Introduction to Survey Sampling

James M. Lepkowski & Michael Traugott

Institute for Social Research University of Michigan

April 29 – May 1, 2013

2

3

4

• 1. Overview of Surveys & Survey

Sampling

• Where does sampling fit in?
• Sampling topics to be covered

– Probability v. non‐probability sampling – Population of inference – Sampling frames – Sample designs for list frames or widespread populations – Sample deficiencies – Weighting – Variance estimation for complex sample surveys

5

WHERE DOES SAMPLING FIT IN?

• During conceptualization, a researcher

considers the RELEVANT POPULATION for evaluating the theory/hypothesis

• In designing the data collection, the

researcher has two concerns in mind:

– External validity – Cost/benefit calculations for the overall cost of the study

DIFFERENCES BETWEEN CENSUSES AND SAMPLES

A census involves an enumeration of a

• population. When the population is large:
• 1. It is costly
• 2. It is time consuming
• 3. May not be feasible with precision

(US Census as an example)

A sample involves a selection of a representative subset of a population in

• rder to draw inferences to the

population Collecting data from a sample of a large population is FAR LESS costly and FAR LESS time consuming

Greater Accuracy

• Because of the cost savings, sampling

allows a researcher to devote

– More resources to the collection of more data (variables) – The reduction of error in measurement (reliability and validity) – Better coverage of the units of analysis

• This fits in with the Total Survey Error

perspective

Total Survey Error

Probability v. non‐probability sampling

• Non‐probability sampling

– Haphazard, convenience, or accidental sampling – Purposive sampling or expert choice – Quota sampling

• Probability sampling

11

Population of inference

• Target population

– Geographical boundaries – Age limits – Date

• Survey population

– Possible exclusions from target population

• Institutionalized
• Homeless
• Nomads
• Remote sparsely settled areas

12

13

Target Survey Frame

Sampling frame

• List frame
• Area frame
• Problems

– Missing elements – Duplicate listings – Clusters – Blanks or ineligibles

14

Sample designs for compact populations

• Simple random sampling
• Systematic sampling
• Stratified sampling

– Proportionate allocation – Disproportionate allocation

15

Sample designs for widespread populations

• Cluster sampling

– One‐stage (take all) – Two‐stage (subsampling) – Multi‐stage

• Probability proportionate to size sampling
• Stratified cluster sampling
• Systematic sampling of clusters

16

Sample deficiencies

• Nonresponse

– Total/unit – Item

• Noncoverage
• Compensation: weighting

– Unequal probabilities – Nonresponse – Noncoverage (poststratification)

• Make the sample distribution conform to known

population distribution

17

Variance estimation

• Standard software cannot handle complex sample

designs correctly

• Methods of variance estimation

– Taylor series approximation – Balanced or Jackknife repeated replication

• Computer software available for these methods

– Requires stratum, cluster, and weight on each sample record

18

• 2. Simple random sampling
• Simple random sampling
• Exercise 1
• Table of random digits
• Faculty salaries

19

Simple random sampling (SRS)

• Rarely used in practice for large scale surveys
• Theoretical basis for other sample designs
• Sample size n from population size N
• Every element of the population has the same

probability of selection (epsem) and every combination of size n has the same probability

• f selection

20

Selection and estimation

• Use a table of random numbers to select SRS

samples

• Sample mean estimates population mean

21

1

1

n i i

y y n



 

1

1

N i i

Y Y N







Exercise 1

• The following table (3 pages) lists the salaries
• f n = 370 faculty members at a major

midwestern university in 2013 in the U.S.

• For each faculty member there is a sequence

number, an ID, division, rank, and 2010‐2011 salary

• The list is ordered alphabetically by surname

and given name (which are not shown)

22

Exercise 1

This is a group exercise. Each group should select a simple random sample of n = 20 from the list. Use the accompanying table of random numbers to select the sample. Then compute the sample mean One member of the group should report the sample mean on behalf of the group.

1

1

n i i

y y n



 

23

Exercise 1: Starting columns for groups

Group Columns 1 2 3 4 5 6 7 8 9 10 11 12 1-3 41-43 81-83 11-13 31-33 51-53 21-23 36-38 56-68 61-63 66-68 71-73

24

25

Exercise 1: Table of Random Digits

R o w C o l u m n 1 -5 6 -1 0 1 1 -1 5 1 6 -2 0 2 1 -2 5 2 6 -3 0 3 1 -3 5 3 6 -4 0 4 1 -4 5 4 6 -5 0 5 1 -5 5 5 6 -6 0 6 1 -6 5 6 6 -7 0 7 1 -7 5 7 6 -8 0 8 1 -8 5 8 6 -9 0 1 49018 34042 72000 49522 85941 84723 51072 56454 67420 05025 25234 10671 05579 90906 54706 79486 57057 40468 2 97294 25351 12331 82557 13834 91334 32510 47165 08535 27491 87064 23579 72223 45164 98781 20189 17391 75145 3 97638 18356 31198 39366 37340 76043 77528 21714 44751 81797 28670 50973 07915 45259 45334 88904 47365 37249 4 34525 30477 75462 34635 51422 60669 62413 52524 79883 26235 46933 23381 72335 74702 77289 83419 28761 68996 5 79619 43993 89902 64817 88397 35390 44558 91500 87656 83603 00491 37693 75524 04058 77373 61598 60059 32241 6 54778 70353 54134 19513 89074 07807 74520 59684 47494 58194 29810 91489 45410 28737 55504 50467 94953 25565 7 12256 17900 33754 11853 65033 24106 41833 68345 62300 33076 70119 60498 70180 06929 34567 37075 57735 44602 8 33297 14796 91080 67108 85984 81892 37533 24643 37522 71461 96220 16177 04449 38396 09675 64290 96410 49117 9 75083 44991 46851 46383 00695 54453 34156 49854 68163 83123 89928 39667 15632 43854 04707 41766 01876 20016 1 0 66288 63908 74090 52902 69701 72959 64480 78123 81841 92675 08731 20577 94939 43211 63438 93640 75825 57922 1 1 84578 05698 92016 94285 26563 36372 55989 94790 36338 30640 81337 56599 05695 42896 57115 73143 49959 84903 1 2 55699 23402 30639 39508 41495 44462 11924 70471 97867 82637 18031 38020 70819 64948 17274 67345 31672 66155 1 3 51917 88538 58239 58633 80392 89447 81230 97654 52579 34888 06454 94398 16452 76723 00902 81924 73166 85669 1 4 36779 68538 88591 96616 84918 29413 99116 66987 41334 43877 00185 90070 43292 01754 01505 25362 39548 60933 1 5 49852 36333 84789 65346 46181 61218 54131 57370 64814 44430 43774 72286 11644 33071 74301 02154 37021 04828 1 6 66752 08578 57498 17884 83667 59532 73254 83347 85751 18536 55969 73265 06726 80734 29351 36800 77081 10687 1 7 61689 45570 53663 66779 85627 27662 34436 58824 18902 49414 05020 98033 85987 53127 72623 00983 92504 54686 1 8 19111 76703 32467 51391 85381 48433 68754 89843 02166 59177 80856 71628 27731 90073 04233 34913 46188 28778 1 9 46913 70576 16918 46675 02304 83330 55894 39684 20753 48885 72907 37048 80065 58931 78214 36397 97252 69593 2 0 22224 48264 96826 15434 52010 22811 07914 89541 61620 83346 96204 52742 27485 37716 71756 79244 04517 20831 2 1 84119 49920 29328 03239 15832 72406 94946 45797 70566 19586 26419 40852 70097 02276 93410 87952 71018 96533 2 2 75594 56191 18861 44995 44764 76960 12585 01842 19324 46085 33903 77234 07418 42805 21925 86305 12510 87281 2 3 34821 90491 28843 85959 72301 14576 94229 43353 55740 86145 73278 89446 36093 39173 07384 32388 17494 52734 2 4 23378 01578 09081 20536 31412 00632 16380 14876 26249 00449 26441 14765 05223 08297 54280 35937 02965 79389 2 5 09985 71346 32130 58906 97244 07003 91231 23396 47378 19064 01118 04376 83218 01890 94316 40309 41332 30966 2 6 43814 09227 11841 44516 62348 31284 58895 88559 19567 82425 00614 68626 10523 96822 79297 16858 52693 63887 2 7 26724 80216 75905 54725 46995 75504 79112 50571 57115 02600 35097 04329 78514 02663 48700 57166 30316 97649 2 8 37876 85859 19333 87221 44809 50700 57889 43075 99310 32235 62624 88356 51865 21946 52479 69599 29065 26434 2 9 23634 07454 63628 30531 52979 28534 03208 75663 33587 27738 04018 32256 32259 14042 27624 94889 91414 72658 3 0 10906 61337 16571 98829 96434 25748 01518 97758 93725 64532 79331 25961 82782 23354 47052 36078 12780 78331 3 1 09372 97239 72017 99537 99977 96404 04824 64248 68816 02734 38384 87274 18213 67600 18730 17870 02026 34180 3 2 86659 47171 96123 33853 64659 76657 53911 09900 70918 07733 89084 42345 22250 13583 52020 96144 25382 10875 3 3 78209 23140 94532 89438 43271 89616 63137 85026 15799 62580 70837 50071 74496 94191 45858 13545 66999 77390 3 4 15430 43742 77673 21745 34854 31505 05275 16758 58996 70211 97794 60918 98986 14446 72130 43056 13412 86691 3 5 64947 43432 14105 78393 03682 47498 75738 76250 69143 19799 31068 31261 31912 47359 26853 62917 40581 40772 3 6 71143 09505 65318 29034 89055 17744 48752 69171 08426 08827 14816 61969 68694 19168 67081 26010 68211 80384 3 7 03104 54280 49703 72368 99964 68555 57769 27567 55962 31100 26364 61603 48176 04177 00935 05130 83625 66323 3 8 56085 69548 50876 92855 52293 11580 22797 94044 67994 50651 26397 01782 73341 80486 72738 66943 75883 10106 3 9 41842 68437 92724 67791 21113 47124 28279 50647 09809 26717 48925 14686 24824 38530 62429 57330 33340 07994 4 0 28521 08035 30260 91407 04111 18581 84777 87116 96280 09202 31360 02923 83625 19821 35903 86927 36021 90593 4 1 85133 15310 42745 84831 82992 73756 67473 62066 83254 02735 55402 39765 92121 07338 39944 36882 74892 00148 4 2 28122 35506 71104 96492 90721 22225 23256 30415 63671 27160 19768 08441 38172 15357 73851 53381 20093 42073 4 3 56665 12467 44282 00817 58668 70312 66617 75720 93458 74491 72624 45673 68051 53523 58745 13730 93676 87636 4 4 19871 89889 70142 63766 71799 97398 23855 08350 11993 16729 23096 75940 45632 05786 46643 52563 30407 28338 4 5 48253 37932 79566 98774 02523 54942 15195 01354 03979 36909 21991 08828 45452 75565 90933 08713 36319 70259 4 6 80828 98357 85671 69918 30878 48784 81471 43729 60566 81014 68445 82593 59634 16601 05712 80642 26928 11496 4 7 09863 88615 26990 94808 32784 51992 60048 09830 75745 30593 64917 90209 55266 57533 68877 37486 91998 30055 4 8 05754 47499 53052 86074 01045 90121 12938 84746 55683 64345 22413 08513 04316 38192 73202 99160 56397 77063 4 9 32883 01773 11423 07799 12268 59983 60446 16744 12452 81457 56278 49040 31680 66267 05187 69329 28067 78017 5 0 82869 70040 36427 18798 57316 09565 11637 30597 11151 46114 30048 60952 48736 39133 79698 90272 80447 88785

