SLIDE 1

Greedy MaxCut Algorithms and their Information Content

Yatao Bian, Alexey Gronskiy and Joachim M. Buhmann

Machine Learning Institute, ETH Zurich

April 27, 2015

1 / 19

SLIDE 2

MaxCut

MaxCut: classical NP-hard problem

3 / 19

SLIDE 5

MaxCut

MaxCut: classical NP-hard problem

G = (V, E), vertex set V , edge set E, weights wij ≥ 0

x y z

1 3 2

3=1+2

cut value

3 / 19

SLIDE 6

MaxCut

MaxCut: classical NP-hard problem

G = (V, E), vertex set V , edge set E, weights wij ≥ 0
CUT c := (S, V \S), cut space C (|C| = 2n−1 − 1)

x y z

1 3 2

3=1+2

cut value

3 / 19

SLIDE 7

MaxCut

MaxCut: classical NP-hard problem

G = (V, E), vertex set V , edge set E, weights wij ≥ 0
CUT c := (S, V \S), cut space C (|C| = 2n−1 − 1)
Cut value: cut(c, G) :=

i∈S,j∈V \S wij

x y z

1 3 2

3=1+2

cut value

3 / 19

SLIDE 8

MaxCut

MaxCut: classical NP-hard problem

G = (V, E), vertex set V , edge set E, weights wij ≥ 0
CUT c := (S, V \S), cut space C (|C| = 2n−1 − 1)
Cut value: cut(c, G) :=

i∈S,j∈V \S wij

x y z

1 3 2

3=1+2

cut value

max cut:-)

x y z

1 3 2

5=2+3

3 / 19

SLIDE 9

Greedy Algorithms for MaxCut

Name Greedy Techniques Heuristic Sorting Init. Vertices Deterministic Double Greedy Double SG (Sahni & Gonzales)

SG3 (variant of SG)
Edge Contraction (EC)

Backward

4 / 19

SLIDE 10

Double Greedy Taxonomy

5 / 19

SLIDE 11

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

5 / 19

SLIDE 12

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

5 / 19

SLIDE 13

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

1: init. 2 solutions S := ∅, T := V

works on 2 solutions

simultaneously

5 / 19

SLIDE 14

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

1: init. 2 solutions S := ∅, T := V

//in random order

2: for each vertex vi ∈ V do 10: end for

works on 2 solutions

simultaneously

for each vertex, decides

whether it should be added to S, or removed from T

5 / 19

SLIDE 15

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

1: init. 2 solutions S := ∅, T := V

//in random order

2: for each vertex vi ∈ V do 3:

ai := gain of adding vi to S

4:

bi := gain of removing vi from T

10: end for

works on 2 solutions

simultaneously

for each vertex, decides

whether it should be added to S, or removed from T

5 / 19

SLIDE 16

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

1: init. 2 solutions S := ∅, T := V

//in random order

2: for each vertex vi ∈ V do 3:

ai := gain of adding vi to S

4:

bi := gain of removing vi from T

5:

if ai ≥ bi then

6:

add vi to S

7:

else

8:

remove vi from T

9:

end if

10: end for

works on 2 solutions

simultaneously

for each vertex, decides

whether it should be added to S, or removed from T

5 / 19

SLIDE 17

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

1: init. 2 solutions S := ∅, T := V

//in random order

2: for each vertex vi ∈ V do 3:

ai := gain of adding vi to S

4:

bi := gain of removing vi from T

5:

if ai ≥ bi then

6:

add vi to S

7:

else

8:

remove vi from T

9:

end if

10: end for 11: return cut: (S, V \S), cut value

works on 2 solutions

simultaneously

for each vertex, decides

whether it should be added to S, or removed from T

5 / 19

SLIDE 18

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

1: init. 2 solutions S := ∅, T := V

//in random order

2: for each vertex vi ∈ V do 3:

ai := gain of adding vi to S

4:

bi := gain of removing vi from T

5:

if ai ≥ bi then

6:

add vi to S

7:

else

8:

remove vi from T

9:

end if

10: end for 11: return cut: (S, V \S), cut value

works on 2 solutions

simultaneously

for each vertex, decides

whether it should be added to S, or removed from T

Differences between the double greedy algorithms:

5 / 19

SLIDE 19

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

1: init. 2 solutions S := ∅, T := V

//in random order

2: for each vertex vi ∈ V do 3:

ai := gain of adding vi to S

4:

bi := gain of removing vi from T

5:

if ai ≥ bi then

6:

add vi to S

7:

else

8:

remove vi from T

9:

end if

10: end for 11: return cut: (S, V \S), cut value

works on 2 solutions

simultaneously

for each vertex, decides

whether it should be added to S, or removed from T

Differences between the double greedy algorithms: D2Greedy → select the first 2 vertices → SG

5 / 19

SLIDE 20

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

1: init. 2 solutions S := ∅, T := V

//in random order

2: for each vertex vi ∈ V do 3:

ai := gain of adding vi to S

4:

bi := gain of removing vi from T

5:

if ai ≥ bi then

6:

add vi to S

7:

else

8:

remove vi from T

9:

end if

10: end for 11: return cut: (S, V \S), cut value

works on 2 solutions

simultaneously

for each vertex, decides

whether it should be added to S, or removed from T

Differences between the double greedy algorithms: D2Greedy → select the first 2 vertices → SG SG → sort the candidates → SG3

5 / 19

SLIDE 21

Backward Greedy – Edge Contraction Algorithm

6 / 19

SLIDE 22

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

6 / 19

SLIDE 23

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

6 / 19

SLIDE 24

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

1: repeat 5: until 2 “super" vertices left

6 / 19

SLIDE 25

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

1: repeat 5: until 2 “super" vertices left

contract the lightest edge in

each step

6 / 19

SLIDE 26

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

1: repeat 5: until 2 “super" vertices left

contract the lightest edge in

each step x y z

1 3 2

v z

2+3 = 5

contraction

6 / 19

SLIDE 27

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

1: repeat 2:

find the lightest edge (x, y) in G

5: until 2 “super" vertices left

contract the lightest edge in

each step x y z

1 3 2

v z

2+3 = 5

contraction

6 / 19

SLIDE 28

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

1: repeat 2:

find the lightest edge (x, y) in G

3:

contract x, y to be a super vertex v

5: until 2 “super" vertices left

contract the lightest edge in

each step x y z

1 3 2

v z

2+3 = 5

contraction

6 / 19

SLIDE 29

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

1: repeat 2:

find the lightest edge (x, y) in G

3:

contract x, y to be a super vertex v

4:

set the edge weights connecting v

5: until 2 “super" vertices left

contract the lightest edge in

each step x y z

1 3 2

v z

2+3 = 5

contraction

6 / 19

SLIDE 30

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

1: repeat 2:

find the lightest edge (x, y) in G

3:

contract x, y to be a super vertex v

4:

set the edge weights connecting v

5: until 2 “super" vertices left 6: return the 2 super vertices

contract the lightest edge in

each step x y z

1 3 2

v z

2+3 = 5

contraction

6 / 19

SLIDE 31

Backward Greedy – Edge Contraction Algorithm

Edge Contraction (EC)

Require: graph G = (V, E) Ensure: cut, cut value

1: repeat 2:

find the lightest edge (x, y) in G

3:

contract x, y to be a super vertex v

4:

set the edge weights connecting v

5: until 2 “super" vertices left 6: return the 2 super vertices

contract the lightest edge in

each step x y z

1 3 2

v z

2+3 = 5

contraction

Backward greedy: EC tries to remove the lightest edge from the cut set in each step

6 / 19

SLIDE 32

Glance of Approximation Set Coding (ASC)

How to measure the robustness of these algorithms facing noise?

7 / 19

SLIDE 34

Glance of Approximation Set Coding (ASC)

How to measure the robustness of these algorithms facing noise?

ASC: an analogy to Shannon’s communication theory

learning procedure ⇔ communication process [Buhmann 2010]

7 / 19

SLIDE 35

Glance of Approximation Set Coding (ASC)

How to measure the robustness of these algorithms facing noise?

