F ROM R ESEARCH T O I NDUSTRY M OBILE EDITION (Or, How I Learned - - PowerPoint PPT Presentation

FROM “RESEARCH” TO “INDUSTRY” MOBILE EDITION

(Or, How I Learned To Stop Worrying about Papers and Start Building Smartphone Apps) Stephen Miller, Co-Founder and SVP Engineering Fyusion, Inc

THIS TALK IS ABOUT…

• How to future-proof your research code
• How to transition from academia to industry
• Hard things I’ve learned growing from a team of ~4 to

a team of >50

• A few tricks for porting desktop code to mobile
• Just enough shameless company promotion to justify

reimbursing the flight

THIS TALK IS NOT ABOUT…

• In-depth technical details

• Any particular library

• Science

• Computer Vision, really, except insofar as it informs

certain challenges

YOU ARE…?

ROUGH OUTLINE

1: Context (~5 min)

• Who I am
• What I did before Fyusion
• What Fyusion is all about

2: Growing pains (~10 min)

• Problems with going from research -> industry
• Particular problems with going from desktop ->

mobile

3: Helpful tips (~10 min)

• General code organization
• Device-specific vs generic code
• Broader startup tips (git flow, process, management)

WHO AM I?

My current face

Robotics 3D Vision Open Source / Industry Collaboration

https://www.youtube.com/watch?v=5FGVgMsiv1s

ROBOTICS @ BERKELEY

(2007 - 2011)

GAP BETWEEN ACADEMIC + PUBLIC EXPECTATION

http://abcnews.go.com/Politics/oklahoma-sen-tom-coburn-report-shows-taxpayer-money/story?id=13689403

3D VISION @ STANFORD

• Started PhD on 3D perception

• Use only low-cost ($100 or less)

sensors

Sensor 0 Sensor 1

(2011 - 2014-ish)

• World’s largest 3D Image Processing initiative

250 500 3/1/11 9/1/11 3/1/12 9/1/12

CUMULATIVE MONTH TO MONTH

D e v e l

• p

e r s

MAINTAINER @ PCL

(2011 - present…ish)

Stop wasting tax dollars and give me all the stuff I saw in the movies

Point clouds, Meshes, Octrees, …

Technologists PROBLEM: CONSUMERS DON’T CARE ABOUT TECH DEMOS Consumers

Point clouds, Meshes, Octrees, …

Technologists PROBLEM: CONSUMERS DON’T CARE ABOUT TECH DEMOS Consumers

Slick, seamless, “magic”

THE CHALLENGE: MAKE IT SO STURDY THEY DON’T


KNOW IT’S RESEARCH

http://fyusion.com

UNDER THE HOOD: SCIENCE

TO THE USER: MAGIC

FASHION, E COMMERCE

CUSTOM CAPTURE MODES

EXAMPLE INDUSTRY: AUTOMOTIVE

EXAMPLE INDUSTRY: AUTOMOTIVE

HOW DID WE SCALE?

REQUIRED BUSTING A LOT OF MYTHS

MYTH: DEMO CODE™

RECENT EXAMPLE: BOTTLENECK

foreach slice [start, end]: fire up decoder march to start fire up processor process to end

Slices were *nonoverlapping* and
 *consecutive*.
 This code is extremely wasteful^

GIT BLAME

ORIGINAL CODE

fire up decoder process fire up processor

“Just hack it!”

ORIGINAL CODE

fire up decoder foreach slice [start, end]: march to start fire up processor process to end

“Just hack it!”

Bad code evolves


• ver time

++

“JUST HACK IT” - INDUSTRY EDITION

THE POINT:


DO IT WELL ENOUGH THE FIRST TIME,
 BECAUSE…

MYTH: THE ENGINEERS™ WILL DO IT LATER

“THE ENGINEER” WILL

• Understand my hacky pseudocode

• Convert my O(n^3) algorithm into O(n) with

Optimization™


• Add helpful comments

• Rename obscure variables and functions

• Write unit tests for everything

“The QArchitician is half QA, half Software Architect, half Mathematician!”

