Errant GTIDs breaking replication

Dieter Adriaenssens Ghent University

2

Who am I?

Dieter Adriaenssens

• Linux System Administrator
• MySQL DBA
• Works at Ghent University
• Open Source : former phpMyAdmin team member
• Lives in Ghent, Belgium
• Climber
• E-mail : dieter.adriaenssens@ugent.be
• Twitter : @dcadriaenssens
• Pictures :

−

(c) Thomas Kindermans https://en.wikipedia.org/wiki/File:Gent_Graslei_zonsondergang.JPG

−

(c) Rouslan Placella

Errant GTIDs breaking replication

How to detect and avoid them

4

Context

Replicating MySQL cluster

• Primary with some replicas
• Master failover
• Replication breaks from new primary

(previous replica) to remaining replicas

• Where did those transactions on the new

primary come from?

‘[..] the master has purged binary logs containing GTIDs that the slave requires.’

5

Overview

• Replication and GTID
• Errant GTIDs on a replica
• Detection
• Where do they come from?
• How to avoid them
• How to fix them
• Demo

Introduction

Replication, GTID, data consistency

7

Replication

MySQL server replication :

• Primary (master)
• Several replicas (slaves)
• Identical state across several servers

Primar y Replic a Replic a

8

Replication : Why

• High availability
• Master failover
• Disaster recovery
• Scaling load
• Regional distribution
• ...

9

Replication : How

MySQL master-slave replication :

• All nodes start from an identical state
• Replicas apply transactions from the

primary node’s binary logs

• Transaction in correct order
• Asynchronous : replica initiates
• Maintain identical state
• Read/write on primary
• Replicas should be readonly

10

Replication : How

Keeping track of binlog position :

• Several binlogfiles : mysql_bin.xxxxxx
• Rotation (size based, restart server)
• Every transaction has a unique

(incremental) position

• Replication start :
• Binary log file name
• position in the binlog
• Problematic
• multiple primaries
• Master failover
• Restore from backup

11

GTID

Global Transaction identifier

• Unique identifier of a transaction
• GTID = Origin ID + transaction ID
• Origin ID : server UUID
• Transaction ID : incremental number

Server_uuid:transaction_id 3E11FA47-71CA-11E1-9E33-C80AA9429562:23

SELECT @@GLOBAL.server_uuid; 3E11FA47-71CA-11E1-9E33-C80AA9429562

12

GTID set

Executed GTID set

• Set of applied GTIDs on a server
• Defines a state of data consistency
• Easy to compare between nodes
• Replica applies GTIDs of a primary
• Simplifies failovers (no need to

remember binlog position)

SHOW SLAVE STATUS; SHOW MASTER STATUS; SELECT @@GLOBAL.gtid_executed; Executed_Gtid_Set:

27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552113, 50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1-80192973, c004c0eb-c84e-11e6-8efc-aa00009002fd: 1-6084195:6140951-6141015

13

ROW based replication

• Changes in rows are replicated
• <-> transaction-based : actual queries
• In combination with GTID => data

consistency across the cluster nodes

14

Replicating cluster with GTID

MySQL Server cluster

• Primary (R/W)
• Replicas (R/O)
• GTID enabled
• Row based replication
• ProxySQL to redirect traffic to correct

cluster node

• Orchestrator managing the cluster nodes

(automatic master failover)

• rchestrator -c topology –alias=demo

node1:3306 [0s,ok,5.7.25,rw,ROW,>>,GTID] + node2:3306 [0s,ok,5.7.25,ro,ROW,>>,GTID] + node3:3306 [0s,ok,5.7.25,ro,ROW,>>,GTID]

Nod e1 Node 2 Node 3 Prox y SQL

Orchestrator

Errant GTID

Definition, consequences, detection, examples, how to avoid, fixes

16

Errant GTID

• Unreplicated transaction existing only on

a replica

• Data is not the same on all nodes
• Cluster is no longer in a consistent state

17

Errant GTID : consequences

• Everything is fine?
• Inconsistent state between nodes
• Split brain
• Different data when reading from

that replica

• Unexpected behaviour when a replica is

promoted to master

• Replication might fail
• If GTID is purged from binlog, on

master failover → replication stops

‘[..] the master has purged binary logs containing GTIDs that the slave requires.’