ASC: an analogy to Shannon’s communication theory

learning procedure ⇔ communication process [Buhmann 2010] 2 instances scenario: training G′, test G′′ (noisy instaces

f G)

G′ G′′ G noise noise “Master" Graph Two Instances

7 / 19

SLIDE 36

Glance of Approximation Set Coding (ASC)

How to measure the robustness of these algorithms facing noise?

ASC: an analogy to Shannon’s communication theory

learning procedure ⇔ communication process [Buhmann 2010] 2 instances scenario: training G′, test G′′ (noisy instaces

f G)

G′ G′′ G noise noise “Master" Graph Two Instances

Models/algorithms should generalize well from G′ to G′′

7 / 19

SLIDE 37

Approximate Solving and Algorithmic Approx. Set

Empirical risk minimizer

c⊥(G) := arg minc R(c, G)

8 / 19

SLIDE 38

Approximate Solving and Algorithmic Approx. Set

Empirical risk minimizer

c⊥(G) := arg minc R(c, G) c⊥(G′)

noise

= c⊥(G′′)

8 / 19

SLIDE 39

Approximate Solving and Algorithmic Approx. Set

Empirical risk minimizer

c⊥(G) := arg minc R(c, G) c⊥(G′)

noise

= c⊥(G′′)

γ-approximation set (solutions γ distant from

c⊥): Cγ(G) :=

c ∈ C
R(c, G) − R(c⊥, G) ≤ γ
γ: resolution

8 / 19

SLIDE 40

Approximate Solving and Algorithmic Approx. Set

Empirical risk minimizer

c⊥(G) := arg minc R(c, G) c⊥(G′)

noise

= c⊥(G′′)

γ-approximation set (solutions γ distant from

c⊥): Cγ(G) :=

c ∈ C
R(c, G) − R(c⊥, G) ≤ γ
γ: resolution

Cγ(G) c⊥ γ

8 / 19

SLIDE 41

Approximate Solving and Algorithmic Approx. Set

Empirical risk minimizer

c⊥(G) := arg minc R(c, G) c⊥(G′)

noise

= c⊥(G′′)

γ-approximation set (solutions γ distant from

c⊥): Cγ(G) :=

c ∈ C
R(c, G) − R(c⊥, G) ≤ γ
γ: resolution

Cγ(G) c⊥ γ

8 / 19

SLIDE 42

Approximate Solving and Algorithmic Approx. Set

Empirical risk minimizer

c⊥(G) := arg minc R(c, G) c⊥(G′)

noise

= c⊥(G′′)

γ-approximation set (solutions γ distant from

c⊥): Cγ(G) :=

c ∈ C
R(c, G) − R(c⊥, G) ≤ γ
γ: resolution

Cγ(G) c⊥ γ

Flow of contractive A : sequence of the

available solution sets in each step t

8 / 19

SLIDE 43

Approximate Solving and Algorithmic Approx. Set

Empirical risk minimizer

c⊥(G) := arg minc R(c, G) c⊥(G′)

noise

= c⊥(G′′)

γ-approximation set (solutions γ distant from

c⊥): Cγ(G) :=

c ∈ C
R(c, G) − R(c⊥, G) ≤ γ
γ: resolution

Cγ(G) c⊥ γ

Flow of contractive A : sequence of the

available solution sets in each step t Algorithmic t-approximation set [Gronskiy and Buhmann 2014]: CA

t (G)

8 / 19

SLIDE 44

Approximate Solving and Algorithmic Approx. Set

Empirical risk minimizer

c⊥(G) := arg minc R(c, G) c⊥(G′)

noise

= c⊥(G′′)

γ-approximation set (solutions γ distant from

c⊥): Cγ(G) :=

c ∈ C
R(c, G) − R(c⊥, G) ≤ γ
γ: resolution

Cγ(G) c⊥ γ

Flow of contractive A : sequence of the

available solution sets in each step t Algorithmic t-approximation set [Gronskiy and Buhmann 2014]: CA

t (G)

