Kernel methods for Network Analysis: An introduction

Chiranjib Bhattacharyya

Machine Learning lab Dept of CSA, IISc chiru@csa.iisc.ernet.in http://drona.csa.iisc.ernet.in/~chiru

13th Jan, 2013

Computational Biology Which super-family does this protein structure belongs to?

Multimedia Who are the actors?

Social Networks How can one run a succesful Ad-campaign on this network?

Data Representation as a vector

Data Representation as a vector

Data Representation as a vector

Data Representation as a vector

Data Representation as a vector                  f e a t u r e m a p                 

When we have Feature maps Linear Classifiers, Principal Component Analysis

Similarity maybe readily available

Problem Feature maps are not readily available

Kernel functions- a formal notion of similarity functions Kernel functions are essentially similarity functions. One can easily generalize many existing algorithms using kernel functions.Sometimes called the kernel trick Kernels can help integrate different sources of data

Agenda

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

PART 1: KERNEL TRICK

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

The problem of classification

Given Training data D = {(xi,yi)|i = 1,...,m}

• bservation xi

class label yi ∈ {−1,1} Find A classifier f : X → {−1,1}. f(x) = sign(w⊤x+b)

Regularized risk

minw,b C

m

∑

i=1

max(1−yi(w⊤xi +b),0)

• Risk

+ 1 2w2 Regularization

Regularized risk

minw,b C

m

∑

i=1

max(1−yi(w⊤xi +b),0)

• Risk

+ 1 2w2 Regularization The SVM formulation minw,b,ξ 1 2w2 +C

m

∑

i=1

ξi subject to yi(w⊤xi +b) ≥ 1−ξi ξi ≥ 0 ∀ i ∈ [m]

SVM formulation

maximizeα

m

∑

i=1

αi − 1 2 ∑

ij

αiαjyiyjx⊤

i xj

subject to 0 ≤ αi,

m

∑

i=1

αiyi = 0

SVM formulation

maximizeα

m

∑

i=1

αi − 1 2 ∑

ij

αiαjyiyjx⊤

i xj

subject to 0 ≤ αi,

m

∑

i=1

αiyi = 0 w = ∑m

i=1 αiyixi

f(x) = sign(

m

∑

i=1

αiyix⊤

i x+b)

C-SVM in feature spaces

Let us work with a feature map, Φ(x) maximizeα − 1 2 ∑

ij

αiαjyiyjΦ(xi)⊤Φ(xj)+

m

∑

i=1

αi subject to 0 ≤ αi,∑

i

αiyi = 0 f(x) = sign(

m

∑

i=1

αiyiΦ(xi)⊤Φ(x)+b) The dot product between any pair of examples computed in the feature space be denoted by K(x,z) = Φ(x)⊤Φ(z)

C-SVM in feature spaces

Let us work with a feature map, Φ(x) maximizeα − 1 2 ∑

ij

αiαjyiyjK(xi,xj)+

m

∑

i=1

αi subject to 0 ≤ αi,∑

i

αiyi = 0 f(x) = sign(

m

∑

i=1

αiyiK(xi,x)+b) The dot product between any pair of examples computed in the feature space be denoted by K(x,z) = Φ(x)⊤Φ(z)

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

Principal Component Analysis(PCA)

Principal Directions Given X = [x1,...,xm] find directions of maximum variance( Jollife 2002). The direction of maximum variance, v, is given by 1 mXX⊤v = λv (assuming that Xe = 0) Define v = Xα 1 mXX⊤Xα = λXα leading to the following eigenvalue problem 1 mKα = λα where (K)ij = (X⊤X)ij = x⊤

i xj.

Nonlinear component analysis(Scholkopf et al. 1996)

Compute PCA in feature spaces Replace x⊤

i xj by Φ(xi)⊤Φ(xj)

Principal component of x In input space In feature space v⊤x ∑m

i=1 αiK(xi,x)

We just need the dot product

Let x ∈ IR2 and Φ(x) = [x2

1 x2 2

√ 2x1x2]⊤ K(x,z) = Φ(x)⊤Φ(z) = x2

1z2 1 +2x1x2z1z2 +x2 2z2 2 = (x⊤z)2

If K(x,z) = (x⊤z)r is a dot product in a d+r−1

r

• feature space

corresponding to x,z ∈ IRd. If d = 256,r = 4, the feature space size is 6,35,376. However if we know K one can still solve the SVM formulation without explicitly evaluating Φ

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

Norms, Distances

Φ(x) =

• Φ(x),Φ(x) =
• K(x,x)

Normalized features ˆ Φ(x) = Φ(x) Φ(x) ˆ K(x,z) = ˆ Φ(x)⊤ ˆ Φ(z) = K(x,z)

• K(x,x)K(z,z)

Distances Φ(x)−Φ(z)2 = (Φ(x)−Φ(z))⊤ (Φ(x)−Φ(z)) = K(x,x)+K(z,z)−2K(x,z) If Φ is normalized K(x,x) = 1 then Φ(x)−Φ(z)2 = 2−2K(x,z)

In the sequel

Will formalize these notions conditions on K will be discussed K for graphs

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

Definition of Kernel functions

Kernel function

Kernel function K : X ×X → IR is a Kernel function if K(x,z) = K(z,x) symmetric Kis positive semidefinite, i.e.∀n,x1,...,xn ∈ X , the matrix Kij = K(xi,xj) is psd Recall that a K ∈ IRd×d is psd if u⊤Ku ≥ 0 for all u ∈ IRd.