THE ACTUAL ENGINEER WILL

• Be deeply frustrated to work with brittle

code as a starting point


• Be very conservative about accidentally

breaking something


• Require your input and review time, and in

all likelihood…


• Quarantine your code before they fix it

AND THEY’LL BE *RIGHT* TO QUARANTINE, BECAUSE…

TOO MANY COOKS SPOIL THE ALGORITHM

Old, hacky research code % you know offhand: 100

New, “clean”, “optimized”, “refactored” code % you know offhand: ~60 % they know offhand: ~60 % shared:
 10

TOO MANY COOKS SPOIL THE ALGORITHM

WHEN CRASHES ATTACK

WHEN CRASHES ATTACK

“This looks nothing like
 my algorithm.”

WHEN CRASHES ATTACK

“Don’t ask me, it’s not
 my algorithm.”

TAKEAWAY: SOMEONE SHOULD FULLY UNDERSTAND


A GIVEN CODE BLOCK.


IF IT’S COMPUTER VISION RELATED,


THAT SOMEONE IS PROBABLY YOU.

MYTH: THE PLATFORM IS IRRELEVANT

There Will Be Bugs

2016 ANDROID RECORDING BUG

• Scattered reports from users on a specific device by a European

manufacturer: “Suddenly, the camera just stops sensing motion”

• Difference in timestamps:


13107153
 13107234
 13107212
 13107128

• ^ 2^17 second offset

2017 IPHONE 8 AND X RECORDING BUG

• “All of a sudden it just stops working” - iPhone 8, 8+, and X users
• Bonus points for anyone who can tell me what is mathematically interesting

about 768614.395 seconds…

2015 VIDEO DECODER BUG

• “It works fine for the first 204…then stops forever”


2015 VIDEO DECODER BUG

• Bug in Apple video decoder (lasted at least 3 years)

video200.mp4 video200.mp4 video200.mp4 video204.mp4 Decoder1 Decoder1 Decoder1 Decoder1 Decoder204

2015 VIDEO DECODER BUG

• Bug in Apple video decoder (lasted at least 3 years)

video200.mp4 video200.mp4 video200.mp4 video204.mp4 Decoder1 Decoder1 Decoder1 Decoder1 Decoder204 video_sym.mp4

EXISTENTIAL QUESTION: HOW DO YOU TEST FOR THIS $@*(&?

• Not scalable to actually test for every possible case


• Irresponsible not to test for


every possible case

“Okay, so before a PR can be merged, we need to make sure we run it on this particular model

• f Alcatel phone for at least 3 weeks, and

also the plus version, and the international version, and a version running Lollipop, and also bring it to that garage, and also…”

MYTH: I CAN JUST DO IT ON THE CLOUD™ INSTEAD

GOING TO THE CLOUD

• 1 minute of 1080p capture on an iPhone = 200MB

• In many cities, you’ll be lucky if that is done in 5

minutes — and that assumes Apple doesn’t kill you first


• If you want to scale globally (China, India), you can’t

assume an LTE connection

Strong AI
 Achieved!

Just point at anything
 and our patented
 algorithm will do
 the rest

MYTH: I CAN JUST SAVE RAW DATA AND DO IT OFFLINE

DOING IT OFFLINE

• 1 minute of 1080p capture = 3600 frames

• If you have a simple thing (e.g. 10 ms or less), you’re

still looking at 30 seconds to run it

• And that’s ignoring h264 decoding time!

• If you can do anything online, do it! Attention spans

are very low, even for cutting edge tech.

MYTH: IT’LL BE LIKE A LAB, WE CAN WING IT!

IN THE BEGINNING…

You and a handful of colleagues know every line of code.
 You move extremely quickly, and have no need for QA

• r code review.





 “Meetings” make you think of Dilbert

EVENTUALLY

50+ people, multiple products, multiple deadlines, actual customers (and this is just one repository) No way for one person to
 keep track of everything

REALIZATION: WE NEED A MORE FORMAL PROCESS

MYTH: PROCESS™ WILL SOLVE IT

PROCESS: A PRIMER

Step 1: Commit to an insane deadline

Five days? I’ll do it in one!

