Lets save our trees with SubtiTree! Opening synthetic biology to new challenges 2 A more local scale 2 The Canal du Midi Southwest of France 42,000 plane trees UNESCO 2 Canal du Midi and Canker Plane trees lining the Canal

slide-1
SLIDE 1

Let’s save our trees with SubtiTree!

slide-2
SLIDE 2

Opening synthetic biology to new challenges

2

slide-3
SLIDE 3

A more local scale

2

slide-4
SLIDE 4

The “Canal du Midi” Southwest of France

2

UNESCO 42,000 plane trees

slide-5
SLIDE 5

Ceratocystis platani

  • Supposed introduction:

American landing in 1944

  • Blocks sap flow
  • No effective treatment

Canal du Midi and Canker

Plane trees lining the Canal Preventive tree cutting implies high costs

3

slide-6
SLIDE 6

Mankind

Observation and modification of nature

Nature

Synthetic Biology

Beauty

Science in the service of art and beauty ?

Our approach

4

Ethical questioning

slide-7
SLIDE 7

Our chassis: Bacillus subtilis, an endophyte bacterium of the plane tree

5

SubtiTree to save our heritage

slide-8
SLIDE 8

Mediated by a chimeric protein targeting chitin components

TARGET

Our chassis: Bacillus subtilis, an endophyte bacterium of the plane tree

5

SubtiTree to save our heritage

slide-9
SLIDE 9

Mediated by a chimeric protein targeting chitin components

Chitin-derived compounds Chitin

TARGET

5

SubtiTree to save our heritage

slide-10
SLIDE 10

Mediated by a chimeric protein anchoring in both fungal cell wall and peptidoglycan

Chitin

BIND

5

SubtiTree to save our heritage

slide-11
SLIDE 11

Mediated by a chimeric protein anchoring in both fungal cell wall and peptidoglycan

Chitin

BIND

5

SubtiTree to save our heritage

slide-12
SLIDE 12

Production of different anti- fungal peptides

Chitin

ERADICATE

5

SubtiTree to save our heritage

slide-13
SLIDE 13

5

SubtiTree to save our heritage

slide-14
SLIDE 14

²

McpA VCD

Concept

McpA McpA

T

N- Acetylglucosamine SubtiTree

Chimeric protein VCD

  • V. cholerae

McpA

  • B. subtilis

Glucose

NAG NAG

Extracellular Intracellular

1- TARGET

6

BBa_1364004

slide-15
SLIDE 15

²

McpA VCD

Concept

McpA McpA

T

N- Acetylglucosamine SubtiTree

Chimeric protein VCD

  • V. cholerae

McpA

  • B. subtilis

Glucose

NAG NAG

Extracellular Intracellular

1- TARGET

6

BBa_1364004

slide-16
SLIDE 16

²

Tube tests

Motility test in capillary

Plate tests

Plug-in-pond protocol

Tests

1- TARGET

Capillary assay

Bacteria swimming to the top of a tip (Imperial College iGEM team 2011)

7 250mM GLC

Bacillus subtilis WT

slide-17
SLIDE 17

²

Glucose NAG Galactose

WT Bacillus subtilis

Final results

WT Bacillus subtilis naturally attracted to NAG!

Tests

1- TARGET

8

slide-18
SLIDE 18

²

9

Concept

CWB Linker CBD T LytC, B. subt. GbpA, V. chol. Peptidoglycan Chitin

SubtiTree

2- BINDING

BBa_1364005

slide-19
SLIDE 19

²

10

2- BINDING

Tests

Chitin-coated magnetic beads Engineered B. subtilis

slide-20
SLIDE 20

²

10

2- BINDING

Tests

Engineered B. subtilis

slide-21
SLIDE 21

²

10

2- BINDING

Tests

slide-22
SLIDE 22

²

10

2- BINDING

Tests

Beads covered with B. subtilis (confocal microscopy)

100 µm

slide-23
SLIDE 23

²

10

2- BINDING

Tests

slide-24
SLIDE 24

²

10

2- BINDING

Tests

slide-25
SLIDE 25

²

10

2- BINDING

Tests

slide-26
SLIDE 26

²

10

2- BINDING

Tests

slide-27
SLIDE 27

²

10

2- BINDING

Tests

slide-28
SLIDE 28

²

10

2- BINDING

Tests

1,E+00 1,E+01 1,E+02 1,E+03 1,E+04 1,E+05 WT SubtiTree

Number of bacteria per mL

= 170x

slide-29
SLIDE 29

² EcAMP GAFP-1 D4E1

Inhibit hyphae elongation Mannose-binding lectin Sterol binding

T in situ production of antifungal peptides

SubtiTree

11

3- ERADICATE

Concept

BBa_1364019 BBa_1364008 BBa_1364009

slide-30
SLIDE 30

²

Setting up the testing protocol

Commercial peptides Copper sulfate WT bacteria Improve experimental conditions Balance the growth