26

Seq. No. ID Division Sex Ran Salary Seq. No. ID Division Sex Ran Salary Seq. No. ID Division Sex Ran Salary 1 1 Eng&Prof m 3 $88 51 155 Eng&Prof m 3 $55 101 217 Lit&SocSci m 2 $55 2 2 Medicine f 3 $45 52 156 Biol&Sci m 1 $49 102 218 Medicine m 3 $80 3 9 Medicine m 3 $57 53 157 Eng&Prof m 3 $57 103 219 Eng&Prof m 1 $114 4 11 Medicine m 1 $133 54 158 Medicine m 1 $118 104 220 Lit&SocSci m 1 $63 5 12 Eng&Prof f 2 $71 55 159 Medicine m 3 $84 105 221 Medicine m 1 $112 6 13 Lit&SocSci m 1 $113 56 160 Eng&Prof m 3 $52 106 222 Medicine m 1 $93 7 14 Medicine f 3 $65 57 161 Medicine m 3 $64 107 223 Lit&SocSci m 2 $47 8 15 Biol&Sci m 3 $47 58 162 Eng&Prof m 1 $75 108 224 Biol&Sci m 1 $127 9 16 Lit&SocSci f 3 $39 59 163 Medicine f 1 $87 109 225 Eng&Prof m 2 $121 10 17 Biol&Sci m 1 $74 60 164 Eng&Prof m 3 $58 110 226 Medicine m 3 $58 11 18 Medicine m 1 $88 61 165 Medicine f 3 $39 111 227 Biol&Sci f 3 $97 12 19 Lit&SocSci m 1 $62 62 166 Medicine m 3 $69 112 228 Lit&SocSci m 1 $71 13 37 Lit&SocSci m 1 $49 63 167 Medicine f 2 $46 113 229 Eng&Prof m 1 $72 14 38 Medicine m 3 $88 64 179 Eng&Prof f 1 $86 114 230 Lit&SocSci m 3 $29 15 39 Medicine m 1 $181 65 180 Medicine m 3 $87 115 231 Medicine m 2 $167 16 40 Eng&Prof m 3 $63 66 181 Medicine m 3 $59 116 232 Lit&SocSci m 3 $36 17 41 Medicine m 2 $94 67 182 Eng&Prof f 3 $44 117 233 Medicine m 1 $57 18 42 Eng&Prof m 1 $91 68 183 Medicine m 2 $123 118 234 Biol&Sci m 1 $107 19 43 Medicine m 1 $60 69 184 Lit&SocSci f 3 $37 119 235 Medicine m 2 $88 20 44 Eng&Prof m 3 $55 70 185 Lit&SocSci m 1 $106 120 236 Medicine m 2 $87 21 45 Biol&Sci m 2 $55 71 186 Lit&SocSci m 1 $91 121 237 Lit&SocSci f 2 $43 22 46 Medicine f 1 $106 72 187 Lit&SocSci m 1 $78 122 238 Lit&SocSci m 1 $79 23 47 Medicine m 1 $116 73 188 Biol&Sci m 1 $77 123 239 Medicine m 2 $113 24 48 Medicine m 3 $79 74 189 Medicine m 1 $90 124 240 Medicine m 3 $55 25 49 Lit&SocSci m 1 $61 75 190 Eng&Prof m 2 $71 125 280 Medicine m 3 $57 26 50 Lit&SocSci f 3 $37 76 191 Medicine f 3 $42 126 281 Eng&Prof m 3 $56 27 51 Medicine m 2 $72 77 192 Medicine f 2 $59 127 282 Eng&Prof m 2 $65 28 52 Eng&Prof m 1 $105 78 193 Eng&Prof m 2 $49 128 283 Medicine m 2 $42 29 59 Medicine m 2 $79 79 194 Biol&Sci m 1 $83 129 284 Medicine m 1 $102 30 133 Medicine m 1 $61 80 195 Lit&SocSci m 1 $34 130 285 Medicine f 3 $40 31 134 Medicine m 1 $86 81 196 Medicine f 3 $42 131 286 Eng&Prof m 3 $53 32 135 Biol&Sci m 1 $103 82 197 Medicine m 2 $97 132 287 Medicine m 3 $82 33 136 Lit&SocSci m 1 $48 83 198 Medicine m 1 $109 133 288 Medicine m 2 $64 34 137 Eng&Prof m 2 $64 84 199 Lit&SocSci f 2 $48 134 289 Eng&Prof m 1 $72 35 138 Eng&Prof m 1 $78 85 200 Medicine m 1 $47 135 290 Biol&Sci f 3 $36 36 139 Medicine f 2 $53 86 201 Eng&Prof m 2 $45 136 291 Lit&SocSci f 1 $66 37 140 Biol&Sci m 1 $85 87 202 Medicine m 3 $83 137 292 Medicine f 3 $66 38 141 Eng&Prof m 1 $61 88 203 Medicine m 2 $51 138 293 Medicine m 2 $102 39 142 Medicine m 1 $106 89 204 Biol&Sci m 1 $78 139 294 Biol&Sci m 1 $103 40 143 Lit&SocSci m 2 $60 90 205 Lit&SocSci m 1 $70 140 295 Medicine m 1 $148 41 144 Biol&Sci f 1 $73 91 206 Eng&Prof f 2 $46 141 296 Lit&SocSci f 1 $60 42 145 Medicine m 1 $70 92 207 Eng&Prof m 1 $85 142 297 Lit&SocSci f 3 $46 43 147 Medicine f 3 $32 93 208 Lit&SocSci m 1 $53 143 298 Lit&SocSci f 1 $57 44 148 Lit&SocSci m 2 $49 94 209 Medicine f 3 $40 144 299 Medicine f 2 $50 45 149 Eng&Prof m 3 $43 95 210 Eng&Prof m 1 $87 145 300 Lit&SocSci m 1 $90 46 150 Medicine m 1 $75 96 211 Lit&SocSci m 1 $71 146 301 Eng&Prof m 3 $63 47 151 Lit&SocSci m 1 $92 97 212 Medicine m 1 $75 147 303 Eng&Prof m 1 $80 48 152 Medicine m 2 $107 98 214 Biol&Sci m 1 $85 148 304 Medicine m 3 $56 49 153 Biol&Sci m 2 $57 99 215 Lit&SocSci m 2 $50 149 305 Medicine m 1 $72 50 154 Medicine m 2 $114 100 216 Medicine m 3 $118 150 306 Eng&Prof m 1 $96

