Got Loss? Get zOVN! Daniel Crisan, Robert Birke, Gilles Cressier, Cyriel Minkenberg, and Mitch Gusat ACM SIGCOMM 2013, 12-16 August, Hong Kong, China Research Zurich Research Laboratory Application Performance in Virtualized Datacenter

slide-1
SLIDE 1

Research – Zurich Research Laboratory

Got Loss? Get zOVN!

Daniel Crisan, Robert Birke, Gilles Cressier, Cyriel Minkenberg, and Mitch Gusat

ACM SIGCOMM 2013, 12-16 August, Hong Kong, China

slide-2
SLIDE 2

Research – Zurich Research Laboratory

Application Performance in Virtualized Datacenter Networks

2

Global Internet

long-and-fat links End-users accessing datacenter services

Physical Datacenter Network

short-and-fat links Router Router

Switch

Switch

Switch

Switch Virtual Switch NIC VM 1

vNIC

VM K1

vNIC

Virtualized Server 1 Virtual Switch NIC VM 1

vNIC

VM KN

vNIC

Virtualized Server N Virtual Switch NIC VM 1

vNIC

VM K2

vNIC

Virtualized Server 2 Virtual Switch NIC VM 1

vNIC

VM K3

vNIC

Virtualized Server 3 …

slide-3
SLIDE 3

Research – Zurich Research Laboratory

Physical Network: Lossless Links

  • IBM builds flow-controlled links since the 80’s
  • High Performance Computing community - large

scale lossless distributed systems

  • Flow control improves performance
  • HPC and Datacenter communities disconnected
  • Why do we disregard the Ethernet flow-control?
  • PAUSE widely available, largely ignored
  • Converged Enhanced Ethernet – applies HPC and

Storage lessons

  • Priority Flow Control (standardized 2011)
  • Constantly improved for 1T

3

slide-4
SLIDE 4

Research – Zurich Research Laboratory

4

Physical Networks Virtual Networks

Packet forwarding

Deterministic bandwidth and delay

Link level flow control

Bandwidth allocation

Latency

µs

ms

Virtual Networks in embryonic stage

Virtual Networks are Different

slide-5
SLIDE 5

Research – Zurich Research Laboratory

Contributions

  • Loss identification and characterization in virtual

networks

  • Dirty-slate approach for latency sensitive applications
  • Exploit a L2 technique to the benefit of TCP and application
  • Introduce zero-loss Overlay Virtual Network
  • Flow-controlled virtual switch
  • Evaluation with Partition/Aggregate
  • Prototype implementation
  • Cross-layer simulation

Flow control improves application performance

5

slide-6
SLIDE 6

Research – Zurich Research Laboratory

Outline

  • Introduction
  • Losses in Virtual Networks
  • zOVN Architecture
  • Evaluation
  • Conclusions

6

slide-7
SLIDE 7

Research – Zurich Research Laboratory

Losses in Virtual Networks

  • Packets traverse a series of queues
  • Producer/Consumer problem on each queue

Not implemented correctly on each queue

7

Physical Machine

vSwitch VM 1

Source

vNIC Tx

VM 2

Source

vNIC Tx

VM 3

Sink

vNIC Rx Port A Tx Port B Tx Port C Rx

slide-8
SLIDE 8

Research – Zurich Research Laboratory

Losses in Virtual Networks (2)

  • Numbers: measurement points
  • Inject UDP packets at (1)
  • Count how many still arrive at (6)
  • Loss locations
  • vSwitch – between (3) and (4)
  • Receive stack – between (5) and (6)

8

Physical Machine

vSwitch VM 1

Source

vNIC Tx

VM 2

Source

vNIC Tx

VM 3

Sink

vNIC Rx Port A Tx Port B Tx Port C Rx

1 1 2 2 3 3 4 5 6

slide-9
SLIDE 9

Research – Zurich Research Laboratory

Losses in Virtual Networks (3)

9

Configuration Hypervisor vNIC vSwitch C1 Qemu/KVM Virtio Linux Bridge C2 Qemu/KVM Virtio Open vSwitch C3 Qemu/KVM Virtio VALE C4 H2 N2 S4 C5 H2 E1000 S4 C6 Qemu/KVM E1000 Linux Bridge C7 Qemu/KVM E1000 Open vSwitch

50 100 150 200 C1 C2 C3 C4 C5 C6 C7 Injected traffic [MBps] Stack Loss vSwitch Loss Received

slide-10
SLIDE 10

Research – Zurich Research Laboratory

Outline

  • Introduction
  • Losses in Virtual Networks
  • zOVN Architecture
  • Evaluation
  • Conclusions

10

slide-11
SLIDE 11

Research – Zurich Research Laboratory

NIC

Hypervisor zOVN bridge

VM

TX Path

11

vSwitch

Application

Port B Tx Port A Rx

Guest kernel

vNIC Tx socket Tx

write return value

Qdisc NIC Tx

Physical link

send frame receive PAUSE

  • verlay

encapsulation wake-up receive return value start/stop queue start_xmit enqueue free skb

slide-12
SLIDE 12

Research – Zurich Research Laboratory

NIC

Hypervisor zOVN bridge

VM

RX Path: Fix Stack Loss

12

vSwitch

Application

Port B Rx Port A Tx

Guest kernel

vNIC Rx socket Rx

read return value

NIC Rx

Physical link

receive frame send PAUSE

  • verlay

decapsulation wake-up send return value pause/resume queue netif_receive skb

NET RX Softirq

setsockopt Select lossy or lossless.