Errant GTID detection

19

Errant GTID detection

• Compare executed GTID sets between

primary node and replica nodes

• Replica has more GTIDs than primary =>

errant GTID

20

GTID executed set

# primary SELECT @@GLOBAL.gtid_executed; 27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552120 # replica SELECT @@GLOBAL.gtid_executed; 27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552113, 50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1-4

21

GTID subset

SELECT GTID_SUBSET( '27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552113', '27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552120') AS is_subset; +-----------+ | is_subset | +-----------+ | 1 | +-----------+ 1 row in set (0.00 sec)

Replica GTID set is a subset of primary GTID set : OK SELECT GTID_SUBSET('<gtid_executed_replica>', '<gtid_executed_primary>');

22

GTID subset

SELECT GTID_SUBSET( '27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552113, 50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1-4', '27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552120') AS is_subset; +-----------+ | is_subset | +-----------+ | 0 | +-----------+ 1 row in set (0.00 sec)

Replica GTID set is NOT a subset of primary GTID set => Errant GTID on replica SELECT GTID_SUBSET('<gtid_executed_replica>', '<gtid_executed_primary>');

23

Find errant GTIDs

SELECT GTID_SUBTRACT( '27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552113, 50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1-4', '27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552120') AS errant_gtid; +------------------------------------------+ | errant_gtid | +------------------------------------------+ | 50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1-4 | +------------------------------------------+ 1 row in set (0.00 sec)

Result is subset of errant GTIDs SELECT GTID_SUBTRACT('<gtid_executed_replica>', '<gtid_executed_primary>');

24

Errant GTID : automatic detection

• Icinga monitoring check
• Orchestrator
• Other tools :
• Mysqlfailover
• Mysqlrpladmin

25

Errant GTID : detection

Monitoring check

• Automate checking for errant GTID
• Icinga compatible output format
• Uses orchestrator for cluster info
• https://github.com/UGent-DICT/check_mysql_gtid

26

Errant GTID : monitoring check

./check_mysql_gtid demo MYSQL_CLUSTER_GTID OK - GTIDs on all nodes are replicated in the cluster! Cluster demo (primary : node1) :

• node2 : OK
• node3 : OK

./check_mysql_gtid <clustername> Everything is fine!

27

Errant GTID : monitoring check

./check_mysql_gtid demo MYSQL_CLUSTER_GTID WARNING : replicas containing unreplicated GTIDs : node2 Cluster demo (primary : node1) :

• node2 : GTIDs only exist on the replica :

50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1-4

• node3 : OK

./check_mysql_gtid <clustername> Check reports unreplicated (errant) GTIDs on one of the nodes

28

Errant GTID : detection

Orchestrator

• Reports errant GTIDs (>= v3.0.13)
• Provides ways to fix them (>= v3.0.14)

29

Errant GTID

Find transaction

• Look for GTID in binary logs
• Each binlog mentions the executed GTID

set (initial state)

• Select relevant binlog
• Find transaction in that binlog

30

Errant GTID : find transaction

mysqlbinlog --base64-output=DECODE-ROWS --verbose node2-bin.00* | grep 50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1 -A6 SET @@SESSION.GTID_NEXT= '50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1'/*!*/; # at 23890384 #180305 6:25:02 server id 590100 end_log_pos 23890464 CRC32 0x2fe8266b Query thread_id=3848059 exec_time=0 error_code=0 SET TIMESTAMP=1520227502/*!*/; SET @@session.sql_mode=1073741824/*!*/; FLUSH ERROR LOGS /*!*/;

31

Errant GTID : Examples

Transactions on a replica

• Manual transactions (by accident on a replica)
• Scripted maintenance tasks (eg. config management)
• User creation
• Database creation
• Master failover gone bad :
• Split brain
• Writes redirected to a replica (eg. host is r/w by

accident, or after a restart)

• Log flushes

32

Intermezzo : flush-logs

• FLUSH LOGS; → not added to binlog (1)
• FLUSH ERROR LOGS; → added to binlog (2)
• FLUSH [LOCAL | NO_WRITE_TO_BINLOG] ERROR LOGS; → not added to binlog
• mysqladmin flush-logs executes FLUSH LOGS;
• mysqladmin flush-logs error (3) executes FLUSH ERROR LOGS;
• (1) expected behaviour, according to documentation : “FLUSH LOGS, FLUSH BINARY LOGS, FLUSH