Faculty Mem ber Salaries (in $1,000)

27

Seq. No. ID Division Sex Ran Salary Seq. No. ID Division Sex Ran Salary Seq. No. ID Division Sex Ran Salary 151 307 Medicine m 3 $65 201 440 Medicine m 1 $108 251 496 Medicine m 3 $60 152 308 Lit&SocSci m 3 $37 202 441 Lit&SocSci m 1 $48 252 497 Eng&Prof m 1 $86 153 309 Eng&Prof m 1 $127 203 442 Medicine m 3 $85 253 498 Medicine m 1 $134 154 310 Lit&SocSci m 1 $90 204 443 Lit&SocSci m 1 $59 254 499 Medicine f 3 $63 155 311 Lit&SocSci m 3 $45 205 444 Lit&SocSci f 1 $63 255 500 Medicine m 1 $123 156 312 Eng&Prof f 1 $75 206 445 Lit&SocSci f 2 $46 256 501 Medicine m 3 $85 157 313 Medicine m 2 $60 207 446 Medicine f 3 $41 257 502 Medicine f 3 $42 158 314 Lit&SocSci m 2 $57 208 447 Medicine m 3 $71 258 503 Medicine f 2 $83 159 315 Medicine m 1 $129 209 448 Eng&Prof f 3 $44 259 504 Lit&SocSci m 1 $54 160 316 Eng&Prof m 1 $102 210 449 Lit&SocSci m 2 $46 260 505 Lit&SocSci f 1 $66 161 317 Eng&Prof m 3 $57 211 450 Medicine m 3 $85 261 506 Medicine m 1 $84 162 318 Eng&Prof m 3 $61 212 452 Medicine m 1 $119 262 507 Eng&Prof m 3 $46 163 319 Eng&Prof m 1 $93 213 453 Medicine m 2 $69 263 508 Eng&Prof m 1 $90 164 320 Medicine f 3 $41 214 454 Eng&Prof m 3 $74 264 509 Medicine m 2 $76 165 321 Medicine m 1 $181 215 455 Biol&Sci m 1 $59 265 510 Eng&Prof m 1 $88 166 322 Medicine f 2 $69 216 456 Biol&Sci m 1 $53 266 515 Medicine f 1 $87 167 323 Lit&SocSci m 1 $81 217 457 Medicine f 3 $49 267 516 Eng&Prof m 3 $75 168 324 Biol&Sci m 1 $94 218 459 Eng&Prof m 1 $78 268 517 Eng&Prof m 3 $64 169 325 Lit&SocSci m 2 $53 219 460 Biol&Sci m 1 $68 269 518 Biol&Sci f 3 $52 170 326 Medicine m 3 $48 220 461 Eng&Prof m 1 $83 270 519 Medicine m 2 $109 171 327 Lit&SocSci m 1 $83 221 462 Eng&Prof m 1 $105 271 520 Lit&SocSci m 1 $144 172 328 Lit&SocSci m 1 $47 222 463 Lit&SocSci m 3 $37 272 521 Eng&Prof m 2 $79 173 329 Lit&SocSci m 3 $45 223 464 Medicine m 1 $111 273 522 Biol&Sci m 1 $56 174 330 Medicine f 1 $75 224 465 Medicine f 2 $70 274 530 Biol&Sci m 1 $60 175 331 Medicine m 3 $49 225 466 Eng&Prof m 1 $57 275 531 Biol&Sci m 3 $52 176 333 Medicine m 3 $53 226 467 Eng&Prof m 1 $71 276 532 Lit&SocSci f 2 $45 177 334 Eng&Prof m 1 $84 227 468 Biol&Sci m 3 $36 277 533 Lit&SocSci m 1 $59 178 335 Eng&Prof m 1 $78 228 469 Eng&Prof f 3 $43 278 534 Eng&Prof m 3 $56 179 336 Lit&SocSci m 1 $102 229 470 Eng&Prof m 1 $120 279 535 Medicine m 1 $123 180 337 Lit&SocSci f 2 $50 230 471 Lit&SocSci m 1 $66 280 536 Medicine m 2 $75 181 338 Medicine f 2 $49 231 472 Eng&Prof m 1 $84 281 537 Eng&Prof m 1 $84 182 339 Medicine m 1 $54 232 473 Medicine m 2 $99 282 538 Medicine m 2 $70 183 340 Medicine m 3 $35 233 474 Biol&Sci f 1 $91 283 539 Medicine m 3 $84 184 341 Medicine m 2 $87 234 475 Eng&Prof m 2 $105 284 540 Eng&Prof m 1 $63 185 342 Lit&SocSci m 1 $52 235 476 Medicine f 2 $60 285 541 Eng&Prof m 1 $121 186 343 Lit&SocSci m 1 $75 236 477 Medicine f 3 $34 286 542 Medicine m 1 $52 187 344 Medicine f 3 $41 237 478 Medicine f 3 $42 287 543 Biol&Sci m 1 $73 188 345 Eng&Prof m 2 $62 238 479 Medicine m 2 $80 288 544 Eng&Prof f 3 $32 189 346 Medicine m 1 $79 239 480 Medicine m 1 $94 289 545 Eng&Prof f 3 $40 190 347 Biol&Sci m 3 $37 240 481 Biol&Sci m 1 $57 290 546 Biol&Sci m 3 $47 191 348 Lit&SocSci m 3 $44 241 482 Medicine m 1 $82 291 547 Medicine m 1 $112 192 349 Lit&SocSci m 3 $47 242 483 Lit&SocSci m 1 $70 292 548 Biol&Sci m 1 $68 193 353 Medicine m 1 $70 243 484 Lit&SocSci m 1 $75 293 550 Medicine m 2 $93 194 433 Lit&SocSci m 1 $113 244 485 Medicine m 1 $139 294 551 Medicine m 1 $124 195 434 Medicine m 3 $55 245 486 Lit&SocSci m 1 $40 295 552 Lit&SocSci f 2 $49 196 435 Lit&SocSci m 1 $50 246 488 Lit&SocSci m 2 $60 296 556 Medicine f 3 $65 197 436 Lit&SocSci f 2 $54 247 489 Eng&Prof f 1 $128 297 557 Eng&Prof m 1 $84 198 437 Eng&Prof m 3 $53 248 490 Medicine m 3 $47 298 558 Medicine f 2 $71 199 438 Biol&Sci m 1 $79 249 491 Eng&Prof m 3 $67 299 559 Medicine f 3 $40 200 439 Biol&Sci m 2 $53 250 495 Eng&Prof m 1 $90 300 560 Medicine m 2 $70

Faculty Mem ber Salaries (Continued)

28

Seq. No. ID Division Sex Ran Salary Seq. No. ID Division Sex Ran Salary Seq. No. ID Division Sex Ran Salary 301 561 Eng&Prof m 1 $98 351 636 Lit&SocSci f 1 $72 302 562 Lit&SocSci m 1 $89 352 637 Eng&Prof m 1 $94 303 563 Medicine f 3 $36 353 638 Eng&Prof m 3 $52 304 564 Medicine m 1 $63 354 639 Biol&Sci m 1 $66 305 565 Eng&Prof m 2 $74 355 640 Eng&Prof m 3 $68 306 566 Medicine f 3 $38 356 641 Lit&SocSci m 1 $89 307 567 Eng&Prof m 3 $76 357 642 Medicine m 2 $148 308 568 Medicine m 3 $97 358 643 Medicine m 1 $159 309 569 Medicine m 1 $76 359 644 Biol&Sci m 1 $62 310 570 Eng&Prof m 1 $86 360 645 Lit&SocSci m 1 $70 311 571 Medicine m 3 $59 361 646 Medicine f 3 $109 312 572 Medicine f 2 $60 362 647 Eng&Prof m 1 $120 313 573 Lit&SocSci m 2 $45 363 648 Eng&Prof m 1 $112 314 595 Biol&Sci m 2 $56 364 649 Medicine m 2 $90 315 596 Lit&SocSci m 1 $63 365 650 Medicine m 1 $108 316 597 Lit&SocSci m 1 $69 366 651 Eng&Prof m 1 $152 317 598 Eng&Prof m 1 $138 367 652 Medicine f 2 $47 318 599 Lit&SocSci f 3 $31 368 653 Medicine m 1 $116 319 600 Medicine f 2 $50 369 654 Biol&Sci m 1 $77 320 601 Eng&Prof m 1 $89 370 655 Biol&Sci M 1 $57 321 602 Eng&Prof m 1 $148 322 603 Lit&SocSci m 3 $55 323 604 Lit&SocSci m 1 $81 324 605 Lit&SocSci m 1 $52 325 606 Medicine m 3 $85 326 607 Medicine m 1 $132 327 608 Lit&SocSci m 1 $85 328 609 Eng&Prof m 1 $66 329 610 Eng&Prof f 1 $94 330 611 Eng&Prof m 2 $77 331 612 Medicine f 2 $76 332 613 Medicine m 1 $109 333 614 Lit&SocSci m 1 $99 334 616 Eng&Prof f 2 $78 335 617 Eng&Prof m 1 $98 336 618 Medicine f 3 $41 337 619 M edicine f 3 $37 338 620 Eng&Prof m 3 $89 339 622 Biol&Sci m 2 $55 340 623 Lit&SocSc m 1 $52 341 624 Eng&Prof m 3 $42 342 625 Biol&Sci m 2 $52 343 626 Lit&SocSc m 1 $63 344 627 Lit&SocSc m 1 $95 345 628 M edicine f 3 $75 346 629 M edicine f 3 $106 347 630 Lit&SocSc f 3 $44 348 631 Lit&SocSc m 1 $58 349 632 Lit&SocSc m 1 $79 350 633 Lit&SocSc m 1 $135

Faculty Mem ber Salaries (Continued)

• 3. Historical perspective
• Historical development
• The beginnings
• Development
• Divergence
• Framework for comparison
• Selection bias
• Development, part II
• What should we do?

