Exploring STAR-CCM+ Capabilities, Enhancements and Practices for Aerospace Combustion Niveditha Krishnamoorthy CD-adapco Outli line Overvie view of mode deling ing capabi bility lity Ap Applications ations, , Practice tices s and
Niveditha Krishnamoorthy CD-adapco
– Gas Turbines – Rocket Nozzles – Scramjets
– RANS, LES and DES
– Combustion – CHT – Fluid-Structure Interaction – Aeroacoustics
Combus ustion tion and nd Emissions
ing
– Models for different flame types: Premixed, non-premixed and partially premixed – Multi-component liquids, solids and gases – Homogeneous and Heterogeneous chemistry – Global, tabulated chemistry, reduced/detailed chemistry – Emission models for Soot, and Nox
– Two –equation semi-empirical model – Method of moments
– Fuel – Prompt – Thermal
Mass Fraction of CO (LES run)
Properties of the medium:
Gas Turbine Combustor Emissions Fuel Flexibility, Flame Stability Thermo-acoustic Instability Mechanical Durability Cost
System Level Combustion Chemistry Heat Transfer Fluid Dynamics Unit Level
– Droplet Evaporation
– Droplet Break-up
– Linear Instability Sheet Atomization (LISA)
– Kelvin Helmholtz-Rayleigh Taylor (KHRT) – Taylor Analogy (TAB) – Stochastic Break-up (SSD)
– Droplet Wall-impingement
– Collision Detection Model
– Two-way Coupling
– Turbulence Dispersion
Global al Chemistr try
– Global multi-step reactions can be calibrated for specific operating conditions – Calibration carried out using HEEDs and DARS-Basic [ Freely propagating Flame]
Variables we can vary
Calibration to match flame speed Blue = Literature Red = uncalibrated Green = Calibrated Purple = Hand Calibrated
– Presumed Probability Distribution Models (PPDF Flamelet)
times
– Flamelet Generated Manifold (FGM)
than the traditional progress variable model
consistent
Case 1 Case 2 Case 1 Case 2
– Conduction – Convection – Radiation
– Single or multiple injectors – Liners can have all details like dilution holes, effusion holes – All solid components can be included: splash plate, dome etc.
– Face Validity – Cell quality – Volume change statistics – Cell and boundary skewness angle
1:1 matching Conformal mesh
– Multicomponent Droplet combustion – Real Gas Equation of State – Equilibrium and finite rate chemistry models
– Coupled Solver – Equilibrium or finite rate chemistry
– Base heating – Film Cooling
– In-situ Adaptive Tabulation
simulation progresses for subsequent look-up
table is populated
– Equilibrium Time-Scale
detailed chemistry calculations
relaxes to local equilibrium composition at time-scale determined by flow and chemistry
Yi=Zinert*Yi_inert+(1-Zinert)*Yi_reaction
– Coupled, implicit formulation with AMG acceleration – TVD reconstruction
– Advanced initialization and convergence control – Real gas models
– Grid sequencing option – Fully implicit newton-type solution algorithm – Controllable number of coarse levels
– Used for high speed flows where convergence for mass flow is slow – Solves pressure correction equation using density based Riemann Flux discretization – Overall and individual cell mass imbalances are minimized at each iteration – Option available for Coupled Implicit Solver.
– Single or multi-step – Variants of eddy break-up model
– PPDF Equilibrium
– DARS-CFD stiff chemistry solver – Use Equilibrium Time-Scale approximation for initial guess – Then switch to finite rate chemistry
– Utilize extruded (directed) mesh as much as possible in long, non-complex, ductwork (isolator, combustor, etc.) – Use directional reordering of mesh in streamwise direction
– Coupled inviscid flux scheme: AUSM+ – Coupled Energy: Enable Enthalpy Formulation
– Specify fuel inlets as mass flow. Ramp flow rate over 1000 iterations – Pressure outlets can have a small area of extrusion w/ free slip wall
Coupl pled ed Imp mplici cit
– CFL = 5.0 – Ramp CFL from 0.1 over first 300 iterations
AMG G Linear near Solv lver er
– Max Cycles = 10 – V-Cycle:
Grid Sequenc uencing ng Initia tializa lization tion
– 10 Levels, 150-250 iter./level, Tolerance = 0.005, CFL = 5.0
Exper ert t Driver
– CFL Ramp:End Iteration = 250 –
–
– Target AMG Cycles = 6
Continuit tinuity y Converg ergenc ence e Ac Accel celerat erator
– URF = 0.6 (Ramp from 0.03 over first 100 iterations) – Enhanced Mass-Imbalance Calculations Enabled – AMG Solver Convergence Tolerance = 0.05, V-Cycle: 1 Pre-Sweep, 1 Post-Sweep, Max levels = 50
– Meshing – Physics set-up – Solver settings – Initial and boundary condition specifications In each area of application across industry sectors
