x, y, z := e, f, g) = (y, x, z := f, e, g) Evaluation of an expression or a condition uses the value most recently assigned to its variables. (asgn − 3) (x := e ; x := f(x)) = x := f(e) (asgn − 4) x := e ; (P ⊳ b(x) ⊲ Q) = (x := e; P) ⊳ b(e) ⊲ (x := e; Q) skip is the unit of composition. (asgn − 5) P; skip = P = skip; P

+ +

29 +

✬ ✫ ✩ ✪

Non-determinism If P and Q are predicates describing the behaviour of programs with the same alphabet. The notation P ⊓ Q stands for a program which is executed either P or Q, but with no indication which one will be chosen. P ⊓ Q =d

f

P ∨ Q α(P ⊓ Q) =d

f

αP Nondeterministic choice may be easily implemented by arbitrary selection of either of the operands, and the selection may be made at any time, either before or after the program is compiled or even after it starts execution.

+ +

30 +

✬ ✫ ✩ ✪

Laws of ⊓ ⊓ is symmetric, associative and idempotent. (⊓ − 1) P ⊓ Q = Q ⊓ P (⊓ − 2) P ⊓ (Q ⊓ R) = (P ⊓ Q) ⊓ R (⊓ − 3) P ⊓ P = P Theorem (Link between ⊒ and ⊓) (P ⊒ Q) iff (P ⊓ Q) = Q

+ +

31 +

✬ ✫ ✩ ✪

Additional Law ⊓ distributes through itself. (⊓ − 4) P ⊓ (Q ⊓ R) = (P ⊓ Q) ⊓ (P ⊓ R) Proof RHS {(⊓ − 1, 2)} = (P ⊓ P) ⊓ (Q ⊓ R) {(⊓ − 3)} = LHS

+ +

32 +

✬ ✫ ✩ ✪

Distributivity All programming combinators defined so far distribute through ⊓. (⊓ − 5) P ⊳ b ⊲ (Q ⊓ R) = (P ⊳ b ⊲ Q) ⊓ (P ⊳ b ⊲ R) (⊓ − 6) (P ⊓ Q); R = (P; R) ⊓ (Q; R) (⊓ − 7) P; (Q ⊓ R) = (P; Q) ⊓ (P; R) (⊓ − 8) P ⊓ (Q ⊳ b ⊲ R) = (P ⊓ Q) ⊳ b ⊲ (P ⊓ R) Corollary All combinators are monotonic in all arguments.

+ +

33 +

✬ ✫ ✩ ✪

Lower And Upper Bounds Let S be a set of relations with the same alphabet. ⊓S denotes the greatest lower bound of relations of S, and is defined by (bound-1) (⊓S) ⊒ R iff P ⊒ R for all P ∈ S The least upper bound of relations of S is defined by (bound-2) (⊔S) ⊑ R iff P ⊑ R for all P ∈ S

+ +

34 +

✬ ✫ ✩ ✪

Top and Bottom The top element of the lattice is ⊤ =d

f

⊓ {} = false The bottom one is ⊥ =d

f

⊔ {} = true

+ +

35 +

✬ ✫ ✩ ✪

Distributivity and Disjunctivity (bound-3) (⊔S) ⊓ Q = ⊔ {X ⊓ Q | X ∈ S} (bound-4) (⊓S) ⊔ Q = ⊓ {X ⊔ Q | X ∈ S} Composition is universally disjunctive (bound-5) (⊓S) ; Q = ⊓ {X; Q | X ∈ S} (bound-6) P; (⊓S) = ⊓ {P; X | X ∈ S}

+ +

36 +

✬ ✫ ✩ ✪

Tarski’s Fixed Point Theorem If F is a monotonic mapping on a complete lattice (C, ⊒), then the solutions of equation X = F(X) form a complete lattice, where µF =d

f

⊓ {P | P ⊒ F(P)} is the weakest solution, and νF =d

f

⊔ {P | P ⊑ F(P)} is the strongest solution. In particular µX = true = ⊥, νX = false = ⊤

+ +

37 +

✬ ✫ ✩ ✪

Laws of Fixed Points (µ − 1) (P ⊒ F(P)) iff P ⊒ µF (µ − 2) F(µF) = µF (ν − 1) (P ⊑ F(P)) iff P ⊑ νF (ν − 4) F(νF) = νF

+ +

38 +

✬ ✫ ✩ ✪

Proof of µ − 2 ∀Y • (Y ⊒ F(Y )) ⇒ (Y ⊒ µF) implies ∀Y • (Y ⊒ F(Y )) ⇒ (F(Y ) ⊒ F(µF)) implies ∀Y • (Y ⊒ F(Y )) ⇒ (Y ⊒ F(µF)) implies ⊓{Y | Y ⊒ F(Y )} ⊒ F(µF) equiv µF ⊒ F(µF) implies (µF ⊒ F(µF)) ∧ (F(µF) ⊒ F2(µF)) implies (µF ⊒ F(µF)) ∧ (F(µF) ⊒ µF) equiv µF = F(µF)

+ +

39 +

✬ ✫ ✩ ✪

Unit 3: Link with wp-Calculus

+ +

40 +

✬ ✫ ✩ ✪

Precondition and Postcondition A condition p has been defined as a predicate not containing dashed variables. It describes the values of global variables of a program Q before its execution

• starts. Such a condition is therefore called a precondition
• f the program.

If r is a condition, Let r′ be the result of placing a dash

• n all its variables. As a result, r′ describes the values of

the variables of a program Q when it terminates. Such a condition is therefore called a postcondition of the program.

+ +

41 +

✬ ✫ ✩ ✪

Hoare Triple The overall specification of the program can often be formalised as a simple implication p = ⇒ r′ Define p{Q}r =d

f Q ⊒ (p =

⇒ r′)

+ +

42 +

✬ ✫ ✩ ✪

A Model for Hoare Logic (1) If p{Q}r and p{Q}s, then p{Q}(r ∧ s) (2) If p{Q}r and q{Q}r, then {(p ∨ q){Q}r (3) If p{Q}r then (p ∧ q){Q}(r ∨ s) (4) r(e){x := e}r(x) (5) If (p ∧ b){Q1}r and (p ∧ ¬b){Q2}r, then p{Q1 ⊳ b ⊲ Q2}r (6) If p{Q1}s and s{Q2}r, then p{Q1; Q2}r (7) If If p{Q1}r and p{Q2}r then p{Q1 ⊓ Q2}r (8) If (b ∧ c){Q}c then c{νX • Q; X ⊳ b ⊲ skip}(¬b ∧ c)

+ +

43 +

✬ ✫ ✩ ✪

Proof of (8) Let Y =d

f (c =

⇒ ¬b′ ∧ c′). By (ν − 1) it is sufficient to prove (Q; Y ) ⊳ b ⊲ skip = ⇒ Y Assume the antecedents (Q; Y ) ⊳ b ⊲ skip) ∧ c = (b ∧ c ∧ Q); Y ∨ (¬b ∧ c ∧ skip) {(6)} = ⇒ ¬b′ ∧ c′

+ +

44 +

✬ ✫ ✩ ✪

Condition vs Annotation Conditions can play a vital role in explaining the meaning of a program if they are included at appropriate points as an integral part of the program documentation. Such a condition is asserted or expected to be true at the point at which it is written. It is known as a Floyd assertion; formally it is defined to have no effect if it is true, but to cause failure if it is false.