12

3- ERADICATE

Tests

slide-31
SLIDE 31

²

Tests with transformed bacteria

Expressing 1, 2 or 3 antifungal peptides

Setting up the testing protocol

Commercial peptides Copper sulfate WT bacteria Improve experimental conditions Balance the growth

SN: Culture supernatant P: cells

12

3- ERADICATE

Tests

slide-32
SLIDE 32

13

Proof of concept Target - Bind - Eradicate

Tests with model plants Modeling Assembling the 3 modules

Let’s look back on the first steps

slide-33
SLIDE 33

²

in planta Tests

14

Nicotiana benthamiana

10 20 30 40 50 60 70 80

Mock WT D4E1 D4E1 + GAFP-1

% of sites showing necrosis

WT SubtiTree

slide-34
SLIDE 34

²

in planta Tests

14

Nicotiana benthamiana

10 20 30 40 50 60 70 80

Mock WT D4E1 D4E1 + GAFP-1

% of sites showing necrosis

WT SubtiTree

slide-35
SLIDE 35

²

15

Modeling

Concept

When to treat the trees ? What will happen to SubtiTree during winter ?

Cardinal temperature model of Rosso (1992)

Tree model  Volume: 30m3  Density: 650kg/m3  Bacteria inoculum: 10mL at 10⁹cfu/mL Two conditions: Bacterial growth Toulouse

slide-36
SLIDE 36

²

16

Results

Growth stops Bacteria die

Bacterial cycle as a function of temperature to predict the active period of SubtiTree

Subtitree action time

Best inoculation time is March Subtitree will not survive to winter

Subtitree death

Average temperatures in Toulouse

Modeling

slide-37
SLIDE 37

²

17

What about now?

The future of SubtiTree

Binding specificity Induction of expression Regulation Further studies

BBa_K314200 BBa_K314201

slide-38
SLIDE 38

²

18

Communication Communication tools

Newsletters iGEM Toulouse presentation flyer iGEM Toulouse presentation poster SubtiTree presentation flyer Social networks

slide-39
SLIDE 39

²

18

Communication Oral presentations

Agora Journées de l’Ecole Doctorale BSB Exposcience BioSynSys conference Novela

Communication tools

Newsletters iGEM Toulouse presentation flyer iGEM Toulouse presentation poster SubtiTree presentation flyer Social networks

slide-40
SLIDE 40

²

18

Communication

Press

14 articles

Oral presentations

Agora Journées de l’Ecole Doctorale BSB Exposcience BioSynSys conference Novela

Communication tools

Newsletters iGEM Toulouse presentation flyer iGEM Toulouse presentation poster SubtiTree presentation flyer Social networks

slide-41
SLIDE 41

²

18

Communication

Press

14 articles 1 radio interview

Oral presentations

Agora Journées de l’Ecole Doctorale BSB Exposcience BioSynSys conference Novela

Communication tools

Newsletters iGEM Toulouse presentation flyer iGEM Toulouse presentation poster SubtiTree presentation flyer Social networks

slide-42
SLIDE 42

²

18

Communication

Press

14 articles 1 tv interview 1 radio interview

Oral presentations

Agora Journées de l’Ecole Doctorale BSB Exposcience BioSynSys conference Novela

Communication tools

Newsletters iGEM Toulouse presentation flyer iGEM Toulouse presentation poster SubtiTree presentation flyer Social networks

slide-43
SLIDE 43

²

19

Public perception

Local & National

INRA Agricultural Ministry Town Halls PUBLIC SUPPORT GOVERNMENTAL ORGANIZATIONS SCIENTIFIC INSTITUTION

Crowdfunding

slide-44
SLIDE 44

20

Achievements

Ethical point

  • f view
slide-45
SLIDE 45

20

Achievements

Ethical point

  • f view

Proof of concept of the modules 16 new BioBricks A new integrative plasmid for

  • B. subtilis (BBa_K1364021)

Improved BBa_K1162001 by adding STOP codon Characterized BBa_K1364009, BBa_K1364013 and BBa_K1364005 Created and improved new protocols

slide-46
SLIDE 46

20

Achievements

Ethical point

  • f view

Tests in planta Proof of concept of the modules

slide-47
SLIDE 47

20

Achievements

Ethical point

  • f view

Tests in planta Toward plane trees

(Modeling)

Proof of concept of the modules

slide-48
SLIDE 48

20

And had a GREAT summer !

Achievements

Ethical point

  • f view

Tests in planta Toward plane trees

(Modeling)

Proof of concept of the modules

slide-49
SLIDE 49

21

Acknowlegments

Sponsors Our institutions Lab equipment support

slide-50
SLIDE 50

Thank you for your attention

22

slide-51
SLIDE 51

Let’s save our trees with SubtiTree!