PROCESS: A PRIMER

Step 1: Commit to an insane deadline Step 2: Fail

PROCESS: A PRIMER

Step 1: Commit to an insane deadline Step 2: Fail Step 3: Blame Process™

“We need JIRA!” “Trello or die!” “Did you even read The Lean Startup?!!” “Scrum you fools! It’s been scrum the whole time!”

THE TRUTH

Process is useful, and necessary.










 But it isn’t a magic bullet.

ENOUGH MYTHS; WHAT SHOULD I DO?

TIP: BEWARE OF CVPR SYNDROME

• “What if it also used GANs to predict when the user

wants to stop recording?”


• “Surely superresolution can help this”

• “Why are we using JPEG? This latest compression

algorithm is *way* better”


• “Couldn’t a neural network handle all the

• n-screen rendering too?”

• “This would be much better if I wrapped it


in Haskell”

TIP: BEWARE OF CVPR SYNDROME

https://www.youtube.com/watch?v=evUWersr7pc

IT WILL GET MORE COMPLICATED ON ITS OWN.
 DON’T PUSH IT.

• Customization per customer

• Exceptions for certain lighting conditions

• Optimizations for particular phones

• New battery constraints that force you to fork and

simplify


• Handling of about 10000 different edge cases

“BUT WAIT, THERE’S…”

TIP: DON’T REINVENT THE WHEEL

• Just because you can make it on your own


doesn’t mean you should.



• Many of the things you hate about a certain

codebase are exactly what will happen to

• yours. But theirs will be tested.

• Best case scenario: you waste time.
• Worst case scenario: years of bugfixing

Your hard-coded quaternion arithmetic Eigen::Quaternionf

TIP: KEEP ALGORITHMS CROSS PLATFORM

libCV.a

Android Source (Java)

FYAndroid.git

CVLib.framework

iOS Source (ObjC, Swift)

FYiOS.git

CVLib Source (C++)

libCV.so

CVLib.git

Debugging Tools Algorithmic Unit Tests

FYServer.git FYOculus.git …

TIP: I/O IS CRITICAL

State Of The Art ™ “Realtime” Algorithm

 25ms

C a m e r a

• >

g r a y s c a l e c v : : M a t
 3 m s cv::Mat -> jpeg
 30ms

• Always look for hardware accelerated options
• Minimize unnecessary data


modifications (resizing, color
 conversions, CPU <-> GPU)

• Color conversions in particular


are a constant source of bugs;
 settle on a bulletproof
 convention ASAP

CVLib.git (C++)

ImageIO.saveImage() RandAccMovieIO.loadFrame(idx) SeqMovieIO.loadNextFrame() DataIO.saveEncrypted(blob) @interface HEIFWriter : ImageIO @interface MJPEGEncoder : RandAccMovieIO @interface HVECEncoder : SyncMovieIO @interface iOSCryptoWrapper : DataIO

FYiOS.git (ObjC)

CVLib.git (C++)

ImageIO.saveImage() RandAccMovieIO.loadFrame(idx) SeqMovieIO.loadNextFrame() DataIO.saveEncrypted(blob) class JPEGWriter : ImageIO class PNGDirIO : RandAccMovieIO class H264Encoder : SyncMovieIO class FastAndroidEncryptor : DataIO

FYAndroid.git (Java)

CVLib.git (C++) FYiOS.git (Obj C)

CVImage resize()
 cvtColor()
 toBitmap() toGLBuffer() … iOSImageWrapper MetalTexture UIImage Processor ImageIO IOSProcessingDelegate ProcessingCB() HEIFWriter

DOWNSIDE: SHARED CODE = TOUGHER QA

TIP: AUTOMATE EVERYTHING

Grad school edition: Makefiles for everything

TIP: CONTINUOUS INTEGRATION IS A LIFESAVER

• Use Jenkins to run sanity checks on device simulators

Build alone is an enormous timesaver, especially on device Keep track of multiple
 products simultaneously