ր step t ⇔ ց resolution γ

8 / 19

SLIDE 45

Analogy of Communication System

9 / 19

SLIDE 46

Analogy of Communication System

(Not going into detail here)

9 / 19

SLIDE 47

Analogy of Communication System

(Not going into detail here)

Analogical mutual information in step t

IA

t

:= EG′,G′′

log
|C|·|∆CA

t (G′,G′′)|

|CA

t (G′)|·|CA t (G′′)|

∆CA

t (G′, G′′) = CA t (G′) ∩ CA t (G′′)

9 / 19

SLIDE 48

Analogy of Communication System

(Not going into detail here)

Analogical mutual information in step t

IA

t

:= EG′,G′′

log
|C|·|∆CA

t (G′,G′′)|

|CA

t (G′)|·|CA t (G′′)|

∆CA

t (G′, G′′) = CA t (G′) ∩ CA t (G′′)

Information content of A

9 / 19

SLIDE 49

Analogy of Communication System

(Not going into detail here)

Analogical mutual information in step t

IA

t

:= EG′,G′′

log
|C|·|∆CA

t (G′,G′′)|

|CA

t (G′)|·|CA t (G′′)|

∆CA

t (G′, G′′) = CA t (G′) ∩ CA t (G′′)

Information content of A

channel capacity IA := maxt IA

t

9 / 19

SLIDE 50

Information Content of an Algorithm A

G′ G′′ P(G) A (G′) A (G′′) Data Inputs Algorithm Optimal c⊥(G) mutual information: IA

t

:= E

log
|C| |CA

t (G′)∩CA t (G′′)|

|CA

t (G′)|·|CA t (G′′)|

(stepwise information)

Information content of A : channel capacity IA := maxt IA

t

10 / 19

SLIDE 51

Information Content of an Algorithm A

G′ G′′ P(G) A (G′) A (G′′) Data Inputs Algorithm Optimal c⊥(G) mutual information: IA

t

:= E

log
|C| |CA

t (G′)∩CA t (G′′)|

|CA

t (G′)|·|CA t (G′′)|

(stepwise information)

ր step t ⇔ ց resolution γ less informative but more robust Information content of A : channel capacity IA := maxt IA

t

10 / 19

SLIDE 52

Information Content of an Algorithm A

G′ G′′ P(G) A (G′) A (G′′) Data Inputs Algorithm Optimal c⊥(G) mutual information: IA

t

:= E

log
|C| |CA

t (G′)∩CA t (G′′)|

|CA

t (G′)|·|CA t (G′′)|

(stepwise information)

ր step t ⇔ ց resolution γ less informative but more robust Information content of A : channel capacity IA := maxt IA

t

10 / 19

SLIDE 53

Information Content of an Algorithm A

G′ G′′ P(G) A (G′) A (G′′) Data Inputs Algorithm Optimal c⊥(G) mutual information: IA

t

:= E

log
|C| |CA

t (G′)∩CA t (G′′)|

|CA

t (G′)|·|CA t (G′′)|

(stepwise information)

ր step t ⇔ ց resolution γ less informative but more robust Information content of A : channel capacity IA := maxt IA

t

10 / 19

SLIDE 54

Information Content of an Algorithm A

G′ G′′ P(G) A (G′) A (G′′) Data Inputs Algorithm Optimal c⊥(G) mutual information: IA

t

:= E

log
|C| |CA

t (G′)∩CA t (G′′)|

|CA

t (G′)|·|CA t (G′′)|

(stepwise information)

ր step t ⇔ ց resolution γ less informative but more robust Information content of A : channel capacity IA := maxt IA

t

10 / 19

SLIDE 55

Information Content of an Algorithm A

G′ G′′ P(G) A (G′) A (G′′) Data Inputs Algorithm Optimal c⊥(G) mutual information: IA

t

:= E

log
|C| |CA

t (G′)∩CA t (G′′)|

|CA

t (G′)|·|CA t (G′′)|

(stepwise information)

