2013-01-21 1 Silvia Stefanova, UDBL - IT - UU

DATABASE DESIGN I - 1DL300

Spring 2013

An Introductory Course on Database Systems

http://www.it.uu.se/edu/course/homepage/dbastekn/vt13/ Uppsala Database Laboratory Department of Information Technology, Uppsala University, Uppsala, Sweden

2013-01-21 2 Silvia Stefanova, UDBL - IT - UU

Introduction to Database Technology

Elmasri/Navathe ch 1-2 Padron-McCarthy/Risch ch 1 Sobhan Badiozamany Silvia Stefanova

Department of Information Technology Uppsala University, Uppsala, Sweden

2013-01-21 3 Silvia Stefanova, UDBL - IT - UU

Outline

• 1. Data Model, Database Schema
• Categories of data models
• Database schemas and instances
• 2. Data Independence
• Three-schema architecture
• Logical independence
• Physical independence
• 3. Database Languages
• 4. Classification of DBMS
• 5. To Summarize

2013-01-21 4 Silvia Stefanova, UDBL - IT - UU

Outline

• 1. Data Model, Database Schema
• Data models, categories of data models
• Database schemas and instances
• 2. Data Independence
• Three-schema architecture
• Logical independence
• Physical independence
• 3. Database Languages
• 4. Classification of DBMS
• 5. To Summarize

2013-01-21 5 Silvia Stefanova, UDBL - IT - UU

Data Model ???

2013-01-21 6 Silvia Stefanova, UDBL - IT - UU

Data Model

• Data Model: A collection of concepts that can be used to

describe the structure of database

• Data Model consists of
• Set of concepts: data types, relationships, constraints
• Set of basic operations for specifying retrievals and updates on

the database

• Every database has a data model which makes it

possible to “hide” the physical representation of data

2013-01-21 7 Silvia Stefanova, UDBL - IT - UU

Categories of data models

• High-level (conceptual) : close to how users perceive

data

• ER (Entity-Relationship) model
• Low-level (physical): details of how data is stored on

computers

• Representational (implementation): in between

conceptual and physical

• Relational (ORACLE, DB2, SQL Server, MySQL, Mimer)
• Object-oriented (ObjectStore, Objectivity, Versant, Poet)
• Object-relational (Informix, Odapter, DB2)
• Hierarchical (IMS)
• Network (IDMS)

2013-01-21 8 Silvia Stefanova, UDBL - IT - UU

What is the difference between database and database description ?

2013-01-21 9 Silvia Stefanova, UDBL - IT - UU

Database Schema and Instances

• Database schema: the database description specified

during the database design and not expected to change

• The actual data in the database may change frequently
• Database instance (state): the data in the database at a

particular moment. Every change of data creates a new instance of the database.

• Valid state: satisfies the structure and constraints in the

database schema

• Meta-data: description of the schema (data about data)

2013-01-21 10 Silvia Stefanova, UDBL - IT - UU

Outline

• 1. Data Model, Database Schema
• Categories of data models
• Database schemas and instances
• 2. Data Independence
• Three-schema architecture
• Logical independence
• Physical independence
• 3. Database Languages
• 4. Classification of DBMS
• 5. To Summarize

2013-01-21 11 Silvia Stefanova, UDBL - IT - UU

Three-schema Architecture

Conceptual schema

Database instance Internal level Conceptual level External level End users view1 view2 … … … viewn

Internal schema

2013-01-21 12 Silvia Stefanova, UDBL - IT - UU

Three-schema Architecture

• Internal level
• Described the physical storage structure of the database
• Uses a physical data model (internal schema)
• Conceptual level
• Describes the structure of the whole database for community
• f users; describes entities, data types, relationships, user
• perations
• Uses a representation data model
• External (view) level
• Describes the part of the database that a particular user group

is interested in; hides the rest from that group

• Has a number of external schemas

2013-01-21 13 Silvia Stefanova, UDBL - IT - UU

What is the goal with the three-schema architecture?

2013-01-21 14 Silvia Stefanova, UDBL - IT - UU

Data Independence

• Data Independence: The capacity to change the

schema at one level of a database system without having to change at the next higher level

2013-01-21 15 Silvia Stefanova, UDBL - IT - UU

Data Independence

• Logical Independence: The capacity to change the

conceptual schema without having to change the external schema

• Example: Add another field to a conceptual schema
• Physical Independence: The capacity to change the

internal schema without having to change the conceptual schema

• Example: Put an access path(index) to reorganize the files

2013-01-21 16 Silvia Stefanova, UDBL - IT - UU

Outline

• 1. Data Model, Database Schema
• Categories of data models
• Database schemas and instances
• 2. Data Independence
• Three-schema architecture
• Logical independence
• Physical independence
• 3. Database Languages
• 4. Classification of DBMS
• 5. To Summarize

2013-01-21 17 Silvia Stefanova, UDBL - IT - UU

Database Languages

• Database Language: Generic term for a class of

languages used for defining, communicating with or manipulating a database.

• Storage Definition Language (SDL) – to specify internal

schema

• Data Definition Language (DDL) – to specify

conceptual schema

• View Definition Language (VDL) – to specify user

views

• Data Manipulation Language (DML) – to manipulate

the data: insert, delete , update)

2013-01-21 18 Silvia Stefanova, UDBL - IT - UU

Database Languages

• In the DDL the database administrator define the

internal and conceptual schema and in this manner the database is designed. Subsequent modifications in the schema design is also made in DDL.

• The DML used by DB users and application programs

retrieve, add, remove, or alter the information in the database.

• SQL represents a combination of DDL, VDL and DML

2013-01-21 19 Silvia Stefanova, UDBL - IT - UU

Outline

• 1. Data Model, Database Schema
• Categories of data models
• Database schemas and instances
• 2. Data Independence
• Three-schema architecture
• Logical independence
• Physical independence
• 3. Database Languages
• 4. Classification of DBMS
• 5. To Summarize

2013-01-21 20 Silvia Stefanova, UDBL - IT - UU

Classification of DBMS

• Criteria data model:
• Relational DBMS
• Object-oriented DBMS
• Object-relational DBMS
• Graph DBMS
• Criteria number of sites on which database is distributed
• Centralized DBMS
• Distributed DBMS

2013-01-21 21 Silvia Stefanova, UDBL - IT - UU

Classification of DBMS

• Criteria number of users:
• Single-user DBMS
• Multi-user DBMS
• Criteria purpose
• General purpose DBMS
• Special-purpose DBMS

2013-01-21 22 Silvia Stefanova, UDBL - IT - UU

Outline

• 1. Data Model, Database Schema
• Categories of data models
• Database schemas and instances
• 2. Data Independence
• Three-schema architecture
• Logical independence
• Physical independence
• 3. Database Languages
• 4. Classification of DBMS
• 5. To Summarize

2013-01-21 23 Silvia Stefanova, UDBL - IT - UU

Summary

• Data model
• Database schema, database instance
• Data independence

2013-01-21 24 Silvia Stefanova, UDBL - IT - UU

Components of a DBMS (Figure 2.3 Elmasri/Navathe)
