FCoE over TRILL

draft-mme-trill-fcoe-00

http://tools.ietf.org/html/draft-mme-trill-fcoe-00

Informational

David Melman Marvell Tal Mizrahi Marvell Donald Eastlake, 3rd Huawei IETF Meeting 81, July 2011

2

Background

} FCoE – Fibre Channel over Ethernet (FCoE). } FCF – FCoE Forwarder. } ENode – FCoE end node. } FCF functionality is a bit similar to RBridge in terms of:

§ Forwards Ethernet frames based on higher layer address. § Modifies MAC addresses to reflect next hop.

3

Background (2)

} The TRILL topology is very similar. } RBridges play similar roles as FCFs.

Host

RBridge RBridge RBridge RBridge RBridge

Host Host TRILL Cloud

4

FCoE with TRILL (1)

} What happens when we have FCoE and TRILL in the same network? } Separate cloud approach:

Host

Ethernet / FCoE RBridge RBridge RBridge RBridge RBridge

TRILL Cloud

Native FC FC Storage Array FCF

Host

Ethernet / FCoE

• FCoE traffic between hosts must

be forwarded through an FCF .

• With separate clouds: goes

through more hops.

5

FCRB – FCF over RBridge

Host

Ethernet / FCoE

Ethernet / FCoE

• ver

TRILL Cloud

Host

Ethernet / FCoE FCF RBridge

FCRB

6

Data Center Topology with FCRB

Native FC

...

Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server

Rack FCRB ToR

Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server

Rack FCRB ToR

Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server

Rack FCRB ToR FCRB EoR FCRB EoR

...

WAN

...

7

Next Steps

} July 2011 – draft 00. } Receive feedbacks from WG.

Thanks

9

Data Center Topology with FCRB (2)

...

Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server

Rack FCRB ToR

Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server

Rack FCRB ToR

Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server Eth/FCoE Server

Rack FCRB ToR RBridge EoR RBridge EoR

...

TRILL Cloud

• EoR are RBridge – not FCRB.
• Traffic between FCRBs is forwarded
• ver TRILL cloud.
