SLIDE 1
Feature Diagrams & Logic There and Back Again
Krzysztof Czarnecki
University of Waterloo
Andrzej W ˛ asowski
IT University of Copenhagen
Feature Models
car
F eature D iagrams & L ogic T here and B ack A gain Krzysztof - - PowerPoint PPT Presentation
F eature D iagrams & L ogic T here and B ack A gain Krzysztof - - PowerPoint PPT Presentation
F eature D iagrams & L ogic T here and B ack A gain Krzysztof Czarnecki University of Waterloo Andrzej W asowski IT University of Copenhagen F eature M odels car F eature M odels car body engine gear keyless-entry power-locks F
SLIDE 2
SLIDE 3
Feature Models
car power-locks keyless-entry gear engine body
SLIDE 4
Feature Models
car power-locks keyless-entry gear engine body electric gas manual automatic
SLIDE 5
Feature Models
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
SLIDE 6
Feature Models
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
Model variability & commonality.
SLIDE 7
Feature Models
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
Model variability & commonality. Standard semantics:
φ(car, body, engine, gear, . . . )
SLIDE 8
Semantics
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
φ
SLIDE 9
Reverse Engineering Syntax
?
φ
SLIDE 10
Reverse Engineering Syntax
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
φ
SLIDE 11
Reverse Engineering Syntax
a → c a b c c a b a b c a, c b
φ
SLIDE 12
Reverse Engineering Syntax
a b c
φ
SLIDE 13
Contents
Motivation Syntax & Semantics (going there) Algorithm (going back again) Concluding remarks
SLIDE 14
Contents
Motivation Syntax & Semantics (going there) Algorithm (going back again) Concluding remarks
SLIDE 15
Theoretical Motivation
To deepen understanding of feature models To explore the relation between logics and FMs To characterize formulæ that are FMs without leftover constraint
SLIDE 16
Applied Motivation
To visualize variability given as systems of constraints.
SLIDE 17
Applied Motivation
To visualize variability given as systems of constraints. To guide the user interactively in visualizing constraints.
SLIDE 18
Applied Motivation
To visualize variability given as systems of constraints. To guide the user interactively in visualizing constraints. To support refactoring tools.
SLIDE 19
Applied Motivation
To visualize variability given as systems of constraints. To guide the user interactively in visualizing constraints. To support refactoring tools. To support reverse engineering FMs from code.
SLIDE 20
Contents
Motivation Syntax & Semantics (going there) Algorithm (going back again) Concluding remarks
SLIDE 21
Syntax: Going There
f
Solitary [1..1] → mandatory
SLIDE 22
Syntax: Going There
f
Solitary [1..1] → mandatory
f
Solitary [0..1] → optional
SLIDE 23
Syntax: Going There
f
Solitary [1..1] → mandatory
f
Solitary [0..1] → optional
f
Solitary [0..1] → grouped
SLIDE 24
Syntax: Going There
f
Solitary [1..1] → mandatory
f
Solitary [0..1] → optional
f
Solitary [0..1] → grouped Group [1..1] → xor-group
SLIDE 25
Syntax: Going There
f
Solitary [1..1] → mandatory
f
Solitary [0..1] → optional
f
Solitary [0..1] → grouped Group [1..1] → xor-group Group [1..k] → or-group
SLIDE 26
Syntax: Going There
f
Solitary [1..1] → mandatory
f
Solitary [0..1] → optional
f
Solitary [0..1] → grouped Group [1..1] → xor-group Group [1..k] → or-group
φ
Left-over constraints
SLIDE 27
Semantics: Going There
a b c d e f
a b c d e f
∧
a c ∨ e f
SLIDE 28
Semantics: Going There
a b c d e f
a b c d e f
∧
a c ∨ e f
a b c d ∨ e f
An implication (hyper)graph
SLIDE 29
Contents
Motivation Syntax & Semantics (going there) Algorithm (going back again) Concluding remarks
SLIDE 30
Why Is It So Hard?