+ +

45 +

✬ ✫ ✩ ✪

Assertion And Assumption c⊥ =d

f

skip ⊳ c ⊲ ⊥ (assertion) c⊤ =d

f

skip ⊳ c ⊲ ⊤ (assumption) Theorem (1) b⊥; c⊥ = (b ∧ c)⊥ (2) b⊥ ⊓ c⊥ = (b ∧ c)⊥ (3) c⊥ ⊳ b ⊲ d⊥ = (c ⊳ b ⊲ d)⊥ (4) b⊥; b⊤ = b⊥

+ +

46 +

✬ ✫ ✩ ✪

Correctness Definition of correctness can be rewritten in a number of different way [Q = ⇒ (p = ⇒ r′)] = [p = ⇒ ((Q = ⇒ r′] = [p = ⇒ (∀v′ • Q = ⇒ r′)] = [p = ⇒ ¬∃v′(Q ∧ ¬r′)] = [p = ⇒ ¬(Q; ¬r)] This last reformulation gives an answer to the following question: What is the weakest precodition under which execution of Q is guaranteed to achieve the condition r′?

+ +

47 +

✬ ✫ ✩ ✪

Weakest Precondition Q wp r =d

f ¬(Q; ¬r)

(wp − 1) (x := e) wp r(x) = r(e) (wp − 2) (P; Q) wp r = P wp (Q wp r) (wp − 3) (P ⊳ b ⊲ Q) wp r = (P wp r) ⊳ b ⊲ (Q wp r) (wp − 4) (P ⊓ Q) wp r = (P wp r) ∧ (Q wp r)

+ +

48 +

✬ ✫ ✩ ✪

Healthiness Conditions Theorem (1) If [r = ⇒ s] then [Q wp r = ⇒ Q wp s] (2) If [Q = ⇒ S], then [S wp r = ⇒ Q wp r] (3) Q wp (r ∧ s) = Q wp r ∧ Q wp s (4) Q wp false = false provided that Q; true = true

+ +

49 +

✬ ✫ ✩ ✪

Right Inverse of Composition Define S/Q =d

f Q wp S

Theorem (P; Q) ⊒ S iff P ⊒ S/Q Theorem (1) S/(Q1; Q2) = (S/Q2)/Q1 (2) S/(Q1 ⊳ b ⊲ Q2) = (S/Q1) ⊳ b ⊲ (S/Q2) (3) S/(Q1 ⊓ Q2) = (S/Q1) ⊔ (S/Q2) (4) (S1 ∧ S2)/Q = (S1/Q) ⊔ (S2/Q)

+ +

50 +

✬ ✫ ✩ ✪

Left Inverse of Composition Let P and S are predicates describing two programs. The notation P\S denotes the weakest postspecification

• f P with respect to S, and is defined by

(P; Q) ⊒ S iff Q ⊒ P\S Theorem (P\S)/Q = P\(S/Q)

+ +

51 +

✬ ✫ ✩ ✪

Unit 4: Design Calculus

+ +

52 +

✬ ✫ ✩ ✪

Incomplete Observation Consider the program ⊥ ; (x, y, z := 1, 2, 3) In any normal implementation, it would fail to terminate, and so be equal to ⊥. Unfortunately, our theory gives ⊥; (x′ = 1 ∧ y′ = 2 ∧ z′ = 3) = (x′ = 1 ∧ y′ = 2 ∧ z′ = 3) This is the same as if the prior non-terminating program had been omitted.

+ +

53 +

✬ ✫ ✩ ✪

Required Laws What we need are the following two laws ⊥; P = ⊥ (left zero law) and P; ⊥ = ⊥ (right zero law)

+ +

54 +

✬ ✫ ✩ ✪

Initiation and Termination We add two logical variables into the alphabet

• k records the observation that the program has been

started.

• k′ records the observation that the program has

terminated. Remark:

• k and ok′ are not global variables held in the store of

any program; and it is assumed that they will never be mentioned in any expression or assignment of the program text.

+ +

55 +

✬ ✫ ✩ ✪

Design A design D is a relation which can be expressed by (ok ∧ P) ⇒ (ok′ ∧ Q) We write D = (P ⊢ Q), where predicates P and Q contain no ok or ok′, and (1) P is an assumption which the designer can rely on when D is initiated. (2) Q is the commitment which must be true when D terminates. ⊥ can be rewritten as ⊥ = true = (false ⊢ true)

+ +

56 +

✬ ✫ ✩ ✪

Refinement Theorem [(P1 ⊢ Q1) ⇒ (P2 ⊢ Q2)] iff [P2 ⇒ P1] and [(P2 ∧ Q1) ⇒ Q2]

+ +

57 +

✬ ✫ ✩ ✪

Proof LHS ≡ [D1[true, false/ok, ok′] ⇒ D2[true, false/ok, ok′]] ∧ [D1[true, true/ok, ok′] ⇒ D2[true, true/ok, ok′]] ∧ [D1[false/ok] ⇒ D2[false/ok]] ≡ [¬P1 ⇒ ¬P2] ∧ [(P1 ⇒ Q1) ⇒ (P2 ⇒ Q2)] ≡ [P2 ⇒ P1] ∧ [(P1 ⇒ Q1) ∧ P2 ⇒ Q2] ≡ RHS

+ +

58 +

✬ ✫ ✩ ✪

Equivalence (D1 ≡ D2) =d

f (D1 ⊒ D2) and (D2 ⊒ D1)

Theorem (1) (P ⊢ Q) ≡ (P ⊢ (P ∧ Q)) (2) (P ⊢ Q) ≡ (P ⊢ (P ⇒ Q)) (3) (P ⊢ Q) ≡ (P ⊢ R) iff [(P ∧ Q) ⇒ R] and [R ⇒ (P ⇒ Q)] (4) (false ⊢ false) ≡ (false ⊢ true)

+ +

59 +

✬ ✫ ✩ ✪

Nondeteminism Theorem (P1 ⊢ Q1) ⊓ (P2 ⊢ Q2) = (P1 ∧ P2) ⊢ (Q1 ∨ Q2) Proof LHS = (P1 ⊢ Q1) ∨ (P2 ⊢ Q2) = ¬ok ∨ ¬P1 ∨ (ok′ ∧ Q1) ∨ ¬ok ∨ ¬P2 ∨ (ok′ ∧ Q2) = ¬ok ∨ ¬(P1 ∧ P2) ∨ ok′ ∧ (Q2 ∨ Q2) = RHS

+ +

60 +

✬ ✫ ✩ ✪

Conditional and Composition Theorem (P1 ⊢ Q1) ⊳ b ⊲ (P2 ⊢ Q2) = (P1 ⊳ b ⊲ P2) ⊢ (Q1 ⊳ b ⊲ Q2) Theorem (P1 ⊢ Q1); (P2 ⊢ Q2) = (¬(¬P1; true) ∧ ¬(Q1; ¬P2)) ⊢ (Q1; Q2)

+ +

61 +

✬ ✫ ✩ ✪

Proof Proof LHS = D1[false/ok′]; D2[false/ok] ∨ D1[true/ok′]; D2[true/ok] = (¬ok ∨ ¬P1); true ∨ (¬ok ∨ ¬P1 ∨ Q1); D2[true/ok] = ¬ok ∨ (¬P1); true ∨ Q1; (¬P2 ∨ ok′ ∧ Q2) = RHS

