FUN Seminar Salvatore GUZZO BONIFACIO 13 May 2014 INTRODUCTION Salvatore GUZZO BONIFACIO Telecommunications Engineer University of Calabria (UNICAL) Master Degree Thesis: Design and implementation of an Arduino based Rover: Communication

SLIDE 1

FUN Seminar

Salvatore GUZZO BONIFACIO 13 May 2014

SLIDE 2

INTRODUCTION

Salvatore GUZZO BONIFACIO Telecommunications Engineer University of Calabria (UNICAL) Master Degree Thesis: “Design and implementation of an Arduino based Rover: Communication and MARG orientation”.

SLIDE 3

SUMMARY

1. Project ETIPOPS iLab
2. Used platforms
3. Version control system
4. Driver development

SLIDE 4

Project ETIPOPS iLab

13 May 2014

1

SLIDE 5

3-year effort INRIA - FUN ETINEO - RDI Nathalie Mitton 0.2 CR Jean-Michel Copin Alexis Ammeux 0.5 0.5 R&D Engineer Salvatore Guzzo Bonifacio 1 ITI Engineer Roudy Dagher 1 PhD Student (CIFRE) Thibaut Pruvost 0.2 Manager

Subjects involved

SLIDE 6

Goliath stack Outdoor Loc. Indoor Loc 1st Year Portability Implem Outdoor Comparison Indoor/outdoor 2nd Year Low Level Enhancements Customization Implem Indoor 3rd Year Idem. Enhancement Enhancement

Project Roadmap

SLIDE 7

Project details – 3RD Year

Objectives Description Available Who WSN 1.1 ETINODES - MSP430

Contiki & drivers I2C /IT
6LowPan (Internet of Things)

Demo Comm SGU, RDR, JMC, AAM WSN 1.2 SerialNet on Dresden Elektronik modules, AVR-studio6 Demo Comm PacR2 RDR, AAM, JMC RTLS 2.1 TDOA 2,4Ghz & Ranging

NanoPan-Nanotron

Demo AAM, JMC, RDR, SGU RTLS 2.2 UWB and other technologies

BeSpoon => Pre-study
BlinkSight => Pre-study

Demo AAM, RDR, JMC RTLS Middleware* Indoor positioning software on plane

State of the art analysis
Architecture: RTLS-Engine, IHM
Nanotron based acquisition

Pre-study AAM,JMC, RDR, SGU RTLS Middleware* Indoor positioning software on plane

Development : RTLS-Engine, IHM, M2M
Acquisition RSSI,TDOA,UWB....

Etineo Product AAM,JMC,RDR

SLIDE 8

Use Case

PAC.R² Reezhom System Architecture

SLIDE 9

13 May 2014

Used Platforms

2

SLIDE 10

Olimex MSP430P1611

Component Description

MCU 16-bit Ultra-Low-Power – MSP430F1611 Buttons User Button Reset Button LEDs User status LED

SLIDE 11

WSN430

Component Description

MCU 16-bit Ultra-Low-Power – MSP430F1611 sensors Light Sensor – TSL2550 Temperature – DS1722 radio communication 2.4 GHz – CC2420 external memory 1MB external flash memory – M25P80 LEDs green, red, blue EEPROM serial number allowing unique identifier – DS2411

SLIDE 12

ETINODE

Component Description

MCU 16-bit Ultra-Low-Power – MSP430F1611 sensors Light Sensor – TSL2550 Barometer/Temperature – MS5611-01 Gyroscope – L3G4200D Accelerometer – LIS331DLH radio communication 2.4 GHz – CC2520 external memory 1MB external flash memory – M25P80 LEDs green, red, blue EEPROM serial number allowing unique identifier – DS2411

SLIDE 13

13 May 2014

Version control system

3

SLIDE 14

What is version control

SLIDE 15

Main Git features and operations

Clone Commit Branch Checkout Merge Fetch Pull Push

SLIDE 16

Fork Workflow

SLIDE 17

13 May 2014

Driver development

4

SLIDE 18

Board related adaptation

➢Introduced active delay method ➢Added i2c multiple read for register independent

perations

➢Configuration procedure to enable RS232 communication ➢Included a routine to handle the initialization of USART. Necessary to properly switch from I2C mode to UART mode and vice versa.

SLIDE 19

Sensors driver

TSL2550

➢Introduced a routine to convert raw value to luminosity expressed in Lux [lx] MS5611-01 ➢Initialization routine and private functions to drive low level

peration inside the component

➢Public function to get sensed temperature (°C) ➢Public function to get pressure value (mbar)

SLIDE 20

Future activities

➢Accelerometer driver ➢Gyroscope driver ➢Contiki OS integration

SLIDE 21

Thank you Any question ?

Salvatore GUZZO BONIFACIO FUN Research Team Inria Lille 13 May 2014
