¡ Subnetworks, or subgraphs, are the building

blocks of networks:

¡ They have the power to characterize and

discriminate networks

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 2

10/9/18

Subgraph decomposition of an electronic circuit

Oxford Protein Informatics Group

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 3

Let’s consider all possible (non-isomorphoic) directed subgraphs of size 3

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 4

¡ For each subgraph:

§ Imagine you have a metric capable of classifying the subgraph “significance” [more on that later]

§ Negative values indicate under-representation § Positive values indicate over-representation

¡ We create a network significance profile:

§ A feature vector with values for all subgraph types

¡ Next: Compare profiles of different networks:

§ Regulatory network (gene regulation) § Neuronal network (synaptic connections) § World Wide Web (hyperlinks between pages) § Social network (friendships) § Language networks (word adjacency)

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 5

10/9/18

Networks from the same domain have similar significance profiles

Milo et al., Science 2004

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 6

Web and social Neurons Gene regulation networks Language networks

Network significance profile

Network significance profile similarity

10/9/18

Closely related networks have more similar significance profiles

Milo et al., Science 2004

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 7

Networks based on their significance profiles

Correlation in significance profile

• f the English and

French language networks

Gene regulatory networks Neurons Social WWW Language

1) Subgraphs: § Defining Motifs and graphlets

§

Finding Motifs and Graphlets 2) Structural roles in networks

§ RolX: Structural Role Discovery Method

3) Discovering structural roles and its

applications:

§ Structural similarity § Role generalization and transfer learning § Making sense of roles

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 8

¡ Network motifs: “recurring, significant

patterns of interconnections”

¡ How to define a network motif:

§ Pattern: Small induced subgraph § Recurring: Found many times, i.e., with high frequency § Significant: More frequent than expected, i.e., in randomly generated networks

§ Erdos-Renyi random graphs, scale-free networks

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 10

¡ Motifs:

§ Help us understand how networks work § Help us predict operation and reaction of the network in a given situation

¡ Examples:

§ Feed-forward loops: found in networks of neurons, where they neutralize “biological noise” § Parallel loops: found in food webs § Single-input modules: found in gene control networks

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 11

Feed-forward loop Single-input module Parallel loop

)/$0123

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 12

No match!

(not induced)

Match!

(induced)

Induced subgraph

• f interest

(aka Motif):

Induced subgraph of graph G is a graph, formed from a subset X of the vertices of graph G and all of the edges connecting pairs of vertices in subset X.

10/9/18

Example borrowed from Pedro Ribeiro

Motif of interest:

¡ Allow overlapping of motifs ¡ Network on the right has

4 occurrences of the motif:

§ {1,2,3,4,5} § {1,2,3,4,6} § {1,2,3,4,7} § {1,2,3,4,8}

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 13

¡ Key idea: Subgraphs that occur in a real

network much more often than in a random network have functional significance

10/9/18

Milo et. al., Science 2002

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 14

10/9/18

¡ Motifs are overrepresented in a network when

compared to randomized networks:

§ 𝑎" captures statistical significance of motif 𝒋: 𝑎" = (𝑂"

'()*− ,

𝑂"

')-.)/std(𝑂" ')-.) § 𝑂"

'()* is #(subgraphs of type 𝑗) in network 𝐻'()*

§ 𝑂"

')-. is #(subgraphs of type 𝑗) in randomized network 𝐻')-.