ր step t ⇔ ց resolution γ less informative but more robust Information content of A : channel capacity IA := maxt IA

t

10 / 19

SLIDE 56

Counting – Double Greedy Algorithms

Counting methods similar for double greedy algorithms (D2Greedy, SG, SG3)

11 / 19

SLIDE 58

Counting – Double Greedy Algorithms

Counting methods similar for double greedy algorithms (D2Greedy, SG, SG3)

SG3: assume k vertices

unlabeled in step t, |CA

t (G

′)| = |CA

t (G

′′)| = 2k 11 / 19

SLIDE 59

Counting – Double Greedy Algorithms

Counting methods similar for double greedy algorithms (D2Greedy, SG, SG3)

SG3: assume k vertices

unlabeled in step t, |CA

t (G

′)| = |CA

t (G

′′)| = 2k

|CA

t (G

′) ∩ CA

t (G

′′)| 11 / 19

SLIDE 60

Counting – Double Greedy Algorithms

Counting methods similar for double greedy algorithms (D2Greedy, SG, SG3)

SG3: assume k vertices

unlabeled in step t, |CA

t (G

′)| = |CA

t (G

′′)| = 2k

|CA

t (G

′) ∩ CA

t (G

′′)|

We propose (and prove correctness) polynomial time algorithm to count (not going in detail here):

11 / 19

SLIDE 61

Counting – Edge Contraction Algorithm

In step t, there are k “super"

vertices, get |CA

t (G

′)| = |CA

t (G

′′)| = 2k−1 − 1 12 / 19

SLIDE 62

Counting – Edge Contraction Algorithm

In step t, there are k “super"

vertices, get |CA

t (G

′)| = |CA

t (G

′′)| = 2k−1 − 1

We propose polynomial time

algorithm (and prove correctness) to exactly count |CA

t (G

′) ∩ CA

t (G

′′)| 12 / 19

SLIDE 63

Counting – Edge Contraction Algorithm

In step t, there are k “super"

vertices, get |CA

t (G

′)| = |CA

t (G

′′)| = 2k−1 − 1

We propose polynomial time

algorithm (and prove correctness) to exactly count |CA

t (G

′) ∩ CA

t (G

′′)| 12 / 19

SLIDE 64

Counting – Edge Contraction Algorithm

In step t, there are k “super"

vertices, get |CA

t (G

′)| = |CA

t (G

′′)| = 2k−1 − 1

We propose polynomial time

algorithm (and prove correctness) to exactly count |CA

t (G

′) ∩ CA

t (G

′′)|

Involves calculating max. number
f common super vertices between 2

super vertex sets (details in the paper)

12 / 19

SLIDE 65

Counting – Edge Contraction Algorithm

In step t, there are k “super"

vertices, get |CA

t (G

′)| = |CA

t (G

′′)| = 2k−1 − 1

We propose polynomial time

algorithm (and prove correctness) to exactly count |CA

t (G

′) ∩ CA

t (G

′′)|

Involves calculating max. number
f common super vertices between 2

super vertex sets (details in the paper)

12 / 19

SLIDE 66

Noise Model: Gaussian Edge Weights

Master Graph G

Gaussian distributed edge weights: Wij ∼ N(µ, σ2

m), µ = 600, σm = 50

Negative edges are set to be µ.

13 / 19

SLIDE 68

Noise Model: Gaussian Edge Weights

Master Graph G

Gaussian distributed edge weights: Wij ∼ N(µ, σ2

m), µ = 600, σm = 50

Negative edges are set to be µ.

Master graph G with Gaussian weights

13 / 19

SLIDE 69

Noise Model: Gaussian Edge Weights

Master Graph G

Gaussian distributed edge weights: Wij ∼ N(µ, σ2

m), µ = 600, σm = 50

Negative edges are set to be µ.

Master graph G with Gaussian weights Noisy Graphs G

′, G ′′

G

′, G ′′ are obtained by adding Gaussian distributed noise.

Negative edges are set to be 0.

13 / 19

SLIDE 70

Noise Model: Edge Reversal

Master Graph G

14 / 19

SLIDE 71

Noise Model: Edge Reversal

Master Graph G

1. approximate bipartite G′

b: light edges,

heavy edges

14 / 19

SLIDE 72

Noise Model: Edge Reversal

Master Graph G

1. approximate bipartite G′

b: light edges,

heavy edges

heavy edges light edges

Approximate bipartite graph G′

b

14 / 19

SLIDE 73

Noise Model: Edge Reversal

Master Graph G

1. approximate bipartite G′

b: light edges,

heavy edges

2. randomly flip edges in G′

b ⇒ G,

flipping: heavy (light) ⇒ light (heavy) (flip eij) ∼ Ber(pm); pm = 0.2

heavy edges light edges

Approximate bipartite graph G′

b

14 / 19

SLIDE 74

Noise Model: Edge Reversal

Master Graph G

1. approximate bipartite G′

b: light edges,

heavy edges

2. randomly flip edges in G′

b ⇒ G,

flipping: heavy (light) ⇒ light (heavy) (flip eij) ∼ Ber(pm); pm = 0.2

heavy edges light edges

Approximate bipartite graph G′

b

Noisy Graphs G

′, G ′′ 14 / 19

SLIDE 75

Noise Model: Edge Reversal

Master Graph G

1. approximate bipartite G′

b: light edges,

heavy edges

2. randomly flip edges in G′

b ⇒ G,

flipping: heavy (light) ⇒ light (heavy) (flip eij) ∼ Ber(pm); pm = 0.2

heavy edges light edges

Approximate bipartite graph G′

b

Noisy Graphs G

′, G ′′

Flip G ⇒ G

′ and G ′′.

Probability of flipping an edge: Bernoulli distribution with p, (flip eij) ∼ Ber(p) p: noise level

14 / 19

SLIDE 76

Stepwise Information IA

t IA

t

:= EG′,G′′

log
|C|·|∆CA

t (G′,G′′)|

|CA

t (G′)|·|CA t (G′′)|

Gaussian Model, σ = 125

Edge Reversal, p = 0.65

15 / 19

SLIDE 77

Stepwise Information IA

t IA

t

:= EG′,G′′

log
|C|·|∆CA

t (G′,G′′)|

|CA

t (G′)|·|CA t (G′′)|

Gaussian Model, σ = 125

Edge Reversal, p = 0.65

IA

t

behavior: increase initially ⇒ reach the optimal step t∗ ⇒ decreases ⇒ vanishes.

15 / 19

SLIDE 78

Stepwise Information IA

t IA

t

:= EG′,G′′

log
|C|·|∆CA

t (G′,G′′)|

|CA

t (G′)|·|CA t (G′′)|

Gaussian Model, σ = 125

Edge Reversal, p = 0.65

IA

t

behavior: increase initially ⇒ reach the optimal step t∗ ⇒ decreases ⇒ vanishes.

consistent with analysis: ր t ⇒ tradeoff of roubstness and

informativeness

15 / 19

SLIDE 79

Information Content IA

IA := maxt IA

t

(channel capacity)

Gaussian Edge Weights Model Edge Reversal Model

16 / 19

SLIDE 80

Information Content IA

IA := maxt IA

t

(channel capacity)

Gaussian Edge Weights Model Edge Reversal Model

All reach max. information content in the noise free limit (G′ = G′′)

(p = 0, 1 in edge reversal model, σ = 0 in Gaussian model)

16 / 19

SLIDE 81

Information Content IA

IA := maxt IA

t

(channel capacity)

Gaussian Edge Weights Model Edge Reversal Model

All reach max. information content in the noise free limit (G′ = G′′)

(p = 0, 1 in edge reversal model, σ = 0 in Gaussian model)

1 node transmits about 1 bit information

16 / 19

SLIDE 82

Effect of Greedy Heuristics

Backward greedy double greedy

Gaussian Edge Weights Model Edge Reversal Model

17 / 19

SLIDE 83

Effect of Greedy Heuristics

Backward greedy double greedy

Gaussian Edge Weights Model Edge Reversal Model

Delayed decision making of backward greedy

17 / 19

SLIDE 84

Effect of Greedy Heuristics

Backward greedy double greedy

Gaussian Edge Weights Model Edge Reversal Model

Delayed decision making of backward greedy
EC preserves consistent solutions by contracting lightest edge (having

low probability to be included in the cut)

17 / 19

SLIDE 85

Effect of Greedy Techniques

Gaussian Edge Weights Model Edge Reversal Model

18 / 19

SLIDE 86

Effect of Greedy Techniques

Gaussian Edge Weights Model Edge Reversal Model

Initializing (D2Greedy ⇒ SG): ց, due to early decision making

18 / 19

SLIDE 87

Effect of Greedy Techniques

Gaussian Edge Weights Model Edge Reversal Model

Initializing (D2Greedy ⇒ SG): ց, due to early decision making
Sorting candidates (SG ⇒ SG3): ց, due to early decision making

18 / 19

SLIDE 88

Discussion

Observation:

Different greedy heuristics (backward, double) and different processing techniques (sorting candidates, initializing the first 2 vertices) sensitively influence the information content of A .

19 / 19

SLIDE 89

Discussion

Observation:

Different greedy heuristics (backward, double) and different processing techniques (sorting candidates, initializing the first 2 vertices) sensitively influence the information content of A .

Conjecture:

Backward greedy

delayed decision making

double greedy

for different noise models and noise levels.

19 / 19

SLIDE 90

Thank you!

Qs?

19 / 19

SLIDE 91

Supplement: Analogy of Communication System

Imaginary communication system:

message: permutations σs ∈ Σ on the data space
encoder: encoding σs using CA

t (σs ◦ G′) (codebook vector)

channel: noisy instances G′, G′′
decoder: max. overlap of approx. sets:

ˆ σ := arg maxσ∈Σ |CA

t (σ ◦ G′′) ∩ CA t (σs ◦ G′)|

Analogical mutual information in step t

IA

t (σs; ˆ

σ) := EG′,G′′

log
|C| |CA

t (G′)∩CA t (G′′)|

|CA

t (G′)|·|CA t (G′′)|

channel capacity IA := maxt IA

t

(Information content of A )

19 / 19

Greedy MaxCut Algorithms and their Information Content

Yatao Bian, Alexey Gronskiy and Joachim M. Buhmann

April 27, 2015

Contents

Greedy MaxCut Algorithms Approximation Set Coding (ASC) Applying ASC: Count the Approximation Sets Applying ASC: Experiments and Analysis

Contents

Greedy MaxCut Algorithms Approximation Set Coding (ASC) Applying ASC: Count the Approximation Sets Applying ASC: Experiments and Analysis

MaxCut

MaxCut: classical NP-hard problem

MaxCut

MaxCut: classical NP-hard problem

x y z

1 3 2

3=1+2

cut value

MaxCut

MaxCut: classical NP-hard problem

x y z

1 3 2

3=1+2

cut value

MaxCut

MaxCut: classical NP-hard problem

x y z

1 3 2

3=1+2

cut value

MaxCut

MaxCut: classical NP-hard problem

x y z

1 3 2

3=1+2

cut value

max cut:-)

x y z

1 3 2

5=2+3

Greedy Algorithms for MaxCut

Name Greedy Techniques Heuristic Sorting Init. Vertices Deterministic Double Greedy Double SG (Sahni & Gonzales)

Backward

Double Greedy Taxonomy

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

simultaneously

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

//in random order

simultaneously

whether it should be added to S, or removed from T

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

//in random order

ai := gain of adding vi to S

bi := gain of removing vi from T

simultaneously

whether it should be added to S, or removed from T

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value

//in random order

ai := gain of adding vi to S

bi := gain of removing vi from T

if ai ≥ bi then

add vi to S

else

remove vi from T

end if

simultaneously

whether it should be added to S, or removed from T

Double Greedy Taxonomy

Deterministic Double Greedy (D2Greedy)

Require: graph G = (V, E) Ensure: cut and the cut value
