Extremely Secure Communication Daniel Romo - daniel.romao@os3.nl Oil Company Oil Company What (almost) everyone knows: NSA collects traffic Confidential data can be compromised Backdoors in encryption-related software and hardware make it

SLIDE 1

Extremely Secure Communication

Daniel Romão - daniel.romao@os3.nl

SLIDE 2

SLIDE 3

SLIDE 4

Oil Company

SLIDE 5

Oil Company

SLIDE 6

What (almost) everyone knows: NSA collects traffic Confidential data can be compromised Backdoors in encryption-related software and hardware make it easier

SLIDE 7

Research Question How can an extremely secure communication

n the Internet be deployed for work teams and

individuals around the globe?

SLIDE 8

What can we do?

1 - Avoid possible backdoors on RNGs

➢ Use a verifiable HRNG to improve the kernel entropy pool

2 - Avoid having all data going over a single link

SLIDE 9

What can we do?

1 - Avoid possible backdoors on RNGs

➢ Use a verifiable HRNG to improve the kernel entropy pool

2 - Avoid having all data going over a single link

SLIDE 10

What can we do?

1 - Avoid possible backdoors on RNGs

➢ Use a verifiable HRNG to improve the kernel entropy pool

2 - Avoid having all data going over a single link

➢ Use a multipoint VPN!

SLIDE 11

Hardware Random Number Generator

Multiple devices exist, mostly closed source

○ Big price differences

Ongoing discussion on noise sources

○ PN junctions, RF noise, clock drift, thermal noise...

SLIDE 12

What if we implement a HRNG that is verifiable and has multiple noise sources?

SLIDE 13

HRNG - Related Work

Rob Seward implemented a basic HRNG on

Arduino using a single PN junction

○ Calibration on startup ○ XOR and Von Neumann filtering ○ Serial interface for output

SLIDE 14

http://holdenc.altervista.org/avalanche/images/noise.png http://robseward.com/misc/RNG2/RNG_Version_2_images/rng2_circuit_small.png

SLIDE 15

HRNG Implemented

Extension of the previous work

○ Multiple noise sources ○ Continuous calibration ○ Second serial interface for logging ○ Raw byte output mode for rng-tools

SLIDE 16

SLIDE 17

SLIDE 18

SLIDE 19

HRNG Testing

○ Entropy, Optimum compression, Chi square, Arithmetic mean, Monte Carlo Pi, Serial correlation

RNGtest

○ FIPS-140-2 test ○ To test cryptographic modules for use by the United States federal government

SLIDE 20

SLIDE 21

Ent results Sample size: 2504 bytes

SLIDE 22

Ent results Sample size: 512Kb

SLIDE 23

RNGtest results Sample size: 512Kb

SLIDE 24

Multipoint VPN

DMVPN

○ Cisco technology ○ Open source implementation exists: OpenNHRP ○ IPSec ○ Hub (server), Spokes (clients)

SLIDE 25

Operating System

Tails Linux

○ Open source operating system ○ Aimed at privacy and anonymity on the Internet ○ Only traffic over Tor and I2P networks can go ○ Always boots from a clean install state

SLIDE 26

SLIDE 27

How to deploy the DMVPN spoke software on Tails?

SLIDE 28

Conclusion

HRNG and a Tails DMVPN spoke integrate well

with each other

Jitter-based noise generator has very low

throughput

Dual oscillator without filtering was overall the

setting with best performance

SLIDE 29

Future Work

More experiments with the HRNG

○ Other noise sources and filtering ○ Faster microcontroller

Optimization of the configuration

Extremely Secure Communication

Daniel Romão - daniel.romao@os3.nl

What (almost) everyone knows: NSA collects traffic Confidential data can be compromised Backdoors in encryption-related software and hardware make it easier

Research Question How can an extremely secure communication

individuals around the globe?

What can we do?

1 - Avoid possible backdoors on RNGs

➢ Use a verifiable HRNG to improve the kernel entropy pool

2 - Avoid having all data going over a single link

What can we do?

1 - Avoid possible backdoors on RNGs

➢ Use a verifiable HRNG to improve the kernel entropy pool

2 - Avoid having all data going over a single link

What can we do?

1 - Avoid possible backdoors on RNGs

➢ Use a verifiable HRNG to improve the kernel entropy pool

2 - Avoid having all data going over a single link

➢ Use a multipoint VPN!

Hardware Random Number Generator

○ Big price differences

○ PN junctions, RF noise, clock drift, thermal noise...

What if we implement a HRNG that is verifiable and has multiple noise sources?

HRNG - Related Work

Arduino using a single PN junction

○ Calibration on startup ○ XOR and Von Neumann filtering ○ Serial interface for output

HRNG Implemented

○ Multiple noise sources ○ Continuous calibration ○ Second serial interface for logging ○ Raw byte output mode for rng-tools

HRNG Testing

○ Entropy, Optimum compression, Chi square, Arithmetic mean, Monte Carlo Pi, Serial correlation

○ FIPS-140-2 test ○ To test cryptographic modules for use by the United States federal government

Multipoint VPN

○ Cisco technology ○ Open source implementation exists: OpenNHRP ○ IPSec ○ Hub (server), Spokes (clients)

Operating System

○ Open source operating system ○ Aimed at privacy and anonymity on the Internet ○ Only traffic over Tor and I2P networks can go ○ Always boots from a clean install state

How to deploy the DMVPN spoke software on Tails?

Conclusion

with each other

throughput

setting with best performance

Future Work

○ Other noise sources and filtering ○ Faster microcontroller

Thank you!

Go get it: https://github.com/dromao/arduino-rng

https://github.com/dromao/dmvpn-spoke