¡ Network significance profile (SP):

𝑇𝑄" = 𝑎"/ 8

9

𝑎

9 :

§ 𝑇𝑄 is a vector of normalized Z-scores § 𝑇𝑄 emphasizes relative significance of subgraphs: § Important for comparison of networks of different sizes § Generally, larger networks display higher Z-scores

15 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu

¡ Goal: Generate a random graph with a

given degree sequence k1, k2, … kN

¡ Useful as a “null” model of networks:

§ We can compare the real network 𝐻'()* and a “random” 𝐻')-. which has the same degree sequence as 𝐻'()*

¡ Configuration model:

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu

B

10/9/18 16

Nodes with spokes Randomly pair up “mini”-n0des

A C D

A B C D

B A C D

Resulting graph

We ignore double edges and self-loops when creating the final graph

¡ Start from a given graph 𝑯 ¡ Repeat the switching step 𝑅 ⋅ |𝐹| times:

§ Select a pair of edges AàB, CàD at random § Exchange the endpoints to give AàD, CàB

§ Exchange edges only if no multiple edges

• r self-edges are generated

¡ Result: A randomly rewired graph:

§ Same node degrees, randomly rewired edges

¡ 𝑅 is chosen large enough (e.g., 𝑅 = 100) for the

process to converge

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 17

B A C D B A C D

10/9/18

Milo et al., Science 2004

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 18

Network significance profile

𝑎" = (𝑂"

'()*− ,

𝑂"

')-.)/std(𝑂" ')-.)

¡ Count subgraphs 𝑗 in 𝐻'()* ¡ Count subgraphs 𝑗 in random networks 𝐻')-.:

§ Configuration model: Each 𝐻')-. has the same #(nodes), #(edges) and #(degree distribution) as 𝐻'()*

¡ Assign Z-score to 𝑗:

§ 𝑎" = (𝑂"

'()*− ,

𝑂"

')-.)/std(𝑂" ')-.)

§ High Z-score: Subgraph 𝑗 is a network motif of 𝑯

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 19

¡ Canonical definition:

§ Directed and undirected § Colored and uncolored § Temporal and static motifs

¡ Variations on the concept

§ Different frequency concepts § Different significance metrics § Under-Representation (anti-motifs) § Different constraints for null model

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 20

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 21

Z-scores of individual motifs for different networks

Milo et al., Science 2004

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 22

Z-scores of individual motifs for different networks

Milo et al., Science 2004

¡ Network of neurons and a gene network

contain similar motifs:

§ Feed-forward loops and bi-fan structures § Both are information processing networks with sensory and acting components

¡ Food webs have parallel loops:

§ Prey of a particular predator share prey

¡ WWW network has bidirectional links

§ Design that allows the shortest path between sets

• f related pages

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 23

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 24

¡ Graphlets: connected non-isomorphic subgraphs

§ Induced subgraphs of any frequency

10/9/18

Przulj et al., Bioinformatics 2004

For 𝒐 = 𝟒, 𝟓, 𝟔, … 𝟐𝟏 there are 𝟑, 𝟕, 𝟑𝟐, … 𝟐𝟐𝟖𝟐𝟕𝟔𝟖𝟐 graphlets!

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 25

¡ Next: Use graphlets to obtain a node-level

subgraph metric

¡ Degree counts #(edges) that a node touches:

§ Can we generalize this notion for graphlets? – Yes!

¡ Graphlet degree vector counts #(graphlets)

that a node touches

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 26

¡ An automorphism orbit takes into account the

symmetries of a subgraph

¡ Graphlet Degree Vector (GDV): a vector with

the frequency of the node in each orbit position

¡ Example: Graphlet degree vector of node v

10/9/18

For a node 𝑣 of graph 𝐻, the automorphism orbit of 𝑣 is 𝑃𝑠𝑐 𝑣 = {𝑤 ∈ 𝑊 𝐻 ; 𝑤 = 𝑔 𝑣 for some 𝑔 = Aut(𝐻)}. The Aut denotes an automorphism group

• f 𝐻, i.e., an isomorphism from 𝐻 to itself.

