SLIDE 1

2012-11-14 1 Silvia Stefanova, UDBL - IT - UU

DATABASE DESIGN I - 1DL300

Autumn 2012

An Introductory Course on Database Systems

http://www.it.uu.se/edu/course/homepage/dbastekn/ht12/ Uppsala Database Laboratory Department of Information Technology, Uppsala University, Uppsala, Sweden

SLIDE 2

2012-11-14 2 Silvia Stefanova, UDBL - IT - UU

Introduction to Relational Algebra

Elmasri/Navathe ch 6 Padron-McCarthy/Risch ch 10 Silvia Stefanova

Department of Information Technology Uppsala University, Uppsala, Sweden

SLIDE 3

2012-11-14 3 Silvia Stefanova, UDBL - IT - UU

Outline

1. Why and what about the Relational Algebra
2. Unary operations
Select operation
Project operation
3. Set operations
Union
Intersection
Set difference (Minus)
4. Cartesian product
5. Join operator
Join
Natural join
Outer join
6. Exercises

SLIDE 4

2012-11-14 4 Manivasakan Sabesan- UDBL - IT - UU

Relational algebra

Relational algebra is a procedural language
Operations in relational algebra takes two or more relations as

arguments and return a new relation.

Relational algebraic operations:

– Operations from set theory:

Union, Intersection, Difference, Cartesian product

– Operations specifically introduced for the relational data model:

Select, Project, Join
It have been shown that the select, project, union, difference, and

cartesian product operations form a complete set. That is any other relational algebra operation can be expressed in these.

SLIDE 5

2012-11-14 5 Silvia Stefanova, UDBL - IT - UU

Outline

1. Why and what about the Relational Algebra
2. Unary operations
Select operation
Project operation
3. Set operations
Union
Intersection
Set difference (Minus)
4. Cartesian product
5. Join operator
Join
Natural join
Outer join
6. Exercises

SLIDE 6

2012-11-14 6 Manivasakan Sabesan- UDBL - IT - UU

Select operation

The select operator, σ, selects a specific set of tuples from a relation

according to a selection condition (or selection predicate P).

Notation: σ<select condition> (R)
The result relation has the same number of attributes as the initial

relation

Example: σ pnumber=9012034455(Person)

SLIDE 7

2012-11-14 7 Silvia Stefanova, UDBL - IT - UU

Relations to work on

id name phone 1 Susan 100 2 Barbara 200 3 Ricardo 200

Teachers

id sname sphone 2 Barbara 200 4 Jimmy NULL 7 Anna 800

Students

cname code tid Database Design 1 DB1 1 Database Design 2 DB2 1 Distributed Systems DS 3

Courses

student course 4 DB1 4 DS 7 DS 7 DB2

Attending

FK, course_taught_by FK, student_attends FK, course_to_attend

SLIDE 8

2012-11-14 8 Manivasakan Sabesan- UDBL - IT - UU

SELECT operation - examples

? Retrieve (select) teachers whose phone number is > = 200 ? Retrieve (select) students with the name ‘Jimmy’ ? Retrieve (select) teachers with name ‘Barbara’ and phone number is > = 200

SLIDE 9

2012-11-14 9 Manivasakan Sabesan- UDBL - IT - UU

Project operation

The project operator, Π, picks out (or projects) listed columns from a

relation and creates a new relation consisting of these columns.

Notation: Π <attribute list> (R)
The result relation is a new relation consisting of the projected

columns

It doesn’t return the duplicates
Example: Π Lname,Fname,Salary (Employee)

SLIDE 10

2012-11-14 10 Manivasakan Sabesan- UDBL - IT - UU

Relational algebra expressions- examples

? Retrieve (select) the names of the teachers whose phone number is > = 200 ? Is it possible in the example above to do the projection before the selection ? Why or why not ?

SLIDE 11

2012-11-14 11 Silvia Stefanova, UDBL - IT - UU

Outline

1. Why and what about the Relational Algebra
2. Unary operations
Select operation
Project operation
3. Set operations
Union
Intersection
Set difference (Minus)
4. Cartesian product
5. Join operator
Join
Natural join
Outer join
6. Exercises

SLIDE 12

2012-11-14 12 Silvia Stefanova, UDBL - IT - UU

Set operations

Relations are required to be union compatible to be able to take

part in the union, intersection and difference operations.

Two relations R1 and R2 is said to be union-compatible if:

R1  D1 × D2 ×... × Dn and R2  D1 × D2 ×... × Dn i.e. if they have the same degree and the same domains.