(PARTICULARLY WITH THE CROSS PLATFORM SIDE)

libCV.a CVLib.framework

CVLib Source (C++)

libCV.so

• Build all targets (iOS, Android, Desktop) to ensure no API breakage.
• Alternative: your research engineers will never be able to push code without

having an iPhone, an Android phone, and extraordinary patience

TIP: (SOME) GIT FLOW IS IMPORTANT

• Lots of blogs take this to an extreme



 (Feature -> sprint -> epic ->
 qa -> release -> …)

TIP: (SOME) GIT FLOW IS IMPORTANT

What works for us is more basic:


• Engineer makes PR onto dev

• dev PR gets code review + unit tested

• > merged

• Once all features are in, PR opened from


dev -> release


• release PR gets more thorough QA,


manual testing -> merged


• Only release branch gets shipped to


iOS, Android, etc repositories

TIP: FIND THE RIGHT REVIEWING BALANCE

Overly Strict:


• Nothing gets merged unless

it is perfect

• Deadlines slip due to inactivity

/ unwillingness to take any chances

• Morale drops to 0

Overly Permissive:


• Everything gets merged

• Destabilizing crashes ruin

every delivery, deadline rushes create unusable code


• Morale drops to 0

6/17/2018 Complex processing changes by sdmiller · Pull Request #1 · sdmiller/cvpr https://github.com/sdmiller/cvpr/pull/1#pullrequestreview-129398515 1/2

master addedProcessing

Trying out slicing 0a85920 Slicing 99472cc 3 days of hard work bbde897 CVPR/Processor.m 46 47 48 49 + + + +‑ (NSArray<ProcessingResult*>*)processForSlices:(NSArray*)slices CVPR/Processor.m 49 50 51 52 +‑ (NSArray<ProcessingResult*>*)processForSlices:(NSArray*)slices +{ + NSMutableArray<ProcessingResult*>* resultsPerSlice = [NSMutableArray new]; + for (Slice* slice in slices) { CVPR/Processor.m 51 52 53 54 + NSMutableArray<ProcessingResult*>* resultsPerSlice = [NSMutableArray new]; + for (Slice* slice in slices) { + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; CVPR/Processor.m 52 53 54 55 + for (Slice* slice in slices) { + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; + int frameCount = ‑1; CVPR/Processor.m 56 57 58 59 + Frame* currentFrame; + while ( (currentFrame = [self.decoder getFrame]) ) { + ++frameCount; + if (frameCount < slice.start) { CVPR/Processor.m 58 59 60 61 + ++frameCount; + if (frameCount < slice.start) { + continue; + } else if (frameCount > slice.end) { CVPR/Processor.m 61 62 63 64 + } else if (frameCount > slice.end) { + break; + } + // BLAH BLAH DO MAGIC CVPR/Processor.m 63 64 65 66 + } + // BLAH BLAH DO MAGIC + } + [resultsPerSlice addObject:result]; CVPR/Processor.m 71 72 73 74 + +‑ (ProcessingResult*)process +{ + ProcessingResult* result = [ProcessingResult new]; CVPR/Processor.m 74 75 76 77 + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; + int frameCount = ‑1; + Frame* currentFrame;

6/17/2018 Complex processing changes by sdmiller · Pull Request #1 · sdmiller/cvpr https://github.com/sdmiller/cvpr/pull/1#pullrequestreview-129398515 1/2

