Lab 2: Buffer Overflows

Fengwei Zhang

Wayne State University CSC 5991 Cyber Security PracCce 1

Buffer Overflows

• One of the most common vulnerabiliCes in

soGware

• Programming languages commonly associated

with buffer overflows including C and C++

• OperaCng systems including Windows, Linux

and Mac OS X are wriOen in C or C++

Wayne State University CSC 5991 Cyber Security PracCce 2

How It Works

• ApplicaCons define buffers in the memory

– unsigned int char [10]

• ApplicaCons use adjacent memory to store

variables, arguments, and return address of a funcCon.

• Buffer Overflows occurs when data wriOen to

a buffer exceeds its size.

Wayne State University CSC 5991 Cyber Security PracCce 3

Overflowing A Buffer

• Defining a buffer in C

– char buf[10];

• Overflowing the buffer

– Char buf [10] = ‘x’; – strcpy(buf, “AAAAAAAAAAAAAAAAAAAAAAA”)

Wayne State University CSC 5991 Cyber Security PracCce 4

Why We Care

• Because adjacent memory stores program

variables, parameters, and arguments

• AOackers can change these values through
• verflowing a buffer
• AOackers can gain control over the program

flow to execute arbitrary code

Wayne State University CSC 5991 Cyber Security PracCce 5

Process Memory Layout

Wayne State University CSC 5991 Cyber Security PracCce 6

Stack Heap Data Segment Text Segment High memory Low memory

Memory Layout for 32-bit Linux

Wayne State University CSC 5991 Cyber Security PracCce 7

Kernel Space Stack Heap BSS Segment Data Segment Text Segment (ELF) 1GB 3GB Local variable: int a FuncCon malloc() UniniCalized staCc variables: staCc char *u staCc char *s = “Hello world” Binary of the program

Virtual Memory Layout

Wayne State University CSC 5991 Cyber Security PracCce 8

Stack Frame

Wayne State University CSC 5991 Cyber Security PracCce 9

• The stack contains acCvaCon frames including

local variables, funcCon parameters, and return address

• StarCng at the highest memory address and

growing downwards

• Last in first out

Wayne State University CSC 5991 Cyber Security PracCce 10

Add (2,3)

3 2 Ret Address EBP C High memory Low memory ESP int add (int a, int b) { int c; c = 1+b; return c; }

A Simple Program

Another Program

int func (char * str) { char mybuff[512]; strcpy(myBuff, str); return 1; } int main (int argc, char ** argv) { func (argv[1]); return 1; }

Wayne State University CSC 5991 Cyber Security PracCce 11

Draw the Stack Frame!

Overflowing “myBuff”

Wayne State University CSC 5991 Cyber Security PracCce 12

(A) str(A) Ret addr(A) EBP(A) A A A A A A High memory Low memory ESP

Buffer Overflow Defenses

• The aOack described is a classical stack smashing

aOack which execute the code on the stack

• It does not work today

– NX – non-executable stack. Most compilers now default to a non-executable stack. Meaning a segmentaCon fault occurs if running code from the stack (i.e., Data ExecuCon PrevenCon - DEP)

• Disable it with –zexecstack opCon
• Check it with readelf –e <PROGRAM> | grep STACK

– StackGuard: Cannaries

• Disable it with –fno-stack-protector opCon
• Enable it with –fstack-protector opCon

Wayne State University CSC 5991 Cyber Security PracCce 13

Stack Canaries

• Stack smashing aOacks do two things

– Overwrite the return address – Wait for algorithm to complete and call RET

• Stack Canaries: Stack Smashing Protector (SSP)

– Placing a integer value to stack just before the return address – To overwrite the return address, the canary value would also be modified – Checking this value before the funcCon returns

Wayne State University CSC 5991 Cyber Security PracCce 14

Stack Canaries (cont’d)

Wayne State University CSC 5991 Cyber Security PracCce 15

(A) str(A) Ret addr(A) EBP(A) Canary(A) A A A A A High memory Low memory ESP

Bypassing NX and Canaries

• NX - non-executable stack

– ExecuCng code in the heap – Data ExecuCon PrevenCon (DEP) – Return Oriented Programming (ROP)

• Stack Canaries

– OverwriCng the Canary with the same value – Brute force aOack (e.g., DynaGuard in ACSAC’15)

Wayne State University CSC 5991 Cyber Security PracCce 16

• Lab 0

– Turn in the class agreement

• Lab 1

– Due today at 11:59pm – Late assignment policy – Submit it via Blackboard

• Lab 2 instrucCons

Wayne State University CSC 5991 Cyber Security PracCce 17

Reminders
