GitHub's online schema migrations for MySQL

Tom Krouper, Shlomi Noach GitHub

1

!

Illustrated with ghosts

How people build sofuware

!

2

!

• The world’s largest Octocat T-shirt and stickers store
• And water botules
• And hoodies
• We also do stuff related to things

GitHub

How people build sofuware

!

3

!

• gh-ost is GitHub’s MySQL schema migration tool
• GitHub Online Schema Transmogrifier/Transfigurator/Transfer/Thingy
• Developed by the @github/database-infrastructure
• Used in production daily
• Open source, github.com/github/gh-ost

But, what is this all about?

gh-ost

How people build sofuware

!

4

!

• No support for foreign keys (partially possible to add)
• No support for triggers (possible to add)
• RBR required on at least one server. FULL binlog image required (for now)
• No support for 5.7 generated columns (possible to add)
• Multisource replication not supported
• Active-active master-master replication not supported (possible to add)
• Bugs: gh-ost owns far more logic and data transfer, therefore needs to get

its hands dirty with timezones, characters sets, etc.. See Issues. Complete listing in github.com/github/gh-ost/blob/master/doc/ requirements-and-limitations.md, github.com/github/gh-ost/issues

Known limitations: let’s get this out of our way

How people build sofuware

!

5

!

• GitHub stores repositories in git, and uses MySQL as the backend database

for all related metadata:

• Repository metadata, users, issues, pull requests, comments etc.
• Our MySQL servers must be available, responsive and in good state:
• Write throughput expected to be high
• Write latency expected to be low
• Replica lag expected to be low

MySQL

How people build sofuware

!

6

!

• MySQL schema migration is a known problem
• Addressed by schema migration tools since 2009. Most common are:
• pt-online-schema-change by Percona
• fc-osc by Facebook
• GitHub develops rapidly. Engineers require changes to MySQL tables daily,

and these changes should take place quickly

• Migrations must not block development
• Migrations must not impact availability

Migrations

How people build sofuware

!

7

!

• We’ve been using pt-online-schema-change for years
• As we grew in volume and traffic, we hit more and more problems
• Some migrations cause such high load that writes were stalled and GitHub

performance degraded

• Others would cause consistent replication lags
• Some tables could only be migrated off-peak
• Some tables could only be migrated during weekend
• We would atuend to running migrations
• Some tables could not be migrated
• In 2016, we suffered outages due to migrations on our busiest tables
• We had a list of “risky” migrations

GitHub migration pains

How people build sofuware

! !

Synchronous triggers based migration

8

!

" "

• riginal table

ghost table

#

insert delete update insert delete update

pt-online-schema-change

• ak-online-alter-table

LHM

How people build sofuware

! !

9

!

" "

• riginal table

ghost table

#

insert delete update inserts

"

changelog table

Asynchronous triggers based migration

fc-osc

How people build sofuware

!

10

!

• Stored routines
• Interpreted, not compiled. Latency to each transaction
• Locks
• Transaction space competes for multiple, uncoordinated locks
• Metadata locks
• Unsuspendible
• Even as throtuling is required, triggers must continue to work
• Concurrent migrations
• Trust issues
• No reliable testing
• Either cannot test in production, or test does not get actual write workload

What’s wrong with triggers?

How people build sofuware

!

11

!

• gh-ost connects as replica and pulls binary log entries (RBR format)
• Interprets related DML (INSERT, UPDATE, DELETE) entries and transforms them

to meet refactored table structure

• Applies on ghost table
• gh-ost connects to master and iterates rows
• One chunk afuer the other, copies rows from the original table to the ghost table
• Much like existing tools, but more on this later
• maintains a “changelog” table for internal lightweight bookkeeping

Binlog based design

How people build sofuware

! !

12

!

" "

• riginal table

ghost table

#

insert delete update no triggers

$

binary log

Triggerless, binlog based migration

How people build sofuware

!

!

13

!

" "

#

$

!

" "

master replica

Binlog based migration, utilize replica

How people build sofuware

!

14

!