master addedProcessing

Trying out slicing 0a85920 Slicing 99472cc 3 days of hard work bbde897 CVPR/Processor.m 46 47 48 49 + + + +‑ (NSArray<ProcessingResult*>*)processForSlices:(NSArray*)slices CVPR/Processor.m 49 50 51 52 +‑ (NSArray<ProcessingResult*>*)processForSlices:(NSArray*)slices +{ + NSMutableArray<ProcessingResult*>* resultsPerSlice = [NSMutableArray new]; + for (Slice* slice in slices) { CVPR/Processor.m 51 52 53 54 + NSMutableArray<ProcessingResult*>* resultsPerSlice = [NSMutableArray new]; + for (Slice* slice in slices) { + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; CVPR/Processor.m 52 53 54 55 + for (Slice* slice in slices) { + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; + int frameCount = ‑1; CVPR/Processor.m 56 57 58 59 + Frame* currentFrame; + while ( (currentFrame = [self.decoder getFrame]) ) { + ++frameCount; + if (frameCount < slice.start) { CVPR/Processor.m 58 59 60 61 + ++frameCount; + if (frameCount < slice.start) { + continue; + } else if (frameCount > slice.end) { CVPR/Processor.m 61 62 63 64 + } else if (frameCount > slice.end) { + break; + } + // BLAH BLAH DO MAGIC CVPR/Processor.m 63 64 65 66 + } + // BLAH BLAH DO MAGIC + } + [resultsPerSlice addObject:result]; CVPR/Processor.m 71 72 73 74 + +‑ (ProcessingResult*)process +{ + ProcessingResult* result = [ProcessingResult new]; CVPR/Processor.m 74 75 76 77 + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; + int frameCount = ‑1; + Frame* currentFrame;

6/17/2018 Complex processing changes by sdmiller · Pull Request #1 · sdmiller/cvpr https://github.com/sdmiller/cvpr/pull/1#pullrequestreview-129398515 1/2

master addedProcessing

Trying out slicing 0a85920 Slicing 99472cc 3 days of hard work bbde897 CVPR/Processor.m 46 47 48 49 + + + +‑ (NSArray<ProcessingResult*>*)processForSlices:(NSArray*)slices CVPR/Processor.m 49 50 51 52 +‑ (NSArray<ProcessingResult*>*)processForSlices:(NSArray*)slices +{ + NSMutableArray<ProcessingResult*>* resultsPerSlice = [NSMutableArray new]; + for (Slice* slice in slices) { CVPR/Processor.m 51 52 53 54 + NSMutableArray<ProcessingResult*>* resultsPerSlice = [NSMutableArray new]; + for (Slice* slice in slices) { + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; CVPR/Processor.m 52 53 54 55 + for (Slice* slice in slices) { + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; + int frameCount = ‑1; CVPR/Processor.m 56 57 58 59 + Frame* currentFrame; + while ( (currentFrame = [self.decoder getFrame]) ) { + ++frameCount; + if (frameCount < slice.start) { CVPR/Processor.m 58 59 60 61 + ++frameCount; + if (frameCount < slice.start) { + continue; + } else if (frameCount > slice.end) { CVPR/Processor.m 61 62 63 64 + } else if (frameCount > slice.end) { + break; + } + // BLAH BLAH DO MAGIC CVPR/Processor.m 63 64 65 66 + } + // BLAH BLAH DO MAGIC + } + [resultsPerSlice addObject:result]; CVPR/Processor.m 71 72 73 74 + +‑ (ProcessingResult*)process +{ + ProcessingResult* result = [ProcessingResult new]; CVPR/Processor.m 74 75 76 77 + ProcessingResult* result = [ProcessingResult new]; + [self.decoder restart]; + int frameCount = ‑1; + Frame* currentFrame;

HEALTHY EXPECTATIONS IN RELATIONSHIPS

Dan Savage relationship advice: “There's no perfect person, no perfect person for you, no perfect match…etc. You'll meet a 0.64 or two if you're lucky—if you're really lucky you might even meet a 0.72—and it's your job to round that [person] up to one.”

HEALTHY EXPECTATIONS IN CODE

My engineering sanity advice: No one will write perfect code, with perfect variable names, perfect comment styles, a unit test for every method so thorough we will know it works simply if it runs. Like human relationships, if you want to ever have a chance at merging, round “pretty good!” up to perfect and move on with your life.

TIP: BUFFERS (THE HUMAN KIND) ARE CRITICAL

Feb 2016: I take over a project for a big client.
 Biweekly phone calls, incremental features. “Hacking is fun! I could do this in my sleep!”
 PRs every day or two with good, targeted improvements By March… ~15 self merge PRs a day, usually with curse words attached.