Examples of Kernel functions

K(x,z) = φ(x)⊤φ(z) where φ : X → IRd K is symmetric i.e. K(x,z) = K(z,x) Positive Semidefinite: Let D = {x1,x2,...,xn} be set of arbitrarily chosen n elements of X . Define Kij = φ(xi)⊤φ(xj) For any u ∈ IRn it is straightforward to see that u⊤Ku =

m

∑

i=1

uiφ(xi)2

2 ≥ 0

Examples of Kernel functions

K(x,z) = x⊤z Φ(x) = x K(x,z) = (x⊤z)r Φt1t2...td(x) =

• r!

t1!t2!....td!xt1 1 xt2 2 ...xtd d

∑d

i=1 ti = r

K(x,z) = e−γx−z2

Kernel Construction

Let K1 and K2 be two valid kernels. K(x,y) = φ(x)⊤φ(y) K(u,v) = K1(u,v)K2(u,v) K = αK1 +βK2 α,β ≥ 0 ˆ K(x,y) = K(x,y)

• K(x,x)
• K(y,y)

Kernel Construction

Let K1 and K2 be two valid kernels. K(x,y) = φ(x)⊤φ(y) K(u,v) = K1(u,v)K2(u,v) K = αK1 +βK2 α,β ≥ 0 ˆ K(x,y) = K(x,y)

• K(x,x)
• K(y,y)

K(x,y) = x⊤y K(x,y) = (x⊤y)i K(x,y) = lim

N→∞ N

∑

i=0

(x⊤y)i i! = ex⊤y ˆ K(x,y) = e− 1

2x−y2

Kernel function and feature map

A theorem due to Mercer guarantees a feature map for symmetric, psd kernel functions. Loosely stated For a symmetric kernel K : X ×X → IR, there exists an expansion K(x,z) = Φ(x)⊤Φ(z) iff

• X g(x)g(z)K(x,z)dxdz ≥ 0

What is a Dot product(aka Inner Product)

Let X be a vector space. What is a Dot product Symmetry < u,v >=< v,u > u,v ∈ X Bilinear < αu+βv,w >= α < u,w > +β < v,w > u,v,w,∈ X Positive Semidefinite < u,u > ≥ 0 u ∈ X < u,u >= 0 iff u = 0 Norm x =

• x,x

x = 0 = ⇒ x = 0

Examples of Dot products

X = IRn,< u,v >= u⊤v X = IRn,< u,v >=

n

∑

i=1

λiuivi λi ≥ 0 X = L2(X) = {f :

• X f(x)2dx < ∞}

f,g ∈ X < f,g >=

• X f(x)g(x)dx

Cauchy Schwartz inequality

Cauchy Schwartz inequality Let X be an inner product space. |x,y| ≤ xy ∀ x,y ∈ X and equality holds iff x = αz for some scalar α Proof: ∀α ∈ IR x−αz2 ≥ 0 x2 −2αx,z+α2z2 ≥ 0∀α Let α = x,z

z2 and the inequality follows by taking square roots. The

claim about equality follows from the definition of norm.

Hilbert Space: Basic facts Definition Inner product space (H ,·,·H ) is a Hilbert Space if it is separable and complete. Denote the norm as ·H .

Projections in Hilbert space

The orthogonal complement of M ⊂ H is defined as M⊥ = {z|x,zH = 0, ∀x ∈ M} Hilbert space Projection theorem Let M be a subspace of Hilbert space H ,·,·H . For every x ∈ H the following holds There exists an unique ΠM(x) ∈ M such that ΠM(x) = argminz∈Mx−zH x−ΠM(x) ∈ M⊥ z,x−ΠM(x)H = 0 ∀z ∈ M x2

H = ΠM(x)2 H +y2 H where

x = ΠM(x)+y where y ∈ M⊥

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

Reproducing kernel Hilbert Space(RKHS)

Let K be any kernel function. Consider the following set H = {f|f(.) =

m

∑

i=1

αiK(.,xi)∀xi ∈ X ,m ∈ N} Reproducible Property ∀f ∈ H ,f(x) =

m

∑

i=i

αiK(x,xi) =

m

∑

i=1

αiK(.,xi),K(.,x) = f(.),K(.,x)

