Filip Blagojević, Costin Iancu, Katherine Yelick, Matthew Curtis-Maury, Dimitrios S. Nikolopoulos, Benjamin Rose (presented by Rajesh Nishtala) For questions please email upc@lbl.gov

• Heterogeneous architectures are High Performance, Cost Effective,

Power-Effective

• Cell BE, FPGA, GPGPU, Larrabee, Rapport Kilocore
• Execution model considered: off-loading
• Enables relatively easy and efficient porting of the existing applications
• Achieves high performance and utilization of the architectures
• Off-loading requires efficient PPE-SPE communication and

synchronization

• Idle time on accelerators
• Co-scheduling policies required for higher utilization

• Efficient chip utilization requires multigrain parallelism:
• PPE oversubscription required for performance (RAxML)
• Parallelization balance depends on application characteristics (1-N PPE-SPE)
• Efficient PPE-SPE synchronization is required
• Number of off-loads in an applications is large (>100,000)
• Linux is unaware of the offloading execution

• Cell SDKs
• Callbacks - register event handler to respond to SPE requests
• Interrupt Mailboxes - PPE process performs blocking call to read a mailbox
• Busy-wait (S/P)PE polls on a shared memory variable

SPE idle

PPE SPEs

OS quantum

Busy Waiting
 Wait_for_SPE(sync_t *flag){ while(!flag); }

S1 S2 S3 S1 P1 P2 P3 P1

• Busy-wait with yielding Yield-If-Not-Ready (YNR)
• Cooperative Scheduling Slack-Minimizing Event-Driven Scheduler (SLED)
• Work-Stealing
• YNR, SLED 1-1 PPE-SPE mapping; WS any-any mapping

. . .

yield if not ready

PPE SPEs

P1 P1 P1 P2 P2 P2 P3 P3 P3

S1 S2 S3 S1 Yield if Not Ready Wait_for_SPE(sync_t *flag){ while(!flag){ sched_yield(); }}

. . .

P1 P1 P1 P2 P2 P2 P3 P3 P3

S1 S2 S3 Ideal SLED_Wait_for_SPE(){ while(not_done){ Determine SPE ready;
 yield_to(ready); }} S1

• Task scheduling: yield_to(pid) system call
• Signaling and task selection
• Shared memory data structure
• Evaluated both user and kernel level interfaces and implementations

SPE1

1 2 3 4 5 6 7 8

PPE with multiple processes

Kernel

PPE schedules process which is ready to run Ready-To-Run List

SPE2 SPE3 SPE4 SPE5 SPE6 SPE7 SPE8

yield_to(pid)

• Evaluated list and array based data structures
• Trade-off between ordering and fast access
• List – FIFO maximizes utilization but requires mutual exclusion
• Array – no ordering but avoids synchronization
• Design:
• Split array data structure
• Processes pinned to PPE h/w contexts
• Static partitioning SPEs to PPE h/w contexts
• Evaluated kernel and user level placement (SPE idle time per offload)
• User-Level = 7us
• Kernel-Level = 9us

• No kernel support and no system calls
• User-Level Work Stealing using BUPC
• Work pool resides in memory shared between processes (any-any PPE-SPE)
• Signaling mechanism identical to SLED, no pinning requirements

. . .

Off-loaded task can be served by any process

PPE SPE 1 3 4 5 6 7 8

. . .

1 2 3 4 5 6 7 8

PPE Processes 2

• Microbenchmarks
• Multiple PPE processes off-load SPE tasks of various length
• Evaluated kernel/user level implementation
• Evaluated multiple signaling data structure designs
• Evaluated SDK synchronization primitives

 Bioinformatics applications to generate Phylogenetic trees

(PBPI,RAxML)

 Evolutionary history among a set of species  Computationally expensive  NP-hard algorithms

 RAxML (Maximum Likelihood) – Master-Worker, Embarrassingly Parallel

 Work unit is multiple loops (three)  Communication between M-W only after unit is completed  Multiple code entry points into an SPE code module (work-stealing requires significant

re-engineering)