+ +

62 +

✬ ✫ ✩ ✪

Left Zero Law ⊥; (P ⊢ Q) = ⊥ Proof ⊥; (P ⊢ Q) = (false ⊢ false); (P ⊢ Q) = ¬(true; true) ∧ ¬(false; ¬P1) ⊢ (false; Q2) = false ⊢ false = ⊥

+ +

63 +

✬ ✫ ✩ ✪

Left Unit Law skip; D = D where skip =d

f true ⊢ (x′ = x ∧ . . . ∧ z′ = z)

Proof skip; (P ⊢ Q) = (¬((¬true); true) ∧ ¬((x′ = x ∧ . . . ∧ z′ = z); ¬P) ⊢ (x′ = x ∧ . . . ∧ z′ = z); Q = P ⊢ Q

+ +

64 +

✬ ✫ ✩ ✪

Complete Lattice of Designs Theorem (1) ⊓i(Pi ⊢ Qi) = (∧i Pi) ⊢ (∨iQi) (2) ⊔i(Pi ⊢ Qi) = (∨i Pi) ⊢ ∧i(Pi ⇒ Qi) The top design is defined by ⊤D =d

f true ⊢ false = ¬ok

It is a left zero of sequential composition in design calculus ⊤D; D = ⊤D

+ +

65 +

✬ ✫ ✩ ✪

Assignment Revisited If the evaluation of expression e always yields a value, then (x := e) =d

f

true ⊢ (x′ = e ∧ . . . ∧ z′ = z)

+ +

66 +

✬ ✫ ✩ ✪

Well-definedness of Expression Let WD(e) be a predicate which is true in just those circumstances in which e can be successfully evaluated WD(x) = true WD(e1 + e2) = WD(e1) ∧ WD(e2) WD(e1/e2) = WD(e1) ∧ WD(e2) ∧ (e2 = 0) Define (x := e) =d

f WD(e) ⊢ (x′ = e ∧ . . . ∧ z′ = z)

+ +

67 +

✬ ✫ ✩ ✪

Algebraic Laws of Assignment We have to reestablish the following laws (asgn − 1) x := e = x, y := e, y (asgn − 2) (x, y, z := e, f, g) = (y, x, z := f, e, g) (asgn − 3) (x := e ; x := f(x)) = x := f(e) (asgn − 4) x := e ; (P ⊳ b(x) ⊲ Q) = (x := e; P) ⊳ b(e) ⊲ (x := e; Q) (asgn − 5) P; skip = P = skip; P

+ +

68 +

✬ ✫ ✩ ✪

Variable Declaration To introduce a new variable x we use the form of declaration var x which permits the variable x to be used in the portion of the program that follows it. The complementary operation (called undeclaration) takes the form end x and terminates the region of permitted use of x. The portion of program Q in which a variable x may be used is called its scope; it is bracketed

• n the left and on the right by the declaration and

undeclaration var x; Q; end x

+ +

69 +

✬ ✫ ✩ ✪

Definition of Declaration Let A be an alphabet which includes x and x′. Then var x =d

f

∃x • skipA end x =d

f

∃x′ • skipA α(var x) =d

f

A \ {x} α(end x) =d

f

A \ {x′} Note that the alphabet constraints forbid the redeclaration of a variable within its own scope. For example, var x; var x is disallowed because x′ ∈ OUTα(var x) but x / ∈ INα(var x)

+ +

70 +

✬ ✫ ✩ ✪

Declaration vs Existential Quantifier Declaration and undeclaration act exactly like existential quantification over their scope var x ; Q = ∃x • Q Q ; end x = ∃x′ • Q As a result, the algebraic laws for declaration closely match those for existential quantification.

+ +

71 +

✬ ✫ ✩ ✪

Algebraic Laws Both declaration and undeclaration are commutative. (var-1) (var x; var y) = (var y; var x) (var-2) (end x; end y) = (end y; end x) (var-3) (var x; end y) = (end y; var x) provided that x and y are distinct. (var-4) If x is not free in b, then var x; (P ⊳ b ⊲ Q) = (var x; P) ⊳ b ⊲ (var x; Q) end x; (P ⊳ b ⊲ Q) = (end x; P) ⊳ b ⊲ (end x; Q)

+ +

72 +

✬ ✫ ✩ ✪

Composition of declaration and undeclaration var x followed by end x has no effect whatsoever. (var-5) var x; end x = skip The sequential composition of end x with var x has no effect whenever it is followed by an update of x that does not rely on the previous value ofd x (var-6) (end x; var x := e) = (x := e) provided that x does not occur in e. Assignment to a variable just before the end of its scope is irrelevant. (var-7) (x := e; end x) = end x

+ +

73 +

✬ ✫ ✩ ✪

Example: Compilation of assignments Many computers can execute only the simplest assignment, with just two or three operands, and most of these operands must be selected from among the available machine registers (such as a, b, c). effect(load x) = a, b := x, a effect(store x) = x, a := a, b effect(add) = a := a + b effect(subtract) = a := a − b effect(multiply) = a := a × b

+ +

74 +

✬ ✫ ✩ ✪

Machine Code for (x := y × z + w) var a, b a, b := y, a load y a, b := z, a load z a := a × b multiply a, b := w, a load w a := a + b add x, a := a, b store x

+ +

75 +

✬ ✫ ✩ ✪

Unit 5: Implementation

+ +

76 +

✬ ✫ ✩ ✪

Machine Language

• Alphabet: Machine state
• Operations: Instruction set

+ +

77 +

✬ ✫ ✩ ✪

Machine State

• 1. A code memory m occupied can be modelled as a

function from addresses to machine instructions m : rom → instruction Once a machine code is stored in m, any update on m is forbidden.

• 2. A data memory M maps addresses to integers:

M : ram → INT The state of M can be updated by executing a machine instruction.

+ +

78 +

✬ ✫ ✩ ✪

Remark In practice, both m and M are part of storage provided by the machine. It is the resposibility of the designer of a compiler to ensure that the storage is properly devided to accomodate both target code and data of a sourse program.

+ +

79 +

✬ ✫ ✩ ✪

Machine State (Cont’d)

• 3. A program pointer P : rom always points to the

current instruction. By updating the contents of P the computer can choose to execute a specific branch of the machine code.

• 4. A stack of data registers

A, B, C : INT are seen as the extension of data memory.