TABLES WITH READ LOCK (with or without a table list), and FLUSH TABLES tbl_name ... FOR EXPORT are not written to the binary log in any case because they would cause problems if replicated to a slave.“ https://dev.mysql.com/doc/refman/8.0/en/flush.html

• (2) Related bug report : https://bugs.mysql.com/bug.php?id=88720
• (3) introduced in MySQL 5.7.4

Avoid errant GTIDs

34

Avoid errant GTIDs

Avoid transactions on replica nodes:

• Don’t execute (write) statements on a replica

35

Avoid errant GTIDs

Use read_only:

• Set read_only on all replicas
• Preferably in the config file, to avoid a writable node after

restart

• Orchestrator can set a previous master to read_only on a

failover : ApplyMySQLPromotionAfterMasterFailover = true

36

Avoid errant GTIDs

Use super_read_only:

• Users with SUPER privileges can still write when read_only is set
• Limit SUPER privileges/users
• Set super_read_only on all replicas
• Orchestrator can set a previous master to super_read_only on a failover :

UseSuperReadOnly = true (>= v3.0.7)

37

Avoid errant GTIDs

Disable binlog for some transactions:

• Some statements don’t have to be replicated
• Examples:
• log flushes
• Fixing an inconsistent state on a replica (eg. errant

GTID)

• Use @@SESSION variable!

SET @@SESSION.SQL_LOG_BIN=0; <statement>; SET @@SESSION.SQL_LOG_BIN=1;

Fix errant GTIDs

39

Fix errant GTIDs

Examine situation :

• Examine transaction (binlog)
• Does it change data?
• Can’t find transaction?
• Check consistency with pt-table-checksum and pt-table-sync
• Is data consistent?

40

Fix errant GTIDs

Possible fixes:

• Insert empty transactions on other nodes (including primary)
• ‘Remove’ GTIDs from replica binlog
• Rollback transactions : Unsplit brain
• Talk Shlomi Noach @ FOSDEM 2019

https://fosdem.org/2019/schedule/event/unplitmysql/

• Restore data from primary/backup

41

Errant GTID : Insert empty transactions

SET gtid_next='50d5e9eb-c5d3-11e6-b86b-aa00009002f7:1'; BEGIN; COMMIT; SET gtid_next='50d5e9eb-c5d3-11e6-b86b-aa00009002f7:2'; BEGIN; COMMIT; SET gtid_next=automatic;

On all nodes (or only on the primary of replication still works):

• Repeat for each errant GTID

42

Errant GTID : Remove from binlog

STOP SLAVE; RESET MASTER; SET GLOBAL GTID_PURGED="27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552120"; START SLAVE;

On the replica

SELECT @@GLOBAL.gtid_executed; 27ab32d2-7f36-11e7-8bd7-aa00009002fd:1-7552120

On the primary RESET MASTER : Binlogs are purged on the replica!

43

Errant GTID : Fix them

Orchestrator (>= v3.0.14)

• Inject empty transactions
• Reset master (remove GTIDs)

Demo

Click to add text

45

Conclusion

Avoid errant GTIDs

• It can break replication
• Data consistency across the cluster is lost
• Avoid manual transactions on replicas
• Set read_only
• Set super_read_only
• Temporarily Disable binlog if you have to do

something on a replica

• Monitor for errant GTIDs

46

Acknowledgements

Thanks to:

• Colleagues at Ghent University
• Tibor Korocz from Percona
• Blogposts :
• https://www.percona.com/blog/2014/05/19/errant-transactions-major-hurdle-for-gtid-based-failover-in-mysql-5-6/
• https://dzone.com/articles/how-createrestore-slave-using
• https://dzone.com/articles/mysql-replication-errant-transactions-in-gtid-base
• https://severalnines.com/blog/mysql-replication-and-gtid-based-failover-deep-dive-errant-transactions
• https://www.percona.com/blog/2013/03/26/repair-mysql-5-6-gtid-replication-by-injecting-empty-transactions/

47

Questions?

• Contact : @dcadriaenssens
• Monitoring check: https://github.com/UGent-DICT/check_mysql_gtid