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 27

¡ Graphlet degree vector counts #(graphlets) that a

node touches at a particular orbit

¡ Considering graphlets on 2 to 5 nodes we get:

§ Vector of 73 coordinates is a signature of a node that describes the topology of node's neighborhood § Captures its interconnectivities out to a distance of 4 hops

¡ Graphlet degree vector provides a measure of a

node’s local network topology:

§ Comparing vectors of two nodes provides a highly constraining measure of local topological similarity between them

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 28

Graphlet Degree Vector (GDV) of node A:

§ 𝑗-th element of GDV(A): #(graphlets) that touch A at

• rbit 𝑗

§ Highlighted are graphlets that touch node A at orbits 15, 19, 27, and 35 from left to right

10/9/18

Yaveroglu et al., Journal of Statistical Software 2015

Orbit 15

F C A B E D

Orbit 19

F C A B E D

Orbit 27 Orbit 35 Orbit 0 1 2...3 4 5 6 7...14 15 16...18 19 20...26 27 28...34 35 36...72 GDV(A) 1 2 0...0 3 0 1 0...0 1 0...0 1 0...0 1 0...0 1 0...0

F C A B E D F C A B E D Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 29

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 30

¡ Finding size-k motifs/graphlets requires solving

two challenges:

§ 1) Enumerating all size-k connected subgraphs § 2) Counting #(occurrences of each subgraph type)

¡ Just knowing if a certain subgraph exists in a

graph is a hard computational problem!

§ Subgraph isomorphism is NP-complete

¡ Computation time grows exponentially as the

size of the motif/graphlet increases

§ Feasible motif size is usually small (3 to 8)

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 31

¡ Network-centric approaches:

§ 1) Enumerating all size-k connected subgraphs § 2) Counting #(occurrences of each subgraph type) via graph isomorphisms test

¡ Algorithms:

§ Exact subgraph enumeration (ESU) [Wernicke 2006] § Kavosh [Kashani et al. 2009] § Subgraph sampling [Kashtan et al. 2004]

¡ Today: ESU algorithm

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 32

¡ Two sets:

§ 𝑊

`abc')de : currently constructed subgraph (motif)

§ 𝑊

(fg(-`hi-: set of candidate nodes to extend the motif

¡ Idea: Starting with a node 𝑤, add those nodes 𝑣

to 𝑊

(fg(-`hi- set that have two properties:

§ 𝑣’s node_id must be larger than that of 𝑤 § 𝑣 may only be neighbored to some newly added node 𝑥 but not of any node already in 𝑊

`abc')de

¡ ESU is implemented as a recursive function:

§ The running of this function can be displayed as a tree-like structure of depth 𝒍, called the ESU-Tree

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 33

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 34

Wernicke, IEEE/ACM Transactions on Computational Biology and Bioinformatics 2006

𝑂lmno 𝑥, 𝑊

pqrstuvw = 𝑂 𝑥 \(𝑊 pqrstuvw ∪ 𝑂(𝑊 pqrstuvw)) is exclusive

neighborhood: All nodes neighboring 𝑥 but not of 𝑊

pqrstuvw or 𝑂(𝑊 pqrstuvw)

¡ Nodes in the ESU-tree include two adjoining sets:

§ 𝑾𝒕𝒗𝒄𝒉𝒔𝒃𝒒𝒊: Current subgraph (a set of adjacent nodes) § 𝑾𝒇𝒚𝒖𝒇𝒐𝒕𝒋𝒑𝒐 : Nodes adjacent to𝑾𝒕𝒗𝒄𝒉𝒔𝒃𝒒𝒊 whose node_ids are larger than starting node 𝑤

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 35

Leaves represent all size-3 induced sub-graphs

4 5 3 1 2

Root ({1}, {3}) ({2}, {3}) ({3}, {4,5}) ({4}, {5}) ({5}, {∅}) ({1,3}, {2,4,5}) ({2,3}, {,4,5}) ({3,4}, {5}) ({4,5}, {∅}) 3 1 2 5 3 1 4 3 2 5 3 2 4 3 1 4 5 3

¡ So far, we enumerated all size-k subgraphs in

the input graph

¡ Next step: Count the graphs

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 36

Count: 5 1

3 1 2 5 3 1 4 3 2 5 3 2 4 3 1 4 5 3

¡ So far, we enumerated all size-k subgraphs in

the input graph

¡ Next step: Count the graphs

Classify subgraphs placed in the ESU-Tree leaves into non-isomorphic size-k classes:

§ Determine which subgraphs in ESU-Tree leaves are topologically equivalent (isomorphic) and group them into subgraph classes accordingly § Use McKay’s nauty algorithm [McKay 1981]

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 37

¡ Graphs 𝐻 and 𝐼 are isomorphic if there exists a

bijection 𝑔: 𝑊 𝐻 → 𝑊(𝐼) such that:

§ Any two nodes 𝒗 and 𝒘 of 𝑯 are adjacent in 𝑯 iff 𝒈(𝒗) and 𝒈(𝒘) are adjacent in 𝑰

¡ Example: Are 𝐻 and 𝐼 topologically equivalent?

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 38

𝐻 𝐼

A 4 B 7 C 1 D 3 E 5 F 8 G 2 H 9 I 6

𝑔:

Need to check 9! possible bijections between node sets Hard computational problem! 𝑯 and 𝑰 are isomorphic!

1) Subgraphs: § Defining Motifs and graphlets

§

Finding Motifs and Graphlets 2) Structural roles in networks

§ RolX: Structural Role Discovery Method

3) Discovering structural roles and its

applications:

§ Structural similarity § Role generalization and transfer learning § Making sense of roles

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 39

¡ Roles are “functions” of nodes in a network:

§ Roles of species in ecosystems § Roles of individuals in companies

¡ Roles are measured by structural behaviors:

§ centers of stars § members of cliques § peripheral nodes, etc.

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 41

10/9/18

centers of stars members of cliques peripheral nodes

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 42

Network Science Co-authorship network [Newman 2006]

¡ Role: A collection of nodes which have similar

positions in a network:

¡ Roles are based on the similarity of ties between subsets of

nodes

§ Different from groups/communities

§ Group is formed based on adjacency, proximity or reachability § This is typically adopted in current data mining

Nodes with the same role need not be in direct,

• r even indirect interaction with each other

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 43

¡ Roles:

§ A group of nodes with similar structural properties

¡ Communities/Groups:

§ A group of nodes that are well-connected to each other

¡ Roles and communities are complementary ¡ Consider the social network of a CS Dept:

§ Roles: Faculty, Staff, Students § Communities: AI Lab, Info Lab, Theory Lab

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 44

10/9/18

RolX Fast Modularity Henderson, et al., KDD 2012

Roles Communities

Clauset, et al., Phys. Rev. E 2004

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 45

¡ Structural equivalence: Nodes 𝑣 and 𝑤 are

structurally equivalent if they have the same relationships to all other nodes [Lorrain & White 1971]

§ Structurally equivalent nodes are likely to be similar in

• ther ways – i.e., friendships in social networks

10/9/18

u v d e a b c

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 46

¡ Nodes 𝑣 and 𝑤 are structurally equivalent:

§ For all the other nodes 𝑙, node 𝑣 has tie to 𝑙 iff node 𝑤 has tie to 𝑙

¡ Example: ¡ E.g., nodes 3 and 4 are structurally equivalent

1 2 3 4 5 Adjacency matrix

1 2 3 4 5 1

• 1

1 2

• 1

1 3

• 1

4

• 1

5

• 10/9/18

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 48

1) Subgraphs: § Defining Motifs and graphlets

§

Finding Motifs and Graphlets 2) Structural roles in networks

§ RolX: Structural Role Discovery Method

3) Discovering structural roles and its

applications:

§ Structural similarity § Role generalization and transfer learning § Making sense of roles

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 48

Task Example Application Role query Identify individuals with similar behavior to a known target Role outliers Identify individuals with unusual behavior Role dynamics Identify unusual changes in behavior Identity resolution Identify, de-anonymize, individuals in a new network Role transfer Use knowledge of one network to make predictions in another another Network comparison Compute similarity of networks, determine compatibility for knowledge transfer

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 50

¡ RolX: Automatic discovery

• f nodes’ structural roles in

networks [Henderson, et al. 2011b]

§ Unsupervised learning approach § No prior knowledge required § Assigns a mixed-membership of roles to each node § Scales linearly in #(edges)

10/9/18

Role Discovery

ü

Automated discovery

ü

Behavioral roles

ü

Roles generalize

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 51

Input Output

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 52

Node × Node Adjacency Matrix Recursive Feature Extraction Node × Feature Matrix Role Extraction Node × Role Matrix Role × Feature Matrix

Example: degree, mean weight, # of edges in egonet, mean clustering coefficient of neighbors, etc.

