FlashBacter UPO-Sevilla Team APPLICATIONS Biosensors Killer proteins production Multiple alleles expression And more OVERVIEW BASIC FLIP FLOP IMPROVED FLIP FLOP EPIGENETIC FLIP FLOP MINI TN7 BIOBRICK CREATOR HUMAN PRACTICES BASIC

slide-1
SLIDE 1

FlashBacter

UPO-Sevilla Team

slide-2
SLIDE 2

APPLICATIONS

Biosensors Killer proteins production Multiple alleles expression And more…

slide-3
SLIDE 3

OVERVIEW

BASIC FLIP FLOP IMPROVED FLIP FLOP EPIGENETIC FLIP FLOP MINI TN7 BIOBRICK CREATOR HUMAN PRACTICES

slide-4
SLIDE 4

BASIC FLIP-FLOP

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-5
SLIDE 5

Basic flip-flop

Green State

GFP cI (ts) Plac Prm LacI RFP GFP cI (ts) Plac Prm LacI RFP Heat shock IPTG pulse

Red State

  • E. coli chassis

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-6
SLIDE 6

Characterization

1000 2000 3000 4000 5000 6000 7000 200 400 600 800 1000 1200 Fluorescence/O.D. Time (minutes)

IPTG State 42 ºC State

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC Induction stop

Basic flip flop time-course experiment

Stability Stability Basal levels Switch

slide-7
SLIDE 7

Multiagent Modeling

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-8
SLIDE 8

TRANSCRIPTION: Michaelis- Menten Kinetics + REPRESSION: Hill Kinetics IPTG INDUCTION: Hill kinetics as IPTG binding to repressor proteins TRANSLATION: Michaelis- Menten Kinetics (as Mass Action kinetics) REPRESSOR DEGRADATION: Mass Action Kinetics

Mathematical Modeling

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-9
SLIDE 9

Basic flip-flop Improved flip-flop Mathematical Modeling: Basic vs Improved

Stochastic simulations Mathematical models H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-10
SLIDE 10

Basic flip-flop Achievements

Experimental and mathematical characterization of the transcriptional flip-flop (information included in the registry) Identification of weaknesses Solutions proposed

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-11
SLIDE 11

IMPROVED FLIP-FLOP

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-12
SLIDE 12

Improved flip-flop

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-13
SLIDE 13

Proteolysis

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC Proteolisis is controlled by the adaptor protein levels

slide-14
SLIDE 14

Proteolysis

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-15
SLIDE 15

asRNA

RybB asRNA H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC A double deletion E.coli strain obtained for the adaptor protein and the asRNA. Lambda red protocol (Datsenko & Wanner, 2000)

slide-16
SLIDE 16

Induction time to achieve stability

Induction time to achieve Stability

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-17
SLIDE 17

Stability over time

1000 2000 3000 4000 5000 6000 7000 200 400 600 800 1000 1200 Fluorescence/O.D. Time (minutes)

Basic Flip-Flop Temperature State Stability

5000 10000 15000 20000 25000 30000 35000 200 400 600 800 1000 1200 Fluorescence/O.D. Time (minutes)

Improved Flip-Flop Temperature State Stability 42 ºC State IPTG State H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

Induction stop

IPTG >> 42º (10h stop induction)>> system evolution 17h time-course experiment Intermediary state Both states increase with time Two clearly defined states Desired state maintained

Induction stop

slide-18
SLIDE 18

Change speed

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

110min

Merge

160min Time (minutes) Time (minutes)

Time (minutes)

Change speed decreased in 50 min (31%)

Fluorescence/O.D. Fluorescence/O.D. Fluorescence/O.D.

slide-19
SLIDE 19

Improved flip-flop Achievements

Design and construction of an improved flip-flop Characterization of the improved flip-flop (information included in the registry) Construction of two new E. coli strains by defined deletions 2 new parts submitted