1. Possibly no models corresponding to φ
SLIDE 31
Why Is It So Hard?
1. Possibly no models corresponding to φ 2. Possibly many models corresponding to φ
a → c a b c c a b a b c a, c b
SLIDE 32
Why Is It So Hard?
1. Possibly no models corresponding to φ 2. Possibly many models corresponding to φ
a → c a b c c a b a b c a, c b
3. Brute-force infeasible
SLIDE 33
Root Feature
Property The root of a feature tree Test A variable r implied by all the
- ther variables:
for all i. φ → (fi → r)
SLIDE 34
Root Feature
Property The root of a feature tree Test A variable r implied by all the
- ther variables:
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
body → car, gas → car, . . .
SLIDE 35
Feature Hierarchy
Property
f is an ancestor of g (descendant)
Test Implication from descendant (g) to ancestor (f)
g → f
SLIDE 36
Feature Hierarchy
Property
f is an ancestor of g (descendant)
Test Implication from descendant (g) to ancestor (f)
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
body → car, gas → car, . . .
SLIDE 37
Feature Hierarchy
Property
f is an ancestor of g (descendant)
Test Implication from descendant (g) to ancestor (f)
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
Direct links: transitive reduction
SLIDE 38
Mandatory Features
Property
g is a mandatory subfeature of f
Test Biimplication between variables corresponding to g and f
f → g
SLIDE 39
Mandatory Features
Property
g is a mandatory subfeature of f
Test Biimplication between variables corresponding to g and f
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
body → car, car → body, . . .
SLIDE 40
And Groups
Property
g is a mandatory subfeature of f
Test Biimplication between variables corresponding to g and f
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
And-groups: cliques in the graph
SLIDE 41
Or Groups
Recall that for an or-group:
φ → (f → f1 ∨ · · · ∨ fk)
But then also
φ → (f → f1 ∨ · · · ∨ fk ∨ g)
holds for g other than fi.
SLIDE 42
Or Groups
Implied disjunction can always be weakened! All implied disjunctions =
- versized and too-many or-groups
So detect minimal disjunctions
SLIDE 43
Or Groups
Implied disjunction can always be weakened! All implied disjunctions =
- versized and too-many or-groups
So detect minimal disjunctions
{fi}i=1..k is a prime implicant of f
(see the paper) Prime implicants are well studied in fault tolerance analysis
SLIDE 44
Or Groups
Property Or-groups of features rooted in f Test Find prime implicants of f
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
electric ∧ gas → engine
SLIDE 45
Or Groups
Property Or-groups of features rooted in f Test Find prime implicants of f
car power-locks keyless-entry gear engine body electric gas manual automatic keyless-entry→power-locks
manual ∧ electric ∧ gas → engine
SLIDE 46
Algorithm
1 if unstatisfiable then quit 2 remove & report dead features 3 compute implication graph & its transitive reduction 4 find and-groups by contracting cliques 5 find all or-groups and xor-groups candidates
SLIDE 47
Contents
Motivation Syntax & Semantics (going there) Algorithm (going back again) Concluding remarks
SLIDE 48
Discussion (I)
Constructs an overapproximation (add a leftover constraint) The graph constructed contains maximum information (complete)
SLIDE 49
Discussion (I)
Constructs an overapproximation (add a leftover constraint) The graph constructed contains maximum information (complete) Implemented using BDDs, algorithm by Coudert&Madre,1992 Efficient and scalable (computing prime implicants is the bottleneck)
SLIDE 50
Discussion (II)
Semantic operations on feature models become logical operations
- n corresponding formulæ
Merge: (φFM1 → r) ∧ (φFM2 → r) Difference: φFM1 ∧ ¬φFM2 ...
SLIDE 51
Future Work
Generalize the kind of models extracted beyond FODA Implement complex refactorings using logical representations Experiment with extracting models from code