+ +

80 +

✬ ✫ ✩ ✪

State Update Machine instructions are defined as assignments that update the state of the data memory and stack of registers. ldc(w) has a constant w as its operand, and its execution pushes w into the stack of registers ldc(w) =d

f A, B, C, P := w, A, B, P + 1

ldl(w) pushes the contents of M[w] to the stack of registers ldl(w) =d

f A, B, C, P := M[w], A, B, P + 1

+ +

81 +

✬ ✫ ✩ ✪

State Update (Cont’d) stl(w) sends the contents of A back into the data memory location w stl(w) =d

f M[w], P := A, P + 1

swap(R1, R2) swaps the contents of the data registers R1 and R2 swap(R1, R2) =d

f R1, R2 := R2, R1

+ +

82 +

✬ ✫ ✩ ✪

Evaluation of Expressions add =d

f

A, P := B + A, P + 1 sub =d

f

A, P := B − A, P + 1 mul =d

f

A, P := B × A, P + 1 divi =d

f

A, P := A/B, P + 1

• r =d

f

A, P := 0, P + 1 ⊳ A = 0 ∧ B = 0 ⊲ A, P := 1, P + 1 and =d

f

A, P := 1, P + 1 ⊳ A = 1 ∧ B = 1 ⊲ A, P := 0, P + 1

+ +

83 +

✬ ✫ ✩ ✪

Evaluation of Expressions (Cont’d) not =d

f

A, P := 0, P + 1 ⊳ A = 1 ⊲ A, P := 1, P + 1 eqc(w) =d

f

A, P := 1, P + 1 ⊳ A = w ⊲ A, P : 0, P + 1 gt =d

f

A, P := 1, P + 1 ⊳ B > A ⊲ A, P := 0, P + 1

+ +

84 +

✬ ✫ ✩ ✪

Machine Programs Suppose a machine program is stored in the memory m between locations s and f. Its behaviour is the combined effect of running the sequence of machine instructions I(s, f, m) =d

f

     P := s (s ≤ P < f) ∗ m[P] (P = f)⊥     

+ +

85 +

✬ ✫ ✩ ✪

Symbol Table At compiler time there are a number of items to which storage must be allocated in order to execute the target

• code. In our case we asume that the target code always

resides in m, and the program variables are stored in the data memory M. We use Ψ to denote a symbol table which maps each program variables to an address of the data memory M. Because no location can be allocated to two identifiers, Ψ has to be injective.

+ +

86 +

✬ ✫ ✩ ✪

Linking Program State with Machine State Define ˆ Ψ =d

f

     var x, .., z ; x, .. z := M[Ψx], ..., M[Ψz] ; end M, A, B, C      ˆ Ψ−1 =d

f

     var M, A, B, C ; M[Ψx], ..., M[Ψz] := x, .., z ; end x, .., z     

+ +

87 +

✬ ✫ ✩ ✪

Valid Implementation A program state can be recovered after it is converted to a machine state and then retrieved back: Theorem (1) ˆ Ψ−1; ˆ Ψ = skip (2) ˆ Ψ ; ˆ Ψ−1 ⊑ skip A machine program stored in m is regarded as a realisation of Q if ˆ Ψ ; Q ⊑ I(s, f, m) ; ˆ Ψ−1

+ +

88 +

✬ ✫ ✩ ✪

Weakest Specification of Valid Implementation For any source program Q, we define a machine program which acts like Q except that it operates on the data memory M: [Ψ](Q) =d

f

ˆ Ψ ; Q ; ˆ Ψ−1 Theorem (ˆ Ψ ; Q) ⊑ (I(s, f, m) ; ˆ Ψ−1) iff [Ψ](Q) ⊑ I(s, f, m)

+ +

89 +

✬ ✫ ✩ ✪

Proof (ˆ Ψ ; Q) ⊑ (I(s, f, m); ˆ Ψ) {; is monotonic} = ⇒ (ˆ Ψ; Q; ˆ Ψ−1) ⊑ (I(s, f, m); ˆ Ψ; ˆ Ψ−1) {ˆ Ψ; ˆ Ψ−1 ⊑ skip} = ⇒ [Ψ](Q) ⊑ I(s, f, m) {; is monotonic} = ⇒ ([Ψ](Q); ˆ Ψ) ⊑ (I(s, f, m) ; ˆ Ψ) {ˆ Ψ−1; ˆ Ψ = skip} = ⇒ (ˆ Ψ ; Q) ⊑ (I(s, f, m); ˆ Ψ)

+ +

90 +

✬ ✫ ✩ ✪

Implementation of Assignment Define eΨ =d

f e[M[Ψx][/x, .., M[Ψz]/x]

Theorem [Ψ](x := e) ⊑ M[Ψx] := eΨ

+ +

91 +

✬ ✫ ✩ ✪

Proof

LHS {end M ; x := e = x := e; end M} = var x, .., z ; x, .., z := M[Ψx], .., M[Ψz] ; x := e ; end M, A, B, C ; ˆ Ψ−1 {merge assignment} ⊑ var x, .., z := eΨ, .., M[Ψz] M[Ψx], .., M[Ψz] := x, .., z ; end x, .., z {merge assignment} ⊑ var x, .., z := eΨ, .., M[Ψz] end x, .., z ; M[Ψx], .., M[Ψz] := eΨ, .., M[Ψz] {varx := e; end x = skip} = M[Ψx] := eΨ

+ +

92 +

✬ ✫ ✩ ✪

Implementation of Sequential Composition Theorem [Ψ](Q; R) = [Ψ](Q); [Ψ](R) Proof LHS {def of [Ψ]} = ˆ Ψ−1; Q; R; ˆ Ψ {ˆ Ψ−1; ˆ Ψ = skip} = ˆ Ψ; Q; ˆ Ψ−1; ˆ Ψ; R; ˆ Ψ−1 {def of [Ψ]} = RHS

+ +

93 +

✬ ✫ ✩ ✪

Implementation of Conditional

Theorem [Ψ](Q ⊳ b ⊲ R) = [Ψ](Q) ⊳ bΨ ⊲ [Ψ](R) Proof LHS {(Q ⊳ b ⊲ R); W = (Q; W) ⊳ b ⊲ (R; W)} = ˆ Ψ; (Q; ˆ Ψ−1) ⊳ b ⊲ (R; ˆ Ψ−1) {end w; (Q ⊳ b ⊲ R) = (end w ; Q) ⊳ b ⊲ (end w R)} = var x, .. z ; (x, .., z := M[Ψx], .., M[Ψz]; end M, A, B, C, P; Q ; ˆ Ψ−1) ⊳bΨ⊲ (x, .., z := M[Ψx], .., M[Ψz]; var w; (Q ⊳ b ⊲ R) = end M, A, B, C, P; R ; ˆ Ψ−1) (var w ; Q) ⊳ b ⊲ (var w R)} = RHS

+ +

94 +

✬ ✫ ✩ ✪

Implementation of Iteration

Theorem [Ψ](b ∗ Q) ⊑ bΨ ∗ [Ψ](Q) Proof (ˆ Ψ−1 ; RHS; ˆ Ψ) {(Q ⊳ b ⊲ R); W = (Q; W) ⊳ b ⊲ (R; W)} = ˆ Ψ−1; {x := e; ⊳Q ⊳ b ⊲ R = ([Ψ](Q); RHS; ˆ Ψ) ⊳ bΨ ⊲ ˆ Ψ (x := e; Q) ⊳ b[e/x] ⊲ (x := e; R)} = (ˆ Ψ−1; [Ψ](Q); RHS; ˆ Ψ) ⊳b ⊲ (ˆ Ψ−1; ˆ Ψ) {ˆ Ψ−1; ˆ Ψ = skip} = (Q; (ˆ Ψ−1; RHS; ˆ Ψ)) ⊳ b ⊲ skip which implies (ˆ Ψ; RHS; ˆ Ψ−1 ⊒ b ∗ Q) = ⇒ (RHS ⊒ ˆ Ψ−1; (b ∗ Q); ˆ Ψ)

+ +

95 +

✬ ✫ ✩ ✪

Empty Machine Program

The empty machine program is the unit of sequential composition. Theorem I(s, s, m); I(s, f, m) = I(s, f, m) = I(s, f, m); I(f, f, m) Proof I(s, s, m) {Def of I} = P := s ; (s ≤ P < s) ∗ m[P] ; (P = s)⊥ {false ∗ Q = skip} = P := s ; (P = s)⊥ {Q ⊳ true ⊲ R = Q} = P := s