slide-13
SLIDE 13

Research – Zurich Research Laboratory

Lossless Virtual Switch

13

vSwitch

Port 1 Tx Port 2 Tx Port N Tx Port 1 Rx Port 2 Rx Port N Rx

Senders:

  • Produce packets
  • Start forwarder
  • Sleep

Receivers:

  • Consume

packets

  • Start forwarder
  • Sleep

Forwarder:

  • Move packets

from Tx to Rx

  • Pause Tx ports if

Rx port full

  • Wake-up Tx ports

when something is consumed

slide-14
SLIDE 14

Research – Zurich Research Laboratory

Fully Lossless Path

  • Fixed

 vSwitch – between (3) and (4)  Receive stack – between (5) and (6) 14

Physical Machine

vSwitch VM 1

Source

vNIC Tx

VM 2

Source

vNIC Tx

VM 3

Sink

vNIC Rx Port A Tx Port B Tx Port C Rx

1 1 2 2 3 3 4 5 6

slide-15
SLIDE 15

Research – Zurich Research Laboratory

Outline

  • Introduction
  • Losses in Virtual Networks
  • zOVN Architecture
  • Evaluation
  • Conclusions

15

slide-16
SLIDE 16

Research – Zurich Research Laboratory

Partition/Aggregate Workload

  • Problem: TCP incast
  • During Aggregate, buffers might overflow.
  • For short flows: TCP ineffective, ACK clock stalled.
  • Must rely on timeouts.
  • Partition and Aggregate – datacenter internal
  • Open to optimizations

16

Master Worker Worker Worker Worker

1 4 2 2 2 2 3 3 3 3

slide-17
SLIDE 17

Research – Zurich Research Laboratory

Testbed Setup

17 Control network HP 1810-8G 1G Switch VM 1 VM 16 IBM x3550 M4 Server

…

1G VM 1 VM 16 IBM x3550 M4 Server

…

1G VM 1 VM 16 IBM x3550 M4 Server

…

1G VM 1 VM 16 IBM x3550 M4 Server

…

1G Data network IBM G8264 10G Switch vSwitch vSwitch vSwitch vSwitch 10G 10G 10G 10G

  • 4x Rack Servers
  • 16 physical cores + HyperThreading
  • Intel 10G adapters (ixgbe drivers)
  • 16 VMs / server
  • 8 VMs for PA traffic*
  • 8 VMs produce background flow

* as in “DCTCP: Efficient

Packet Transport for the Commoditized Data Center” SIGCOMM 2010

slide-18
SLIDE 18

Research – Zurich Research Laboratory

Testbed Results (CUBIC)

18

1 10 100 1000 1 10 100 1000 10000 Mean completion time [ms] Response size [Packets] LL LZ ZL ZZ

Virtual Network Flow Control Physical Network Flow Control No No No Yes Yes No Yes Yes

  • Virtual only better than physical only: vSwitch primary

congestion point. Physical switch congestion negligible

  • No improvement for short/long flows: Long transfers can

remain on lossy priorities

slide-19
SLIDE 19

Research – Zurich Research Laboratory

Simulation Setup

  • Larger topology: 256 servers
  • 4 VMs / server
  • 3 VMs produce PA traffic
  • 1 VM background flows
  • Assumption: infinite CPU

19

slide-20
SLIDE 20

Research – Zurich Research Laboratory

Simulation Results (64 packets)

  • Confirm findings from prototype experiments
  • (LZ) Physical only flow control: shift the drop point into the

virtual network

  • (ZZ) Both flow controls required for better performance

20

5 10 15 20 25 30 35 40 45 NewReno Vegas Cubic Mean completion time [ms] LL LZ ZL ZZ

Virtual Network Flow Control Physical Network Flow Control No No No Yes Yes No Yes Yes

slide-21
SLIDE 21

Research – Zurich Research Laboratory

Faster CPUs or faster networks?

  • Loss ratio influenced by CPU/network speed ratio

21

TX

  • Slow CPU coupled with a

fast network is desirable

  • e.g. Xeon + 1G network

drops more than Core2 + 1G network RX

  • Fast CPU coupled with a

slow network is desirable

  • e.g. Xeon + 10G network

drops more than Xeon + 1G network

  • Conflicting requirements: cannot solve problem by

changing hardware

The only solution: add flow control !

slide-22
SLIDE 22

Research – Zurich Research Laboratory

Conclusions

  • Loss identification and characterization in OVN
  • First flow-controlled vSwitch for future Overlay

Virtual Networks

  • Dirty-slate approach for latency sensitive applications
  • Un-tuned TCP
  • Commodity 1-10G Ethernet fabric
  • Result replication trivial
  • Orthogonal to other proposals
  • Lossless links: Order of magnitude completion time

reduction in Partition/Aggregate

22

slide-23
SLIDE 23

Research – Zurich Research Laboratory

Backup

23

slide-24
SLIDE 24

Research – Zurich Research Laboratory

24

Encapsulation in Overlay Virtual Networks

Workflow

1.

Source VM sends packet to its attached vSwitch.

2.

vSwitch queries the Controller to find the address of the destination.

3.

Controller answers. The information is cached by the switch.

4.

Packet sent over physical network encapsulated with new headers.

5.

Packet decapsulated at destination virtual Switch.

Payload TCP| IP|Eth Encap|UDP|IP|Eth Physical Network

VM VM VM

vSwitch

Cache

(1) (3) (2)

VM VM VM

vSwitch

Cache

(5) (4)

Destination Server Source Server Fabric Controller