SLIDE 13

2012-11-14 13 Silvia Stefanova, UDBL - IT - UU

Union operation

The union of two union-compatible relations R and S is the set
f all tuples that either occur in R, S, or in both.
Notation: R  S
The duplicates don’t exist in the union.
Example:

id sname sphone 2 Barbara 200 4 Jimmy NULL 7 Anna 800

Students 

id name phone 1 Susan 100 2 Barbara 200 3 Ricardo 200

Teachers =

id sname sphone 2 Barbara 200 4 Jimmy NULL 7 Anna 800 1 Susan 100 3 Ricardo 200

SLIDE 14

2012-11-14 14 Silvia Stefanova, UDBL - IT - UU

Intersect operation

The intersection of two union-compatible sets R and S, is the set
f all tuples that occur in both R and S.
Notation: R ∩ S
Example:

id sname sphone 2 Barbara 200 4 Jimmy NULL 7 Anna 800

Students ∩

id name phone 1 Susan 100 2 Barbara 200 3 Ricardo 200

Teachers =

id sname sphone

SLIDE 15

2012-11-14 15 Silvia Stefanova, UDBL - IT - UU

Difference operation

The difference of two union-compatible relations R and S is the

set of all tuples that occur in R but not in S.

Notation: R - S
Example:

id sname sphone 2 Barbara 200 4 Jimmy NULL 7 Anna 800

Students -

id name phone 1 Susan 100 2 Barbara 200 3 Ricardo 200

Teachers =

id sname sphone

SLIDE 16

2012-11-14 16 Silvia Stefanova, UDBL - IT - UU

Outline

1. Why and what about the Relational Algebra
2. Unary operations
Select operation
Project operation
3. Set operations
Union
Intersection
Set difference (Minus)
4. Cartesian product
5. Join operator
Join
Natural join
Outer join
6. Exercises

SLIDE 17

2012-11-14 17 Silvia Stefanova, UDBL - IT - UU

Cartesian product

The Cartesian product of R and S combines all tuples from R

with all tuples from S.

Notation: R x S
Example:

id name phone 1 Susan 100 2 Barbara 200 3 Ricardo 200

Teachers

cname code tid Database Design 1 DB1 1 Database Design 2 DB2 1 Distributed Systems DS 3

Courses x

SLIDE 18

2012-11-14 18 Silvia Stefanova, UDBL - IT - UU

Cartesian product

The result is a new relation with (3+3) attributes and (3*5) tuples

cname code tid id name phone Database Design 1 DB1 1 1 Susan 100 Database Design 1 DB1 1 2 Barbara 200 Database Design 1 DB1 1 3 Ricardo 200 Database Design 2 DB2 1 1 Susan 100 Database Design 2 DB2 1 2 Barbara 200 Database Design 2 DB2 1 3 Ricardo 200 Distributed Systems DS 3 1 Susan 100 Distributed Systems DS 3 2 Barbara 200 Distributed Systems DS 3 3 Ricardo 200

Courses x Teachers

SLIDE 19

2012-11-14 19 Silvia Stefanova, UDBL - IT - UU

Outline

1. Why and what about the Relational Algebra
2. Unary operations
Select operation
Project operation
3. Set operations
Union
Intersection
Set difference (Minus)
4. Cartesian product
5. Join operator
Join
Natural join
Outer join
6. Exercises

SLIDE 20

2012-11-14 20 Silvia Stefanova, UDBL - IT - UU

Join

The join operator creates a new relation by combining tuples from

two relations that satisfy a condition

Notation: R <join condition> S
Example:

id name phone 1 Susan 100 2 Barbara 200 3 Ricardo 200

tid=id Teachers

cname code tid Database Design 1 DB1 1 Database Design 2 DB2 1 Distributed Systems DS 3

Courses

SLIDE 21

2012-11-14 21 Silvia Stefanova, UDBL - IT - UU

Join

The result is a relation with (3+3) attributes

Courses tid=id Teachers cname

code tid id name phone Database Design 1 DB1 1 1 Susan 100 Database Design 1 DB1 1 2 Barbara 200 Database Design 1 DB1 1 3 Ricardo 200 Database Design 2 DB2 1 1 Susan 100 Database Design 2 DB2 1 2 Barbara 200 Database Design 2 DB2 1 3 Ricardo 200 Distributed Systems DS 3 1 Susan 100 Distributed Systems DS 3 2 Barbara 200 Distributed Systems DS 3 3 Ricardo 200

SLIDE 22

2012-11-14 22 Manivasakan Sabesan- UDBL - IT - UU

Join

? Receive the same result by using x and σ ! ? Why do we need if this can be done by x and σ ?

