A First Qualitative Comparison of the Admission Control in FTT-SE, HaRTES and AVB Ins lvarez , Lus Almeida, Julin Proenza Introduction Ethernet is gaining importance in automation, avionics and automotive. Multimedia &

slide-1
SLIDE 1

A First Qualitative Comparison of the Admission Control in FTT-SE, HaRTES and AVB

Inés Álvarez, Luís Almeida, Julián Proenza

slide-2
SLIDE 2

Introduction

  • Ethernet is gaining importance in automation, avionics

and automotive.

  • Multimedia & control traffic coexistence.
  • Diversity in size, intensity and timing of the traffic.
  • Ethernet lacks for real-time and adaptivity.
  • Flexible Time-Triggered and Audio Video Bridging.
  • Admission control is provides adaptivity.

In this paper we compare FTT and AVB Admission Control mechanisms in mono-hop networks.

slide-3
SLIDE 3

Flexible Time-Triggered

  • Time-triggered (synchronous) and event-triggered

(asynchronous) traffic.

  • Master/multi-slave architecture.
  • Communication done through streams.
  • Any slave can request the creation of streams.

COTS Switch S1 S2 S3 M

FTT-SE

slide-4
SLIDE 4

Flexible Time-Triggered

  • Time-triggered (synchronous) and event-triggered

(asynchronous) traffic.

  • Master/multi-slave architecture.
  • Communication done through streams.
  • Any slave can request the creation of streams.

S1 S2 S3 Switch M

HaRTES

slide-5
SLIDE 5

FTT - Switched Ethernet

Master and slaves connected though a COTS switch.

COTS Switch

S1 S2 S3 M

slide-6
SLIDE 6

COTS Switch

S1 S2 S3 M

Admission control: signalling of requests.

FTT - Switched Ethernet

slide-7
SLIDE 7

Admission control: signalling of requests.

FTT - Switched Ethernet

COTS Switch

S1 S2 S3 M

slide-8
SLIDE 8

Admission control: transmission of schedule

FTT - Switched Ethernet

COTS Switch

S1 S2 S3 M

slide-9
SLIDE 9

COTS Switch

S1 S2 S3 M

FTT - Switched Ethernet

Admission control: transmission of schedule

slide-10
SLIDE 10

COTS Switch

S1 S2 S3 M

FTT - Switched Ethernet

Admission control: slave request

slide-11
SLIDE 11

FTT - Switched Ethernet

COTS Switch

S1 S2 S3 M

Admission control : slave request

slide-12
SLIDE 12

FTT - Switched Ethernet

COTS Switch

S1 S2 S3 M

Admission control: master command

slide-13
SLIDE 13

COTS Switch

S1 S2 S3 M

FTT - Switched Ethernet

Admission control: master command

slide-14
SLIDE 14

HaRTES

Master embedded in the switch.

S1 S2 S3 Switch M

slide-15
SLIDE 15

Hard Real Time Ethernet Switching

S1 S2 S3 Switch M

Admission control: slave request

slide-16
SLIDE 16

Hard Real Time Ethernet Switching

S1 S2 S3 Switch M

Admission control: master command

slide-17
SLIDE 17

Audio Video Bridging

N1 N2 N3 AVB Switch

  • Set of standards that, among other things, provide

admission control.

  • Communication also done through streams.
  • Stream Reservation Protocol for Admission Control.
  • Creation of streams triggered only by the publisher.
  • The reservation of resources is done by the switch.
slide-18
SLIDE 18

Audio Video Bridging

N1 N2 N3 AVB Switch

Admission control: announcement of publisher

slide-19
SLIDE 19

Audio Video Bridging

N1 N2 N3 AVB Switch

Admission control: announcement of publisher

slide-20
SLIDE 20

Audio Video Bridging

Admission control: announcement of subscriber

N1 N2 N3 AVB Switch

slide-21
SLIDE 21

Audio Video Bridging

N1 N2 N3 AVB Switch

Admission control: announcement of subscriber

slide-22
SLIDE 22

Comparison

Compare reliability, flexibility and performance.

Reliability Flexibility Performance Trans. Faults Perm. Faults QoS change Class change Legacy nodes # messages FTT-SE      12 HaRTES      4 AVB      4

slide-23
SLIDE 23

Questions? Please meet me at the poster!
