INTRODUCTION TO MUSICAL TIMBRE

YU / LAMONT FEBRUARY 20, 2018

LINGUIST 197M, SPRING 2018. CLASS 5.1

SLIDE 2

LINGUIST 197M, SPRING 2018. CLASS 5.1

CHROME MUSIC LAB: PIANO ROLL

2

http://musiclab.chromeexperiments.com/Piano-Roll

SLIDE 3

LINGUIST 197M, SPRING 2018. CLASS 5.1

CHROME MUSIC LAB: SPECTROGRAM

3

http://musiclab.chromeexperiments.com/Spectrogram

SLIDE 4

4

BRIEF REMINDER: HARMONICS AND COMPLEX WAVES

SLIDE 5

LINGUIST 197M, SPRING 2018. CLASS 5.1

FROM PURE TONES TO COMPLEX WAVES

5

http://musiclab.chromeexperiments.com/Sound-Waves

SLIDE 6

LINGUIST 197M, SPRING 2018. CLASS 3.1

EXERCISE: SOUND OF ADDING IN HARMONICS

6

https://soundphysics.ius.edu/?page_id=949

Can you adjust the amplitudes

f the harmonics to get the

timbre to sound like some instrument you like?

SLIDE 7

LINGUIST 197M, SPRING 2018. CLASS 3.1

DEMO: COMPLEX WAVES

7

https://musiclab.chromeexperiments.com/Oscillators

SLIDE 8

LINGUIST 197M, SPRING 2018. CLASS 3.1

BUILDING UP A SQUARE WAVE WITH SINES

8

https://en.wikipedia.org/wiki/User:LucasVB/Gallery#/media/File:Synthesis_square.gif

SLIDE 9

LINGUIST 197M, SPRING 2018. CLASS 3.1

BUILDING UP A SQUARE WAVE

9

https://en.wikipedia.org/wiki/User:LucasVB/Gallery#/media/File:Fourier_transform_time_and_frequency_domains.gif

SLIDE 10

LINGUIST 197M, SPRING 2018. CLASS 3.1

TWO REPRESENTATIONS OF SQUARE WAVE

10

https://en.wikipedia.org/wiki/User:LucasVB/Gallery#/media/File:Fourier_transform_time_and_frequency_domains.gif

Time domain: waveform Frequency domain: spectrum

SLIDE 11

LINGUIST 197M, SPRING 2018. CLASS 3.1

HARMONIC AMPLITUDES

11

https://sites.google.com/a/georgiasouthern.edu/julia-inozemtseva/teaching-math-animations-and-pics? tmpl=%2Fsystem%2Fapp%2Ftemplates%2Fprint%2F&showPrintDialog=1#TOC-Fourier-Series

SLIDE 12

LINGUIST 197M, SPRING 2018. CLASS 3.1

BUILDING UP A TRIANGLE WAVE WITH SINES

12

https://en.wikipedia.org/wiki/User:LucasVB/Gallery#/media/File:Fourier_transform_time_and_frequency_domains.gif

SLIDE 13

LINGUIST 197M, SPRING 2018. CLASS 5.1

ADDITIVE SYNTHESIS

13

http://meettechniek.info/additional/additive-synthesis.html

Can you use an additive synthesizer to try to replicate the timbre of an instrument?

SLIDE 14

14

RESONANCE

SLIDE 15

LINGUIST 197M, SPRING 2018. CLASS 5.1

RESONANCE

15

Rossing (1990): The Science of Sound.

Resonance occurs when a force applied to a vibrating system varies with a frequency at or near the natural frequency of a system

http://stmary.ws/HighSchool/Physics/home/notes/waves/animations/AnimFact/ swing_set_playground_traci_closeup_hg_wht.gif

SLIDE 16

LINGUIST 197M, SPRING 2018. CLASS 5.1

BREAKING A WINE GLASS WITH SOUND

16

http://courses2.cit.cornell.edu/physicsdemos/secondary.php?pfID=17

SLIDE 17

LINGUIST 197M, SPRING 2018. CLASS 5.1

STRING RESONANCE

17

Strings naturally vibrate at a fundamental frequency, and at harmonics that are integer multiples of the fundamental

https://upload.wikimedia.org/wikipedia/commons/5/5c/Standing_waves_on_a_string.gif

SLIDE 18

LINGUIST 197M, SPRING 2018. CLASS 5.1

CHROME MUSIC LAB: STRING RESONANCE

18

https://musiclab.chromeexperiments.com/Strings https://musiclab.chromeexperiments.com/Harmonics

SLIDE 19

LINGUIST 197M, SPRING 2018. CLASS 5.1

MOVIES: STRING RESONANCE

19

https://youtu.be/ttgLyWFINJI https://youtu.be/oZ38Y0K8e-Y?t=8s

SLIDE 20

LINGUIST 197M, SPRING 2018. CLASS 5.1

STRING RESONANCE: CALCULATIONS

20

How long is the wavelength relative to the length

f the string for the fundamental?

https://upload.wikimedia.org/wikipedia/commons/5/5c/Standing_waves_on_a_string.gif

The “length” of a standing wave vs. the cycle “length” of a traveling wave: wavelength in space is like period in time for a traveling wave

SLIDE 21

LINGUIST 197M, SPRING 2018. CLASS 5.1

SYMPATHETIC VIBRATION: TUNING FORKS

21 https://youtu.be/zWKiWaiM3Pw

Other fun resonance videos at: http://blog.prosig.com/2011/09/20/5-videos-that-explain- resonance/

SLIDE 22

LINGUIST 197M, SPRING 2018. CLASS 5.1

EXAMPLE: SYMPATHETIC RESONANCE

22

B resonates to A if B’s vibrations make A vibrate too. Effect: B has more energy than it did The closer B’s natural frequency is to A’s the stronger the vibrations of B

22

SLIDE 23

23

WAVEFORMS, SPECTRA, AND SPECTROGRAMS

SLIDE 24

LINGUIST 197M, SPRING 2018. CLASS 5.1

SYNTHESIZE A VOCALIC SOUND…

24

SLIDE 25

LINGUIST 197M, SPRING 2018. CLASS 5.1

REVIEW: FIND PERIOD FROM THE WAVEFORM

25

What are the x- and y-axes in the waveform? What’s that blue line?