SLIDE 23

2012-11-14 23 Silvia Stefanova, UDBL - IT - UU

Theta join

Notation: R  C S

C is the join condition which has the form Ar  As , where  is

ne of {=, <, >, ≤, ≥, ≠}. Several terms can be connected as

C1 AND C2 AND … Ck

A join operation with this kind of general join condition is called

Theta join. A≤F =

A B 1 1 1 6 9 2 2 2 7 7 C D 3 3 3 8 8 2 7 7 7 7 A B 1 6 9 2 7 7 C 3 8 8 D E 2 7 7 3 3 8 F 4 5 9

R A≤F S

E 3 3 8 8 8 F 4 5 9 9 9

R S

SLIDE 24

2012-11-14 24 Silvia Stefanova, UDBL - IT - UU

Equijoin

Notation: R  C S
In C the only comparison operator is =

B=C =

A B a a 2 4 C D 2 4 d d A B a a 2 4 C D 2 4 9 d d d E e e e

R B=C S

E e e

R S

SLIDE 25

2012-11-14 25 Silvia Stefanova, UDBL - IT - UU

Natural join

Natural join is equivalent with the application of join to R and S

with the equality condition Ar = As (i.e. an equijoin) and then removing the redundant column As in the result.

Notation: R *Ar,As S

Ar,As are attribute pairs that should fulfill the join condition which has the form Ar = As. B=C =

A B a a 2 4 D d d A B a a 2 4 C D 2 4 9 d d d E e e e

R B=C S

E e e

R S

SLIDE 26

2012-11-14 26 Silvia Stefanova, UDBL - IT - UU

Natural join

cname code tid id name phone Database Design 1 DB1 1 1 Susan 100 Database Design 2 DB2 1 1 Susan 100 Distributed Systems DS 3 3 Ricardo 200

Courses * tid=id Teachers

SLIDE 27

2012-11-14 27 Silvia Stefanova, UDBL - IT - UU

Outer join

Extensions of the join operations that avoid loss of information.
Computes the join and then adds tuples from one relation that do

not match tuples in the other relation to the result of the join.

Fills out with null values:

 null signifies that the value is unknown or does not exist.  All comparisons involving null are false by definition.

SLIDE 28

2012-11-14 28 Silvia Stefanova, UDBL - IT - UU

Outer join

Left Outer join

loan borrower

loan borrower (left outer join)

branch-name Downtown Redwood Perryridge loan-number 1-170 L-230 L-260 amount 3000 4000 1700 customer-name Jones Smith Hayes loan-number 1-170 L-230 L-155 customer-name Jones Smith null loan-number 1-170 L-230 null branch-name Downtown Redwood Perryridge loan-number 1-170 L-230 L-260 amount 3000 4000 1700

SLIDE 29

2012-11-14 29 Manivasakan Sabesan- UDBL - IT - UU

A task

? Retrieve the names of the teachers teaching DB1!

id name phone 1 Susan 100 2 Barbara 200 3 Ricardo 200

Teachers

id sname sphone 2 Barbara 200 4 Jimmy NULL 7 Anna 800

Students

cname code tid Database Design 1 DB1 1 Database Design 2 DB2 1 Distributed Systems DS 3

Courses

student course 4 DB1 4 DS 7 DS 7 DB2

Attending

FK, course_taught_by FK, student_attends FK, course_to_attend

SLIDE 30

2012-11-14 30 Silvia Stefanova, UDBL - IT - UU

Relational Algebra

Exercises on RA expressions:

Find the codes of the courses taken by the student having the name “Jimmy”. Retrieve the names and phones of the students who are taking a database course

(“Database Design 1” or “Database Design 2” ).

List the students, names and phones of the teacher “Susan”. Retrieve the phones of the teachers who are students as well.

T1 T2 T3 T4

SLIDE 31

2012-11-14 31 Silvia Stefanova, UDBL - IT - UU

Boyce-Codd Normal Form - BCNF

BCNF: A relation is in BCNF if: – It is in 1NF – Every determinant is a candidate key. Normalization: Decompose the relation so that after joining the new relations spurious tuples will not be generated ( lossless join decomposition )

Teach

department course teacher Computing Science Database 1 Sara S Computer Systems Database 1 Sara S Engineering Signals and Systems Peter E Computing Science Database 2 Sven P

SLIDE 32
