HEALTHCARE EQUIPMENT Utilizing BIM In Healthcare Engineering and Planning Bukola Jaji, Cockrell School of Engineering MEDICAL EQUIPMENT PLANNING INTRODUCTION My Role as Equipment Coordinator Senior Project Engineer at Beck Healthcare
SLIDE 2
SLIDE 3
My Role as Equipment Coordinator § Senior Project Engineer at Beck Healthcare § Medical Equipment enthusiast, current student at Cockrell Engineering in MSEM program Building Information Modeling (BIM) for Equipment Planning § For healthcare providers § For AEC team Significance of Healthcare Design and Construction § Areas of new development in the industry § You as a patient are the end receiver of product
INTRODUCTION
SLIDE 4
IT’S MY FIRST DAY
SLIDE 5
LESSON LEARNED
Preparation begins in the project model…Not in the field.
SLIDE 6
THE EMPHASIS OF QAQC
SLIDE 7
THE EMPHASIS OF QAQC
SLIDE 8
SEEK & FIND
SLIDE 9
SEEK & FIND HEALTHCARE FLOOR PLAN
SLIDE 10
SEEK & FIND HEALTHCARE FLOOR PLAN
SLIDE 11
SEEK & FIND HEALTHCARE FLOOR PLAN
How Fast was it to find the items in the first Floor Plan? How Fast was it to find items in Second Floor Plan? 5min/item checking datasheets vs. 0.5 secs applying filter for all items If this were scored on Accuracy, which would you feel more comfortable with submitting?
SLIDE 12
§ Parameter usage Optimizes use/function/operation of Revit Technology § Consolidates medical equipment data (information accessible to multiple parties by linkage of programs) § Produces higher quality and informative plans for AEC team and makes QAQC more efficient process
QAQC IN BIM
SLIDE 13
BIM IN MEDICAL EQUIPMENT PLANNING
SLIDE 14
REVIT
SLIDE 15
REVIT
SLIDE 16
SLIDE 17
SLIDE 18
DROFUS
SLIDE 19
SLIDE 20
CONNECTING THE DOTS
SLIDE 21
CONNECTING BIM APPLICATIONS
SLIDE 22
This takes time.
MODELING THE EQUIPMENT
The 3d detail isn’t the time investment. The time investment is getting general shapes right, getting general size right, comparing and reading through multiple pages of Literature on devices. High level 3D detail is a small add on time, but valuable.
SLIDE 23
EQUIPMENT LIBRARY BUILT IN DROFUS
BUILDING THE DATABASE
SLIDE 24
- 1. DROFUS DATA EXPORTED IN EXCEL
- 2. REVIT .RFA FAMILIES (WITH SELECTED PARAMETERS EXPORTED VIA CTC)
- 3. POPULATE DATA Via Excel (Functions MATCH and INDEX, CADID)
- 4. IMPORT data BACK IN TO REVIT via CTC
LINKING THE DATA
SLIDE 25
SLIDE 26
SLIDE 27
DELIVERABLE
SLIDE 28
REVIT VISABLITY FEATURE
SLIDE 29
ELECTRICAL EQUIPMENT
SLIDE 30
TELECOM EQUIPMENT
SLIDE 31
PLUMBING EQUIPMENT
SLIDE 32
Add Tags and schedule for reference, This could be the handoff to our MEP engineers to design CDs…
NEXT STEP IS TO INCLUDE SCHEDULE
SLIDE 33
- Reduce field change cost
- Reduce delays in schedule
- Improve quality of CDs
- Transition more smoothly for hospital and staff
- Happy staff, happy patients
PROS IN IMPLEMENTING THIS METHOD
SLIDE 34
DISCUSSION
SLIDE 35
…TO BE INNOVATIVE? OR NOT
SLIDE 36
REFERENCES
"Company." dRofus. dRofus, 2015. Web. 5 Aug. 2016. <http://www.drofus.no/en/company/>. Elahi, Furqan. Medical Equipment Planning and Construction of a Interventional neuroradiology Suite. N.p.: n.p., 2006. Print. Kemper, John E. Launching A Capital Facility Project. Chicago: Health Administration Press, 2010.
- Print. A Guide for Healthcare Leaders.
Linehan, Michael, and Brandon Andress. "Medical Equipment and BIM." Health Facility Management 1
- Nov. 2013: 13-15. Print.
"Overview." Autodesk. Autodesk, n.d. Web. 5 Aug. 2016. <http://www.autodesk.com/products/ revit-family/overview>. "Products." CAD Technology Center. CAD Technology Center, 2014. Web. 5 Aug. 2016. <https://www.cadtechnologycenter.com/products/revit-expresstools.html>
SLIDE 37
THANK YOU.
