Explaining Machine Learning Models

Armen Donigian Director of Data Science Engineering

Roadmap

+ Definition of Interpretability + The Need for Interpretability + Role of Interpretability in Data Science Process + Relevant Application Domains + Barriers to Adoption + Conveying Interpretations + Research Directions

Working Definition of Interpretability

“The ability to explain or to present in understandable terms to a human.”

Paper titled "Towards A Rigorous Science of Interpretable Machine Learning"

The Need for Interpretability

In Supervised ML, we learn a model to accomplish a specific goal by minimizing a loss function. Purpose is to trust & understand how the model uses inputs to make predictions. Validation loss is Not Enough! Can’t encode needs below into single loss function... Bias: Non-stationarity Fairness: Overlook gender-biased word embeddings (or other protected classes)

(Refer paper titled: “Man is to Computer Programmer as Woman is to Homemaker? Debiasing Word Embeddings”)

Safety: Infeasible to test all failure scenarios Regulatory compliance: Adverse Action & Disparate Impact Mismatched Objectives

• Single-Objective: Overly associates wolves with snow
• Multi-Objective trade-off: Privacy vs Prediction Quality

Security: Is model vulnerable to an adversarial user?

• User asks for increase in credit ceiling to increase

credit score

Train Test Validation

Interpretability: The Need to Keep Up

As our methods to learn patterns from data become more complex...

Failure Modes: Adversarial examples

(more complex model can have less intuitive failure modes) GoogLeNet

Paper titled "Explaining and Harnessing Adversarial Examples"

Small carefully constructed noise

Figure 1

Role of Interpretability: Data Science Process

Reference ML Engineer Application End User Figure 1

Application Domains for Interpretability

Credit UW (Equal Credit Opportunity Act)

• Adverse Action
• Disparate Impact

Neural machine translation

• Bridge translation gap between source & target languages
• Large corpus, unwanted co-occurrences of words which bias

the model

Medical diagnoses

• Show physician regions where lesions appear in retina

Autonomous driving

• Saliency map of what model used to predict orientation & direction of steering

Scientific discoveries

• Show how molecules interact w/ enzymes, potential to learn causal relationships

Think of the cost of an incorrect prediction!

Figure 1 Figure 2 Figure 3

The Explainable Machine Learning Challenge FICO teams up with Google, UC Berkeley, Oxford, Imperial, MIT and UC Irvine to sponsor

a contest to generate new research in the area of algorithmic explainability

• Home Equity Line of Credit (HELOC) dataset
• Lines of credit $5,000 to $150,000

The black box nature of machine learning algorithms means that they are currently neither interpretable nor explainable… Without explanations, these algorithms cannot meet regulatory requirements, and thus cannot be adopted by financial institutions.

• FICO blog

Barrier to Adoption in Underwriting

Catalogue Methods by Output

Visualizations (Intuitive)

Partial Dependence Plots, Correlations, Dim Reduction, Clustering

Text

For image captioning, we can use stochastic neighborhood embedding using n-dims to find relative neighborhoods

Examples

Find most influential training samples by unweighing different samples &

• bserve sensitivity

t-SNE Influence Functions DeepDream

Asked to find bananas, DeepDream finds bananas in noise Figure 1 Figure 2 Figure 3

Ways to Convey Interpretability (Feat Level)

Naturally Interpretable Models Sensitivity Analysis: “What makes the shark less/more a shark?”

• Measure sensitivity of output to changes made in the input features
• Randomly shuffle feature values one column at a time and measure change on

performance

• Saliency map of what model was looking for when it made decision

○ Which pixels lead to increase/decrease of prediction score when changed? Approach: Permutation Impact

Decomposition: “What makes the shark a shark?”

• Breaks down relevance of each feature to the prediction as a whole
• Done with respect to some reference (select bottom tier of good loans)
• Feature attributions must add up to the whole prediction (normalizing factor)

Approach: Backprop Figure 1 Figure 2

Naturally Interpretable Models

Linear Models f(x) = a1x1 + a2x2 + b contrib(xi) = aixi f(x) - f(x0) = icontrib(xi)

Decomposition: assigns blame to causes (some reference cause) Sensitivity: Take gradient of this model w/ respect to input, coefficients remain.

Decision Trees

Trace path of each decision & observe how it changes the regression value.

• Feature importances. How often a feature is used to make a decision?

