SLIDE 1
Implicit Reparameterization Gradients — Michael Figurnov
Implicit Reparameterization Gradients Michael Figurnov, Shakir - - PowerPoint PPT Presentation
Implicit Reparameterization Gradients Michael Figurnov, Shakir - - PowerPoint PPT Presentation
Implicit Reparameterization Gradients Michael Figurnov, Shakir Mohamed, Andriy Mnih Poster: Room 210 #33 Reparameterization gradients Core part of variational autoencoders, automatic variational inference, etc. Backpropagation in graphs with
SLIDE 2
SLIDE 3
Implicit Reparameterization Gradients — Michael Figurnov
Reparameterization gradients
differentiable (ELBO, …) continuous (Normal, ...) backpropagation
Core part of variational autoencoders, automatic variational inference, etc. Backpropagation in graphs with continuous random variables
SLIDE 4
Implicit Reparameterization Gradients — Michael Figurnov
Core part of variational autoencoders, automatic variational inference, etc. Backpropagation in graphs with continuous random variables
Reparameterization gradients
requires a tractable inverse transformation! Normal, Logistic, … differentiable (ELBO, …) continuous (Normal, ...) backpropagation
SLIDE 5
Implicit Reparameterization Gradients — Michael Figurnov
Core part of variational autoencoders, automatic variational inference, etc. Backpropagation in graphs with continuous random variables We show how to use implicit differentiation for reparameterization of other continuous random variables, such as Gamma and von Mises
Reparameterization gradients
requires a tractable inverse transformation! Normal, Logistic, …
SLIDE 6
Implicit Reparameterization Gradients — Michael Figurnov
Explicit and implicit reparameterization
Cumulative density function Sampling (forward pass) Gradients (backward pass) Explicit Implicit
SLIDE 7
Implicit Reparameterization Gradients — Michael Figurnov
Explicit and implicit reparameterization
Cumulative density function Sampling (forward pass) Gradients (backward pass) Explicit Implicit
SLIDE 8
Implicit Reparameterization Gradients — Michael Figurnov
Explicit and implicit reparameterization
Cumulative density function Sampling (forward pass) Gradients (backward pass) Explicit Implicit
SLIDE 9
Implicit Reparameterization Gradients — Michael Figurnov
Explicit and implicit reparameterization
Cumulative density function Sampling (forward pass) Gradients (backward pass) Explicit Implicit
using any sampler (e.g., rejection sampling)
SLIDE 10
Implicit Reparameterization Gradients — Michael Figurnov
Explicit and implicit reparameterization
Cumulative density function Sampling (forward pass) Gradients (backward pass) Explicit Implicit
using any sampler (e.g., rejection sampling)
SLIDE 11
Implicit Reparameterization Gradients — Michael Figurnov
Explicit and implicit reparameterization
Cumulative density function
Derivation: implicit differentiation
Sampling (forward pass) Gradients (backward pass) Explicit Implicit
using any sampler (e.g., rejection sampling)
SLIDE 12
Implicit Reparameterization Gradients — Michael Figurnov
Derivation: implicit differentiation
Sampling (forward pass) Gradients (backward pass) Explicit Implicit
using any sampler (e.g., rejection sampling)
Explicit and implicit reparameterization
- ften not implemented in
numerical libraries
Cumulative density function
SLIDE 13
Implicit Reparameterization Gradients — Michael Figurnov
Jankowiak, Obermeyer “Pathwise Derivatives Beyond the Reparameterization Trick.” ICML, 2018
How to compute ?
Relative metrics (lower is better)
Gamma Von Mises Method Error Time Error Time Automatic differentiation of the CDF code 1x 1x 1x 1x Finite difference 832x 2x 514x 1.2x Jankowiak & Obermeyer (2018) concurrent work; closed-form approximation 18x 5x
SLIDE 14
Implicit Reparameterization Gradients — Michael Figurnov
How to compute ?
Relative metrics (lower is better)
Gamma Von Mises Method Error Time Error Time Automatic differentiation of the CDF code 1x 1x 1x 1x Finite difference 832x 2x 514x 1.2x Jankowiak & Obermeyer (2018) concurrent work; closed-form approximation 18x 5x
- Knowles (2015)
approximate explicit reparameterization 2840x 63x
- Knowles, “Stochastic gradient variational Bayes for Gamma approximating distributions.” arXiv, 2015
Jankowiak, Obermeyer “Pathwise Derivatives Beyond the Reparameterization Trick.” ICML, 2018
SLIDE 15
Implicit Reparameterization Gradients — Michael Figurnov
Variational Autoencoder
2D latent spaces for MNIST Normal prior and posterior
- 3
3 3 3
SLIDE 16
Implicit Reparameterization Gradients — Michael Figurnov
Variational Autoencoder
2D latent spaces for MNIST Normal prior and posterior Uniform prior, von Mises posterior
- 3
3 3 3
- 𝜌
𝜌 𝜌 𝜌
Torus adapted from https://en.wikipedia.org/wiki/Torus#/media/File:Sphere-like_degenerate_torus.gif
SLIDE 17
Implicit Reparameterization Gradients — Michael Figurnov
Variational Autoencoder
2D latent spaces for MNIST Normal prior and posterior Uniform prior, von Mises posterior
- 3
3 3 3
- 𝜌
𝜌 𝜌 𝜌
Torus adapted from https://en.wikipedia.org/wiki/Torus#/media/File:Sphere-like_degenerate_torus.gif
Also in the paper: Latent Dirichlet Allocation
SLIDE 18
Implicit Reparameterization Gradients — Michael Figurnov
Implicit Reparameterization Gradients
Michael Figurnov, Shakir Mohamed, Andriy Mnih
- A more general view of the reparameterization gradients
○ Decouple sampling from gradient estimation
- Reparameterization gradients for Gamma, von Mises, Beta, Dirichlet, ...
○ Faster and more accurate than the alternatives ○ Implemented in TensorFlow Probability:
tfp.distributions.{Gamma,VonMises,Beta,Dirichlet,...}
- Move away from making modelling choices for computational convenience