29

Historical development

• Sampling practice:

– Result of attempts to solve practical problems

• Function of theory

– Formalize implicit assumptions, and confirm, correct,

• r extend practice
• Origins

– Data gathering

• health and social problems
• social physics

– Census – Monography

30

The beginnings

• Berne, 1895

– Kaier at ISI: Representative method

• Miniature of country
• Large number of units
• Use prior information in selection

– Von Mayr and others

• No calculation where observation is possible
• Cf. Godambe, Basu after 1950

– Cheysson and others

• Monography: detailed examination of typical cases

31

Development

• 1903 ISI Resolution

– Four implicit principles

• Representative
• Objective
• Measurability
• Specification

– Actuality

• Multistage proportionate stratified samples (no theory)

32

Divergence

• Representative

– Purposive sampling – Expert choice – Balanced sampling

• Objective

– Randomized selection – Bowley, 1906 (colleague

• f R.A. Fisher)

33

Separation

• ISI Commission 1926 report

– Sampling established as basis for information collection – Equal status given to random and purposive sampling – No theory for unequal sized clusters

• No basis for comparing the two

methodologies

34

Framework for comparison

• Neyman, 1934
• The sampling distribution

– Properties of sample under repeated sampling

• All possible samples and their associated probabilities
• f occurrence

– The sampling distribution of an estimator

35

Conditions for inference

• Conditions under which different procedures

will produce valid estimates

– Probability sampling

• “Unbiased” irrespective of population structure

– Purposive/balanced/quota sampling

• Tough assumptions about population structure, unlikely

to be achieved in practice

36

Selection bias

• Italian census storage problem
• Sample of completed forms to be retained
• Gini and Galvani, 1929

– Matched sample communes on 7 variables – Other variables, even aspects other than means of 7 variables, showed wide deviations from population values

37

What should we do?

• Probability sampling for objectivity
• Stratification for precision

(representativeness)

• Variance estimation from the sample
• Complete and comprehensible description of

the sampling procedure

38

39

• 4. Element samples
• Element samples
• The sampling distribution
• Properties of the sampling distribution
• Central limit theorem
• Properties of the sample mean for SRS
• Estimation of variance
• Determination of sample size
• Formulas
• Exercise 2

40

Element samples

• A sample design for which the unit of

selection is the population element

• Basic framework: Neyman, 1934

– Must be applicable to all populations – Must not depend on assumptions about the population structure – Appropriate for large populations of elements

41

Element samples

• Repeated sampling

– Objective (mechanical) selection of elements – Consider possible outcomes of the sampling process – Evaluation of the whole set of possible outcomes

42

The sampling distribution

• The set of all possible values of the estimator

that can be obtained with a given sample design

– For a given sample we obtain a particular value, the estimate (such as )

• We want to know …

– … how likely is the estimate to be close to the population value

y

43

Sample realization

• In fact, we select just one sample
• The estimate may be correct, or incorrect
• Want to maximize the probability of a

satisfactory estimate

44

Properties of the sampling distribution

• Unbiasedness

– Expected value (average value):

• Variability from one sample to another

– Variance of the estimator – The square root of the variance is called the standard error

• f the estimator:
• Measurable design

– A design for which the variance can be estimated from the sample itself

 

E y

( ) Var y

( ) Var y

45

Central limit theorem

• For large samples, the sampling distribution of

is Normal

• Confidence intervals

y

(1 /2)

( ) y z Var y

 



46

Properties of the sample mean for SRS

• Unbiased
• Variance

– Consider

• – Where and

 

E y

2

( ) 1 n S Var y N n        

1 1 n f N   

2

S

n

 

2 2 1

1 1

N i i

S Y Y N



   

 

2

1 S P P  

47

Estimation of variance

• Can use (sample) to estimate (population)
• Estimate of (population)

– (sample)

• From a single sample we can not only estimate

using but also estimate the precision of using

• Note that and for a

proportion

2

s

2

S

2

( ) 1 n s var y N n        

2

( ) 1 n S Var y N n        

Y y y

( ) var y

 

2 2 1

1 1

n i i

s y y n



   

 

2

1 s p p  

48

Determination of sample size

• What sample size do we need to obtain a given

standard error of the estimator?

• population variance known (or guessed)

– Census – Other surveys – Administrative records

• Desired standard error

– Policy requirements in terms of – Decision making requirements

2

S

( ) Var y

49

Sample size formulas

• In general,
• For an infinitely large population (or for

sampling with replacement), this is

• We can calculate the necessary sample size to

achieve variance as

2

( ) 1 n S Var y N n        

2

( ) S Var y n 

 

Var y

 

2

n S Var y 

50

Sample size formulas (continued)

• In general (that is, not assuming N is large),

the variance may be expressed as

– Where

2 2

( ) 1 ' n S S Var y N n n         

' 1 n n n N        

51

Sample size formulas (continued)

• We can compute the necessary as
• To calculate the n necessary for a population
• f a particular size, we use the formula

' ' 1 n n n N  

' n  

2

' S n Var y 

52

Exercise 2

• The variability in income levels is comparable

across many countries

• For a country with a value of (which

would give ), we want an estimate of the mean income which has a standard error ( ) of 50.

• Answer the following questions in groups:

2,000 S 

2

4,000,000 S 

 

Var y

53

Exercise 2 (continued)

Calculate the sample size needed in China with N = 1,400,000,000? What about in the US where N = 320,000,000? What about in Qatar where N = 1,700,000? What about in a small city where N = 100,000? What about in a small town where N = 10,000?

54

• 5. Systematic sampling
• Systematic sampling
• Problems with intervals in systematic sampling
• Solutions
• Exercise 3

55

Systematic sampling

• A simple method of selecting a sample from a

list

• Once the first element is chosen, every k th

element is selected by counting through the list sequentially

• In probability sampling, the first element is

chosen at random

56

Sampling intervals

• Determine the sampling interval
• Select a random number (RN) from 1 to k
• Add k repeatedly
• Example:

– N = 12,000 dwellings in a city – Sample of n = 500 required – k = 12,000/500 = 24 – Take a RN from 01 to 24, say 03 – Take the third dwelling, and every 24th thereafter: 3, 27, 51, etc.

k N n 

57

Problems with intervals

• Take 1 in k where
• k may not be an integer
• Examples

– N = 9, n = 2, and k = 4.5 – N = 952, n = 200, and k = 4.76 – N = 170,345, n = 1,250, and k = 136.272 k N n 

58

Solutions: round sampling interval

• Round the fractional interval

– Let the sample size vary, depending on the choice of the “integer interval” k – Example: N = 9, n =2, take k = 4 or 5

• If k = 4 and RN = 1, the sample is elements 1, 5, 9.
• If RN = 2, 3, or 4, the sample has only two elements
• If k = 5 and RN = 1, 2, 3, or 4, the sample has two elements
• If RN = 5, the sample has only one element

– Under this method, what happened when N = 952 and n = 200? – What about for N = 170,345 and n = 1,250?