+ +

96 +

✬ ✫ ✩ ✪

Entry of Machine Code

Theorem If s ≤ j < f, then I(j, f, m) ⊑ P := j ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥ Proof RHS {(b ∨ c) ∗ Q = b ∗ Q ; (b ∨ c) ∗ Q} = P := j ; (j ≤ P < f) ∗ m[P] ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥ {(P = f)⊥ = (P = f)⊥; (P; = f)} ⊒ I(j, f, m) ; (P := f) ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥ {false ∗ Q = skip} = I(j, f, m); P := f; (P = f)⊥ {b⊥; b⊥ = b⊥} = LHS

+ +

97 +

✬ ✫ ✩ ✪

Elimination of Machine Code

Theorem If s < f and m[s] = jump(f − s − 1), then I(s, f, m) = I(f, f, m) Proof LHS {Unfolding of b ∗ Q} = P := s ; m[s] ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥ {def of jump(w)} = P := s ; P := P + f − s (s ≤ P < f) ∗ m[P] ; (P = f)⊥ {false ∗ Q = skip} = P := f ; (P = f)⊥ {false ∗ Q = skip} = P := f; (f ≤ P < f) ∗ m[P]; (P = f)⊥

+ +

98 +

✬ ✫ ✩ ✪

Void Initial State

If a machine program contains an instruction jumping backwards to its start address, then it does not matter whether the execution starts at its first instruction or that jump instruction. Theorem If s ≤ j < f, and m[j] = jump(s − j − 1) then (P := j ; (s ≤ P < f) ∗ m[P]) = (P := s ; (s ≤ P < f) ∗ m[P]) Proof LHS {unfolding iteration} = P := j ; m[j] ; (s ≤ P < f) ∗ m[P] {def of jump(w)} = P := j ; P := P + s − j ; (s ≤ P < f) ∗ m[P] {merge assignment} RHS

+ +

99 +

✬ ✫ ✩ ✪

Concatenation The concatenation of two machine programs is a refinement of their sequential composition, since it is easy for the former to materialise its normal exit commitment. Theorem If s ≤ j ≤ f then I(s, f, m) ⊒ I(s, j, m); I(j, f, m)

+ +

100 +

✬ ✫ ✩ ✪

Proof

RHS {def of I} = P := s; (s ≤ P < j) ∗ m[P] ; (P = j)⊥; P := j; (j ≤ P < f) ∗ m[P]; (P = f)⊥ {Entry of machine code} ⊑ P := s; (s ≤ P < j) ∗ m[P] ; (P = j)⊥; P := j; (s ≤ P < f) ∗ m[P]; (P = f)⊥ {(P = j)⊥ = (P = j)⊥; (P := j} ⊑ P := s ; (s ≤ P ≤ j) ∗ m[P] ; skip (s ≤ P < f) ∗ m[P] ; (P = f)⊥ {b ∗ Q ; (b ∨ c) ∗ Q = (b ∨ c) ∗ Q} = P := s ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥ {def of I} = LHS

+ +

101 +

✬ ✫ ✩ ✪

Conditional Jump vs Conditional A conditional jump can be used to choose a branch of machine codes according to the initial state of the register A Theorem If s < j − 1 < f and m[s] = tjump(j − s − 1) and m[j − 1] = jump(f − j − 1), then I(s, f, m) ⊒       I(j, f, m) ⊳A = 0⊲ (I(s + 1, j − 1, m); I(f, f, m))      

+ +

102 +

✬ ✫ ✩ ✪

Proof

LHS {unfolding iteration} = P := s ; m[s] ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥ {def of tjump} = (P := j ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥) ⊳A = 0 ⊲ (P := s + 1; (s ≤ P < f) ∗ m[P] ; (P = f)⊥) {Entry of machine code} ⊒ I(j, f, m) ⊳ A = 0 ⊲ (P := s + 1 ; (s ≤ P < j − 1) ∗ m[P] ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥) {(P = k)⊥; P := j = (P = k)⊥} ⊒ I(j, f, m) ⊳ A = 0 ⊲ (P := s + 1 ; (s ≤ P < j − 1) ∗ m[P] ; (P = j − 1)⊥ ; P := j − 1 ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥) {V oid initial state} ⊒ RHS

+ +

103 +

✬ ✫ ✩ ✪

Backward Jump vs Iteration Theorem Assume that s < j < f − 1. If I(s, j, m) ⊒ (A := 1 ⊳ b ⊲ A := 0) and m[j] = tjump(f − j − 1) and m[f − 1] = jump(s − f), then I(s, f, m) ⊒ µX •       (A := 1, ; I(j + 1, f − 1, m) ; X) ⊳ b ⊲ (A, P := 0, f)      

+ +

104 +

✬ ✫ ✩ ✪

Proof

LHS {b ∗ Q ; (b ∨ c) ∗ Q = (b ∨ c) ∗ Q} ⊒ I(s, j, m) ; (P := j) ; (s ≤ P < f) ∗ m[P] ; (P = f)⊥ {I(s, j, m) ⊒ (A := 1 ⊳ b ⊲ A := 0)} ⊒ I(s, j, m) ; (I(f, f, m) ⊳ A = 0⊲ (I(j + 1, f − 1, m); (P := f); (s ≤ P < f) ∗ (s, f, m) ; (P = f)⊥) {Sequential composition} = (A := 1) ⊳ b ⊲ (A := 0) ; (I(f, f, m) ⊳ A = 0⊲ (I(j + 1, f − 1, m); I(s, f, m)) {; − ⊳ ⊲ distribuitivity} = (A := 1; I(j + 1, f − 1, m); I(s, f, m)) ⊳b ⊲ (A, P := 0, f)

+ +

105 +

✬ ✫ ✩ ✪

Unit 6 : Design Capturing

+ +

106 +

✬ ✫ ✩ ✪

Healthiness Condition 1 R makes no prediction on the final values of variables until the program has started. H1 R = (ok ⇒ R) Theorem H1 (Algebraic Representation) R satisfies H1 iff R satisfies the left zero and left unit laws.

+ +

107 +

✬ ✫ ✩ ✪

Proof of Theorem H1 If R = skip; R = (¬ok ∨ skip); R = (¬ok; R) ∨ (skip; R) = (¬ok; true; R) ∨ (skip; R) = (¬ok; true) ∨ R = ¬ok ∨ R

+ +

108 +

✬ ✫ ✩ ✪

Proof of Theorem H1 Only if true; R = true; (¬ok ∨ R) = (true; ¬ok) ∨ (true; R) = true

+ +

109 +

✬ ✫ ✩ ✪

Healthiness Condition 2 Non-termination is something that is never wanted. H2 [R[false/ok′] ⇒ R[true/ok′]] Theorem H2 (Syntactical Representation) A predicate satisfies the healthiness conditions H1 and H2 iff it is a design.