Dot product in RKHS

Dot product ∀f,g ∈ H ,f(.) =

m1

∑

i=1

αiK(.,xi) , g(.) =

m2

∑

i=1

βjK(.,xj) f,gH =

m1

∑

i=1 m2

∑

j=1

αiβjK(xi,xj) As K is symmetric, f,gH = g,fH f(.),f(.) =

m

∑

i=1 m

∑

j=1

αiαjK(xi,xj) Recall that K is a psd matrix if K is kernel function and so f(.),f(.)H ≥ 0 CS inequality holds so |f(x)| ≤

• f,fH
• K(x,x)

Representer theorem

Representer theorem Let K be a valid kernel defined on X and H be the corresponding

• RKHS. Let Ω be an increasing function. The optimization problem

min

g∈H G(g) = m

∑

i=1

l(g(xi),yi)+Ω(g2

H )

is solved when g∗ = ∑m

i=1 αiK(.,xi)

Representer theorem

Representer theorem Let K be a valid kernel defined on X and H be the corresponding

• RKHS. Let Ω be an increasing function. The optimization problem

min

g∈H G(g) = m

∑

i=1

l(g(xi),yi)+Ω(g2

H )

is solved when g∗ = ∑m

i=1 αiK(.,xi)

Proof: Let M = {∑m

i=1 αiK(.,xi) i = 1,...,m}. Clearly M is a

subspace of H . Take any g ∈ H . g(xi) = g,K(.,xi) = gM +gper,K(.,xi) = gM,K(.,xi)+gper,K(.,xi) = gM,K(.,xi) = gM(xi) As Ω is an increasing function, Ω(g2

H ) ≥ Ω(gM2 H )

Back to C-SVM formulation

Given a Kernel function K defined on X one can create a RKHS H = {

n

∑

i=1

βizi|zi ∈ X ,n ∈ N} Classifier: f(x) = sign(g(x)+b) ming∈H ,b∈IR

m

∑

i=1

max(0,1−yi(g(xi)+b))

• l(g(xi),yi)

+g2

H

At optimality g(.) = ∑m

i=1 γiK(.,xi)

(Representer theorem)

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

Many Applications

Ideal to model molecules Protein-protein interaction networks metabolic networks Social networks

Graph Kernels

Kernels on vertices on a Graph, G = (V,E) Compute K(vi,vj), where vi,vj ∈ V Kernels on Graphs Compute K(G1,G2) where G1,G2 are two graphs

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

Diffusion Kernels(Kondor and Lafferty 2002)

Let X = {1,...,m} and there be some associated edges between

• them. The adjacency matrix of the resulting graph be A.

Diffusion Kernel K = lim

s→∞(I + β

s H)s H = A−D, where D is diagonal with dii = ∑j aij. K is positive definite and Symmetric. Computation is O(m3)

Diffusion Kernels(Kondor and Lafferty 2002)

Let X = {1,...,m} and there be some associated edges between

• them. The adjacency matrix of the resulting graph be A.

Diffusion Kernel K = lim

s→∞(I + β

s H)s H = A−D, where D is diagonal with dii = ∑j aij. K is positive definite and Symmetric. Computation is O(m3) lim

s→∞(1+ β

s x)s = eβx K = eβH = ∑m

i=1 vieβλivi where (λi,vi) are the (eigen-value,

eigen-vector) of H

Diffusion Kernels(Kondor and Lafferty 2002)

Sometimes can be computed in closed form for special graphs e.g. complete graphs K(i,j) =

• 1+(m−1)e−mβ

m

i = j

1−e−mβ m

i = j Has a very interesting analogue with Diffusion equation in physics.

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

Kernels on graphs

Graph Isomorphism Find a mapping g to the vertices of G1 = (V1,E1) to the vertices of G2 = (V2,E2) such that G1 and G2 are identical. If (u,v) ∈ E1 iff (g(u),g(v)) ∈ E2 then g is an isomorphism SubGraph Isomorphism Is there a subgraph S of G1 and a subgraph T of G2 such that S and T are isomorphic NP hard. Need computationally efficient approximations.