• Binary logs can be read from anywhere
• gh-ost prefers connecting to a replica, offloading work from master
• gh-ost controls the entire data flow
• It can truly throtule, suspending all writes on the migrated server
• gh-ost writes are decoupled from the master workload
• Write concurrency on master turns irrelevant
• gh-ost’s design is to issue all writes sequentially
• Completely avoiding locking contention
• Migrated server only sees a single connection issuing writes
• Migration algorithm simplified

Binlog based design implications

How people build sofuware

!

15

!

! !

$

" "

master replica binary log

• riginal

table ghost table gh-ost migration:

• creates ghost table on migrated server
• alters ghost table
• hooks up as a MySQL replica, streams binary log events
• interchangeably:
• applies events on ghost table
• copies rows from original table onto ghost table
• cut-over

Preferred setup:

• connects to replica
• inspects table structure, table dimensions on replica
• hooks as replica onto replica
• apply all changes on master
• writes internal & heartbeat events onto master,


expects them on replica " "

gh-ost design

How people build sofuware

!

16

!

!

$

!

$

!

$

!

$

!

$

!

$ $

! !

$

!

$

• a. connect to replica
• b. connect to master
• c. migrate/test on replica

gh-ost operation modes

How people build sofuware

!

Trust

What makes gh-ost, a newcomer tool, trusted with

• ur data?

As trusted as - or more trusted than - existing solution?

17

How people build sofuware

!

18

!

• Other than unit tests and integration tests, gh-ost supports testing in

production

• You will execute a gh-ost migration on a replica
• gh-ost will execute as normal, but applying changes on replica
• Just before cut-over it stops replication
• Execution ends with both original and ghost tables in place, replication stopped
• At your leisure, you can compare/checksum the two tables
• We have dedicated servers that continuously test our entire production

table set

• Each table is migrated on replica via “trivial” (no schema change) migration
• Tables data checksummed and expected to be identical

Testing

How people build sofuware

!

19

!

! ! !

$

Testing in production

!

$

!

$

! ! !

production replicas testing replicas master

How people build sofuware

!

20

!

• There are no triggers. gh-ost can completely throtule the operation when it

chooses to.

• Throtuling based on multiple criteria:
• Master metrics thresholds (e.g. Threads_running)
• Replication lag
• Arbitrary query
• Flag file
• Use command
• Trust: you could choose, at any time and effective immediately, to throtule

gh-ost’s operation and resume normal master workload.

• And you may resume operation once satisfied

Throtuling

How people build sofuware

!

21

!

• The final migration step: replacing the original table with the ghost table,

incurs a brief table lock

• This metadata-locks-involved step is a critical point for the migration
• During brief lock time, number of connections may escalate
• People tend to stick around during this phase.
• People actually plan ahead migration start time based on the estimated

completion time, so they can guarantee to be around

• gh-ost offers postponed cut-over (optional, configurable)
• As cut-over is ready, gh-ost just keeps synching the tables via binlog events
• Requires an explicit command/hint to cut-over
• Trust: I can safely go to bed

Cut-over

How people build sofuware

!

22

!

• gh-ost will invoke your hooks at points of interest
• If you like, do your own cleanup, collecting, auditing, chatuing.
• Hooks available for:
• startup, validated, row-copy about to begin, routinely status, about to cut-over,

stop-replication, success, failure

• gh-ost will populate environment variables for your process
• htups://github.com/github/gh-ost/blob/master/doc/hooks.md
• Trust: integrate with your infrastructure

Hooks

How people build sofuware

!

23

!

• gh-ost supports niceness
• Explicitly forcing it to periodic sleep based on nice-ratio
• Trust: one can reduce gh-ost’s load at any time

nice

How people build sofuware

!

24

!

• gh-ost monitors replication lag in subsecond-resolution
• For control-replicas, it requires a query that is known to return subsecond lag.
• At GitHub replication lag is normally kept subsecond
• We don’t like it when we see 5 second lag
• We really don’t like it when we see 10 second lag
• 20 second lag typically leads to investigation
• We are able to migrate our busiest tables, during rush hour, and keep

replication lag below 300ms

• Trust: migrations will do whatever it takes to keep replicas up-to-date

Subsecond replication lag

How people build sofuware

!

throtuling in production

25

!

no migration migration updated
 max-lag-millis=200 migration begins
 max-lag-millis=500

Our production replication lag, before and during migration on one of our busiest tables


CEST tz

How people build sofuware

!

