FUNCTIONAL SAFETY AND THE GPU Richard Bramley, 5/11/2017 How good - PowerPoint PPT Presentation

FUNCTIONAL SAFETY AND THE GPU Richard Bramley, 5/11/2017 How good is good enough What is functional safety Functional safety and the GPU AGENDA Safety support in Nvidia GPU Conclusions 2 HOW GOOD IS GOOD ENOUGH ? 3 N. Saxena 4 ACCIDENT


  1. FUNCTIONAL SAFETY AND THE GPU Richard Bramley, 5/11/2017

  2. How good is good enough What is functional safety Functional safety and the GPU AGENDA Safety support in Nvidia GPU Conclusions 2

  3. HOW GOOD IS GOOD ENOUGH ? 3

  4. N. Saxena 4 ACCIDENT STATISTICS – US 1 Description 2013 Statistics 2015 Statistics Fatal Crashes 30,057 35,092 Non-Fatal Crashes 5,657,000 6,263,834 Number of Registered Vehicles 269,294,000 281,312,446 Licensed Drivers 212,160,000 218,084,465 Vehicle Miles Travelled 2,988,000,000,000 3,095,373,000,000 Fatal Crash Rate in FITs 2,3 250 – 500 283 - 566 Non-Fatal Crash Rate in FITs 2,3 46K – 92K 51K – 102K What is an appropriate target ? Google Non-Fatal Crash FIT Rate = 150K 1 Source: Traffic Safety Facts 2013/2015, NHTSA document reference DOT HS 812384 4 2 Derived from NHTSA data on driver related fatal crashes 3 Assumes an average speed of 50MPH

  5. TARGET FAILURE RATES Description Statistics Acceptable risk (no further improvement required) 1:1,000,000 1 US population (2015) >321,000,000 Traffic deaths 35,092 “Acceptable” deaths as per guidelines 321 Required improvement x100 Wide variety of targets in industry Target risk reduction of 2x to 100x compared to human driver 5 1 Derived following data from UK health and safety executive publications

  6. SAFETY AND AUTONOMOUS VEHICLES Software Algorithms Hardware Safety during intended operation Safety of the intended function Safety in presence of a fault (SOTIF ISO/PAS 21448 in Functional Safety ISO-26262 development) 6

  7. FUNCTIONAL SAFETY BASICS 7

  8. DEFINITION PER STANDARDS “ Absence of unreasonable risk due to hazards caused by malfunctioning behavior of electrical/electronic systems ” – ISO 26262-1:2011; 1.51 “ Part of overall safety relating to the equipment under control and the equipment under control, control system that depends on the correct functioning of the electrical/electronic/programmable electronic safety-related systems and other risk reduction measures ” – IEC 61508-4:2010; 3.1.12 8

  9. CLASSIC EXAMPLE IEC 61508-0:2005; 3.1 • Consider a motor winding which may overheat and cause a hazard. Reliability engineering approach • might design the winding to be more resilient to over-temperature conditions Functional safety engineering • approach might add a temp sensor to detect the over-temperature condition and switch off the motor https://upload.wikimedia.org/wikipedia/commons/0/0f/Stator_Winding_of_a_BLDC_Motor.jpg 9

  10. ACHIEVING FUNCTIONAL SAFETY Systematic and random faults must be considered Systematic faults mitigated by: Following compliant process at all stages of development Monitoring of the complete product lifecycle Random faults are mitigated by: Failure mode analysis to understand the fault behavior of the system Application of diagnostic measures to detect the failure modes Transition to the safe state on failure mode detection 10

  11. FAIL SAFE Good State Detected Failures Undetected Failures Failed Safe State State 11 m – mission , b- backup, (x), m or b is in repair mode.

  12. FAIL OPERATIONAL Detected Failures Good Backup State Detected Failures Repair Final safe Undetected Failures state Undetected Failures Failed State For full autonomy the initial “safe state” can be a transition to the backup system 12 m – mission , b- backup, (x), m or b is in repair mode.

  13. FAULT CLASSIFICATIONS ISO 26262-10; B.1 Non-Safety Related Safe λ S Element λ NSR Safe λ S All Faults λ Single Point λ SPF Residual λ RF Safety Related Multi-Point Element λ SR Latent λ MPF , L Multi-Point Detected λ MPF , D Multi-Point Perceived λ MPF , P 13

  14. SINGLE POINT FAULT METRIC (SPFM) Shows the percentage of overall single point faults which are: Safety related AND Safe OR dangerous but detected λ s - safe fault failure rate, can also be expressed as a % (Fsafe) the ration of overall possible faults which are safe. 14

  15. LATENT FAULT METRIC (LFM) Shows the percentage of overall multiple point faults which are: Safety related AND Safe OR dangerous but detected OR dangerous but perceived Customarily limited to scenarios considering 2 point independent faults Primary consideration is fault in mission logic combined with fault in safety mechanism 15

  16. ARCHITECTURAL METRIC TARGETS ASIL A ASIL B ASIL C ASIL D SPFM N/A >=90% >=97% >=99% LFM N/A >=60% >=80% >=90% All targets are recommendations. Developers can set their own targets based on appropriate argumentation. 16

