Grid Interoperation and Regional Collaboration Eric Yen ASGC Academia Sinica Taiwan 23 Jan. 2006 Dreams of Grid Computing Global collaboration across administrative domains by sharing of people, resources, data, applications, and

slide-1
SLIDE 1

Grid Interoperation and Regional Collaboration

Eric Yen ASGC Academia Sinica Taiwan 23 Jan. 2006

slide-2
SLIDE 2

Dreams of Grid Computing

 Global collaboration across administrative domains

by sharing of people, resources, data, applications, and instruments, etc.

 Production efficiency  enables the e-Infrastructure -- a global knowledge

infrastructure

 Scalability of the number, robustness & performance

  • f services

 On-demand provisioning  Global science needs global grid  Bridge the digital divide

slide-3
SLIDE 3

Goals for Grid Interoperation

 All for one and one for all !  Abstraction of system functions, commands, and user actions to

achieve system and installation independence

 Retain full administrative autonomy at all participants  Natural extension of each grid’s efforts to include more resources in

their own infrastructure

 Efficiency through collaboration  Facilitating Grid Standardization  Other functionality concerns

 Discovery - metadata standards for grid resources  Site Verification - ongoing / one time / scheduled  Job monitoring  Define Policies and Rules of Engagement.  Security procedures  Problem resolution

slide-4
SLIDE 4

Service-Oriented Architecture I

 A service is the logical manifestation of some

physical or logical resources (like DBs, programs, devices, humans, etc.) and/or some application logic that is exposed to the network.

 Service interaction is facilitated by message

exchanges.

from Atkinson, DeRoure, Dunlop, and Fox et. al., Web Service Grids: An Evolutionary Approach

slide-5
SLIDE 5

Service-Oriented Architecture II

 Success of the Grid infrastructure needs to be

application-driven, and under-pinned by a set of core middleware services.

 Decompose over the Network -- Ian Foster

 Client can integrate dynamically

 select & compose services  select “best of breed” providers  publish result as a new service

 Problems

 Wide diversity of software platforms used by Grid projects/systems.  re-invention of similar services in multiple projects  limited sharing of software prototypes between projects

slide-6
SLIDE 6

Web Services-based Grid Infrastructure

 Model the world as a collection of services  Resource Descriptions and Aggregation  Discovery  Composition  Adaptation & Evolution  Quality of Services: security, performance,

reliability, ...

 Workflow (lifecycle management)  Open Source Implementation

slide-7
SLIDE 7

Oliver Keeble

Enabling Grids for E-sciencE

INFSO-RI-508833 7

Components

Component LCG/EGEE OSG ARC Monitoring/IS MDS, LDAP, GLUE, BDII, R-GMA MDS, GLUE, GridCat, MonALISA, LDAP LDAP, ARC schema, MDS Security GSI GSI GSI Software Installation Privileged users, Publish utility All VO members, Flatfile Job submission & description GRAM / JDL GRAM / RSL, Condor-G GridFTP / RSL VO support and management VOMS, LDAP VOMS, GUMS VOMS Data Management GridFTP, LFC, RLS SRM GridFTP, SRM v1.1 GridFTP, RC, RLS SRM v1.1 client

  • Avoid Divergence!

Source: Oliver Keeble, LCG Interoperation

slide-8
SLIDE 8

LCG

slide-9
SLIDE 9

Oliver Keeble

Enabling Grids for E-sciencE

INFSO-RI-508833 9

OSG in the GOCdb

Source: Oliver Keeble, LCG Interoperation

slide-10
SLIDE 10

Oliver Keeble

Enabling Grids for E-sciencE

INFSO-RI-508833 10

LCG/OSG Timeline

  • Week 2

– LCG client tools installed as exp software – Site Passes Gstat Grid Status tests – LCG to OSG job submissions working via RB

  • Week 3

– SFTs running at the OSG site.

