GVPLS/LPE - 1

GVPLS/LPE - Generic VPLS Solution based on LPE Framework Update version 01

Andrew Malis Alain Vedrenne Himanshu Shah Pascal Menezes Marty Borden Simon Hunt Vasile Radoaca Ananth Nagarajan Javier Achirica Muneyoshi Sujuki Yael Dayan Yaron Raz

Vasile Radoaca/Dinesh Mohan Nortel Networks

GVPLS/LPE - 2

Agenda

• Characteristics of the GVPLS Model
• Key elements of the version 01
• Requirements compliance
• Next Steps

GVPLS/LPE - 3

History

• LPE Framework document – September 2001
• GVPLS/LPE solution - November 2002
• draft-rosen-ppvpn-l2-signaling-02.txt – March

2002

GVPLS/LPE - 4

Characteristics of the GVPLS model

• Decomposes MAC Learning and Forwarding from the

VPLS core forwarding

– MAC learning is done on the U-PE access devices – VPLS core forwarding is done on the N-PE devices

• Minimizes the number of control sessions between the

U-PE devices

– regardless of the number of U-PE devices, each U-PE device has maximum 2 control sessions with the local N-PE device

• The VPLS core PWs identify both the N-PE and U-PE

devices

– tradeoff between MAC-Learning and the number of PWs in the core

• Allows efficient OAM and Multicast schemes to be

implemented

– provides a consistent traceability path between SP U-PE devices

GVPLS/LPE - 5

GVPLS Reference Model

PW: P2P or MP2P VC-4 Extension PWs: VC-2 Attachment VC VC-3

VSI-N VSI-N

N-PE A N-PE B U-PE U-PE CE CE

VSI

SET

VSI VSI-U

CE

VSI-U

CE Attachment VC VC-1 VC-6 VC-7 VC-8

GVPLS/LPE - 6

Key elements for version 01

• Extends and complements the non-distributed model

– non-distributed and distributed models can co-exist together

• Aligns with the Functional decomposition proposed by the DT
• Explains the rationale of the Distributed Model and deployment scenarios
• Supports clear separation between access and metro-core networks

– forwarding the customer packets is based on a SP Address scheme instead of the customer MAC addresses

• Supports different access technologies

– Q-in-Q – PW Martini – 802.1 Q VLAN – flexible to adopt new L2 protocols

• Supports P2P PW and M2P PW in a consistent way

– The M2P PW are not mandatory, but may enhance the scalability of the model

• Extends the PWE3/Martini signaling method to support both the distributed

and non-distributed models– also, it allows P2P, M2P PWs to coexist together

• Allows inter-working between VPLS/HVPLS and GVPLS
• Supports L2 VPN Requirements

GVPLS/LPE - 7

GVPLS Solution

Abstraction Layer

• Common Information Model
• Common Signaling Model
• Common Date Plan
• Common Auto-discovery model

DPE HPE

• U-PE-sf devices
• Access Encapsulation
• Martini
• MAC-in-MAC
• proprietary type
• - MPLS core
• U-PE-s devices
• Access Encapsulation
• Martini
• Q-in-Q
• VLAN
• - MPLS core

Solutions: VPLS/HVPLS Solutions LPE, DTLS

Value

GVPLS/LPE - 8

Additional Requirements addressed by version 01

• Performance & Scalability transparency to the type &

number of CE devices

• Scalable deployment:

– Incremental build-up – # of VPNs – # of End-points/VPLS – # of customer MAC addresses

• VPLS Customers protection

– remove Single Point of Failure – isolates the customer MAC addresses to the SP Edge U-PE and forward the customer packets using SP address scheme

• Allow the N-PE devices to perform simultaneous

multiple services [IPVPN, VPLS, L2VPN]

GVPLS/LPE - 9

Future Steps

• Convergence on Signaling

– draft-rosen-ppvn-signaling-02.txt

• Integrate QoS, Resiliency
• Enhance OAM capabilities
• Convergence with VPLS

GVPLS/LPE - 10

History of the Distributed model

• LPE Framework document – publish on

September 2001

• GVPLS/LPE solution - publish on November

2002

• DTLS – publish August 2001
• draft-rosen-ppvpn-l2-signaling-02.txt – publish
• n 2002