 PBPI (Parallel Bayesian Phylogenetic Inference) - Data Parallel

 Three main loops offloaded separately  ALL_TO_ALL communication after each loop body

 Whole loop body offloaded in both applications  Over 95% of execution time spent on SPEs in both applications

PPE-SPE Synchronization Overhead

Better Better

SPE Utilization

• “MBOX” - synchronization via interrupt mailboxes 19us
• “PPE” - yielding overhead with oversubscription (6 processes on PPE) 14us
• “YNR” < “PPE” due to congestion
• Average latency : Work-Steal 3us, SLED 7us, YNR 10us

Faster synchronization leads to improved SPE utilization

• Work-stealing for RAxML produces a 23%

slowdown for the workload (work migration implementation is not a full Continuation Passing Style)

• SLED improves the performance for up to 5%

(3% avg)

Better

• Work-Stealing improves the performance for

up to 21% (12% avg)

• SLED improves the performance for up to

10% (5% avg) For very short tasks (length < context switch) YNR always performs best

PBPI Speedup

• 10%
• 5%

0% 5% 10% 15% 20% 25% 204 444 684 924 1164 1404 1644 1884 2124 2364 2604 2844 3084 3324 3564 3804 4044 4284 4524 4764

Speedup DNA Sequence Length

SLED-Kernel SLED-User Work-Steal

RAxML Speedup

• 4%
• 3%
• 2%
• 1%

0% 1% 2% 3% 4% 5% 6%

100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000

Speedup

DNA Sequence Length

SLED User SLED Kernel

• Left-hand y-axis represents the reductions of the idle time when compared to the YNR idle time.
• IDLE: (right-hand y axis): time when SPEs are waiting for work as a percentage of total execution time

with YNR.

• SLED reduces the SPE idle time by up to 20% for both applications
• UPC Work-Steal reduces SPE idle time by up to 30% for PBPI
• With optimizations SPE still idle 20% (PBPI) and 10% (RAxML)

Task Distribution

50000 100000 150000 200000 250000 300000 350000 400000

0-10: 10-20: 20-30: 30-40: 40-50: 50-60: 60-70: 70-80: 80-90: 90-100: 100-200: 200-300: 300-400: 400-500: 500-600: 600-700: 700-800: 800-900: 900-1000: 1000-10000:

Task Length Number of Tasks

RAxML 105 RAxML 1176 RAxML 3063 PBPI 105 PBPI 1176 PBPI 3063

• Cell execution models:
• Offloading:
• P. Bellens et al “CellSs: A Programming Model for the Cell BE Architecture”
• M. de Krujif and K. Sankaralingam “MapReduce for the Cell B.E. Architecture”
• K. Fatahalian et al “Memory - Sequoia: Programming the Memory Hierarchy”
• M. Monteyne “RapidMind Multi-core Development Platform”
• Streaming
• Kudlur & Mahlke
• Shared memory model
• Eichenberger et al “Optimizing Compiler for the Cell Processor”
• SPE micro-kernels
• Mohamed F. Ahmed et al “SPENK: Adding Another Level of Parallelism on the Cell Broadband Engine”
• Many Application Studies
• F. Petrini et al. “Challenges in Mapping Graph Exploration Algorithms on Advanced Multicore Processors”
• D. Bader et al. “On the Design and Analysis of Irregular Algorithms on the Cell Processor: A Case Study on List Ranking”
• Jayram M. N. “Brain Circuit Bottom-Up Engine Simulation and Acceleration on Cell BE, for Vision Applications”

• Efficient execution on accelerators requires careful scheduling of

disjoint parallelism

• The current support for synchronization among the heterogeneous

cores is not sufficient (callbacks, mailboxes, busy wait)

• The cooperative scheduling strategies explored improve performance
• Impact of coscheduling will increase as contention on the general

purpose core increases (Cell blade with 8SPEs instead of PS3 with 6 SPEs)

• Ratio task length/scheduling overhead likely to remain constant in the

future architecture revisions
