SLIDE 1

Herodotos Herodotou Nedyalko Borisov Shivnath Babu

Duke University

SLIDE 2

Table Partitioning

 Split parent table into smaller child tables (partitions)  Partitioning methods: hash, range, list  Benefits

 Improve query performance  Faster data loading, archival, backup  Efficient statistics maintenance  Better cardinality estimation  Fine-grained control for tuning  . . .

06/14/2011 Duke University 2

id date . . .

Sales

id date . . .

Sales_Jan_11

id date . . .

Sales_Feb_11

id date . . .

Sales_Mar_11

SLIDE 3

Recent Trends

 Growing usage due to increased data sizes  Growing user control due to new SQL extensions

 Partitioning conditions for derived tables

 DBA must satisfy multiple objectives and constraints

regarding partitioning

 Implications

 DBA may have limited control over partitioning scheme  Diverse mix of partitioning schemes

06/14/2011 Duke University 3

SLIDE 4

Partitioning Schemes

 Multidimensional (Hierarchical) partitioning  Tables partitioned on same key but different ranges  Range partitioning with non-equi ranges

06/14/2011 Duke University 4

S11 S12 S13 S21 S22 S23 S31 S32 S33 S1 S2 S3 S.d Sales S S11 S12 S13 S21 S22 S23 S31 S32 S33 S41 S42 S43 S.id S.d

20 40 60 80

L1 L2 L3 L4

20 40 60 80

L.id Loans L P1 P3 P5 P7 P2 P4 P6 P8

20 40 60 80 30 10 50 70

P.id Payments P A1 A2 A3 A4 A5 A.d Ads A

SLIDE 5

Partition-aware Query Optimization

06/14/2011 Duke University 5

S11 S12 S13 S21 S22 S23 S31 S32 S33 S1 S2 S3 S.d Sales S S11 S12 S13 S21 S22 S23 S31 S32 S33 S41 S42 S43 S.id S.d

20 40 60 80

P1 P3 P5 P7 P2 P4 P6 P8

20 40 60 80 30 10 50 70

P.id Payments P P5 P7 P4 P6 P8 P1 P3 P2 S11 S21 S31 S41 S12 S22 S32 S42 S13 S23 S33 S43 S32 S33 S32 S33 S42 S43 S12 S13 S22 S23

SELECT * FROM Sales S, Payments P WHERE S.id = P.id AND S.d > Feb-15 AND P.id < 25

SLIDE 6

Partition-aware Query Optimization

06/14/2011 Duke University 6

S12 S22 S.id S.d

20 40

P1 P3 P2

20 30 10

P.id Payments P Sales S S13 S23

SELECT * FROM Sales S, Payments P WHERE S.id = P.id AND S.d > Feb-15 AND P.id < 25

HJ Union TS(P1) TS(P2) TS(P3) Union TS(S22) TS(S23) TS(S12) TS(S13)

P1: “join of unions”

MJ IS(P3) Union TS(S22) TS(S23) Union HJ Union Union TS(P1) TS(P2) TS(S12) TS(S13)

P2: “union of (partition-wise) joins”

SLIDE 7

Partition-aware Query Optimization

 More efficient partition-wise joins  More appropriate join orders  More appropriate join operators

06/14/2011 Duke University 7

MJ IS(P3) Union TS(S22) TS(S23) Union HJ Union Union TS(P1) TS(P2) TS(S12) TS(S13) TS(L1) TS(L2) Union HJ

Legend S = Sales P = Payments L = Loans

S ⋈ P ⋈ L IS(P3) MJ TS(L1) TS(L2) Union MJ TS(S22) TS(S23) Union HJ INLJ Union Union TS(P1) TS(P2) TS(S12) TS(S13) S ⋈ P ⋈ L

SLIDE 8

Problem & Challenges

 Problem Definition

 Given a partitioning scheme and a query

find the optimal query execution plan

 Challenges

 Dealing with plan space explosion  Incorporating into state-of-the-art optimizers  Partitions as physical or logical properties?  Supporting a wide range of partitioning conditions

