Hunting for Metamorphic

By Péter Ször and Peter Ferrie

Introduction

• Polymorphic virus engines resulted in stronger virus

scanners.

• Paper focuses on how virus creators have challenged virus

scanners over the past decade.

Evolution of Code: 32-bit Encrypted Viruses

• Cascade

○ One of the first DOS viruses that used encryption. ○ Starts with constant decryptor that's followed by decrypted virus body. ○ Method appeared in early 32bit Windows viruses, and is also used in more recent viruses.

• Code pattern for decryption is unique enough that

detection is possible without decrypting virus body and infected code can easily be repaired.

Evolution of Code: 32-bit Oligomorphic Viruses

• Oligomorphic viruses change decryptors.
• Detection through decryptor's code became

more challenging.

• Dealt with virus by dynamic decryption of

code that is encrypted.

Evolution of Code: 32-bit Polymorphic Viruses

• Polymorphic viruses are able

to create new decryptors that use different encryption methods to encrypt the constant part of the virus body.

• To make the AV scanner's

job more difficult, entry point

• bscuring techniques were

used in combination with 32- bit polymorphism..

Generations of a polymorphic virus.

Evolution of Code: 32-bit Metamorphic Viruses

• Polymorphic viruses take time to create and

sometimes are not seen in the wild because of bugs.

• Researchers could find a method fo detecting

such viruses between minutes and a few days.

• Low number of efficient external polymorphic

engines.

• Metamorphic viruses:

○ No decryptor ○ No constant virus body ○ Able to change how they look and behave

Virus body changes in different generations of metamorphic virus

Evolution of Code: Simple Metamorphic Viruses

• In 1998, Win95/Regswap virus was created.

○ Register usage exchange ○ Virus body uses the same code but different registers.

• In 2000, Win32/Evol virus appeared.

○ Capable of running on any major Win32 platform. ○ Capable of inserting garbage between core instructions. Evolution of Code: Complex Metamorphic Viruses

• In 2000, variations of Win95/Zperm appeared using method from Ply DOS

virus. ○ Jump instructions inserted into code ○ Points to a new instruction of the virus ○ Creates new mutations by removing and adding jump and garbage instructions ○ Cannot be detected by search strings in the files or in memory.

Evolution of Code: Complex Metamorphic Viruses

Evolution of Code: Complex Metamorphic Viruses

• In 2000, Win95/Bistro was created

○ Based on sources of Zperm virus and RPME (Real

Permutating Engine, available for other virus writers to create new metamorphic viruses).

○ Uses a random code block insertion engine ○ Generates millions of iterations to challenge code

emulator's speed.

• Win95/Zmist, virus, created by Zombie

○ Entry Point-Obscuring metamorphic virus ○ Randomly uses additional polymorphic decryptor ○ Supports code integration ○ Randomly inserts jump instructions after every single instruction of the code section

Evolution of Code: Advanced Metamorphic Viruses Engines

• Zmist, virus, created by Zombie

○ Entry Point-Obscuring metamorphic virus ○ Randomly uses additional polymorphic decryptor ○ Supports code integration ○ Randomly inserts jump instructions after every single instruction of the code section

• Initialization

○ Doesn't alter host entry point ○ Merges with existing code

• Direct Action Infection

○ Checks to see if there's at least 16MB of physical memory ○ Then allocates memory blocks, permutates virus body, recursive search for .exe files

Evolution of Code: Advanced Metamorphic Viruses Engines

• Permutation

○ Slow ○ Consists of instruction replacement

• Infection of Portable Executable Files

○ File must be <448 KB ○ Begin with "MZ" ○ Portable Executable file

• "Islands" of code are integrated into random locations in host linked

together by jumps.

Evolution of Code: Advanced Metamorphic Viruses Engines

• Geometric Detection

○ Based on changes to the file structure

• DisassemblingTechniques

○ Separates instructions to look for garbage instructions that has been inserted by a virus. ○ CMP AX, "ZM"

• Use of Emulators for Tracing

○ Allows virus to execute freely in an environment it cannot escape

Metamorphic Virus Detection

Possible Future Virus Developments

• More metamorphic engines will be written in

the future.

• Viruses that are able to communicate with

each other.

○ Export engine of virus to another virus or worm ○ Exchange trigger routines

Conclusion

• Metamorphic viruses are becoming more

prevalent and must be taken seriously.

• Metamorphic viruses continue to evolve and

become a very great challenge for antivirus researchers.