59

Solutions: elimination or duplication

• Eliminate, or duplicate, population elements

by epsem to get exact multiple

– Example: N = 9 and n = 2. Eliminate one of 9 at random, and take 1 in 4 of remaining 8. – If N = 952 and n = 200, duplicate 48 at random, and take 1 in 5 from the 1,000 listed elements – If N = 170,345 and n = 1,250, eliminate 345 at random, and take 1 in 136 of the remainder

60

Solutions: circular list

• Treat the list as circular
• Select one element at random from anywhere
• n the list
• Take every [k]th thereafeter, where [k] is an

integer near N/n, until n selections are made

61

Exercise 3

• Consider again the list of 370 faculty member

salaries given in Exercise 1 (slides 23‐25)

• Suppose again we seek a sample of n = 20 from

this list Each group should select two systematic samples of n = 20 from the list using as random starts the next appropriate numbers from the random number table (slide 22) ‐‐ that is, the next random number after the last one used in Exercise 1

62

Exercise 3 (continued)

Each group should select two systematic samples of n = 20 from the list using as random starts the next appropriate numbers from the random number table (slide 22) ‐‐ that is, the next random number after the last one used in Exercise 1 Since N/n is not an integer, use for one sample the rounding method (letting the sample size vary depending

• n the choice of k) for the first sample

And the circular list method for the second sample For each sample, compute the mean salary

20 1

1 20

i i

y y







63

• 6. Cluster sampling
• Cluster sampling
• Equal‐sized cluster sampling
• Effective sample size
• Design effect
• Intra‐class correlation
• Exercise 4

64

Cluster sampling

• Populations widely distributed geographically
• Cannot afford to visit n sites drawn randomly

from the entire area

• Cluster sampling reduces the cost of data

collection

– Sample schools and children within them – Sample blocks and households within them

65

Cluster sampling

• Cluster sampling is also useful when the sampling

frame lists clusters and not elements

– Select clusters and list elements in selected clusters – Frame of blocks: list households within selected blocks

• Clusters are often naturally occurring units

– Facilitates sample selection

66

Cluster sampling

• Suppose we select an SRS of a = 10 classrooms

from A = 1,000, and examine the immunization history of all b = 24 children in selected classrooms

• Here
• We refer to the A classrooms as primary

sampling units or PSU’s 240 n a b   

67

Cluster sampling

• For each of the a = 10 selected PSU’s, we

record the number of children immunized:

• Adding the numerators, there are 160

immunized children

• The overall proportion immunized is

9 11 13 15 16 17 18 20 20 21 , , , , , , , , , 24 24 24 24 24 24 24 24 24 24

160/ 240 0.67 p  

68

Cluster sampling

• Recall for SRS (without replacement selection
• f n elements), the sample mean was
• The estimated sampling variance is
• But for an SRS of a equal‐sized clusters from A,

we have a for each selected PSU

1 n i i

y y n





   

2

var 1 y f s n   p

69

Cluster sampling: variance estimation

• In cluster sampling, treat the sample as an SRS
• f a units from A:

– Where

• That is,

 

2

1 var( )

a

f p s a  

   

2 2 1

1

a a

s p p a

 

  



/ f a A 

   

2 1

1 var( ) 1

a

p p f p a a

 

   



70

Cluster sampling: estimated variance

• For the illustration,

       

2 2 2 2

1 9 160 11 160 10 1 24 240 24 240 0.02816 var 1 0.002760 var 0.0525

a a

s p f s a se p p                                 

71

Design effect

• If the sample had instead been an SRS of n =

240 children from all schools, then

     

160/ 240 1 var 1 1 0.0009112

SRS

p p p p f n      

72

Design effect

• Compared to cluster sampling, the estimated

variance of p is considerably smaller for SRS

• A ratio quantifies the comparison:

     

var 0.002760 3.029 var 0.0009112

SRS

p deff p p   

73

roh

• The design effect is a function of …

– the size of the clusters b – the degree of homogeneity of elements within clusters

• The homogeneity is measured by the intra‐

cluster correlation roh

• The design effect is given by

   

1 1 deff p b roh   

74

Estimating roh

• The intra‐cluster correlation can be estimated

from the design effect:   1

1 3.029 1 24 1 0.088 deff p roh b       

75

Features of roh

• roh is a property of the clusters and the variable

under study

• roh is substantive, not statistical
• roh is nearly always positive

– Elements in a cluster tend to resemble one another

• Source of roh

– Environment – Self‐selection – Interaction

76

Magnitude of roh

• Magnitude depends on

– The characteristic (variable) under study (e.g., disease status, age) – The nature of the clusters (e.g., households, establishments) – The size of the cluster (e.g., household, blocks of household, census tracts)

77

Effective sample size

• Alternatively, the actual sample size is n = 240

in the cluster sample, but an SRS that is equally precise would only have to have

240 79 3.209

eff

n  

78

Examples

• Consider alternative outcomes for our sample
• f a = 10 classrooms

– Homogeneity with, heterogeneity between

16 24 24 24 24 24 24 , , , , , , , , , 24 24 24 24 24 24 24 24 24 24

23.90 1 0.996 24 1 roh    

23.90 deff 

240/ 23.9 10

eff

n  

 

2

0.2222 var 0.02178

a

s p  

79

Examples

• Heterogeneity within, homogeneity among:

16 16 16 16 16 16 16 16 16 16 , , , , , , , , , 24 24 24 24 24 24 24 24 24 24

deff 

240/ 0

eff

n 

 

2

0.0 var 0.0

a

s p  

80

Exercise 4

• An equal probability (epsem) sample of n =

2,400 was obtained from a one‐stage sample

• f 60 equal‐sized clusters selected by SRS
• In a journal article describing survey results,

we found the following information

– For a key proportion, p = 0.40 – And

Estimate deff and roh

 

var 0.00021795 p 

81

• 7. Two‐stage sampling
• Two‐stage sampling
• Portability of roh
• Exercise 5

82

Two‐stage sampling

• Selecting many elements per cluster increases

variances

• Even small values of roh can be magnified by

large b since

• Consider the following for

   

1 1 deff p b roh   

240 n a b   

240 1 1000 24 24000 24000 100 a b a b f      

83

Subsamples of size b

• Sample a = 20 classrooms and b = 12:
• Sample a = 30 classrooms and b = 8:
• Sample a = 80 classrooms and b = 3:

   

1 12 1 0.088 1.97 122

eff

deff p n      

   

1 8 1 0.088 1.62 148

eff

deff p n      

   

1 3 1 0.088 1.18 204

eff

deff p n      

84

Portability of roh

• Estimation
• Design

 

2 (1)

1 var ( )

a

f p s a  

 

(1), (1)

1 var ( )

SRS

p p y n  

(1) (1) (1),

var ( ) var ( )

SRS

p deff p 

(1) (1)

1 1 deff roh b   

roh

(2) (2)

1 ( 1) deff b roh   

 

(2), (2)

1 var ( )

SRS

p p y n  

(2) (2) (2),

var ( ) var ( )

SRS

p deff p  

85

Exercise 5

• Suppose the sample described in Exercise 4

(with n = 2,400 and a = 60) is to be repeated with a smaller sample of n =1,200 and in only a = 30 equal‐sized clusters Project how large the sampling variance of p will be under this new design.

86

Exercise 5 (continued)

• Now suppose the reduced size of n = 1,200 is

retained, but we want to consider a = 60 equal‐sized clusters. Project how large the sampling variance of p will be under this new design.

87

• 8. Probability proportionate to size

sampling

• Unequal‐sized cluster sampling
• Sampling with fixed rates
• Control of subsample size
• Selection of fixed size subsamples
• PPS sampling
• Systematic PPS sampling
• Exercise 6

88

Unequal‐sized cluster sampling

• Naturally occurring clusters tend to be

unequal in size

• Fixed sampling rates and unequal sized

clusters result in variation in sample size

89

Consider the following sample of 12 schools:

School School 1 2 3 4 5 6 308 823 146 809 827 775 7 8 9 10 11 12 393 148 321 393 207 850

a

B

a

B

90

Fixed rate sample

• An epsem sample of n = 100 students is to

be selected from the N = 6,000 students in the 12 schools:

• Two stages: Select a = 2 schools, say an SRS
• f a = 2 schools (a rate of 2/12 = 1/6)
• And then choose students at the rate 1/10

within the selected schools

100 6000 1/ 60 f  

   

1 6 1/10 1 60 f   

91

Unequal subsample sizes

• Suppose schools 3 and 8 are chosen

– Subsampling at the rate of 1/10 yields sample size

• On the other hand, if schools 5 and 12 were

chosen instead,

• Subsample size varies from 29 to 143 …

– Sample administration becomes difficult

 

146 148 /10 14.6 14.8 29.4 n     

 

727 750 /10 72.7 75 142.7 n     

92

Sample size variation

• Variation in the overall sample size is

undesirable

• Since n is a random variable, no

longer applies

• We need to use a ratio estimator

1

1

n i i

y y n



      

1 1 a a

y y r x x

     

 

 

93

Control of subsample size

• In the survey literature, we need to find a

way to control the sample size – keep it from varying

• A controlled sample size provides

administrative convenience in fieldwork

• It also has greater statistical efficiency
• Several methods – we discuss two

– Select exactly b elements per cluster – Probability proportionate to size (PPS)

94

Selection of fixed subsample sizes

• Suppose a = 2 schools are chosen at

random

• And b = 50 students are chosen at random

per selected school

• Sample size is n = 2 x 50 =100

– Sample size does not vary across samples!

• But this design, on average across, all

possible samples, over‐represent students in small schools

– Why?