+ +

110 +

✬ ✫ ✩ ✪

Proof of Theorem H2 Only if R = ¬ok ∨ R = ¬ok ∨ (¬ok′ ∧ R[false/ok′]) ∨ (ok′ ∧ R[true/ok′]) = ¬ok ∨ (¬ok′ ∧ R[false/ok′]) ∨ (ok′ ∧ (R[false/ok′] ∨ R[true/ok′])) = ¬ok ∨ R[false/ok′] ∨ (ok′ ∧ R[true/ok′]) = ¬R[false/ok′] ⊢ R[true/ok′]

+ +

111 +

✬ ✫ ✩ ✪

Healthiness Condition 3 If R fails to terminate, then its behaviour is unpredictable H3 R = R; skip Theorem H3 (P ⊢ Q) satisfies H3 iff P = ∀v′ • P

+ +

112 +

✬ ✫ ✩ ✪

Proof of Theorem H3 Proof (P ⊢ Q); skip = (P ⊢ Q); (true ⊢ (v′ = v)) = ¬(¬P; true) ⊢ Q which implies that P ⊢ Q satisfies H3 iff P = ¬(¬P; true) = ∀v′ • P An assumption P satisfying the above condition is called a precondition which it only refers the initial values of variables.

+ +

113 +

✬ ✫ ✩ ✪

Healthiness Condition 4 If the precondition of a program is satisfied, the program is required to deliver final values for the program variables. H4 R; true = true Theorem H4 b ⊢ Q satisfies H4 iff [b ⇒ (Q; true)]

+ +

114 +

✬ ✫ ✩ ✪

Proof of Theorem H4 Proof (b ⊢ Q); true = (b ∧ ¬(Q; true)) ⊢ (Q; true) which implies that b ⊢ Q satisfies H4 iff b ∧ ¬(Q; true) = false

• r equivalently

[b ⇒ (Q; true)]

+ +

115 +

✬ ✫ ✩ ✪

Closure of Healthy Predicates Theorem If both P and Q satisfy Hi, so are P; Q, P ⊓ Q and P ⊳ b ⊲ Q.

+ +

116 +

✬ ✫ ✩ ✪

Proof of Closure Theorem Proof Let P and Q in H1. We are going to show that P; Q satisfies left unit and left zero laws. true; (P; Q) = true; Q = true skip; (P; Q) = (skip; P); Q = P; Q

+ +

117 +

✬ ✫ ✩ ✪

Mapping Relations To Designs A mapping M from relations to designs is a retraction if it satisfies the following conditions

• Monotonic: P1 ⊒ P2 implies M(P1) ⊒ M(P2)
• Idempotent: M2(P) = M(P)
• Weakening: P ⊒ M(P)

We are going to show the healthiness conditions can be characterised by the corresponding retraction.

+ +

118 +

✬ ✫ ✩ ✪

H1-healthy Predicates Define H1(P) =d

f

(ok ⇒ P) Theorem H1 is monotonic, idempotent and weakening P ⊒ H1(P) for all P Theorem P satisfies the healthiness condition H1 iff P = H1(P)

+ +

119 +

✬ ✫ ✩ ✪

Homomorphism Theorem H1(P op Q) ⊒ (H1(P) op H1(Q)) Proof H1(P op Q) ⊒ H1(H1(P) op H1(Q)) = H1(P) op H1(Q)

+ +

120 +

✬ ✫ ✩ ✪

Closure of Recursion Theorem µX • F(X) satisfies the healthiness condition H1, where F is formed by programming combinators. Proof H1(µX • F(X)) = H1(F(µX • F(X))) ⊒ F(H1(µX • F(X))) which implies that H1(µX • F(X)) ⊒ µX • F(X) Because H1 is weakening one has µX • F(X) ⊒ H1(µX • F(X))

+ +

121 +

✬ ✫ ✩ ✪

H2-healthy Predicates Define H2(P) =d

f

P; ((ok ⇒ ok′) ∧ (x′ = x ∧ . . . ∧ z′ = z)) Theorem (1) H2 is monotonic, idempotent and weakening. (2) P satisfies H2 iff P = H2(P) (3) H2(P op Q) ⊒ (H2(P) op H2(Q)) (4) µX • F(X) satisfies H2, where F is formed by programming combinators.

+ +

122 +

✬ ✫ ✩ ✪

H3-healthy Predicates Define H3(P) =d

f

(P; skip) Theorem (1) H3 is monotonic, idempotent and weakening. (2) P satisfies H3 iff P = H3(P) (3) H3(P op Q) ⊒ (H3(P) op H3(Q)) (4) µX • F(X) satisfies H3, where F is formed by programming combinators.

+ +

123 +

✬ ✫ ✩ ✪

H4-healthy predicates Define H4(P) =d

f

((P; true) ⇒ P) Theorem (1) H4 is idempotent and weakening. (2) P satisfies H4 iff P = H4(P) (3) H4(P op Q) ⊒ (H4(P) op H4(Q)) (4) µX • F(X) satisfies H4, where F is formed by programming combinators.

+ +

124 +

✬ ✫ ✩ ✪

Unit 7: Linking Theories

+ +

125 +

✬ ✫ ✩ ✪

Subset theories If T is a subset of S, there is always a link from T to S R =d

f

λX ∈ T • X A more interesting mapping is to be sought in the other direction: it is an endofunction L : S → S which ranges over all the members of T range(L) = T

+ +

126 +

✬ ✫ ✩ ✪

Examples idS =d

f

λX ∈ S • X

• rP

=d

f

λX ∈ S • (P ∨ X) preP =d

f

λX ∈ S • (P; X) postQ =d

f

λX ∈ S • (X; Q)

+ +

127 +

✬ ✫ ✩ ✪

Endofunctions Theorem (range of an idempotent) If L is idempotent, then X = L(X) iff X lies in the range of L. Theorem (monotonic endofunctions) If both L1 and L2 are monotonic, so is their composition L1 ◦ L2. Theorem (weakening endofunctions) If both L1 and L2 are monotonic weakening, so is their composition L1 ◦ L2.

+ +

128 +

✬ ✫ ✩ ✪

Closure of Idempotent Theorem (idempotent endofunctions) If L1 and L2 are idempotent and satisfy L1 ◦ L2 = L2 ◦ L1 then L1 ◦ L2 is an idempotent. Examples (1) Ψ =d

f (H1 ◦ H2 ◦ H3) is an idempotent.

(2) Ψ ◦ H4 is also idempotent.

+ +

129 +

✬ ✫ ✩ ✪

Link and Recursion L is a link if it is idempotent and weakening. Let S be a complete lattice, and T ⊆ S also a complete

• lattice. Assume that F is a monotonic mapping on S,

and closed in T. Theorem (1) If L : S → S is a link and satisfies L ◦ F ⊒ F ◦ L, then µSX • F(X) = µTX • F(X) (2) If L is monotonic idempotent, and satisfies L ◦ F ⊒ F ◦ L, then L(µSX • F(X)) = µTX • F(X)

+ +

130 +

✬ ✫ ✩ ✪

Proof of (1) L(µSX • F(X)) = L(F(µSX • F(X))) ⊒ F(L(µSX • F(X))) which and L(µSX • F(X)) ∈ T imply that µTX • F(X) ⊑ L(µSX • F(X)) ⊑ µSX • F(X)

+ +

131 +

✬ ✫ ✩ ✪

Proof of (2) µTX • F(X) ⊒ µSX • F(X) ⇒ L(µTX • F(X)) ⊒ L(µSX • F(X)) ⇒ µTX • F(X) ⊒ L(µSX • F(X)) µSX • F(X) = F(µSX • F(X)) ⇒ L(µSX • F(X)) = L(F(µSX • F(X))) ⇒ L(µSX • F(X)) ⊒ F(L(µSX • F(X))) ⇒ L(µSX • F(X)) ⊒ µTX • F(X)

+ +

132 +

✬ ✫ ✩ ✪

Goal of a Subset Theory A frequent goal in the definition of a subset theory is to ensure that the validity on that subset of certain additional algebraic laws. For example, the desired law may be of the form X = L(X) Now if L happens to be idempotent, the goal is simply achieved: just take the link L itself and define T =d

f range(L)

+ +

133 +

✬ ✫ ✩ ✪

Goal of a Subset Theory As an additional advantage, it is frequently found that

• ther useful laws become true in T.