  • All green except for accounting and CAs
  • Needed modification to find middleware
  • MON box at CERN

– OSG to LCG job submissions working

Source: Oliver Keeble, LCG Interoperation

slide-11
SLIDE 11

Oliver Keeble

Enabling Grids for E-sciencE

INFSO-RI-508833 11

LCG/OSG: STATUS

  • Interoperation is a mutual process…
  • LCG to OSG

– OSG appears as a single site – 3 OSG sites moving to full interoperability – IS, monitoring, job matches, data transfer – Modified SFTs pass with the exception of Accounting and CAs – Generic Info Provider installed – Dteam supported

  • OSG to LCG

– Job submission works – Further work required on OSG monitoring of LCG sites – No standard monitoring interface

Source: Oliver Keeble, LCG Interoperation

slide-12
SLIDE 12

Oliver Keeble

Enabling Grids for E-sciencE

INFSO-RI-508833 12

LCG/OSG: Outstanding issues

  • LCG jobs need to source the environment

– Requires RB fix

  • Investigate the exp software installation and advertisement

– Harmonisation?

  • VOs and their management

– Common monitoring VO? – GUMS / VOMS versioning

  • CAs
  • Accounting

– Adequate logging for audit

  • Operations

– What happen when sites have problems – EGEE has a very proactive operations policy

  • Monitoring

– Suffer from lack of common interfaces, N² problem – MonALISA/R-GMA interoperation – MIS-CI

  • Data Management

– FTS

  • Add more OSG sites!

Source: Oliver Keeble, LCG Interoperation

slide-13
SLIDE 13

Oliver Keeble

Enabling Grids for E-sciencE

INFSO-RI-508833 13

ARC

  • From the meeting between LCG and Nordugrid at CERN

31st August 2005, three options were presented.

– LONG TERM - Agree on the interfaces at the site level and work towards producing code that works with these interfaces.

  • Deploy the LCG CE and SE information provider in parallel with the

ARC

– MEDIUM TERM - Present these interfaces at the Grid boundary and create a portal that does forwarding and translation. – SHORT TERM - Deploy the LCG and ARC CE in parallel at large sites.

  • Outstanding Tasks

– Document the LCG CE – LCG to ARC job submission – ARC to LCG job submission – Service Discovery / Glue 2

Source: Oliver Keeble, LCG Interoperation

slide-14
SLIDE 14

ARC/NorduGrid

slide-15
SLIDE 15

Joint OSG and EGEE Operations Workshop, Culham, September 2005 15

Interoperability background

  • Proposed work plan from the CERN meeting:

–Short term: Multiple Middlewares at large sites –Medium term: Gateways between grids –Long term: Common Interfaces

  • Short term is being addressed already
  • Work plan made for Medium term tasks
  • Long term: CRM Initiative, GLUE2, GGF, GT4

Source: Michael Gronager, EGEE/ARC Interoperability Status

slide-16
SLIDE 16

Joint OSG and EGEE Operations Workshop, Culham, September 2005 16

Common Interfaces

Service/component LCG-2, gLite ARC Basis GT2 from VDT GT2 own patch, GT3 pre-WS Data transfer GridFTP, SRM (DPM) GridFTP, SRM v1.1 client Data management EDG RLS, Fireman & Co, LFC RC, RLS, Fireman Information LDAP, GLUE1.1, MDS+BDII, R- GMA LDAP, ARC schema, MDS-GIIS Job description JDL (based on classAds) RSL Job submission Condor-G to GRAM GridFTP VO management VOMS, gLite VOMS, CAS (?) VOMS

  • Diverges mainly on:
  • Job submission and description
  • However, work on JSDL is in progress
  • Information system

Source: Michael Gronager, EGEE/ARC Interoperability Status

slide-17
SLIDE 17

Joint OSG and EGEE Operations Workshop, Culham, September 2005 17

Common Interfaces – higher level

  • Condor / Condor-G

–LCG supports submission via Condor-G natively –LCG supports Condor as a queuing system –ARC supports Condor as a queuing system –Cooperation between ARC and Condor led in October 2004 to Condor-G version that can submit jobs to ARC GridFTP (translation from ARC infosystem schema to GLUE was developed by Rod Walker). Was meant to be used by LCG – but nobody configured an RB this way yet

  • Perhaps the most important common

interface?