  17. PROBABILISTIC METRICS Probabilistic Metric for (Random) Hardware Failure (PMHF) Examines the residual probability of violation of safety goal after application of diagnostics, in a given time of operation. ISO 26262-10:2011; 8.3.3 Some pushback in market due to inconsistency between methods used by NOTE: Multiple versions of equation possible depending on conditional probability of failures. Simplest form shown different vendors. 17

  18. PMHF TARGETS ASIL A ASIL B ASIL C ASIL D PMHF N/A 100 FIT 100 FIT 10 FIT All targets are recommendations. Developers can set their own targets based on appropriate argumentation. 18

  19. RELEVANCE TO GPU 19

  20. EXAMPLES OF SAFETY CRITICAL OPERATION ON GPU TRADITIONAL CV MACHINE LEARNING* Normalize gamma and color CNN (Convolutional Neural network) Compute gradients MLP (Multi-layer perceptron) Weighted voting SVM (Support vector machine) Contrast and normalize Collect HOGS Traditional Classification: (pattern and template matching) 20 *Focus is inferencing, training handled analogously to validation and calibration of a traditional safety related algorithm.

  21. GPU MEASUREMENT METHODOLOGIES Architectural Safeness, Silicon-based fault Injection Diagnostic Design Representative Simulation Coverage Further Workloads Fault (SPFM,LFM), Safety Analysis Injection SRAM C-models/ “Liveness” RAM Liveness Beamtesting Much of the measurement is done on representative kernels as the final applications are not available at design time 21

  22. MEASURING SAFE FAULTS IN RAMS “LIVENESS” RAMs are sensitive to particle radiation (4x larger failure rate per bit than flops) RAM contents may not be sensitive to faults (pixels) RAM contents may be very sensitive to faults (instructions) An important indicator is RAM Liveness Majority of RAMS in this GPU less than 10% occupancy Fsafe > 90% t r1 120 100 W 1 t r2 Occupancy % W 2 80 t r3 = 0 60 W 3 t r4 t r4’ 40 W 4 20 time T exe 0 winograd_i… k27376_rfdp k27422_rfdp sparse_rfdp cudnn3_rfdp k27382_L2 cudnn1_L2 HOG_L2 winograd_L2 k27398_L1 harris_L1 cudnn2_L1 k27376_icc k27422_icc sparse_icc cudnn3_icc k27382_ifb cudnn1_ifb HOG_ifb k27398_gcc harris_gcc cudnn2_gcc k27376_tail k27422_tail sparse_tail cudnn3_tail write read The occupancy can be computed: (t r1 + t r2 + t r3 + t r4 + t r4’ ) / 4 x T exe . 22

  23. TESTING REPRESENTATIVE KERNELS Parameter measurement is very sensitive to kernel definition Traditional CV has a wide diversity of operations Difficult to define representative kernels Machine learning has a smaller set of repeated operations Enabling a more complete definition of kernels for measurements More accurate and reliable measurements 23

  24. DEEP LEARNING APPLICATION SAFENESS GIE GoogLeNet Output 1000 Class, GoogLeNet, total_run=5000 1200 100% 67 kernels in GoogLeNet inference 90% 1000 Faults in latter kernels have 80% a higher possibility to cause 70% 800 errors 60% #FAIL Counts represents the #Runs Ratio 600 50% proportion of faults for which the application 40% 400 predicted the wrong final 30% class 20% 200 Weighted average safeness 10% is >99 % 0 0% 0 1 2 3 4 5 6 62 63 64 65 66 Kernel ID sorted by Launch order FAIL Counts Residual fault ratio Diagnosed fault ratio 24

  25. SAFETY SUPPORT IN NVIDIA GPUS 26

  26. SYSTEMATIC DEVELOPMENT OF GPU HARDWARE Selected GPU cores targeted for automotive usage are developed with a process for ISO 26262 compliance 27

  27. LAYERED SAFETY MECHANISMS HW plausibility checks enabling multiple execution checks throughout the GPU, Redundant execution Protection of large safety related memories, HW machine checks Parity/ECC protection of key structures Dependent failure mitigation; mainly caches and shared structures, NVIDIA CONFIDENTIAL. DO NOT DISTRIBUTE. 28

  28. FLEXIBLE REDUNDANCY MODEL Flexible Execution model Built-in HW and SW diagnostics GPU Machine Checks SM0 Parity /ECC GPU Context SM1 Channel 0 Work Memory Distribution Access Channel 1 SM2 Common cause SM3 Channel N failure mitigation 29

  29. FLEXIBLE REDUNDANCY MODEL Flexible Execution model Built-in HW and SW diagnostics GPU Machine Checks SM0 Parity /ECC GPU Context SM1 Channel 0 Work Memory Distribution Access Channel 1 SM2 Common cause SM3 Channel N failure mitigation 30

  30. SYSTEMATIC CONSIDERATIONS Software and tools Software in the runtime is under TensorRT development for ISO 26262 compliance Software used in development (training) considered as off-line tools per ISO 26262 31

  31. GPU FAULT MITIGATION 32
