Hydrogen Storage Type 1 & Type 4 for H2 Fueling

2

FIBA Mission Statement

Our mission is to manufacture and provide the finest quality gas containment equipment and services to our global

• customers. We will deliver, on time, environmentally-friendly

products of unparalleled safety, innovation and value.

3

CGA Leonard Parker Pool Safety Award 2017

• Sponsored by Air Products and Chemicals, Inc., the award was created in 1978 in memory of

Leonard Parker Pool, the founder and former chief executive of Air Products and Chemicals,

• Inc. The awards are presented annually to participating CGA member companies that have

recorded the greatest improvement in safety performance during the previous two years, and is based upon the total recordable case incidence rates as defined by the Occupational Safety and Health Administration.

• FIBA earned this award by lowering ITS company-wide incident rate by 47% over the prior two

years.

FIBA Overview

5

Introduction

History

• FIBA was founded in 1958 as a distributor of medical gases. In 1978 FIBA

diversified into the leasing of high pressure gas trailers and for nearly 40 years has become the world’s leading manufacturer and packager of equipment to store and transport high pressure and liquefied gases. Core Strengths of FIBA

• Employees: FIBA has nearly 300 dedicated employees and we take pride in the

fact that we are the only American owned and operated seamless high pressure tube manufacturer in the industry.

• Quality: FIBA is ISO 9001-2015 approved manufacturer. When it comes to

experience, expertise and excellence in gas containment equipment, FIBA Technologies, Inc. stands alone.

• Vertical Integration: FIBA is the only supplier fully integrated to offer

manufactured vessels, assemblies, servicing and leasing of both cryogenic and high pressure storage systems.

6

FIBA Facilities

Millbury, MA Rayne, LA East Greenville, PA Louisville, KY Taichung, Taiwan Westborough, MA Littleton, MA (Headquarters)

9 Strategically located facilities across the globe

Midvale, OH Adelanto, CA

7

Notable Projects

All Seas Project: Netherlands Pioneering Spirit $3 Billion, World's Largest Ship Single Lift Installation/Removal of Oil Platforms *1,200 Storage Vessels Chevron Gorgon Gas Project: Australia $50 Billion Project LNG Plant: 40 Trillion FT3 LNG *672 Storage Vessels DOD: Afghanistan / Iraq Aerostat Surveillance Persistent Threat Detection Systems Used Helium For Tethering *2,250 Storage Vessels

Hydrogen Projects

9

Domestic

Thousand Palms, CA Project 2003

10

Los Angeles, CA Project 2017

11

International

South Korea Project 2017

Hydrogen Type I Vessel

13

1,034 BAR Hydrogen Type 1 Pressure Vessel

14

3-Bank Cascade Hydrogen Refueling Station – 500 BAR, 700 BAR and 1,034 BAR

15

Addition of a 700 BAR middle zone between 500 BAR and 1,034 BAR zones introduces the following system improvements:

• Allows cascading of more vehicles before compressor starts.
• Reduces min-max pressure range (stress intensity) within a cycle, increasing fatigue life of the pressure vessel.

Cycles without 700 BAR Vessel (1,034 Bar – brown line) Cycles with 700 BAR Vessel (blue line)

Cycle Comparison with and without an intermediate 700 BAR Zone

16

Comparison of 1000 BAR (100 Mpa) Hydrogen Pressure Vessels Available in the World

Hydrogen Type IV Composite Vessel

18

FIBA Type IV Transportable Composite Vessel

• FIBA has manufactured trailers MEGCs for gas transportation for over 50 years .
• Our combined experience with design and operation, makes us the leader in

the industry. Future products include:

• 7,500 psi (517 Bar) H2 tube trailer transport, ISO 11515

19

Design Targets

Revolutionary, Cost Effective, World Class Design

• Safety-First, no compromise technology
• Provide full equivalent level of safety to FIBA’s steel pressure tubes
• Fully meet the requirements of ASME Section X, Class 3 for ground storage and

ISO 11515 for transportation

• Overcome limitations of competitors’ Type 4 CPVs
• Reduce costs with efficient design and lean manufacturing operations
• Industry-best flame resistance
• Provide built-in flame resistance that eliminates need for complicated PRD

devices and reduces the chance of accidental discharge

• Certifications:

DOT, ASME Section X, PED, TPED, TC, IMDG, ADR / RID, UN, ABS,

20

Composite Facility

JC Poussin, International Sales Manager jcpoussin@fibatech.com
