HeapTherapy+: Efficient Handling of (Almost) All Heap Vulnerabilities Using Targeted Calling-Context Encoding Qiang Zeng , Golam Kayas, Emil Mohammed, Lannan Luo, Xiaojiang Du, and Junghwan Rhee DSN 2019 2 Trend of Memory Vulnerability

slide-1
SLIDE 1

Qiang Zeng, Golam Kayas, Emil Mohammed, Lannan Luo, Xiaojiang Du, and Junghwan Rhee

DSN 2019

HeapTherapy+: Efficient Handling of (Almost) All Heap Vulnerabilities Using Targeted Calling-Context Encoding

slide-2
SLIDE 2

Trend of Memory Vulnerability Exploitation

  • Memory vulnerability exploitation
  • Stack-based
  • Heap-based
  • Many effective protection for call stacks
  • Stack canaries
  • Reordering local variables
  • Safe SEH (Structured Exception Handling)
  • Heap vulnerability exploitation becomes the trend
  • Heartbleed: heap buffer overread
  • WannaCry: heap buffer overwrite
  • Popular ROP (return oriented programming) attack [1]:

Heap overflow => overwrite a function pointer => stack pivoting

2

[1] McAfee, “Emerging ‘Stack Pivoting’ Exploits Bypass Common Security”, 2013

slide-3
SLIDE 3

3

“Because the success of stack-based exploits has been reduced by the numerous security measures, heap-based attacks are now common” [Ratanaworabhan 2009]

[Ratanaworabhan 2009] Ratanaworabhan, et al.."NOZZLE: A Defense Against Heap-spraying Code Injection Attacks." USENIX Security. 2009.

slide-4
SLIDE 4

Types of Heap Vulnerabilities

  • Uninitialized read
  • Information leakage; …

4

str = (char*) malloc(128); … // str is not initialized cout << str;

slide-5
SLIDE 5

Types of Heap Vulnerabilities

  • Uninitialized read
  • Information leakage; …
  • Use-after-free
  • Control-flow hijacking; …

5

(1) D *p = new D(); … (2) delete p; (3) … (4) p->foo(); // use-after-free this // buffer re-allocated and used p malicious virtual function table “More than 50% of known attacks targeting Windows 7 exploit use-after-free” [Zhang 2016]

[Zhang 2016] Zhang, Chao, et al. "VTrust: Regaining Trust on Virtual Calls." NDSS. 2016.

Virtual function table foo() bar()

slide-6
SLIDE 6

Types of Heap Vulnerabilities

  • Uninitialized read
  • Information leakage; …
  • Use-after-free
  • Control-flow hijacking; …
  • Buffer overflow

Ø Over-write

  • Manipulating data; control-flow hijacking; …

Ø Over-read

  • Information leakage; …

6

slide-7
SLIDE 7

Existing Measures

  • Checking every buffer access is great…but expensive
  • SoftBound (handle overflow and use-after-free): 67%
  • AddressSanitizer (handle overflow and use-after-free): 73%
  • MemorySanitizer (handle uninitialized read): 2.5x
  • SFI (software fault isolation), CFI (control-flow integrity),

XFI, CPI (code pointer integrity), …

  • Challenges when working with existing shared libs (legacy code)
  • Some (like XFI) are still very expensive
  • Our previous work
  • Cruiser [PLDI’11], Kruiser [NDSS’12]: only handle overwrite
  • HeapTherapy [DSN’15]: only handle overwrite and overread

7

slide-8
SLIDE 8

A Patching Perspective

  • Patching is an indispensable step throughout the life of a

software system; however,

  • 153 days on average for delivering a patch [1]
  • Only 65% of vulnerabilities have patches available [2]
  • Fresh patches break systems frequently
  • Our goals
  • Handle heap overflow, uninitialized read, and use-after-free
  • Generate patches instantly with zero manual diagnosis efforts
  • Install patches without altering code, i.e., code-less patching
  • A very small overhead

8 [1] S. Frei, “The Known Unknowns,” 2013. [2] S. frei, “” “End-point security failures, insight gained from secunia psi scans,” 2011.

slide-9
SLIDE 9

Hypotheses

9

More generally, for a use-after-free or uninitialized-read vulnerability, the vulnerable buffers share the same calling context when they are allocated Given a heap buffer overflow bug, the vulnerable buffers share the same calling context when they are allocated

slide-10
SLIDE 10

Verifying Hypotheses

10

→

clone start_thread handle_one_connection do_handle_one_connection my_malloc malloc thd_prepare_connection do_command MDL_key::mdl_key_init stpcpy Pathogen buffers are allocated. Pathogen buffers are overflowed.