Source: Michael Gronager, EGEE/ARC Interoperability Status

slide-18
SLIDE 18

Joint OSG and EGEE Operations Workshop, Culham, September 2005 18

Gateways

  • Possible submission scheme from LCG to

ARC

–Setup an LCG CE using Condor LRMS –Setup Condor-G queue to submit to ARC

  • Possible submission scheme from ARC to

LCG

–Setup an ARC CE using Condor LRMS –Setup Condor-G queue to submit to LCG

Source: Michael Gronager, EGEE/ARC Interoperability Status

slide-19
SLIDE 19

Joint OSG and EGEE Operations Workshop, Culham, September 2005 19

Major Architectural Difgerences

  • Globus GRAM submission does not work for many

jobs:

–Each new queued job spawns a process on the gate keeper, which regularly executes a Perl script –Does not perform for more than 400 jobs

  • Globus MDS badly implemented:

–Problems with caching –Schema not complete

  • Globus has no broker

Source: Michael Gronager, EGEE/ARC Interoperability Status

slide-20
SLIDE 20

last update 01/11/06 04:29 AM

LCG

LCG and EGEE Grid Sites in the Asia-Pacific Region

4 LCG sites in Taiwan 12 LCG sites in Asia/ Pacific Academia Sinica Grid Centre

  • - Tier-1 Centre for the LHC

Computing Grid (LCG)

  • - Asian Operations Centre

for LCG and EGEE

  • - Coordinator of the

Asia/Pacific Federation in EGEE

LCG site

  • ther site

PAEC NCP Islamabad IHEP Beijing KNU Daegu

  • Univ. Melbourne

GOG Singapore KEK Tsukuba ICEPP Tokyo Taipei - ASGC, IPAS NTU, NCU VECC Kolkata Tata Inst. Mumbai

AP Federation now shares the e-Infrastructure with WLCG

slide-21
SLIDE 21

2005/12/16 Simon C. Lin / ASGC

  • Aim of EGEE:
  • “to establish a seamless European Grid infrastructure for the

support of the European Research Area (ERA)”

  • Achievements of EGEE:
  • Exceeding almost all final goals
  • Scope expanded beyond Europe
  • Originally, 4 Federations of CERN, Italy, UK, France
  • Russia joined 25 March 2005
  • Taiwan joined 17 October 2005
  • AP Federation was late in terms of EGEE operations
  • However, LCG was operational simultaneously with the rest
  • f world since 19 March 2003 (LCG-0)

Asia Pacific Federation

slide-22
SLIDE 22

2005/12/16 Simon C. Lin / ASGC

Plan of AP Federation

 VO Services: deployed from April 2005 in Taiwan (APROC)  LCG: ATLAS, CMS  BioInformatics, BioMed  Geant4  APeSci : for collaboration general e-Science services in Asia

Pacific Areas

 APDG: for testing and testbed only  TWGRID: established for local services in Taiwan  Potential Applications  LCG, Belle, nano, biomed, digital archive, earthquake, GeoGrid, astronomy, Atmospheric Science

slide-23
SLIDE 23

2005/12/16 Simon C. Lin / ASGC

 Production CA Services  AP CIC/ROC  VO Support  Pre-production site  User Support  MW and technology development  Application Development  Education and Training  Promotion and Outreach  Scientific Linux Mirroring and Services

EGEE Asia Pacific Services by Taiwan

slide-24
SLIDE 24

Interoperation and Collaboration

 Objectives

 Building Grid Infrastructure by Application-led projects  Ensure to be scalable in number, robustness & performance of

services and sites

 Protect the regional investments in Grid MW components and

evolve continuously

 Approaches: Application-driven

 Converge to a simple, well-defined service-oriented architecture  Capture generic middleware infrastructure components  Construct a middleware repository for re-engineering, integrative

testing and interoperability insurance.

 Adaption to Web Services Architecture  Close collaboration with other major Grids projects and

standardization organizations in the world

slide-25
SLIDE 25

Summary

 Capturing generic middleware services from application

requirements --> closely interaction with application communitites to constuct effective science services

 Simplify construction by decomposing content, function and

resource

 Construct a middleware repository for re-engineering,

integrative testing and interoperability insurance.

 Open Source Model provides a new kind of knowledge- and

community-building infrastructure

 Diversity is the norm and healthy, but collaboration is

essential on a worldwide scale