26

!

• With existing tools, you run your migration tool based on some

configuration.

• If configuration does not match your workload, you kill the migration and

start a new one with more relaxed/aggressive config

• gh-ost listens on Unix socket file and/or TCP
• You can connect to a running migration and ask:
• status
• max-lag-millis=500
• throtule
• cut-over
• Trust: you can always get a reliable status or reconfigure as you see fit

Dynamic visibility & control

How people build sofuware

!

27

!

• We work from/with ChatOps
• Are slowly and incrementally integrating gh-ost into our flow and ChatOps
• We control migrations via chat:
• .migration sup
• .migration max-lag-millis 300
• .migration cut-over
• Migrations ping us in chat to let us know their status; or if they’re ready to

cut-over

• Migrations are accessible to everyone, not just DBAs

gh-ost @ GitHub

How people build sofuware

!

gh-ost chatops @ GitHub

28

!

• We control gh-ost via chatops
• And gh-ost chats to us
• The chat is a changelog visible to all. It tells us what happened when,

and who did what.

How people build sofuware

!

The future

We want to make gh-ost robust We want it to be widely adopted We have a few ideas on where it can go

29

How people build sofuware

! !

30

!

"

• riginal table

ghost table

#

insert delete update binary log row copy "

$

row-copy still couples tables

How people build sofuware

! !

31

!

" "

• riginal table

ghost table

#

insert delete update

$

binary log read rows no data flow
 between tables write events,
 write rows

decoupling row-copy

How people build sofuware

!

! !

32

!

• riginal, ghost tables
• riginal, ghost tables

#

insert delete update

$

binary log write events,
 write rows

master replica

" " " "

decoupled row-copy, utilizing replica

read rows

How people build sofuware

! !

! !

33

!

• riginal table
• riginal table

#

insert delete update

$

binary log

master replica

" "

ghost table

"

some unrelated server
 in a far galaxy

write events,
 write rows

remote, live table migration

read rows

How people build sofuware

!

!

!

34

!

• riginal table

#

insert delete update

$

master

"

ghost table

"

some unrelated server
 in a far galaxy

remote, live table migration

How people build sofuware

!

!

35

!

" "

#

$

Resurrection

• gh-ost bails out on meeting critical-load
• Or someone kills it
• Resurrect operation!
• Resume rowcopy from same place
• Resume binlog apply from same position
• Both are idempotent, accurate sync is not necessary

How people build sofuware

!

Open source

How gh-ost is developed and what we envision

36

How people build sofuware

!

37

!

• gh-ost is released under the MIT license
• We encourage collaboration
• Issues
• Bugs
• Questions
• Feature requests
• Sharing experience
• Pull requests
• Code
• Documentation
• We suggest some work for the community, that is not on our immediate

roadmap

Open Source

How people build sofuware

!

Usage

Best read the docs.

38

!

How people build sofuware

!

39

!

gh-ost

• -user="gh-ost"
• -password="123456"
• -host=replica.with.rbr.com
• -database="my_schema"
• -table="my_table"
• -verbose
• -alter="engine=innodb"
• -max-load=Threads_running=25
• -critical-load=Threads_running=1000
• -chunk-size=1000
• -throttle-control-replicas="myreplica.1.com,myreplica.2.com"

[continued next slide]

Execution sample

How people build sofuware

!

40

!

[continued]

• -heartbeat-interval-millis=100
• -replication-lag-query="select unix_timestamp(now(6)) -

unix_timestamp(ts) from meta.heartbeat order by ts desc limit 1"

• -max-lag-millis=500
• -switch-to-rbr
• -exact-rowcount
• -concurrent-rowcount
• -panic-flag-file=/tmp/ghost.panic.flag
• -postpone-cut-over-flag-file=/tmp/ghost.postpone.flag
• -hooks-path=/path/to/hooks/
• -hooks-hint="@$(whoami)"

[--execute]

Execution sample

How people build sofuware

!

Thank you!

Questions?

41

!

github.com/tomkrouper @CaptainEyesight

 github.com/shlomi-noach @ShlomiNoach

 /cc
 github.com/ggunson @shebang_the_cat

 github.com/jonahberquist @hashtagjonah