Desideratum of a kernel function

Computationally efficient Positive Definite Can relate graph structures Applicable to wide variety of graphs

Some Definitions

Let A be a m×n and B be a p×q matrix. A

• B =

   a11B ··· a1nB . . . ... . . . am1B ··· amnB   

Definitions: Product graph

Let G1 = (V1,E1) and G2 = (V2,E2) be two graphs. G = (V,E) is the product graph of G1 and G2 if V = V1 ×V2 and ((i,i′),(j,j′)) ∈ E iff (i,j) ∈ E1 and (i′,j′) ∈ E2. A(G) = A(G1)

• A(G2)

Random walk kernel between two graphs(Vishwanathan et

• al. 2010)

Random walk kernel K(G1,G2) =

V

∑

i,j=1 ∞

∑

t=0

λ tAt = e⊤(I −λA)−1e V is the number of vertices of product graph of G1,G2 A = A(G1)A(G2) Counts the number of paths by simultaneously random walks on G1 and G2. Computational complexity is O(n6), where n = V(G1) = V(G2)

Can we compute it more efficiently(Vishwanathan et al. 2010)

Sylvester Equation Given S,T and M0 one can solve for M M = SMT⊤ +M0 in O(n3) time

1 Kernel Trick

SVMs and Non-linear Classification Principal Component Analysis What can we compute with the dot product in feature spaces?

2 Mathematical Foundations

RKHS, Representer theorem

3 Kernels on Graphs aka Networks

Kernels on vertices of a Graph Kernels on graphs

4 Advanced Topics: Multiple Kernel Learning

PART 5: Multiple Kernel Learning

Recap of SVMs

On a dataset D = {(xi,yi)|i = 1,...,m} SVMs solve the following problem ω(K) = maxα ∑

i

αi − 1 2α⊤YKYα (1) 0 ≤ αi ≤ C

∑

i

αiyi = 0 (2) where Kij = k(xi,xj) is the kernel function defined on examples xi and xj. The final classifier is y = sign(∑i αiyiK(x,xi)+b)

Recap of SVMs

Does not scale well The function ω(K) is a pointwise maximum of a set of functions and hence is convex If the maximization in α is not unique then ω(K) is not differentiable. ω(K) maynot be differentiable, but subgradients exist. Let us relax the problem a little and say that µi ≥ 0

Learning a linear combination of Multiple Kernels Let {K1,...,Kn} be a given library of kernels. Given a training set of m examples, each Ki = K⊤

i ∈ IRm×m

MKL(Lanckriet et al. 2004) minKω(K) K =

l

∑

i=1

µiKi trace(K) = c K 0

MKL is a Semi-definite Programming problem

minz c⊤z s.t. F(z) = ∑l

i=1 ziFi 0

Bz = d z ∈ IRl and Fi = F⊤

i ∈ IRm×m.

F(z) is positive semidefinite Instance of a convex optimization problem. Can be solved by interior point methods

MKL formulation

SDP formulation minµ,t,λ,ν>0 t (3)

• ∑l

i=1 µiYKiY⊤

e+ν +λy e+ν +λy t

• (4)

∑n

i=1 µiKi 0

(5)

Reformulation of MKL

The SDP problem can be recast as QCQPs maxα,t α⊤e−ct (6) s.t. α⊤YKiYα ≤ rit i = 1,...,l (7) α⊤y = 0 0 ≤ α ≤ C (8) where ri = trace(Ki) QCQPs are instances of SOCPs minz c⊤z (9) Aiz+bi2 ≤ c⊤

i z+di

(10) where Ai ∈ IRni×l,bi,ci,c,z ∈ IRl,di ∈ IR

Equivalence with Block L1 reqularization

Bach et al. (2004) showed that the QCQP formulation is equivalent to minw,b,ξ

1 2

    

l

∑

i=1

diwi

• Block L1

    

2

+C∑m

i=1 ξi

(11) s.t. yi(∑j w⊤

j φj(xi)+b) ≥ 1−ξi ∀ i = {1,...,m}

ξi ≥ 0 (12) for proper choice of di Block L1 norm promotes sparsity i.e. most of µi = 0

Efficient algorithms for MKL

A trick Let γ ∈ IBn = {γ ∈ IRn|γi ≥ 0, ∑n

i=1 γi = 1} For any

ai ∈ IR, i = 1,...,n (

n

∑

i=1

|ai|)2 ≤

n

∑

i=1

a2

i

γi This implies that

• n

∑

i=1

wi 2 ≤

n

∑

i=1

1 γi wi2 where γ lies in a probability simplex Can be helpful in reformulating the L1 formulation.

Solving MKL by reusing SVM solvers

The following problem is equivalent to the Block L1 formulation(Rakotomamonjy et al. 2007) Sm = {α|0 ≤ αi ≤ C,α⊤y = 0} and IB = {µ|0 ≤ µi ∑l

i=1 µi = 1}

minµ∈IBJ(µ)

• = maxα∈Smα⊤e− 1

2 ∑l i=1 µiα⊤YKiYα

• (13)

A gradient descent algorithm-iteration 1.) Solve SVM problem with Kernel K = ∑l

i=1 µiKi

2.) Differentiate J w.r.t µ and update µ See also Sonnenberg et al. 2006

References

Kernel methods in Computational Biology Scholkopf et al. 2004 Kernel methods for Pattern Analysis John Shawe Taylor and N. Cristanini Learning with Kernels Scholkopf and Smola 2002