Vulnerable buffers are allocated Vulnerable buffers are exploited

Given this vulnerability, many different exploits were collected and replayed

slide-11
SLIDE 11

Main Approach

11

Using allocation-time calling context to characterize vulnerable buffers

  • 1. When replaying the attack, record the allocation-time

calling context of each buffer. When the offending

  • peration (e.g., overflow) is detected, output the

allocation-time calling context of the vulnerable buffer

  • 2. During runtime, if a buffer being allocated has that

allocation-time calling context, enhance it

slide-12
SLIDE 12

Challenges

  • How to retrieve and compare calling contexts efficiently?
  • Retrieving calling context via stack walking is too expensive
  • ASLR makes the collected RAs useless
  • How to bridge offline attack analysis and online defense

generation?

  • How to achieve code-less patching?
  • How to handle the diverse vulnerabilities in a uniform way?

12

slide-13
SLIDE 13
  • Targeted Calling Context Encoding
  • Offline Attack Analysis and Patch Generation
  • Online Defense Generation

13

slide-14
SLIDE 14

Calling Context Encoding

  • Using an integer (or very few integers) to encode the

calling context

  • The integer is updated at each function call and return; using

simple arithmetic operations

  • <3% slowdown; concise representation
  • Wide applications: testing coverage, anomaly detection,

compilation optimization, logging, …

14

PCC

[Bond 2007]

PCCE

[Sumner 2010]

DeltaPath [Zeng 2014] Support Object-Oriented

✔ ✗ ✔

Decoding

✗ ✔ ✔

Scalability

✗ ✗ ✔

slide-15
SLIDE 15

Example: PCC

  • Goal: each unique ID represents a unique calling context

15

1 B() { 2 C(); 3 D(); 4 } 5 6 C() { 7 D(); 8 } 9 10 D() { 11 Sensitive API! // calling context? 12 } B C D ID = 13 ID = 3 ID = 0 ID = t * 3 + 2 ID = t * 3 + 3 Answer: Read the variable “ID” to get the calling context ID t = ID t = ID ID = t * 3 + 7 ID = 2

slide-16
SLIDE 16

Targeted Calling Context Encoding

  • A set of ideas that can minimize the encoding overhead
  • Key insight: When the target functions, whose calling

contexts are of interest, are known, many call sites do no need to be instrumented

  • E.g., some functions never appear in the calling contexts that lead

to the target functions

  • Target functions in our work:
  • malloc, calloc, realloc, memalign, aligned_alloc

16

slide-17
SLIDE 17

17

(a) FCS (full-call-site instrumentation): original PCC encoding (b) TCS (targeted-call-site): H and I cannot reach the targets T1 and T2 (c) Slim: B, E and G each has only one out-going edge that reaches the targets (d) Incremental: F-T1 and F-G-T2 can be distinguished through the target

slide-18
SLIDE 18

Encoding overhead

  • Implementation: added an LLVM pass for instrumentation
  • Evaluation: SPEC CPU2006 Integer
  • Size overhead
  • PCC: 12%
  • Targeted Calling context Encoding: 4.4%
  • 2.7x of improvement
  • Speed overhead
  • PCC: 2.4%
  • Targeted Calling Context Encoding: 0.4%
  • 6x of speed up

18

slide-19
SLIDE 19
  • Targeted Calling Context Encoding
  • Offline Attack Analysis and Patch Generation
  • Online Defense Generation

19

slide-20
SLIDE 20

20

One-time program instrumentation Patch generation Patched program execution Program Instrumentation Tool

Instrumented program

Online Defense Generator Program Attack inputs Configuration file Patches Offline Patch Generator

slide-21
SLIDE 21
  • Accessibility-bit (A-bit): whether the byte can be accessed
  • If a buffer has been free-ed, all its A-bits are 0
  • Each buffer is surrounded by two red zones (16B each), whose A-bits are 0
  • Validity-bit (V-bit): whether the bit is initialized
  • When a fresh buffer is malloc-ed, all it V-bits are 0
  • Each buffer’s alloc-API and CCID are recorded