95

Selection of fixed subsample sizes

• For example, for school 3,
• While for school 12,
• If students in large schools are different than

those in small, we have bias

• The bias can be taken care of through

weighting (later discussion)

  

1 6 50 146 1/17.52 f  

  

1 6 50 750 1/ 90 f  

96

PPS

• Require a method that is equal chance for

students (epsem)

• And still achieves equal sized subsamples

– And thus achieves fixed sample sizes

• Again, consider a = 2 and b = 50
• “Selection equation:”

 

1 50 60 f P B



   

97

PPS: Achieving epsem

• For example, if school 1 is chosen, then
• In order to make this epsem for students,

we need for each school to be selected with probability …

   

1 50 1 60 308 6.16 f P P       

   

1 50 1 60 60 50 3000 B B P OR P B

  

      

98

PPS: Selection by size

• Re‐expressing this in terms of selecting both

schools,

• In general, this becomes, across two stages,

 

2 2 6000 B B P B

   

     

 

a a

a B b a b n f P and B B B N

   

        

 

99

PPS selection of schools

School Cum.

1 2 3 4 5 6 7 8 9 10 11 12 308 823 146 809 827 775 393 148 321 393 207 850 308 1131 1277 2086 2913 3688 4081 4229 4550 4943 5150 6000  702  1744

B



B



100

PPS:Choosing schools

• Select Random Numbers (RN’s) from 1 to 6000:

– RN = 702 – RN = 1744

• Find the first school with cumulative sum greater

than or equal to the first RN

• Find the next school with sum greater than the

second RN

• These choose hospitals 2 and 4:

101

Systematic PPS

• How can we avoid selecting the same school

twice?

• Systematically: select one RN from 1 to the

interval 6000/2 = 3000

– Say RN = 702

• Find the selected school, as above (school 2)
• Add the interval to the RN to obtain 702 + 3000 =

3702

• Find the second school with this selection

number, as above, school 7

• RN 702 leads to the selection of schools 2 & 7

102

Exercise 6

• A two‐stage epsem sample of 200 students is to

be selected from the following 10 schools with 4,588 total students Select two schools from this list with PPS using two Random Numbers (taken from the Table of Random Digits for Exercise 1). What is the within school sampling rate for the first selected school? Select two schools using systematic PPS.

103

School Um Hakeem Ahmad Bin Hanbal Independent AlShamal Khaleefa Lusail AlTijara Qatar Independent Campus Bilal Bin Rabah Al Shahhaniya Independent AlFatat AlMuslima 261 677 965 406 427 661 169 285 662 75 Total 4,588

B



104

• 9. Stratified random sampling
• Stratification
• Advantages
• Stratification – an

example

• Stratified sample
• SRS
• Design effect
• Effective sample size
• Problems
• Multipurpose surveys
• Domains of study
• Proportionate stratified

sampling

• Disproprotionate

stratification

• Exercise 7

105

Stratification

• Procedure

– Form strata – Independent selection within each – Estimate for stratum h, – Overall estimate

• Where

h

y

1 H h h h

y W y



 

h h

W N N 

106

Variance

• For the overall sample estimate
• With estimated variance

   

2 1 H h h h

Var y W Var y





   

2 1 H h h h

var y W var y





107

Formation of strata

• Strata should be internally homogeneous
• Strata should differ as much as possible from each
• ther
• Advantages

– Gains in precision – Administrative convenience – Guaranteed representation of important domains – Acceptability/credibility – Flexibility

108

Stratification – an example

Population Stratum 1 Qatari Stratum 2 White & Blue Collar Expatriate (Other) Size N 1,000,000 200,000 800,000 Variance 1,800,000 4,000,000 1,000,000 Mean 1,400 3,000 1,000

1

N

2

N

2 1

S

2 2

S Y

1

Y

2

Y

2

S

109

Stratified sample

• What will be ?

1 2

240, 960 n n  

( ) Var y          

2 2 2 1 2 2 2 2 1 1 1 2 2 2 2 2

( ) 1 0.2 4000000 / 240 0.8 1000000 / 960 666.7 666.7 1333

h h h h h

Var y f W S n W S n W S n



        



110

SRS

• For What will be ?

1200 n 

( )

SRS

Var y

     

2

1 1800000 1 1200 1000000 1200 1800000 1500 1200

SRS

Var y f S n      

111

Design effect

• As for cluster sampling,
• For this example,

     

SRS

Var y for a given design deff y Var y of same size 

     

1333 1500 0.89

SRS

Var y deff y Var y   

112

Effective sample size

• What sample size with SRS would be

necessary to achieve the same precision (variance) as the given design?

• Effective sample size:
• For our example,

 

eff

n n deff y  1200 0.89 1348

eff

n  

113

Problems

• Availability of data

– Census – Administrative reports – Other surveys

• Multipurpose surveys

– Survey of households in Qatar – Fixed assets, buildings, use of expatriate labor, expenditures, income, health, health care use, psychological well‐being, social integration

114

Problems

• Domains of study

– Subpopulations for which separate estimates are required – Geographic subdivisions such as provinces, districts, subdistricts – Socio‐demographic characteristics, such as age groups, occupation, income, education

115

Proportionate stratified sampling

• Same sampling fraction in all strata
• Variance
• Compare

h h h

f n N n N f   

     

2 2 2 1 1

1 1

H H h h h h h h h

f Var y f W S n W S n

 

   

 

     

2 2 1 2

1

SRS H h h h

f Var y S n W S deff y S



   

116

Disproportionate stratification

• Purposes

– Gains in precision for overall estimator – Precision for comparisons – Precision for domains

• Factors to consider

– Size of strata – Variability within strata – Cost within strata

h

W

2 h

S

h

c

117

Exercise 7

Calculate for each of the following combinations of sample sizes across the two strata:

 

Var y

1 2

100 1100 n n  

1 2

240 960 n n  

1 2

400 800 n n  

1 2

600 600 n n  

1 2

960 240 n n  

118

• 10. Frame problems
• Frame problems
• Objective respondent selection

119

Frame problems

• Frame: set of materials used to designate a

sample of units

• Simple list, or set of materials such as maps,

lists, rules for linking frame elements to population elements, etc.

• Accurate, up‐to‐date frames in single location,

arranged suitably for selection

– Numbered or computerized lists useful

120

Four types of frame problems

• Consider the following list of housing units

in Doha

• Interested in sampling persons within these

housing units

• The question is whether there are any of

the following types of problems on the frame:

– Non‐coverage – Blanks – Duplicates – Clusters

121

ResidenceID City Street ResidenceType Nationality Persons 1 Doha Wahb Villa Non-Qataris 3 2 Doha Wahb Villa Non-Qataris 6 3 Doha Wahb Villa Non-Qataris 3 4 Doha Wahb Villa Qataris 5 5 Doha Wahb Villa Non-Qataris 5 6 Doha Wahb Villa Non-Qataris 5 7 Doha Wahb Villa Non-Qataris 3 8 Doha Wahb Villa Non-Qataris 5 9 Doha Wahb Villa Qataris 13 10 Doha Wahb Villa Non-Qataris 6 11 Doha Wahb Villa Non-Qataris 3 12 Doha Wahb Villa Non-Qataris 5 13 Doha Wahb Villa Non-Qataris 4 14 Doha Wahb Villa Non-Qataris 3 15 Doha Al Quds Villa Non-Qataris 4 16 Doha Al Quds Villa Non-Qataris 5 17 Doha Al Quds Villa Qataris 8 18 Doha Al Quds Villa Non-Qataris 2 19 Doha Al Quds Villa Non-Qataris 3 20 Doha Al Quds Villa Non-Qataris 5

122

ResidenceID City Street ResidenceType Nationality Persons 21 Doha Al Quds Villa Non-Qataris 4 22 Doha Al Quds Villa Non-Qataris 4 23 Doha Al Quds Villa Non-Qataris 4 24 Doha Al Quds Villa Qataris 3 25 Doha Al Quds Villa Non-Qataris 1 26 Doha Al Quds Villa Non-Qataris 4 27 Doha Al Quds Villa Qataris 5 28 Doha Al Quds Villa Non-Qataris 3 29 Doha Al Quds Villa Non-Qataris 3 30 Doha Al Quds Villa Non-Qataris 5 31 Doha Murwab Villa Qataris 4 32 Doha Murwab Villa Non-Qataris 2 33 Doha Murwab Villa Non-Qataris 5 34 Doha Murwab Villa Non-Qataris 2 35 Doha Murwab Villa Non-Qataris 5 36 Doha Murwab Villa Non-Qataris 2 37 Doha Murwab Villa Non-Qataris 3 38 Doha Murwab Villa Non-Qataris 5 39 Doha Murwab Villa Non-Qataris 4 40 Doha Murwab Villa Non-Qataris 4

