Grid-enabled for Digital Archives: The Development and Applications of SRM- SRB interface for DataGrid Services

Wei-Long UENG Academia Sinica Grid Computing Taiwan

Outline

• Introduction to the National Digital

Archive Program Data Grid Services

• Deployment of Data Grid as the

Information Infrastructure

• Interoperation

– SRM-SRB interface implementation and application

• Summary

Goals of NDAP

• Preserve national cultural collections
• Popularize fine cultural holdings
• Revitalize cultural heritage and cultural

development

• Invigorate cultural, content and value-added

industries

• Enhance research, education and learning
• Promote knowledge and information sharing
• Improve literacy, creativity and quality of life
• Embrace international communities and

collaboration Cultural, Academic, Socio- economic & Educational (CASE) Values

Digital Archives in Taiwan

• Three Levels

– Archive Level

• high resolution, for preservation purposes
• accessible on a case-by-case basis

– Open-Market Level

• medium resolution, for value-added, commercial

purposes

• accessible for a fee by membership or by licensing

agreement

– Public Information Access Level

• low resolution, for educational purposes
• accessible to the public free of charge

Information Infrastructure

• Digital archives/libraries are widely

recognized as a crucial component of a global information infrastructure

• Pursue research and development efforts
• n many aspects of digital archive/library

technologies:

– (1) the establishment of standardized information reference guidelines for digital content creation, storage, and processing – (2)the development of common and application-specific information processing infrastructure and tools

Requirements

• Long-Term Preservation and Data Creation

– preserving ability to read (physically) and understand (logically)

• Full Spectrum and Precise Metadata in Collection, Object

and Management Level

• Workflow Support: Digital Information Life-Cycle

– Create--> Content Analysis & Annotation--> IPR Protection --> Repurposing-->Multi-modal/Integrative Search --> Archive

• Data Exploration across Institutional and Disciplinary

Domains

• Petabyte Scale Storage Management with Performance

Requirements

• Long-Term Preservation and Data Creation

– preserving ability to read (physically) and understand (logically)

• Full Spectrum and Precise Metadata in Collection, Object

and Management Level

• Workflow Support: Digital Information Life-Cycle

– Create--> Content Analysis & Annotation--> IPR Protection --> Repurposing-->Multi-modal/Integrative Search --> Archive

• Data Exploration across Institutional and Disciplinary

Domains

• Petabyte Scale Storage Management with Performance

A New Information Infrastructure is Required!

Why Grid is needed in multiple projects

• To conduct R&D and integration tasks to help

digitize and network the collections and resources of different institutes or multiple projects.

• A Data Grid Services is necessary to provide

virtualized middleware services for sharing data across distributed, heterogeneous data resources in different administrative and security domains.

• Digital Archives in Taiwan demand reliable storage systems

for persistent digital objects, well-organized information structure for effective content management, efficient and accurate information retrieval mechanisms, and flexible services for variant users needs.

• Grid technology enlightened a viable solution for long-

term preservation and processing diversified heterogeneous Petabyte scale digital archives.

• Data Grid aims to set up a computational and data-

intensive grid of resources for data analysis. It requires coordinated resource sharing, collaborative processing and analyzing on huge amounts of data produced and stored by many institutions.

Why Grid infrastructure for NDAP in general is required

Workflow of Digital Archives

Middleware Deployment

• The SRB system in Taiwan is used for the

long-term preservation of the digital contents produced by the digital archives projects.

• The system was deployed by the

Academia Sinica Grid Computing Centre (ASGC) in early 2004.

• Constituted from 8 sites in different

institutes.

System Architecture

Interoperation

• With the nature of Grid, the most

effective way to share data resources is to integrate the data sources and data grids.

• SRM for SRB interface is to make the

popular SRB Data Grid System interoperable with the EGEE infrastructure.

• Support the standard SRM services

for SRB

14

Why SRM

15

• SRM is an unique interface for accessing diffident backend storages

for diffident middleware.

• Easy to develop applications to adapt different backend storages.
• Provide space and file management on the storage system.
• SRM is the web service interface and the implementation usually

depends on the backend storage technology.