BURNOUT

By April… Actual photo in China after 2 sleepless weeks Fever medicine

HOW IT WORKS: ENGINEER <-> CUSTOMER

“Is X possible?” “How long?” Boss 2: “PUSH PUSH PUSH” “Great talk to you in 16 hours with a new buglist!” “Yes everything is trivial” “I have a PhD 9 hours” “What about Y?” “Idk, 7 hours?” Boss 1:
 “Keep Customer happy” “I don’t pay you to sleep!” “But what about sleep?” “You don’t pay me at a—“

Engineer Customer’s
 PM

1 WEEK LATER

Boss 2: “Great pushing today, Jimbo!” Boss 1: “Why is our codebase in Piglatin?”

HOW IT SHOULD WORK: PM <-> CUSTOMER

Product Manager Customer’s
 PM

“Is X possible?” “How long?” “So when will it be ready?” “I don’t know I’d need to ask my Engineer.” “I’ll ask tomorrow.” “What about Y?” “I’ll ask tomorrow.” Boss 1:
 “Keep Customer happy” “Okay put it in a giant spreadsheet” “Engineers, right? I’ll text u tmrw” “I love those!” Boss 2: “PUSH PUSH PUSH”

HOW IT SHOULD WORK: PM <-> ENGINEER

Product Manager Engineer

“I went rock climbing and watched Westworld, per CS stereotype” “Are you even listening I have a Ph—” “How was your weekend, champ?” “Cool cool cool hey, can we touch base on X later?” “It’s trivial I have a PhD I could do that in 9 hours.” “Can you do it by Friday?” “Friday! You’re a champ!”

1 WEEK LATER

Boss 2: “Great pushing today, Jimbo!” Boss 1: “Friday deadline on track?”

LOW-LEVEL LIGHTNING ROUND

TIP: GUARD THE MAIN THREAD WITH YOUR LIFE

Viewer

• Separate viewing logic


(previsualization, computation) from actual
 rendering


• iOS: DisplayLink very useful here

• Bonus: manually decode JPEGs on a


background thread; don’t let viewer
 handle it on the fly

TIP: GUARD THE MAIN THREAD WITH YOUR LIFE

Viewer Camera

• Separate viewing logic


(previsualization, computation) from actual
 rendering


• iOS: DisplayLink very useful here

• Bonus: manually decode JPEGs on a


background thread; don’t let viewer
 handle it on the fly

• Decouple online computation (detections,


keypoint tracking, style transfer, etc) from
 preview rendering


• Don’t queue forever: know when to


throttle, when to revert to offline


• Write flexibly; remember, what looks


good on the iPhone X won’t look good


• n a 4s

TIP: MEMORY MATTERS

• iOS: @autoreleasepool, intercept


memory warnings


• Android: reason with the garbage collector in mind

(and the stutter it could cause)


• Trust design patterns for asynchronous


systems: they are *hard* to rederive
 from scratch


• Favor online approaches wherever


possible

TIP: MEMORY MATTERS

• Common mistake: bad delegate patterns

TIP: MEMORY MATTERS

CameraViewController DGBGDetector @property (strong) ___ *detector @property (strong) ___ *delegate

Circular reference = memory leak!

TIP: MEMORY MATTERS

CameraViewController DGBGDetector @property (strong) ___ *detector @property (weak) ___ *delegate

TIP: MEMORY MATTERS

• Even more nefarious: inline function blocks


self.successHandler = ^{
 _statusButton.text = @“SUCCESS!”
 }


• Correct pattern: weak pointers


__weak typeof(self) *weakSelf = self; self.successHandler = ^{
 weakSelf.statusButton.text = @“SUCCESS!”
 }

self successHandler

@property (strong) void() * @property (strong) Controller *

weakSelf successHandler

@property (strong) void() * @property (weak) Controller *

TIP: MEMORY MATTERS

• Be strict:

• Reuse large objects (i.e neural networks, filters) as

global singletons


• Clean up unneeded memory ASAP; don’t wait for


garbage collector to get around to it

THANKS!

• Check us out at http://fyusion.com

• Try our newly released Viewer SDK at http://developers.fyusion.com

• Tweet me @sdavidmiller, find me at http://sdavidmiller.com, or…

• Google “Stephen Miller”, and help PageRank devalue this guy:
