GPU Clusters for HPC

Bill Kramer Director of Blue Waters National Center for Supercomputing Applications University of Illinois at Urbana- Champaign

National Center for Supercomputing Applications: 30 years of leadership

• NCSA
• R&D unit of the University of Illinois at Urbana-Champaign
• One of original five NSF-funded supercomputing centers
• Mission: Provide state-of-the-art computing capabilities (hardware, software, hpc

expertise) to nation’s scientists and engineers

• The Numbers
• Approximately 200 staff (160+ technical/professional staff)
• Approximately 15 graduate students (+ new SPIN program), 15 undergrad students
• Two major facilities (NCSA Building, NPCF)
• Operating NSF’s most powerful computing system: Blue Waters
• Managing NSF’s national cyberinfrastructure: XSEDE

Source: Thom Dunning

Petas cale Computing Facility: Home to Blue Waters

• Modern Data Center
• 90,000+ ft2 total
• 30,000 ft2 raised floor

20,000 ft2 machine room gallery

• Energy Efficiency
• LEED certified Gold
• Power Utilization Efficiency

= 1.1–1.2

• Blue Waters
• 13PF, 1500TB,

300PB

• >1PF On real apps
• NAMD, MILC,

WRF, PPM, NWChem, etc

Source: Thom Dunning

Data Intensive Computing

Source: Thom Dunning

LSST, DES Personalized Medicine w/ Mayo

NCSA’s Industrial Partners

Source: Thom Dunning

NCSA, NVIDIA and GPUs

• NCSA and NVIDIA have been partners for over a

decade, building the expertise, experience and technology.

• The efforts were at first exploratory and small scale, but

have now blossomed into providing the largest GPU production resource in the US academic cyber- infrastructure

• Today, we are focusing on helping world class science

and engineering teams decrease their time to insight for some of the world’s most important and challenging computational and data analytical problems

Imaginations unbound

Original Blue Waters Goals

• Deploy a computing system capable of sustaining more than one

petaflops or more for a broad range of applications

• Cray system achieves this goal using a well defined metrics
• Enable the Science Teams to take full advantage of the sustained

petascale computing system

• Blue Waters Team has established strong partnership with Science Teams, helping them to

improve the performance and scalability of their applications

• Enhance the operation and use of the sustained petascale system
• Blue Waters Team is developing tools, libraries and other system software to aid in operation of

the system and to help scientists and engineers make effective use of the system

• Provide a world-class computing environment for the petascale

computing system

• The NPCF is a modern, energy-efficient data center with a rich WAN environment (100-400

Gbps) and data archive (>300 PB)

• Exploit advances in innovative computing technology
• Proposal anticipated the rise of heterogeneous computing and planned to help the computational

community transition to new modes for computational and data-driven science and engineering

Imaginations unbound

Blue Waters Computing S ys tem

Sonexion: 26 usable PB

>1 TB/sec 100 GB/sec

10/40/100 Gb Ethernet Switch

Spectra Logic: 300 usable PB

120+ Gb/sec

100-300 Gbps WAN

IB Switch External Servers

Aggregate Memory – 1.6 PB

Imaginations unbound

Details of Blue Waters

Imaginations unbound

Computation by Discipline on Blue Waters

Imaginations unbound

Astronomy and Astrophysics 17.8% Atmospheric and Climate Sciences 10.4% Biology and Biophysics 23.6% Chemistry 6.5% Computer Science 0.5% Earth Sciences 2.0% Engineering 0.05% Fluid Systems 5.1% Geophysics 1.3% Humanities 0.0002% Materials Science 3.3% Mechanical and Dynamic Systems 0.03% Nuclear Physics 0.7% Particle Physics 25.9% Physics 2.5% Social Sciences 0.3% STEM Education 0.01%

Actual Usage by Discipline

XK7 Usage by NSF PRAC teams – A Behavior Experiment – First year

Imaginations unbound

MD - Gromacs QCD – MILC and Chroma MD- NAMD/VMD MD - Amber

• An observed experiment – teams self select what type of node is

most useful

• First year of usage

Increasing allocation size

Production Computational Science with XK nodes

• The Computational Microscope
• PI – Klaus Schulten
• Simulated flexibility of ribosome trigger factor complex at

full length and obtained better starting configuration of trigger factor model (simulated to 80ns)

• 100ns simulation of cylindrical HIV 'capsule’ of CA proteins

revealed it is stabilized by hydrophobic interactions between CA hexamers; maturation involves detailed remodeling rather than disassembly/re-assembly of CA lattice, as had been proposed.

• 200ns simulation of CA pentamer surrounded by CA

hexamers suggested interfaces in hexamer-hexamer and hexamer-pentamer pairings involve different patterns of interactions

• Simulated photosynthetic membrane of a chromatophore in

bacterium Rps. photometricum for 20 ns -- simulation of a few hundred nanoseconds will be needed

Images from Klaus Schulten and John Stone, University of Illinois at Urbana-Champaign Imaginations unbound

Production Computational Science with XK nodes

• Lattice QCD on Blue Waters
• PI - Robert Sugar, University of California, Santa Barbara
• The USQCD Collaboration, which consists of nearly all of

the high-energy and nuclear physicists in the United States working on the numerical study of quantum chromodynamics (QCD), will use Blue Waters to study the theory of the strong interactions of sub-atomic physics, including simulations at the physical masses of the up and down quarks, the two lightest of the six quarks that are the fundamental constituents of strongly interacting matter

Imaginations unbound

Production Computational Science with XK nodes

• Hierarchical molecular dynamics sampling for assessing pathways and free

energies of RNA catalysis, ligand binding, and conformational change

• PI - Thomas Cheatham, University of Utah
• Attempting to decipher the full landscape of RNA structure and function.
• Challenging because
• RNA require modeling the flexibility and subtle balance between charge, stacking and other molecular

interactions

• structure of RNA is highly sensitive to its surroundings, and RNA can adopt multiple functionally relevant

conformations.

• Goal - Fully map out the conformational, energetic and chemical landscape of RNA.
• "Essentially we are able to push enhanced sampling methodologies for molecular

dynamics simulation, specifically replica-exchange, to complete convergence for conformational ensembles (which hasn't really been investigated previously) and perform work that normally would take 6 months to years in weeks. This is critically important for validating and assessing the force fields for nucleic acids,” - Cheatham.

Imaginations unbound

Images courtesy – T Cheatham

Most Recent Computational Use of XK nodes

Imaginations unbound

• 1,000,000.0

2,000,000.0 3,000,000.0 4,000,000.0 5,000,000.0 6,000,000.0 7,000,000.0 8,000,000.0 9,000,000.0 Karimabadi-3D Kinetic Sims. of… Sugar-Lattice QCD Yeung-Complex Turbulent Flows… Schulten-The Computational… Cheatham-MD Pathways and… Aksimentiev-Pioneering… Shapiro-Signatures of Compact… Mori-Plasma Physics Sims. using… Ott -CCSNe, Hypermassive… Voth -Multiscale Sims. of… Tajkhorshid -Complex Biology in… Glotzer-Many-GPU Sims. of Soft… Woosley-Type Ia Supernovae Jordan -Earthquake System… Aluru-QMC of H2O-Graphene,… Tomko-Redesigning Comm. and… Bernholc -Quantum Sims.… Pande -Simulating Vesicle Fusion Kasson-Influenza Fusion… Chemla-Chemla Lusk-Sys. Software for Scalable… Thomas -QC during Steel… Fields-Benchmark Human Variant… Makri-QCPI Proton & Electron… Hirata -Predictive Comp. of… Elghobashi-DNS of Vaporizing… Jongeneel-Accurate Gene… Lazebnik -Large-Scale… Beltran -Spot Scanning Proton… Woodward -Turbulent Stellar… Node*Hours

Teams with both XE and XK usage - July 1, 2014 to Sept 30, 2014

Total Node*hrs XK Node Hrs XE Node Hrs

Most Resent Computational Use of XK nodes

Imaginations unbound

• 1,000,000.0

2,000,000.0 3,000,000.0 4,000,000.0 5,000,000.0 6,000,000.0 7,000,000.0 8,000,000.0 9,000,000.0 Node*Hours

Teams with both XE and XK usage - July 1, 2014 to Sept 30, 2014

Total Node*hrs XK Node Hrs XE Node Hrs

Evolving XK7 Use on BW - Major Advance in Understanding of Collisionless Plasmas Enabled through Petascale Kinetic Simulations

• PI: Homayoun Karimabadi,

University of California, San Diego

• Major results to date:
• Global fully kinetic simulations
• f magnetic reconnection
• First large-scale 3D

simulations of decaying collisionless plasma turbulence

• 3D global hybrid simulations

addressing coupling between shock physics & magnetosheath turbulence

Fully kinetic simulation (all species kinetic; code: VPIC) ~up to 1010 cells ~up to 4x1012 particles ~120 TB of memory ~107 CPU-HRS ~up to 500,000 cores Large scale hybrid kinetic simulation: (kinetic ions + fluid electrons; codes: H3D, HYPERES) ~up to 1.7x1010 cells ~up to 2x1012 particles ~130 TB of memory Slide courtesy of H Karimardi

Imaginations unbound

Evolving XK7 Use on BW - Petascale Particle in Cell Simulations of of Kinetic Effects in Plasmas

• PI – Warren Mori – Presenter – Frank

Tsung

• Use six parallel particle-in-cell (PIC) codes

to investigate four key science areas:

• Can fast ignition be used to develop inertial

fusion energy?

• What is the source of the most energetic

particles in the cosmos?

• Can plasma-based acceleration be the basis of

new compact accelerators for use at the energy frontier, in medicine, in probing materials, and in novel light sources?

• What processes trigger substorms in the

magnetotail?

• Evaluating New Particle-in-Cell (PIC)

Algorithms on GPU and comparing to standard

• Electromagnetic Case 2-1/2D EM Benchmark

with 2048x2048 grid, 150,994,944 particles, 36 particles/cell optimal block size = 128, optimal tile size = 16x16. Single precision. Fermi M2090 GPU

• First result
• OSIRIS : 2PF sustained on BW
• Complex interaction could not be understood

without the simulations performed on BW

Image and Information courtesy of Warren Mori and Frank Tsung

Imaginations unbound

1 2 2 3 4

CVM-S4.26 BBP-1D

Evolving XK7 Use on BW - Comparison of 1D and 3D CyberShake Models for the Los Angeles Region

• 1. lower near-fault intensities due to 3D scattering
• 2. much higher intensities in near-fault basins
• 3. higher intensities in the Los Angeles basins
• 4. lower intensities in hard-rock areas

Slide courtesy of T Jordan - SCEC

Imaginations unbound

XK7 For Visualization on Blue Waters

• Many visualization utilities rely on the OpenGL API for

hardware-accelerated rendering

• Unsupported by default XK7 system software
• Enabling NVIDIA’s OpenGL required that we:
• Change operating mode of the XK7 GPU firmware
• Develop a custom X11 stack
• Work with Cray to acquire alternate driver package from NVIDIA
• Blue Waters is the first Cray to offer this functionality

which has been distributed to other systems now

Imaginations unbound

Impact: VMD

• Molecular dynamics analysis and

visualization tool used by “The Computational Microscope” science team (PI Klaus Schulten)

• 10X to 50X rendering speedup in

VMD

• Interactive rate visualization
• Drastic reduction in required time to

fine tune parameters for production visualization

Imaginations unbound

Impact of integrated system reduces data movement

Computational fluid dynamics volume renderer used by “Petascale Simulation of Turbulent Stellar Hydrodynamics” science team (PI Paul R. Woodward) Visualization created on Blue Waters:

• 10,5603 grid inertial confinement fusion

(ICF) calculation (26 TB)

• 13,688 frames at 2048x1080 pixels
• 711 frame stereo movie (2 views) at

4096x2160 pixels

• Total rendering time: 24 hours
• Estimated time to just ship

data to team’s remote site where they had been doing visualization (no rendering): 15 days

• 20-30x improvement in

time to insight

Imaginations unbound

Summary

• UIUC, NCSA and NVIDIA have a very stong partnership

for some time

• NCSA has helped move GPU computing into the

mainstream for several discipline areas

• Molecular dynamics, particle physics, seismic, …
• NCSA is leading innovation in use of GPUs for grand

challenges

• Blue Waters has unique capabilities' for computation and

data analysis

• There is still much work to do in order to make GPU

processing a standard way of doing real computational science and modeling for all disciplines

Imaginations unbound