For example, let L =d

f H1 = λX • (ok ⇒ X)

In the subset T =d

f range(L), both left zero law and

the left unit law are valid.

+ +

134 +

✬ ✫ ✩ ✪

Unit 8: Galois Connection

+ +

135 +

✬ ✫ ✩ ✪

Galois Connection Let (S, ⊒S) and (T, ⊒T) be complete lattices. L : S → T and R : T → S form a Galois connection if for all X ∈ S and all Y ∈ T (L(X) ⊒T Y ) iff (X ⊒S R(Y ))

+ +

136 +

✬ ✫ ✩ ✪

Examples (1) (P ∧ X) ⊒ Y iff X ⊒ (P ⇒ Y ) (2) (weakest post-specification) (P; X) ⊒ Y iff X ⊒ ∀m • (P(m, v) ⇒ Y (m, v′)) (3) (weakest prespecification) (X; Q) ⊒ Y iff X ⊒ ∀m • (Q(v′, m) ⇒ Y (v, m))

+ +

137 +

✬ ✫ ✩ ✪

Galois Connection and Inverse Theorem If L and R are monotonic, then they form a Galois connection iff (L ◦ R) ⊒T idT and (R ◦ L) ⊑S idS Theorem If (Li, Ri) for i = 1, 2 are Galois connections, then L1 = L2 iff R1 = R2

+ +

138 +

✬ ✫ ✩ ✪

Proof Assume that L1 = L2 X ⊒ R1(Y ) ≡ L1(X) ⊒ Y ≡ L2(X) ⊒ Y ≡ X ⊒ R2(Y )

+ +

139 +

✬ ✫ ✩ ✪

Disjunctivity and Conjunctivity L : S → T is universally disjunctive if for all sets U L(⊓S U) = ⊓T {L(X) | X ∈ U} L is disjunctive if the above equation holds for all nonempty sets U. Examples (1) λX • (P; X) is fully disjunctive. (2) λX • (X; Q) is fully disjunctive. (3) λX • (P ∨ X) is disjunctive, but not fully disjunctive.

+ +

140 +

✬ ✫ ✩ ✪

Galois Connection vs Disjunctivity Theorem There exists R such that (L, R) is a Galois connection iff L is universally disjunctive.

+ +

141 +

✬ ✫ ✩ ✪

Proof (⇒) L(⊓S U) ⊒T Y ≡ (⊓S U) ⊒S R(Y ) ≡ ∀X ∈ U • (X ⊒S R(Y )) ≡ ∀X ∈ U • (L(X) ⊒T Y ) ≡ ⊓T{L(X) | X ∈ U} ⊒T Y

+ +

142 +

✬ ✫ ✩ ✪

Proof (cont’d) Let R(Q) =d

f ⊓S{X | L(X) ⊒T Q}

(⇐) L(P) ⊒T Q ≡ P ∈ {X | L(X) ⊒T Q} ⇒ P ⊒S R(Q) ⇒ L(P) ⊒T L(R(Q)) ≡ L(P) ⊒T ⊓T {L(X) | L(X) ⊒ Q} ⇒ L(P) ⊒T Q

+ +

143 +

✬ ✫ ✩ ✪

Simulation and Galois Connection Let D and U be designs satisfying (D; U) ⊒ skip and skip ⊒ (U; D) In this case, D is called a simulation and U a co-simulation. Theorem If (D, U) is a pair of simulations, then L(X) =d

f (D; X; U)

and R(Y ) =d

f (U; Y ; D)

form a Galois connection over designs.

+ +

144 +

✬ ✫ ✩ ✪

Galois Connection and Recursion Theorem Let F and G be monotonic, and let (L, R) be a Galois connection. If R ◦ F = G ◦ R, then R(µX • F(X)) = µX • G(X)

+ +

145 +

✬ ✫ ✩ ✪

Unit 9: Algebraic Representation

+ +

146 +

✬ ✫ ✩ ✪

The Notations of the Language < program > ::= true | skip | < variable list >:=< exp list > | < program > ⊳bool − exp⊲ < program > | < program >; < program > | < program > ⊓ < program > | < recursive identifier > | µ < recursive identifier > • < program >

+ +

147 +

✬ ✫ ✩ ✪

Assignment Normal Form A total assignment is the first of normal forms x, y, . . . , z := e, f, . . . , g L1 (x, y . . . := e, f, . . .) = (x, y, . . . , z := e, f, . . . , z) L2 (x, . . . , z, y, . . . := e, . . . , g, f, . . .) = (x, . . . , y, z, . . . := e, . . . , f, g, . . .) L3 (v := g ; v := f(v)) = (v := f(g)) L4 (v := f) ⊳ b ⊲ (v := g) = (v := (f ⊳ b ⊲ g)) L5 (v := f) = (v := g) iff [f = g]

+ +

148 +

✬ ✫ ✩ ✪

Non-deterministic Normal Form (v := f) ⊓ . . . ⊓ (v := h) Let A and B be finite sets of total assignments L1 (⊓A) ⊓ (⊓B) = ⊓ (A ∪ B) L2 (⊓A) ⊳ b ⊲ (⊓B) = ⊓ {v := g ⊳ b ⊲ h | (v := g) ∈ A ∧ (v := h) ∈ B} L3 (⊓A); (⊓B) = ⊓ {(v := g(h)) | (v := h) ∈ A ∧ (v := g) ∈ B} L4 (⊓A) ⊒AL R iff ∀(v := e) ∈ A • ((v := e) ⊒AL R) L5 (v := e) ⊒AL (v := g ⊓ . . . ⊓ v := h) iff [e ∈ {g, . . . , h}]

+ +

149 +

✬ ✫ ✩ ✪

Non-termination Normal Form b ∨ (⊓A) L1 (b ∨ P) ⊓ (c ∨ Q) = (b ∨ c) ∨ (P ⊓ Q) L2 (b ∨ P) ⊳ d ⊲ (c ∨ Q) = (b ⊳ d ⊲ c) ∨ (P ⊳ d ⊲ Q) L3 (b ∨ P); (c ∨ Q) = (b ∨ {c(e) | (v := e) ∈ P}) ∨ (P; Q) L4 (b ∨ P) ⊒AL (c ∨ Q) iff [b ⇒ c] ∧ (P ⊒AL (c ∨ Q)) L5 (v := e) ⊒AL (c ∨ (v := g ⊓ . . . ⊓ v := h)) iff [c ∨ e ∈ {g, . . . , h}]

+ +

150 +

✬ ✫ ✩ ✪

Infinite Normal Form S = {Si | i ∈ N} where each Si+1 is stronger than its predecessor (Si+1 ⊒ Si), for i ∈ N L1 (⊔S) ⊓ P = ⊔ (Si ⊓ P) L2 (⊔S) ⊳ b ⊲ P = ⊔i (Si ⊳ b ⊲ P) L3 (⊔S); P = ⊔i (Si; P) L4 P; (⊔S) = ⊔i (P; Si)