06/14/2011 Duke University 8

SLIDE 9

Overview

06/14/2011 Duke University 9

P1 P2 P3 P S12 S13 S22 S S23 S.id = P.id P1 P2 P3 S12 S13 S22 S23

1. Matching

P1 P2 P3 S12 S13 S22 S23

2. Clustering
3. Path Selection

TS(S22) TS(S23) Union TS(P3) HJ TS(S22) TS(S23) Union TS(P1) TS(P2) Union MJ

SLIDE 10

Matching Phase

 Goal

 Identify partition-wise join pairs that can generate

utput records

 New data structure: Partition Index Tree (PIT)

 Core idea: associate each partition with intervals  Functionalities: index intervals, efficient lookups  Implementation: Augmented red-black tree

06/14/2011 Duke University 10

SLIDE 11

Matching Algorithm

Inputs: Table S, Table P, Join condition J Step 1: Convert partitioning conditions to intervals Step 2: Build PIT with intervals of S Step 3: Probe PIT with intervals of P Output: Partition-wise join pairs (Si, Pj)

06/14/2011 Duke University 11

Partition Interval Max Notation:

S22 [20, 40) 40 S13 [0, 20) 40 S23 [20, 40) 40 S12 [0, 20) 40

Partition Interval Max Notation:

S22 [20, 40) 40 S13 [0, 20) 40 S23 [20, 40) 40 S12 [0, 20) 40 P2 [10, 20) Probe

✓ ✓

Output: Partition Join Pairs (S12, P1) (S12, P2) (S13, P1) (S13, P2) (S22, P3) (S23, P3)

SLIDE 12

Matching Algorithm

06/14/2011 Duke University 12

 Benefits

 O(n log(n)), n = number of partitions of S  Θ(n) memory needs  Build & reuse PITs multiple times

 Additional support

 Numeric, dates, and string ranges or lists  Complex partitioning conditions (AND, OR)  Complex join conditions (AND, OR)  Non-equi joins  Details in the paper

SLIDE 13

 Goal

 Minimize number of partition-wise join pairs

Clustering Phase

06/14/2011 Duke University 13

Input: Partition Join Pairs (S12, P1) (S12, P2) (S13, P1) (S13, P2) (S22, P3) (S23, P3) Output: Clustered Join Pairs ({S12,S13},{P1,P2}) ({S22,S23},{P3}) Intermediate: Join Partition Graph S12 P1 P2 S13 S12 P3 S13

Input: Partition join pairs (output from Matching Phase) Step 1: Build bipartite join partition graph Step 2: Find connected components using Breadth-First-Search Output: Clustered join pairs

SLIDE 14

Path Creation and Selection

 Goal

 Create and cost partition-wise join paths for child tables

06/14/2011 Duke University 14

IS(P3) MJ TS(L1) TS(L2) Union MJ TS(S22) TS(S23) Union HJ INLJ Union Union TS(P1) TS(P2) TS(S12) TS(S13) S ⋈ P ⋈ L

SLIDE 15

Bottom-up Query Optimization

06/14/2011 Duke University 15

LSP

Find & retain best 3-way join paths per interesting order

LS LP SP

Find & retain best 2-way join paths per interesting order

P S L

Find & retain best access paths

SLIDE 16

Bottom-up Query Optimization

06/14/2011 Duke University 16

SP

HJ Union TS(P1) TS(P2) TS(P3) Union TS(S22) TS(S23) TS(S12) TS(S13) MJ Union IS(P1) IS(P2) IS(P3) Union TS(S22) TS(S23) TS(S12) TS(S13)

Logical Relation (Join) Best (physical) join path Best (physical) join path with interesting order

SLIDE 17

 Original enumeration

 Create and cost join of unions

 Extended enumeration

 Create and cost union of joins  Retain best path per interesting order

 Not enough!