123

Non‐coverage

• Some elements of the population are not

contained on the frame

– Housing units not appearing on the list – Remedies

• Use a frame that provides complete coverage
• Supplement the existing frame with other frames
• Use “population control adjustment weights” to

compensate in analysis

124

Blanks

• List elements for which there are no eligible

members of the population

– Voter has moved – Remedies

• Reject blank listings
• Variation in sample size (smaller than desired): select

additional listings

• Avoid selecting next element on list

125

Duplicates

• Population element appears more than once
• n the list

– Introduces unequal probabilities of selection – Housing unit appears more than once – Person living in two different addresses – Remedies

• Determine number of times element is on list, and

weight

• Modify address list to eliminate duplicates

126

Clustering

• More than one population element is

associated with a single list element

– Variation in sample size – Remedies

• Subsample clusters, and weight results by the inverse of

the probability of selection

• Accept variation in sample size

127

Within Household Selection: Objective Respondent Selection

• Remedy for selecting elements from small

clusters, objectively in field settings

• Not epsem
• Suppose there are a maximum of four age‐

eligible persons per household

• Consider the following listing and selection

table:

128

Relationship to informant Age Gender 1 2 3 4

129

Respondent selection table

If number of eligible subjects is … … then select subject number … 1 2 3 4 1 2 3 3

130

Interviewer instructions

• Interviewer:

– List eligible household members by gender and age – Follow the instructions on the selection table to determine whom to interview

• This scheme is based on a set of 6 tables

which are rotated among households to achieve the desired probabilities of selection for each subject:

131

Respondent selection tables

Table A (1/4) If number of eligible subjects is Select subject number 1 2 3 4 1 1 1 1 Table B (1/12) If number of eligible subjects is Select subject number 1 2 3 4 1 1 1 2 Table C (1/6) If number of eligible subjects is Select subject number 1 2 3 4 1 1 2 2 Table D (1/6) If number of eligible subjects is Select subject number 1 2 3 4 1 2 2 3 Table E (1/12) If number of eligible subjects is Select subject number 1 2 3 4 1 2 3 3 Table F (1/4) If number of eligible subjects is Select subject number 1 2 3 4 1 2 3 4

132

• 11. Weighting
• Weighting to compensate for within

household selection

• Exercise 8
• Weighting to compensate for unequal

selection probabilities: over‐ and under‐ sampling

• Weighting to compensate for nonresponse
• Poststratification

133

Weighting

• Among four problems, two remedies involve

weighting to compensate for unequal selection probabilities

• Weights common in survey practice

– Within household selection – *Duplication of elements on the frame* – Over or under sampling – Nonresponse – Poststratification

134

f=n/N F=N/n n N Sampling Procedure: List sample Population Sample ? N

135

Weighting for within household selection

• As long as the sampling is epsem …

–

• Then
• For example, from N = 2000 adults, select n = 20 with

epsem

• Each adult represents themselves and 99 others

i

f n N     

1 2

1 1 1

i n

y y y y y n       



  20 1 100 2000 100

i i

and w    

136

Non‐epsem estimation

• But the mapping may not be equal for every

element

• A weighted estimator is required:
• When the weights are constant, they cancel

1 2 20

100 100 100 100 1 100 1 100 1

i i i w i i

w y y y y y w              

 

 

137

Within household sampling

• Suppose a sample of 20 households are

selected

• For 8 households, 1 adult: 3 reported being
• utside the country in the past year
• For 6 households, 2 adults: 3 outside
• For 4 households, 3 adults: 3 outside
• For 2 households, 4 adults: 2 outside

138

Probability of selecting adults

• When 1 adult in the household, two stages of

selection and

• When 2 adults in the household,
• When 3 adults in the household,
• When 4 adults in the household,

  

20 2000 1 1 1 100 100

i i

w    

  

20 2000 1 2 1 200 200

i i

w    

  

20 2000 1 3 1 300 300

i i

w    

  

20 2000 1 4 1 400 400

i i

w    

139

ID Response (Y) Housing unit prob.

• No. persons 18+

Weight

1 1 0.01 1 100 2 1 0.01 1 100 3 0.01 1 100 4 0.01 1 100 5 0.01 1 100 6 0.01 1 100 7 1 0.01 1 100 8 1 0.01 1 100 9 0.01 2 200 10 0.01 2 200 11 1 0.01 2 200 12 0.01 2 200 13 0.01 2 200 14 1 0.01 2 200 15 0.01 3 300 16 1 0.01 3 300 17 1 0.01 3 300 18 1 0.01 3 300 19 1 0.01 4 400 20 1 0.01 4 400

140

Weighted or unweighted estimate

• This can be represented in the weighted mean

(proportion of adults who recycle) as

• The corresponding unweighted mean is

100 1 100 1 400 1 0.65 100 1 100 1 100 4

i i i w i i

w y y w               

 

  1 1 1 0 1 0.55 20

i i y

y n         





141

Exercise 8

• Selected a sample of 20 households
• Selected one person 15 years or older (15+)

in each

• Asked them whether they had been outside

Qatar in the past year:

142

ID Response (Y) Housing unit prob.

• No. persons 18+

Weight

1 1 Unknown, but equal 5 2 Unknown, but equal 4 3 1 Unknown, but equal 4 4 Unknown, but equal 4 5 Unknown, but equal 3 6 Unknown, but equal 4 7 1 Unknown, but equal 11 8 1 Unknown, but equal 5 9 Unknown, but equal 2 10 Unknown, but equal 2 11 1 Unknown, but equal 4 12 Unknown, but equal 3 13 Unknown, but equal 2 14 1 Unknown, but equal 6 15 Unknown, but equal 2 16 1 Unknown, but equal 5 17 1 Unknown, but equal 3 18 1 Unknown, but equal 3 19 1 Unknown, but equal 4 20 1 Unknown, but equal 2

143

Exercise 8 (continued)

Compute the weights for each sample person. Compute an unweighted estimate of the proportion who have been outside in the past year Compute a weighted estimate of the proportion who have been outside in the past year

144

Over‐ and under‐ sampling

• The basic approach above has been to weight

by

– Count an element times

• Consider the following population and sample

distribution for persons 15 years and older (15+) in Qatar comparing Qatari and White and Blue Collar Expatriates (Other):

1

i

 1

i



145

Group N n Sampling rate Weight A Weight B Qatari Other 150,000 1,350,000 125 875 1/1,500 1/1,500 1,500 1,500 1 1 Total 1,500,000 1,000 1/1,500 1,500 1

146

Sample selection

• This is a proportionate allocation, with equal

probabilities in each group

• Some investigators might prefer that the

distribution in the sample be equal across the two groups:

147

Group N n Sampling rate Weight A Weight B Qatari Other 150,000 1,350,000 500 500 1/300 1/2,700 300 2,700 1 9 Total 1,500,000 1,000 1/1,500 1,500

148

Proportionate v. equal allocation

• The equal allocation would be used for

comparing the two groups

• The proportionate allocation would be used to

represent the population

• Consider the consequences of the equal

allocation when estimating “proportion never married” among, again, 15+, across the two groups:

149

Proportionate allocation

Group Never married Proportionate allocation Weights n Never married A B Qatari Other 0.400 0.305 170 830 0.400 0.305 1,500 1,500 1 1 Total 0.315 1,000 0.315

150

Equal allocation

Group Never married Dispro- portionate allocation Weights Weighted estimate n Never married A B Qatari Other 0.400 0.305 500 500 0.400 0.305 300 2,700 1 9 (500)(1)(0.400) (500)(9)(0.305) Total 0.315 1,000 0.353

• - --

0.315

151

Restoring the balance

• Weights will restore the balance to the

population distribution:

( ) ( ) ( ) ( )

0.400 0.305 0.353 1 (0.400) 9 (0.305) 0.315 1 9 300 (0.400) 2700 (0.

i i B i w(B) i B i A i w(A) i A

y 500 x + 500 x y = = = n 500 + 500 y w = y w 500 x x + 500 x x = = 500 x + 500 x y 500 x x + 500 x x w = = y w      305) 0.315 300 2700 = 500 x + 500 x

152

Weights in practice

• Is it necessary to weight, even when unequal

probabilities are involved?