Check out SHapley Additive exPlanations, treeinterpreter

Boston housing prices dataset

baseline: x0 = (0,0)

Figure 1

Permutation feature importance

Randomly shuffle feature values one column at a time and measure change

• n performance

Pros

Simple implementation Model agnostic

Cons

No variable interaction Computationally expensive

Permutation Feature Importance

Single pixel perturbation does not change prediction Works when few features are important &

• perate independently

Surrogate Models (LIME)

Local Interpretable Model-Agnostic Explanations Learn a simple interpretable model about the test point using proximity weighted samples Pros

Model-agnostic

Cons

Computationally Expensive

Figure 2 Figure 1 Top 3 predicted classes Figure 3

Backpropagation Based Approaches

Gradients (saliency map)

• Start w/ particular output
• Assign importance scores to neurons in layer below

depending on function connecting those 2 layers

• Repeat process until you reach input
• With a single backward prop, you get importance scores for all

features in the input Gradient w/ respect to inputs gives us feature attributions

Pros

Simple and efficient GPU-optimized implementation

Cons

Fails in flat regions (e.g. ReLU)...gives 0 when contribution isn’t zero

Backprop Approaches

Improving gradients

Dealing with absence of signal Towards decomposition Define a set of axioms:

Sensitivity Implementation invariance Completeness/additivity Linearity x x0

if f(x) ≠ f(x0) attribution(x2) > 0 f(x) - f(x0) = iattr(xi) If 2 feature vectors differ only on a single feature but have different predictions then the differing feature attributions should be non-zero attribution.

Backprop Approaches

Better way to backprop thru RELUs

• DeconvNet

Equivalent to gradients, but ReLU in backwards direction

• Guided Backprop

Gradients, but ReLU in both directions

• PatternNet/Attribution

Correct gradient for correlated distracting noise

• Layerwise Relevance Propagation

Equivalent to input-scaled gradients

Some other interesting approaches...

• Integrated Gradients

Path integral of gradients from baseline

• DeepLIFT

True decomposition relative to baseline with discrete jump

• Deep Taylor Decomposition

Taylor approximation about a baseline for each neuron Integrated Gradients

• Pick starting value, scale up linearly from reference to

actual value, compute gradients along the way

• Positive & negative contribution scores

DeepLift

• Compare activation of each neuron to its reference

activation

• Assign contribution scores based on difference
• Positive & negative contribution scores
• Generalizes to all activations
• Importance is propagated even when gradient is 0

Evaluating Interpretability Methods

If we have a set of feature contributions...

Spearman’s Rank-Order Correlation What % of Top-K intersect

Experimental Evaluation Approaches

Assign a user (domain expert) tasks based on the produced feature attributions

• Show saliency maps, ask user to choose which classifier generalizes better
• Show attributions & ask user to perform feature selection to improve the model
• Ask user to identify classifier failure modes

Interpretability can suffer from adversarial attacks independently of prediction Attack types Top-k attack Take top 5 features, create distortion which drops their rank

Center attack

Take center of mass, try to move it as far as it can with some constrained distortion, goal to move the

center of mass of the saliency map

Adversarial Examples

Paper titled "Interpretation of Neural Networks is Fragile" Figure 1 Figure 2

Research Directions

Better loss functions for interpretability Understand what makes certain models more interpretable and how interpretability fails Explain models in unsupervised learning, sequence learning (RNNs), and reinforcement learning

E.g. generating text explanations of the actions of a reinforcement learning agent

Develop interpretability techniques into tools for model diagnostics, security, and compliance

Founded in 2009 by Douglas Merrill, former CIO and VP, Engineering, Google Located in Los Angeles, CA 100+ Employees primarily comprised

• f Data Scientists, Engineering and

Business Analysts from top US institutions

Meet ZestFinance

1

Investors What others are saying

Mission: Make fair and transparent credit available to everyone

ZestFinance is one of the five most promising financial artificial intelligence companies in the world. “we worked with ZestFinance to harness the capability of machine learning to analyze more data and to analyze our data differently”- Ford Credit CRO, Joy Falotico “Synchrony is looking at making adjustments to its underwriting approaches... It is testing technology from vendors including ZestFinance”, Machine-learning is also good at automating financial decisions,…Zest Finance has been in the business of automated credit-scoring since its founding in 2009.”

Backup Slides

Two Related Concepts

Transparency - understand the inner workings of a model Attention - model learns regions of input to focus on