• Grid middleware needs to access files with an uniform interface

Concept

16

Concept

16

Architecture Overview

17

Core SRB+DSI Auxiliary Filecatalog Gridftp/management API SRM API File transfer (gridftp)

Web Service Data server management Users/applications

18

• User Interface

18

• User Interface
• SURL
• Gridftp/

management commands

18

• User Interface
• SURL
• Gridftp/

management commands

• Host information
• Hostname:t-ap51.grid.sinca.edu.tw
• Info: AMGA server

18

• User Interface
• Hostname: t-ap20.grid.sinica.edu.tw
• Info: SRB server (SRB-DSI installed)
• Return some

information

• SURL
• Gridftp/

management commands

• Host information
• Hostname:t-ap51.grid.sinca.edu.tw
• Info: AMGA server

18

• User Interface
• Hostname: t-ap20.grid.sinica.edu.tw
• Info: SRB server (SRB-DSI installed)
• Return some

information

• Hostname: fct01.grid.sinica.edu.tw
• The end point: httpg://fct01.grid.sinica.edu.tw:8443/axis/services/srm
• Info: SRM interface
• TURL
• SURL
• Gridftp/

management commands

• Host information
• Hostname:t-ap51.grid.sinca.edu.tw
• Info: AMGA server

List the content of a SRB directory

19

[sary357@fct01 isgc2008]$ sh SrmLs.sh Please input the SURL you'd like to list the content:srm://fct01.grid.sinica.edu.tw:8443/axis/services/srm?/AS/home/sary357.ASGC/sary3571/ *************** SrmLs ********************** Status code: SRM_SUCCESS Explanation: null ========================================================== ===== The individual status and result ========= The status code:SRM_SUCCESS The explanation:null File name:/AS/home/sary357.ASGC/sary3571 The Size:0 The File Type:DIRECTORY The owner of this file/directory:sary357 The owner permission of this file/directory:RW ************** The sub dir and files ***************** File name:/AS/home/sary357.ASGC/sary3571/steps2.html1 CheckSumType: The Size:9 The File Type:FILE The owner of this file/directory:sary357 The owner permission of this file/directory:RW File name:/AS/home/sary357.ASGC/sary3571/20080409 The Size:0 The File Type:DIRECTORY The owner of this file/directory:sary357

Putting a file

20

sary357@fct01 isgc2008]$ sh SrmPut.sh Please input the local file name you'd like to put:/tmp/testFile1.txt Please input the SURL you'd like to put:srm://fct01.grid.sinica.edu.tw:8443/axis/services/srm?/AS/home/sary357.ASGC/sary3571/testFile1.txt ***************SrmPrepareToPut*********************** Token:1207660686127 Status code: SRM_SUCCESS Explanation: null =============================================================== URI: srm://fct01.grid.sinica.edu.tw:8443/axis/services/srm?/AS/home/sary357.ASGC/sary3571/testFile1.txt | The status code: SRM_SPACE_AVAILABLE | TURL: gsiftp://t-ap20.grid.sinica.edu.tw:2811/AS/home/sary357.ASGC/sary3571/testFile1.txt **********Try to upload the data****************** Upload TURL: gsiftp://t-ap20.grid.sinica.edu.tw:2811/AS/home/sary357.ASGC/sary3571/testFile1.txt start.... Upload TURL: gsiftp://t-ap20.grid.sinica.edu.tw:2811/AS/home/sary357.ASGC/sary3571/testFile1.txt end...... *************** SrmPutDone ********************* Status code: SRM_SUCCESS Explanation: null

Getting a file

21

[sary357@fct01 isgc2008]$ sh SrmGet.sh Please input the SURL you'd like to get:srm://fct01.grid.sinica.edu.tw:8443/axis/services/srm?SFN=/AS/home/sary357.ASGC/111.jpg Please input the local file name you'd like to store:/tmp/111.jpg *************** SrmPrepareToGet ********************** The status: Status code: SRM_SUCCESS Explanation: null ======================================================== The individual result: The SURL: srm://fct01.grid.sinica.edu.tw:8443/axis/services/srm?SFN=/AS/home/sary357.ASGC/111.jpg the status code:SRM_FILE_PINNED the explanation of this SURL:null The TURL:gsiftp://t-ap20.grid.sinica.edu.tw:2811/AS/home/sary357.ASGC/111.jpg ************* Got the TURL **************************** ************* Download file *************************** download from TURL: gsiftp://t-ap20.grid.sinica.edu.tw:2811/AS/home/sary357.ASGC/111.jpg start.... download from TURL: gsiftp://t-ap20.grid.sinica.edu.tw:2811/AS/home/sary357.ASGC/111.jpg end...... And the file name after downloading is /tmp/111.jpg. *************** SrmReleaseFiles ******************* Status code: SRM_SUCCESS Explanation: null ==========================================================

Summary

• Need more interactions & sharing in LTP & data

curtain experiences inside and between academy and industry.

• Provides an production quality infrastructure for

distributed access to central-based data and replications.

• Make SRB an archival system of gLite-based e-

infrastructure.

• Support Lifetime policy for files - volatile, durable,

permanent in SRB

• Impose the same VO and security control to SRB as

the Grid infrastructure

Many thanks for your attention.
