SLIDE 1
On-Site Treatment of a Dissolved Chromium Plume: From Bench Trial to Remediation to Results
Barry Rakewich, P.Ag., EP Kyle Jackson, C.E.T. Nichols Environmental (Canada) Ltd.
From Bench Trial to Remediation to Results Barry Rakewich, P.Ag., - - PowerPoint PPT Presentation
From Bench Trial to Remediation to Results Barry Rakewich, P.Ag., - - PowerPoint PPT Presentation
On-Site Treatment of a Dissolved Chromium Plume: From Bench Trial to Remediation to Results Barry Rakewich, P.Ag., EP Kyle Jackson, C.E.T. Nichols Environmental (Canada) Ltd. Outline Site History Phase II ESA Bench Trial
SLIDE 2
SLIDE 3
Site History
September 2003 Environmental Review Completed June and July 2009 Violations of Sewer Use Bylaw April 2011 Phase I ESA June to Dec 2011 Phase II ESA 29 MWs July to Sep. 2012 Pump and Treat Installation September 2012 In Situ Chemical Reduction February 2012 Phase II ESA 3 MWs September 2012 Initiate Pump and Treatment August 2013 In Situ Chemical Reduction October 2015 End of Pump and Treatment September 2017 Most Recent GW Sampling September 2012 Bench Trial
SLIDE 4
Site Layout
SLIDE 5
Phase II ESA
Completed numerous Phase II ESAs to
gain delineation
June 2011 (M11-01 to M11-06) July/August 2011 (M11-07 to M11-16) Nov/Dec 2011 (M11-17 to M11-29) Feb 2012 (M12-30 to M12-32)
SLIDE 6
Phase II ESA – June 2011
SLIDE 7
Phase II ESA – July/Aug 2011
SLIDE 8
Phase II ESA – Nov/Dec 2011
SLIDE 9
Phase II ESA – Feb 2012
SLIDE 10
Phase II ESA
Assessment Criteria
Alberta Tier 2 Soil and Groundwater Remediation Guidelines (February 2016) Site zoned Medium Industrial (IM); also permits commercial land use
Commercial Land Use
Subsoils predominately silty-clay and were confirmed through sieve analyses
Fine-Grained Soils
Surface water retention pond (~1.1 km)
Exclude the protection freshwater aquatic life (FWAL) pathway
SLIDE 11
Phase II ESA
SLIDE 12
Phase II ESA
Pre-Treatment Chromium Concentrations
- 0.05
M11-01 Jul-11 0.0638 0.059 M11-02 Aug-11 0.6620 0.149 M11-03 Aug-11 4.15 4.1 M11-05 Aug-11 308 300 M11-14 Nov-11 20.3 19.7 M11-22 Dec-11 70.1 63
BOLD = Applicable Guideline Criteria BOLD = Parameter Exceeds Recommended Guideline Criteria *Alberta Tier 2 Soil and Groundwater Remediation Guidelines (Table 2). February 2016. (All concentrations in mg/L = ppm, unless noted)
- -- = No value provided in guidelines
Hexavalent Chromium Alberta Tier 2 Guideline (Commerical Land Use)* Sample ID Total Chromium Sample Date
SLIDE 13
Phase II ESA
SLIDE 14
Bench Trial
Ferrous Sulphate (FeSO4) Sodium Metabisulphite (Na2S2O5) Readily Available Readily Available Solubility - 29.51 g/100 mL (25 °C) Solubility - 67 g/100 mL (25 °C) pH adjustment not required Effectiveness highly pH dependent Presence of iron produces rapid flocculation Production of SO2 by-product can be an irritant ½ cost of sodium metabisulphite per Highly corrosive when mixed with water
SLIDE 15
Bench Trial
Ferrous Sulphate (FeSO4) Sodium Metabisulphite (Na2S2O5) 30 mg/L 25 mg/L 99% Reduction of Cr6+ after 5 mins 53% Reduction of Cr6+ after 5 mins Rapid flocculation/settling Marginal flocculation/settling
SLIDE 16
Remediation Design
Pump and Treatment
Focus on high concentration plume Large diameter bored wells w/submersible pumps installed in ‘hot spots’ Treatment/settling tanks w/secondary containment Filter pot discharge to sanitary
In-Situ Chemical Reduction (ISCR)
Focus on low concentration plume and Site boundaries Entire site surfaced with concrete Established network of pre-cored injection points High-pressure direct injections at GW interface
SLIDE 17
Pump and Treatment
SLIDE 18
Pump and Treatment
SLIDE 19
Pump and Treatment
Installed 3 – 60 cm diameter recovery wells
Recovery wells consisted of galvanized CSP (resulted in dissolved zinc in GW)
Submersible pumps (3.5 HP) installed into each of the three wells, capable of 5 gpm.
SLIDE 20
Pump and Treatment
On-site treatment plant consisting of two – 20,000 L ASTs
Secondary containment system
Sample ports and filter pot prior to discharge
SLIDE 21
Pump and Treatment
Groundwater Recovery – Volume in Litres
2012 (September to November) 17,800 2013 (March to November) 119,300 2014 (May to October) 85,000 2015 (May to October) 112,600
Total 334,700
Average Batch Volume = 7,500 L treated with 35 kg of FeSO4 ~1550 kg of FeSO4 utilized during treatment process
SLIDE 22
Pump and Treatment
Operation and Maintenance Costs
2012 (installation) $75,000 2012 (operational) $15,000 2013 (operational) $30,000 2014 (operational) $33,000 2015 (operational) $31,000
Total Costs $184,000
SLIDE 23
Pump and Treatment
SLIDE 24
ISCR
SLIDE 25
ISCR
Injection Summary – Volume in Litres
15% Ferrous Sulphate
September 2012 1,000 August 2013 7,900 July 2015 12,000
Total 20,900
SLIDE 26
ISCR
SLIDE 27
Results
Post-Treatment Chromium Concentrations
- 0.05
Jul-11 0.0638 0.059 Sep-17 0.0306 <0.01 Aug-11 0.6620 0.149 Apr-17 0.0120 <0.01 Aug-11 4.15 4.1 Sep-15 0.0055 <0.01 Aug-11 308 300 Sep-17 0.193 0.01 Nov-11 20.3 19.7 Sep-17 17.6 0.05 Dec-11 70.1 63 Sep-17 0.105 0.11
BOLD = Applicable Guideline Criteria BOLD = Parameter Exceeds Recommended Guideline Criteria *Alberta Tier 2 Soil and Groundwater Remediation Guidelines (Table 2). February 2016. (All concentrations in mg/L = ppm, unless noted)
- -- = No value provided in guidelines
Sample ID Sample Date Total Chromium Hexavalent Chromium Alberta Tier 2 Guideline (Commerical Land Use)* M11-01 M11-02 M11-03 M11-05 M11-14 M11-22 % Reduction Hexavalent Chromium 100% 100% 100% 99.99% 99.75% 99.83%
SLIDE 28
Results
SLIDE 29
Results
SLIDE 30
Results
SLIDE 31
Conclusions
Outcome - success in plume reduction Learning – do not use galvanized CSP Learning – Explore pathway elimination Next Steps…
Confirmatory Soil and GW Sampling in 2018 Risk Management for residual plume Decommissioning