SLIDE 26

LINGUIST 197M, SPRING 2018. CLASS 5.1

REVIEW: TAKE SPECTRAL SLICE (SPECTRUM)

26

Make sure you select a window of at least 5 cycles of the waveform to take the spectral slice over!

SLIDE 27

LINGUIST 197M, SPRING 2018. CLASS 5.1

REVIEW: UNDERSTANDING THE SPECTRUM

27

Make sure to zoom in on the spectrum! What are the axes? How far apart are two adjacent spectral peaks and why?

SLIDE 28

LINGUIST 197M, SPRING 2018. CLASS 5.1

NEW: THE SPECTROGRAM!

28

SLIDE 29

LINGUIST 197M, SPRING 2018. CLASS 5.1

NEW: THE SPECTROGRAM!

29

SLIDE 30

30

FROM THE SPECTRUM TO THE SPECTROGRAM

SLIDE 31 0.0 0.5 1.0 1.5 2.0

1.0

0.5 t f = 1 Hz 0.0 0.5 1.0 1.5 2.0

1.0

0.5 t f = 2 Hz 0.0 0.5 1.0 1.5 2.0

1.0

0.5 t f = 3 Hz 0.0 0.5 1.0 1.5 2.0

1.0

0.5 t f = 4 Hz

f = 1 Hz f = 2 Hz f = 3 Hz f = 4 Hz

SLIDE 32

LINGUIST 197M, SPRING 2018. CLASS 5.1

SPECTRUM OF COMPLEX WAVEFORM

32

0.0 0.5 1.0 1.5 2.0 5 10 15 20 t wave.complex

1 2 3 4 Amplitude (dB) 1 Frequency (Hz) Amplitude (dB) Time (s)

SLIDE 33

LINGUIST 197M, SPRING 2018. CLASS 5.1

SPECTRUM OF COMPLEX WAVEFORM

33

0.0 0.5 1.0 1.5 2.0 5 10 15 20 t wave.complex

1 2 3 4 Amplitude (dB) 1 Frequency (Hz) Amplitude (dB) Time (s)

Waveform: x-axis is time Spectrum: x-axis is frequency

SLIDE 34

LINGUIST 197M, SPRING 2018. CLASS 5.1

FROM SPECTRUM TO SPECTROGRAM: STEP 1

34

1 2 3 4 Amplitude (dB) 4 3 2 1 Freq (Hz) 1 2 3 4 Amplitude (dB) 4 3 2 1 Freq (Hz) Rotate clockwise

SLIDE 35

LINGUIST 197M, SPRING 2018. CLASS 5.1

FROM SPECTRUM TO SPECTROGRAM: STEP 2

35

1 2 3 4 Frequency (Hz) 1 2 3 4 Amplitude (dB) 1 2 3 4 Amplitude (dB) 4 3 2 1 Freq (Hz) Flip vertically

SLIDE 36

LINGUIST 197M, SPRING 2018. CLASS 5.1

FROM SPECTRUM TO SPECTROGRAM: STEP 3

36

1 2 3 4 Frequency (Hz) 1 2 3 4 Amplitude (dB) 1 2 3 4 Encode amplitude levels (the height/ length of the blue spikes) in grayscale* *or with heat map

SLIDE 37

LINGUIST 197M, SPRING 2018. CLASS 5.1

FROM SPECTRUM TO SPECTROGRAM: STEP 4

37

1 2 3 4 Frequency (Hz) 1 2 3 4 Frequency (Hz) 1 2 3 4 Amplitude (dB) Encode amplitudes in grayscale… …at time t1

SLIDE 38

LINGUIST 197M, SPRING 2018. CLASS 5.1

FROM SPECTRUM TO SPECTROGRAM: STEP 5

38

1 2 3 4 Frequency (Hz) Line up spectral slices taken over time… t1 t2 t3 t4 t5 t6

SLIDE 39

LINGUIST 197M, SPRING 2018. CLASS 5.1

FROM SPECTRUM TO SPECTROGRAM: FINIS

39

…and you have a spectrogram

Time (s) 0.8772 1.128 5000 Frequency (Hz)

SLIDE 40

40

MUSICAL INSTRUMENTS AND TIMBRE

SLIDE 41

LINGUIST 197M, SPRING 2018. CLASS 5.1

RECORDINGS OF INSTRUMENTS IN PRAAT

41

Homework: bring in a musical instrument Thursday! Let’s do some recordings of your musical instruments in Praat!

SLIDE 42

LINGUIST 197M, SPRING 2018. CLASS 5.1

REAL-TIME OSCILLOSCOPE

42

http://academo.org/demos/virtual-oscilloscope/

SLIDE 43

LINGUIST 197M, SPRING 2018. CLASS 5.1

REAL-TIME SPECTRUM ANALYZER

43

http://academo.org/demos/spectrum-analyzer/

SLIDE 44

LINGUIST 197M, SPRING 2018. CLASS 5.1

REAL-TIME SPECTRUM ANALYZER II

44

http://musiclab.chromeexperiments.com/Spectrogram