• Descriptive statistics require weights

– Otherwise, estimates will be biased

• Analytic statistics are more controversial

– Comparing income between Latino and non‐Latino groups – no need to weight – Comparing income between male and female respondents in the same sample requires weighting

153

Effect of weights

• Often the effect of weights is not large for

descriptive statistics

• If not large, analysts may decide not to use

weights

– Use of weights more difficult historically because

• f lack of software to handle weights

– Duplication factors used

154

Weighting for nonresponse

• Suppose that not everyone in the sample of

1,000 drawn from our two groups responded

• Ignoring nonresponse produces slightly biased

estimates when averaging across the now disproportionately distributed groups:

155

Group n r Weight A Never marri ed Weighted estimate Qatari Other 500 500 450 350 1 9 0.400 0.305 (450)(1)(0.400) (350)(9)(0.305) Total 1,000 800

• 0.315

0.317

156

Nonresponse weights

• Compute weighted response rates in each group
• Adjust the base weights (those computed to

compensate for unequal probabilities of selection) for nonresponse

• Assumption: data is missing at random (MAR) within

subgroups

• Response rate in each group is a “sampling rate”

under the MAR assumption

157

Group Qatar Other 1 9 450 350 0.90 0.70 1.11 1.43 1.11 12.86 Total 800 0.80

h

n

h

r

 

1 h

r

 1 i i h

w w r 

1i

w

158

Nonresponse weights

• These nonresponse adjusted weights ‘restore the

balance’:

( ) ( )

4 0.400 3 0.305 0.358 4 35 45 1.11 (0.400) 35 12.86 (0.305) 0.315 45 1.11 35 12.86

i i B i w(B) i B

y 50 x + 50 x y = = = n 50 + y w = y w 0 x x + 0 x x = = 0 x + 0 x   

159

Poststratification

• Poststratification is used to make the

weighted sample distribution conform to a known population distribution

• Adjust the nonresponse adjusted weights
• Suppose that gender in the sample does not

agree with known gender distributions in the population:

160

Gende r Male Female 500 300 0.615 0.375 1,222,000 278,000 0.815 0.185 1.320 0.490 Total 800 1.000 1,500,000 1.000

• g

n

g

N

g

p

g

P

g g g

w P p 

161

A final weight

• In poststratification, the weights for the

individuals in groups are adjusted up or down to obtain the distribution of the sum of weights that corresponds to the population distribution

• The final weight is an adjustment of the

baseline weight for nonresponse and poststratification:

162

Group/Gender Qatari Male Female 215 235 1.11 x 1.320 = 1.465 1.11 x 0.490 = 0.549 Other Male Female 285 65 12.86 x 1.320 = 16.975 12.86 x 0.490= 6.301 Total 800

hg

n

hg

w

163

• 12. Variance estimation
• Sampling error
• General sample design
• Variance estimation
• Simple replicated sampling
• Problems with simple replicated estimates
• Three methods of variance estimation
• Comparison of methods
• Computer software

164

Sampling error

• Problem

– Many variables in a single survey – Many subclasses (domains) of interest – Fairly complex designs – Enormous computing task

• Requirement

– Practical and efficient methods of variance estimation – Computer programs to implement them

165

General sample design

• Stratified
• Clustered

– Primary stage units – b elements within each PSU

• Weights
• Sampling methods

– Over representation of domains – Optimum allocation (rarely)

• Nonresponse
• Poststratification

166

Variance estimation

• Durbin, 1952

– If clusters (PSU’s) selected independently, variance can be estimated using only PSU totals – Variance estimate contains the contribution of later stages of subsampling – For rapid methods of variance estimation, no components of variance are needed

167

Simple replicated subsampling

• Alternative approaches based on ‘repetition’
• c independent subsamples (replicates)

selected under same design from population

• Estimate some statistic Z
• Each replicate provides
• Compute

i

z

   

 

 

2

1 var( ) 1 1

i i i i

z c z z c c z z    

 

168

Three general estimators

• Taylor series expansion

– Approximate analytic solution

• Balanced repeated replication (BRR)

– Based on replicated sampling, but actually replicated subsampling

• Jackknife repeated replication (JRR)

– Simplified form of replicate formation: drop out one – General methodology developed for another purpose – has broad application

169

Comparison of methods

• Empirical studies conducted for variety of statistics

and methods of variance estimation

– Mean square errors (MSE) of variance estimates favor Taylor series – Coverage properties of confidence intervals favor BRR

• All three methods reasonably good for

– Correlation coefficients – Ratio means – Regression coefficients

• Taylor series most versatile, with respect to sample

designs

– Jackknife is the most general approach

170

Computer programs

• Standard statistical packages such as SPSS, SAS,

Stata, assume SRS by default

• Necessary input to compute sampling errors

– PSU for every element – Stratum for every element – Weight for every element – At least two PSU’s per stratum

• See American Statistical Association web site for

comprehensive review:

http://www.hcp.med.harvard.edu/statistics/survey‐soft/

171

• 13. Survey sampling textbooks

172

• Barnett, V. (1974). Elements of Sampling Theory. London: English Universities
• Press. A short introduction to topics in sampling theory.
• Cassell, C‐M., Sarndal, C‐E., and Wretman, J.J. (1977). Foundations of

Inference in Survey Sampling. New York: J.W. Wiley and Sons, Inc. Theoretical treatment of survey sampling inference, including issues such as admissibility

• f estimators.
• Cochran, W.G. (1977). Sampling Techniques, 3rd edition. New York: J.W.

Wiley and Sons, Inc. Excellent and widely used text on the basic theory for sampling techniques.

• Deming, W.E. (1950). Some Theory of Sampling. New York: Dover. Text on

sampling theory and practice.

• Deming, W.E. (1960). Sample Design in Business Research. New York: J.W.

Wiley and Sons, Inc. Text on sampling theory and practice, with emphasis on replicated sampling methods. Recently released by Wiley as a paperback Classics edition.

173

• Hajek, J. (1981). Sampling from a Finite Population. New York: Marcel
• Dekker. A monograph on sampling theory from an advanced perspective.
• Hansen, M.H., Hurwitz, W.N., and Madow, W.G. (1953). Sample Survey

Methods and Theory. Volume I: Methods and Applications. Volume II: Theory. New York: J.W. Wiley and Sons, Inc. Classic two volume text on sampling practice and theory that is considered still to be the standard.

• Jessen, R.J. (1978). Statistical Survey Techniques. New York: J.W. Wiley and

Sons, Inc. An intermediate text on sampling with a presentation of lattice sampling methods.

• Kalton, G. (1983). Introduction to Survey Sampling. Beverly Hills, CA: Sage
• Publications. Short non‐mathematical treatment of sampling. A Sage

mongraph.

• Kish, L. (1965). Survey Sampling. New York: J.W. Wiley and Sons, Inc.

Comprehensive text on sampling practice, about to be issued as a paperback Classic edition.

174

• Konijn, H.S. (1973). Statistical Theory of Sample Survey Design and Analysis.

New York: American Elsevier. Advanced text on sampling theory.

• Levy, P.S. and Lemeshow, S. (1991). Sampling of Populations: Methods and
• Applications. New York: J.W. Wiley and Sons, Inc. Intermediate level text on

sampling methods.

• Lohr, Sharon L. (1999). Sampling: Design and Analysis. Pacific Grove, CA:

Duxbury Press. Intermediate level text blending theory and practice, including exercises and sample data sets for analysis of survey data.

• Moser, C.A. and Kalton, G. (1971). Survey Methods in Social Investigation,

2nd edition. London: Heinemann. Text on survey methods with a non‐ mathematical introduction to sampling methods.

• Murthy, M.N. (1967). Sampling Theory and Methods. Calcultta: Statistical

Publishing Society. Advanced text on sampling theory and practice.

• Raj, D. (1968). Sampling Theory. New York: McGraw Hill. Advanced text on

sampling theory.

175

• Raj, D. (1972). The Design of Sample Surveys. New York: McGraw‐Hill, Inc.

Two part text: the first is an intermediate‐level text on sampling practice, and the second presents surveys applications.

• Särndal, C‐E. SwenÑson, B. and Wretman, J. (1991). Model Assisted Survey
• Sampling. New York: Springer‐Verlag. Advanced text on sampling methods.
• Scheaffer, R.L., Mendenhall, W., and Ott, L. (1990). Elementary Survey

Sampling, 4th edition. Boston: PWS Kent. Elementary text requiring minimal mathematical background.

• Stuart, A. (1984). The Ideas of Survey Sampling, revised edition. London:
• Griffin. Short text that illustrates the basic concepts of sampling with a small

numerical example.

• Sudman, S. (1976). Applied Sampling. New York: Academic Press.

Intermediate‐level text on sampling practice.

• Sukhatme, P.V., Sukhatme, B.V., Sukhatme, S., and Asok, C. (1984). Sampling

Theory of Surveys with Applications, 3rd edition. Ames, Iowa: Iowa State University Press. Advanced text on sampling theory with important treatments on ratio estimation.

176

• Thompson, S.K. (1992). Sampling. New York: J.W. Wiley and Sons, Inc.

Intermediate‐level text on sampling methods, including a number used widely in the natural sciences, and a discussion of adpative sampling techniques.

• Williams, W.H. (1978). A Sampler on Sampling. New York: J.W. Wiley and

Sons, Inc. Intermediate‐level treatment of sampling methods.

• Yamane, T. (1967). Elementary Sampling Theory. Englewood Cliffs, NJ:

Prentice Hall. An introductory text that provides a mix theory and simple illustrations; useful for students with limited mathematical backgrounds.

• Wolter, K.M. (1985). Introduction to Variance Estimation. New York:

Springer‐Verlag. Comprehensive treatment of variance estimation for survey sampling.

• Yates, F. (1981). Sampling Methods for Censuses and Surveys, 4th edition.

London: Griffin. Advanced text on sampling practice.