21

Byte1 Byte2 ………….. Byten Application Memory Byte2 Shadow Information Shadow Information ………….. Shadow Information Shadow Memory Shadow Information 1 1 1 1 1 1 1 1 1

A bit V bits

0 0 0 0 0 0 0 0

A bit V bits

… … … …

(1) Detect overflow: an overflow will touch the inaccessible red zone (2) Detect use-after-free: a free-ed buffer is set as inaccessible and then added to a queue to delay the space reuse (3) Detect uninitialized read: more complex, but mainly relies on V-bits

slide-22
SLIDE 22

Patches as a configuration file

  • Each patch is simply a tuple

<alloc-API, CCID, vul-type>

  • Code-less patching: to “install” a patch, just add one line

in the config file

22

………… …………

<API, CCID, Vulnerability> <memalign, 1854955292, OVERFLOW> <calloc, 8643565443, USE-AFTER-FREE> <malloc, 2598251483, UNINITIALIZED-READ> … ... Read by Online … … … Configuration file

slide-23
SLIDE 23
  • Targeted Calling Context Encoding
  • Offline Attack Analysis and Patch Generation
  • Online Defense Generation

23

slide-24
SLIDE 24

Patches read into a hash table

24

………… …………

<API, CCID, Vulnerability> <memalign, 1854955292, OVERFLOW> <calloc, 8643565443, USE-AFTER-FREE> <malloc, 2598251483, UNINITIALIZED-READ> … ... Read by Online Defense Generator Key Value <MEMALIGN, 1854955292> <CALLOC, 8643565443> <MALLOC, 2598251483> ….. (001)2 (010)2 (100)2 … … Configuration file Hash table

A shared lib

slide-25
SLIDE 25

Vulnerability Handling

  • Handle overflow
  • Append a guard page to each vulnerable buffer
  • Handle use-after-free
  • Delay the deallocation of the free-ed vulnerable buffers
  • Handle uninitialized read
  • Initialize the newly allocated vulnerable buffer with zeros

25

slide-26
SLIDE 26

26

slide-27
SLIDE 27

Evaluation

  • Effectiveness
  • Efficiency
  • SPEC CPU2006: 4.3% (zero patch), 4.7% (one patch), 5.2% (five)
  • 1.9% due to malloc/free hooking, 2% due to buffer metadata maintaining
  • The 3.9% can be eliminated if our system is integrated into the allocator
  • MySQL (w/t Heartbleed): mysql-stress-test.pl; no observable overhead
  • Nginx (w/t Heartbleed): AB; throughput overhead 4.2%

27 Program Vulnerability Reference Heartbleed UR & Overflow CVE-2014-0160 bc-1.06 Overflow Bugbench [57] GhostXPS 9.21 UR CVE-2017-9740

  • ptipng-0.6.4

UaF CVE-2015-7801 tiff-4.0.8 Overflow CVE-2017-9935 wavpack-5.1.0 UaF CVE-2018-7253 libming-0.4.8 Overflow CVE-2018-7877 SAMATE Dataset Variety 23 heap bugs [58]

slide-28
SLIDE 28

Contribution and Limitations

  • The first work that can patch all the following heap vulnerabilities without

manual analysis effort

  • Overflow, use after free, uninitialized read
  • Prominent features:
  • Code-less patching
  • Very small overhead (several percentages)
  • You can still use your favorite heap allocator
  • A showcase how heavyweight offline analysis can be seamlessly

combined with lightweight online defenses

  • Targeted calling context encoding: 6x speed up
  • Limitations
  • Cannot handle some vulnerabilities: e.g., an overflow within a struct
  • Overflow leads to DoS: padding may be considered, as used in HeapTherapy
  • Re-compilation needed: binary instrumentation is possible

28

slide-29
SLIDE 29

THANKS!

Q&A

Qiang Zeng (zeng1@cse.sc.edu)

slide-30
SLIDE 30

30

free call Align bit is set? Get alignment information Get original buffer address Invoke original free End Push the buffer into the queue of freed blocks Overflow bit is set? Turn the guard page into a normal page Yes Yes No No Use-after-free bit is set? No Yes