 Not considering entire

plan space (e.g., if Pj is best, no 3-way partition-wise joins)

Extended Enumeration

06/14/2011 Duke University 17

HJ Union TS(P1) TS(P2) TS(P3) Union TS(S22) TS(S23) TS(S12) TS(S13) Pj MJ TS(P3) Union TS(S22) TS(S23) Union HJ Union Union TS(P1) TS(P2) TS(S12) TS(S13) Pu

SLIDE 18

Treating Partitions as Physical Properties

 Interesting partitions in joins

 Can make later joins less expensive

 Approach

 Retain best path for each interesting order  Retain best path for each interesting partition

 Limitation

 Not considering entire plan space (e.g., cannot create

union of joins with different join orders)

06/14/2011 Duke University 18

SLIDE 19

Treating Partitions as Logical Properties

06/14/2011 Duke University 19

Logical child joins

 Treated like

logical parent joins

 Retain best join

paths per interesting

rder

LSP L1S12S13P1P2 L2S22S23P3 P P1 P2 P3 S S12 S13 S22 S23 L L1 L2 LS L1S12S13 L2S22S23 LP L1P1P2 L2P3 SP S12S13P1P2 S22S23P3

Logical parent join Logical child joins

SLIDE 20

Treating Partitions as Logical Properties

 Property 1

 Interesting orders independent across child joins

 Property 2

 Child joins can have different join orders/operators

 Property 3

 Entire extended plan space is enumerated

 Optimality guarantee

 Our bottom-up optimizer will find the optimal plan in

the extended plan space

06/14/2011 Duke University 20

SLIDE 21

Experimental Evaluation

 Prototype using PostgreSQL 8.3.7  TPC-H benchmark (scale 30)  Evaluation Methodology

 DBA has full/limited control over partitioning scheme  State-of-the-art Vs. Our partition-aware optimizer

 Optimizer evaluation metrics

 Execution time  Optimization time  Memory utilization

06/14/2011 Duke University 21

SLIDE 22

Evaluation: Execution Time

06/14/2011 Duke University 22

20 40 60 80 100 120 140 2 3 4 5 7 8 9 10 12 14

Execution Time (min) Query

Basic Advanced State-of-the-art Partition aware

SLIDE 23

Evaluation: Optimization Time

06/14/2011 Duke University 23

50 100 150 200 250 300 350 2 3 4 5 7 8 9 10 12 14

Optimization Time (ms) Query

Basic/Intermediate Advanced

SLIDE 24

Evaluation: Memory Utilization

06/14/2011 Duke University 24

10 20 30 40 2 3 4 5 7 8 9 10 12 14

Memory Usage (MB) Query

Basic Advanced

PostgreSQL Partition-aware

SLIDE 25

Summary

 Extended plan space to include plans with multiway

partition-wise joins

 Developed new partition-aware optimization

techniques

 Easy incorporation into bottom-up query optimizers

06/14/2011 Duke University 25

SLIDE 26

Extensions to Parallel Databases

 Data placement strategy

 Hash partitioning to

nodes

 Range/list partitioning

within each node

 Our extensions

 Create partition-wise

joins Si ⋈ Pi for each node Ni

 Produce child joins for

Si ⋈ Pi

06/14/2011 Duke University 26

 Data placement strategy

 Replicate dimension

tables

 Partition fact tables

aaaa

 Our extensions

 Further partition all

tables

 Produce child joins on

each node

SLIDE 27

Evaluation: Vary Partition Size

06/14/2011 Duke University 27

50 100 150 200 250 300 350 64 96 128 192 256 64 96 128 192 256

Optimization Time (ms) Partition Size (MB)

SLIDE 28

Evaluation: Vary Data Size

06/14/2011 Duke University 28

SLIDE 29

Cardinality Estimation

06/14/2011 Duke University 29

1.E+00 1.E+01 1.E+02 1.E+03 1.E+04 1.E+05 1.E+06 1.E+07 1.E+08 1.E+09 1.E+10 1.E+11 1.E+12 1.E+13 1.E+14 1.E+15 Q02 Q03 Q04 Q05 Q07 Q08 Q09 Q10 Q12 Q14

Estimated Number of Records Query