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-20
SLIDE 20

EPIGENETIC FLIP-FLOP

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-21
SLIDE 21

Epigenetic flip-flop: how it works

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-22
SLIDE 22

Docking modeling approach

Docking models for the TetR-Swi6 interaction The best three shape docking results are displayed in the top row, while the best shape+electrostatics docking results are shown in the row below. H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-23
SLIDE 23

Epigenetic flip-flop: how it works

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-24
SLIDE 24

Epigenetic flip-flop Achievements

Design of a novel epigenetic flip-flop Docking simulations performed to check the functionality

  • f the recombinant silencing proteins

Construction of the reporter and the compacting module Registration of the first 5 parts for the yeast Schizosaccaromyces pombe model organism in the Registry

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-25
SLIDE 25

MINI-TN7 TOOL KIT

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-26
SLIDE 26

Design and function of the miniTn7

Site-specific genome integration

Transposase action Flp Recombinase action

Antibiotic resistance removal

bacterial genome bacterial genome

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-27
SLIDE 27

miniTn7: Effects of device copy number Single copy conformation to improve the tightening of regulatory circuits

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-28
SLIDE 28

Tightening Safer

  • rganisms

Stability Industrial & environment applications Host-range MiniTn7 tool

Single copy insertion Horizontal transfer minimized Stable insertion at known neutral site Drug selection not required Suitable for multiple bacterial hosts

Plasmid Vectors

High copy number Potential for horizontal transfer Not fully stable Drug selection required Host-range restricted to

  • E. coli and

enterics

Advantages of using miniTn7 for BioBrick genome integration

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-29
SLIDE 29

Tn7 attachment site conservation

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-30
SLIDE 30

miniTn7 Characterization

Hosts Delivery methods Transformation efficiency

(transformants /ug DNA)

Transposition efficiency

(transposants /ug DNA)

Transposition frequency

(transposants/ vible cfu)

Site-specific insertions

(checked by PCR) Pseudomonas putida Mating NA NA 1 x 10-4 12/12 Electroporation 6 x 109 7 x 101 NA 10/12 Escherichia coli Heat-shock transformation 1 x 108 4 x 102 NA 11/12

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-31
SLIDE 31

6/100 drug-resistance marker excised miniTn7 Characterization

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-32
SLIDE 32

The tool kit

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-33
SLIDE 33

miniTn7 & flip-flops

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-34
SLIDE 34

A portable Tn7 attachment site

97/100 cfu got a miniTn7 inside its portable attTn7 after a transposition assay

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-35
SLIDE 35

miniTn7 Tool Achievements

Demonstration of better tightening of regulatory circuits when the device copy number decreases Construction and characterization of a transposon-based tool for chromosome integration Study of Tn7 attachment site level of conservation, obtaining a consensus sequence New section in the Part’s Registry: Genome Integration Tool Kit 10 new plasmids submitted, including miniTn7-flip-flops A portable Tn7 transposon insertion site (submitted and characterized)

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-36
SLIDE 36

BIOBRICK CREATOR

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-37
SLIDE 37

How it works

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-38
SLIDE 38

HUMAN PRACTICE

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-39
SLIDE 39

Synthetic Biology in High Schools

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-40
SLIDE 40

Sevilla’s Science Fair

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-41
SLIDE 41

Tornillos y Genes blog

http://tornillosygenes.com

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-42
SLIDE 42

Best Human Practice Advance, Europe

H.PRACTICES BB.CREATOR MINITN7 EPIGENETIC IMPROVED BASIC

slide-43
SLIDE 43

CONCLUSIONS

Studying the existing basic flip flop and identifying its flaws. Development of an improved flip flop (proteolysis and asRNA controls). Experimental characterization of the improved flip flop, proving its advantages A new concept of flip-flop by chromatin remodelation: the epigenetic flip flop. miniTn7 tool: a BioBrick chromosome integration tool kit. A software tool: the BioBrick Creator. Human Practice: High Schools, Science Fairs, Synthetic Biology Blog.

31 new BioBricks and BioBrick compatible plasmids registered 13 physical DNA parts submitted 5 new parts characterized 1 preexisting part characterized

slide-44
SLIDE 44

Thank you!!