+ +

151 +

✬ ✫ ✩ ✪

Continuity L5 (⊔S) ⊓ (⊔T) = ⊔i (Si ⊓ Ti) L6 (⊔S) ⊳ b ⊲ (⊔T) = ⊔i (Si ⊳ b ⊲ Ti) L7 (⊔S) ; (⊔T) = ⊔i (Si ; Ti) L8 µX • (⊔iSi(X)) = ⊔i (µX • Si(X)) L9 µX • F(X) = ⊔i (F i(true)) where F 0(X) =d

f true,

and F n+1(X) =d

f F(F n(X))

+ +

152 +

✬ ✫ ✩ ✪

Computability How to compute the limit ⊔(bn ∨ Pn) The execution depends on the property (bn ∨ Pn) = (bn ∨ Pn+k) Let P = (v := e1 ⊓ . . . ⊓ v := en) and Q = (v := f1 ⊓ . . . ⊓ v := fm). (b ∨ P) ≤ (c ∨ Q) =d

f

[c ⇒ b] and [¬b ⇒ ({e1, . . . , en} = {f1, . . . , fm})]

+ +

153 +

✬ ✫ ✩ ✪

Strong Monotonicity Theorem If X ≤ Y then F(X) ≤ F(Y ), for all programming

• perators F.

Theorem {F n(true) | n ∈ N} is a ≤-descending chain. L1 ⊔S ⊑AL ⊔T iff Sn ⊑AL (⊔T) for all n L2 Let P = (v := e1 ⊓ . . . ⊓ v := em) and Qn = (v := f n

1 ⊓ . . . ⊓ v := f n k )

(b ∨ P) ⊑AL ⊔(cn ∨ Qn) iff [(∧kck) ⇒ b] and [cn∨ b ∨ ({f n

1 , . . . , f n k } ⊆ {e1, . . . , em})]

+ +

154 +

✬ ✫ ✩ ✪

Completeness A reduction to normal form gives a method of testing the truth of any proposed implication between any pair of programs: reduce both of them to normal form, and test whether the inequation satisfies the conditions of previous two laws. The converse conclusion can also be drawn. Theorem [P ⇒ Q] iff (P ⊒AL Q)

+ +

155 +

✬ ✫ ✩ ✪

Denotational Semantics If j is a list of constants, (state := j); P(state, state′) describes all possible observations of the final state of an execution of P that starts in initial state j. The implication [(state := k) ⇒ (state := j); P] means the state k is among the possible final state, i.e. P(j, k) [P ⇒ Q] iff [t ⇒ (s; P)] implies [t ⇒ (s; Q)] for all constant assignment.

+ +

156 +

✬ ✫ ✩ ✪

Defining Equations R(true) = {(j, k) | j, k ∈ STATE} R(v := e(v)) = {(ok, v), (ok′, v′) |ok ⇒ (ok′∧v′ = e(v))} R(P; Q) = {(j, k) | ∃m • (j, m) ∈ R(P) ∧ (m, k) ∈ R(Q)} R(P ⊳ b ⊲ Q) = {(j, k) | (state := j); b ∧ (j, k) ∈ R(P) ∨ (state := j); ¬b ∧ (j, k) ∈ R(Q)} R(P ⊓ Q) = {(j, k) | (j, k) ∈ R(P) ∨ (j, k) ∈ R(Q)} R(µX • F(X)) = {(j, k)| ∀n ∈ N • (j, k) ∈ R(F n(true))}

+ +

157 +

✬ ✫ ✩ ✪

From Algebraic to Denotational Presentation Define A(P) =d

f ¬d(v) ⊢ Q(v, v′)

where d(j) = true iff (v := j; P) = true is provable, and Q(j, k) = true iff (v := j; P) ⊑AL (v := k) is provable. Theorem A satisfies the defining equation of R

+ +

158 +

✬ ✫ ✩ ✪

Unit 10 : An Operational Model

+ +

159 +

✬ ✫ ✩ ✪

Operational Semantics An operational semantics suggests a complete set of individual steps which may be taken in the execution m → m′ where m and m′ are of the form (s, P) (1) s is a text, defining the data state as a constant assignment to all variables. (2) P is a program text, representing the rest of program that remains to be executed. When this is II, there is no more program to be executed.

+ +

160 +

✬ ✫ ✩ ✪

Algebraic Specification of a Step ((s, P) → (t, Q)) =d

f

((s; P) ⊑AL (t; Q)) (1) (s, v := e) → (v := s; e, II) (2) (s, II; R) → (s, R) (3) If (s, P) → (t, Q), then (s, P; R) → (t, Q; R) (4) (s, P ⊓ Q) → (s, P) (s, P ⊓ Q) → (s, Q) (5) (s, P ⊳ b ⊲ Q) → (s, P), whenever s; b (s, P ⊳ b ⊲ Q) → (s, Q), whenever s; ¬b (6) (s, µX • F(X)) → (s, F(µX • F(X))) (7) (s, true) → (s, true)

+ +

161 +

✬ ✫ ✩ ✪

Correctness There are two kinds of error which may occur in design

• f an operational semantics.

(1) There may be too few transitions. As a result, the set of steps is incomplete. For example we omit the rule (s, P ⊓ Q) → (s, Q) thereby eliminating non-determinism from the language. (2) There are too many transitions. For example (s, P) → (s, P) is entirely consistent since it expresses reflexivity of ⊑. However such rule can lead to an infinite execution.

+ +

162 +

✬ ✫ ✩ ✪

The Reflexive Transitive Closure Define

∗

→ as the reflexive transitive closure of →, and define

1

→ =d

f

→

n+1

→ =d

f ( 1

→ ;

n

→) A machine state (s, P) is divergent if it can lead to an infinite execution (s, P) ↑ =d

f ∀n • ∃t, Q • (s, P) n

→ (t, Q)

+ +

163 +

✬ ✫ ✩ ✪

Ordering Relation Define a relation ⊑STATE over states (s, P) ⊑STATE (t, Q) =d

f

(s, P) ↑ ∨ ∀u • ((t, Q)

∗

→ (u, II)) ⇒ ((s, P)

∗

→ (u, II)) Define a relation ⊑OP over program texts by P ⊑OP Q =d

f ∀s • (s, P) ⊑STATE (s, Q)

Theorem ⊑OP is a pre-order. Define P ∼ Q =d

f (P ⊑OP Q) and (Q ⊑OP P)

+ +

164 +

✬ ✫ ✩ ✪

From Operational to Algebraic Semantics Lemma 1 (s, P) ↑ iff (s; P) = true is algebraically provable. Lemma 2 (s, P) ↑ or (s, P)

∗

→ (t, II) iff (s; P) ⊑AL t is algebraically provable Theorem P ∼ Q iff P = Q is algebraically provable.

+ +

165 +

✬ ✫ ✩ ✪

From Operational to Denotational Semantics Define O(P) =d

f ¬d(v) ⊢ Q(v, v′)

where d(j) =d

f (v := j, P) ↑

Q(j, k) =d

f (v := j, P) ∗

→ (v := k, II) Theorem O satisfies the defining equation of R.

+ +