Input Output

¡ Recursive feature extraction [Henderson, et al. 2011a] turns

network connectivity into structural features

¡ Neighborhood features: What is a node’s connectivity pattern? ¡ Recursive features: To what kinds of nodes is a node connected?

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 53

ReFeX

Local Egonet Recursive Neighborhood Regional

1411# 0# 1# 2# 1# 0# 0# 0# 1# 1# 0# 1# 0# 0# 1# 1# 2# 2# 1410# 0# 1# 1# 1# 0# 1# 0# 0# 1# 0# 1# 0# 1# 0# 1# 1# 1# 338# 0# 0# 0# 0# 1# 0# 1# 0# 0# 1# 0# 0# 0# 1# 0# 0# 0# 339# 1# 0# 0# 0# 2# 0# 1# 0# 0# 2# 0# 1# 0# 1# 0# 0# 0# 1415# 0# 1# 1# 2# 0# 1# 0# 0# 0# 0# 0# 0# 1# 1# 1# 1# 1# 941# 0# 0# 0# 0# 1# 0# 1# 0# 0# 1# 0# 0# 0# 0# 0# 0# 0# 1414# 0# 1# 1# 1# 0# 1# 0# 0# 0# 0# 0# 0# 1# 1# 0# 1# 1# 942# 0# 0# 0# 0# 1# 0# 0# 0# 0# 0# 0# 0# 0# 0# 0# 0# 0# 1413# 0# 1# 1# 1# 0# 1# 1# 0# 0# 0# 0# 0# 1# 1# 0# 1# 1# 1412# 0# 0# 0# 0# 0# 0# 0# 1# 2# 0# 1# 1# 0# 0# 1# 2# 0# 940# 0# 0# 1# 0# 0# 0# 0# 1# 0# 0# 0# 1# 1# 0# 1# 1# 1# 1419# 0# 0# 1# 0# 0# 1# 0# 1# 1# 0# 1# 1# 1# 0# 1# 1# 1# 945# 0# 1# 4# 3# 0# 0# 0# 0# 2# 0# 1# 0# 0# 2# 1# 3# 1# 332# 0# 0# 0# 0# 1# 0# 1# 0# 0# 1# 0# 0# 0# 0# 0# 0# 0# 1418# 0# 0# 1# 0# 0# 0# 0# 1# 0# 0# 0# 1# 2# 0# 1# 0# 1# 946# 0# 1# 1# 0# 0# 1# 0# 1# 0# 0# 0# 1# 4# 0# 1# 1# 2# 333# 0# 0# 0# 0# 1# 0# 1# 0# 0# 1# 0# 0# 0# 0# 0# 0# 0# 1417# 0# 1# 1# 1# 0# 2# 0# 0# 1# 0# 1# 0# 1# 0# 1# 1# 1# 943# 0# 0# 0# 1# 0# 0# 0# 0# 0# 0# 0# 0# 0# 0# 1# 0# 0# 330# 1# 3# 2# 0# 1# 2# 2# 0# 2# 2# 2# 0# 3# 1# 0# 2# 5# 1416# 0# 1# 1# 1# 1# 2# 0# 0# 1# 0# 1# 0# 1# 0# 0# 1# 1# 944# 0# 1# 4# 2# 0# 0# 0# 0# 2# 0# 1# 0# 0# 2# 0# 3# 1# 331# 0# 3# 2# 1# 0# 1# 0# 0# 2# 0# 2# 0# 2# 0# 1# 2# 5# 949# 0# 0# 0# 0# 2# 0# 0# 1# 0# 1# 0# 1# 0# 0# 0# 0# 0# 336# 0# 0# 0# 0# 2# 0# 0# 1# 1# 1# 1# 1# 0# 0# 0# 1# 0# 337# 1# 1# 1# 0# 0# 1# 2# 0# 1# 1# 1# 0# 1# 1# 1# 1# 1# 947# 1# 0# 0# 0# 2# 0# 1# 0# 0# 2# 0# 1# 0# 1# 0# 0# 0# 334# 0# 0# 0# 1# 1# 0# 0# 0# 0# 0# 0# 0# 0# 0# 0# 0# 0# 948# 0# 0# 0# 0# 0# 1# 0# 1# 1# 0# 1# 1# 1# 0# 1# 1# 0# 335# 0# 0# 0# 1# 0# 0# 0# 0# 0# 0# 0# 0# 0# 0# 1# 0# 0# 531# 1# 0# 0# 0# 1# 0# 2# 0# 0# 2# 0# 0# 0# 2# 0# 0# 0#

