Etteplan Procket Rapid

October 2017 Tero Leppänen Vesa Koski Esa Kivioja

Procket Variants

Procket Rapid Procket Desktop Procket Compact Procket Flex

Procket Fixture Solutions

Adjustable Fixed Cassette Adapter

Procket Rapid Procket Desktop Procket Compact Procket Flex Adjustable O O O Fixed O O O Cassette O O O Adapter O O

Procket Rapid - Adjustable Test Fixture

Test Fixture

• Spring loaded probe contacts to DUT
• Manually adjustable jibs for test probes
• Max DUT board size: 270 x 120mm

Espotel’s genreal purpose IF board

• Isolation relays for ISP programmer
• Connectors for programmer, DAQ,

PSU, …

• SW compatible with other Procket

fixtures Suitable for

• R&D testing
• Programming
• Small volume production

Procket Rapid – Benefits

• No need for mechanics design
• No need for machinery of custom parts
• General purpose IF board provides

support for most common testing tasks  No need for custom hardware design

• Simple documentation
• Reusable fixture
• Tester SW development can be started

immediately

• Enables ultra fast tester development

Procket Rapid – Typical Instrumentation

IF Board

ISP Programmer USB DAQ DC Power Supply

Procket Rapid – Minimum Viable Tester

Procket Rapid – IF Board

• IF board provides signal conditioning electronics for test applications and

interfaces for external instrumentation

• IF board utilizes NI USB-6003 for control and measurements

Procket Rapid Python SW library

• Procket Rapid Python SW library is an easy to use tool to operate NI

USB-6003 DAQ card and accompanied Procket Rapid interface board.

• With the library, one can create automated test sequences that also

generates test reports.

• Full rights for customer to use, modify and make copies of the SW.
• Works in both Windows and Linux environments.
• Support for Python v2.7.x and v3.6.x
• Example code and user guide included to demonstrate the usage with

Robot Framework.

• Enhance and automate your SW testing with hardware-in-the-loop

(HIL) method using Procket Rapid Python SW library and Procket Rapid HW.

Procket Rapid Python SW library examples

Example test result log when run with Robot Framework Example test execution in high level in command line

Procket Rapid - Limitations

Procket Rapid

Procket Rapid is NOT suitable for

• Volume production
• High voltage (>60Vdc) testing without

additional cover and safety consideration

• Complex test applications (>30 test

probes) If customization is required, consider

• ther fixture platforms (ATX, Ingun, GPS,

etc.) as basis.

Sales prices

IF Board

Pricelist

• Fixture only (incl. 20 jibs*):

1 390 €

• Fixture + IF board + NI USB-6003 OEM DAQ

3 850 €

• Additional Jibs, 10pcs set

400 €

• Procket Rapid Python SW library

2 500 €

• Custom-made, 3D printed probe bed (typical costs, ask a quote)
• Design work

~500…1500 €

• Materials and manufacturing

~200…500 €

Fixture – What is included?

IF Board

• 1 x Procket Rapid Fixture frame
• 5 x Contacting jibs 85 mm with spring contact pin 100 mil
• 5 x Contacting jibs 120 mm with spring contact pin 100 mil
• 1 x Fixed guiding edge
• 1 x Contacting jib 85 mm with guiding edge
• 2 x Contacting jibs 120 mm with guiding edge
• 1 x Contacting jib 85 mm with guiding brink
• 1 x Contacting jib 120 mm with guiding brink
• 2 x Contacting jibs 85 mm with guiding pin
• 2 x Contacting jibs 120 mm with guiding pin

Procket Rapid in use

IF Board

Contact Info

IF Board

Teppo Välisaari teppo.valisaari@etteplan.com Vesa Koski vesa.koski@etteplan.com Esa Kivioja esa.kivioja@etteplan.com