Nodes

Recursive feature extraction

Egonet for red node

¡ Idea: Aggregate features of a node and use them

to generate new recursive features

¡ Base set of a node’s neighborhood features:

§ Local features: All measures of the node degree:

§ If network is directed, include in- and out-degree, total degree § If network is weighted, include weighted feature versions

§ Egonet features: Computed on the node’s egonet:

§ Egonet includes the node, its neighbors, and any edges in the induced subgraph on these nodes § #(within-egonet edges), #(edges entering/leaving egonet)

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 54

Egonet for red node

¡ Start with the base set of node features ¡ Use the set of current node features to generate

additional features:

§ Two types of aggregate functions: mean and sum

§ E.g., mean value of “unweighted degree” feature between all neighbors of a node § Compute means and sums over all current features, including other recursive features

§ Repeat

¡ The number of possible recursive features

grows exponentially with each recursive iteration:

§ Reduce the number of features using a pruning technique:

§ Look for pairs of features that are highly correlated § Eliminate one of the features whenever two features are correlated above a user-defined threshold

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 55

Features

Nodes

Output

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 56

Features

Nodes

Recursively extract features Cluster nodes based on extracted features

Input Output

RolX uses non negative matrix factorization for clustering, MDL for model selection, and KL divergence to measure likelihood

¡ Task: Cluster nodes based on their structural

similarity

¡ Two networks:

§ Network science co-authorship network:

§ Nodes: Network scientists; § Edges: The number of co-authored papers

§ Political books co-purchasing network:

§ Nodes: Political books on Amazon; § Edges: Frequent co-purchasing of books by the same buyers

¡ Setup: For each network:

§ Use RolX to assign each node a distribution over the set of discovered, structural roles § Determine similarity between nodes by comparing their role distributions

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 57

Making sense of roles:

¡

Blue circle: Tightly knit, nodes that participate in tightly-coupled groups

¡

Red diamond: Bridge nodes, that connect groups of nodes

¡

Gray rectangle: Main-stream, majority of nodes, neither a clique, nor a chain

¡

Green triangle: Pathy, nodes that belong to elongated clusters

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 58

Role-colored graph: each node is colored by the primary role that RolX finds Role affinity heat-map

10/9/18

Bright blue nodes are peripheral nodes Bright red nodes are locally central nodes

conservative liberal neutral

Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 59

Book labels (i.e., liberal, conservative, neutral) were not given to role discovery algorithm

1) Subgraphs: § Defining Motifs and graphlets

§

Finding Motifs and Graphlets 2) Structural roles in networks

§ RolX: Structural Role Discovery Method

3) Discovering structural roles and its

applications:

§ Structural similarity § Role generalization and transfer learning § Making sense of roles

10/9/18 Jure Leskovec, Stanford CS224W: Machine Learning with Graphs, cs224w.stanford.edu 62
